Behringer Europower EPX4000 User manual

EUROPOWER EPX4000: Professional
4,000-Watt Lightweight Stereo Power
Amplier with ATR (Accelerated
Transient Response) Technology
2 x 2000 Watts into 2 Ohms;
2 x 1200 Watts into 4 Ohms;
4000 Watts into 4 Ohms
(bridge mode)
EUROPOWER EPX2800: Professional
2,800-Watt Lightweight Stereo Power
Amplier with ATR (Accelerated
Transient Response) Technology
2 x 1400 Watts into 2 Ohms;
2 x 800 Watts into 4 Ohms;
2800 Watts into 4 Ohms
(bridge mode)
Common Features
ATR (Accelerated Transient Response)
technology for ultimate punch
and clarity
Ultra-light, ultra-low noise and
ultra-ecient switch-mode power
supply for noise-free audio, superior
transient response and
low power consumption
Switchable limiters oer maximum
output level with reliable
overload protection
Detented gain controls for precise
setting and matching of sensitivity
Precise Power, Signal and Limit LEDs
to monitor performance
XLR, ¼'' TRS and RCA input
connectors for compatibility
with any source
Professional speaker connectors and
“touch-proof” binding posts support
most speaker wiring systems
Ultra-light, Built on a Legacy
Power amps have always been
heavy, mainly because of their massive
transformers and heat sinks. Our
new EPX Series amps are based on
groundbreaking switch-mode power
supply technology, which eliminates
the heavy transformer. As a result,
these amps weigh about 40% less than
their conventional counterparts. In fact,
the EPX2800 and EPX4000 are just 22.3 lbs
(10.1 kg) each, so you can practically
lift them with just one nger. Best of
all, EPX Series amps are super-reliable
and provide even tighter bass
performance than their predecessors,
since they can deliver ultra-high peak
currents on demand.
In a Class of Their Own
The secret to the EPX Series’ incredible
power-to-weight ratio is the use of a
switch-mode power supply combined
with Class-H topology. Because they
work on demand, instead of operating
continuously at full power, switch-mode
power supplies are much more ecient
than traditional power supplies.
And since they don’t require the massive
transformers and heat sinks typically
found in conventional power amps,
they are signicantly smaller and lighter,
yet still deliver ample power.
Think of a Class-H amp as being similar
to a car with two engines (in amps, we call
them “rails”). One engine runs all the time.
The other runs only when musical peaks
demand the extra power output. An EPX
Class-H amp only generates a fraction
more power than is immediately needed,
while the output stage operates at its
maximum eciency all the time. And just
like in today’s hybrid cars, the eciency
of this dual system is far greater than
having just one engine or rail that has
to operate continuously.
Continued on next page
EUROPOWER
EPX4000/EPX2800
PA Ampliers

Page 2 of 5
Built-in Subwoofer/Satellite
crossover for more exibility
Independent DC and thermal
overload protection on each channel
automatically protects amplier
and speakers without shutting
down the show
“Back-to-front” ventilation
system including air lter for
reliable operation
“Built-like-a-tank“, impact-resistant,
all-steel 2U rackmount chassis
High-quality components and
exceptionally rugged construction
ensure long life
Conceived and designed by
BEHRINGER Germany
Accelerated Transient Response
Delivers the Knockout Punch
It takes huge pulses of energy
(current and voltage) to propel a woofer
cone out fast enough to match a bass
beat. That’s called Transient Response
and it’s the holy grail of amp designers.
By carefully selecting transistors with
extremely high slew rates and optimizing
other proprietary parts of our circuitry,
EPX amps can react instantly to even
the most demanding electronic bass
impulses. If the woofers in your PA system
can keep up, your audience will hear a
tighter, crisper, more natural sound.
BEHRINGER didn’t invent Class-H
technology, but our R&D Department
has been working for years to perfect our
own version, creating lightweight amps
that run cool and achieve our goal of
Accelerated Transient Response.
Everything You Need
The simple front panel controls of
these amps give you all of your sound’s
vital signs at a glance. After pressing
the Power Button, the POWER LED will
light when the amp is ready for action.
Both channels have independent gain
dials, as well as CLIP LEDs that notify you
when the signal is distorted and you
need to reduce the gain. There are also
SIGNAL LEDs that light up when a signal
is present at the input.
Panel Discussion
The EPX Series’INPUTs accept
balanced XLR, ¼" TRS, and unbalanced
¼" TS and RCA connections. Take your
pick of professional locking speaker
outputs or touch-proof binding posts to
securely connect speakers.
0
-10
-20
Signal level LED meter
with clipping LED
Ventilation
openings
Detented channel
GAIN controls
Power
Switch
IEC power
socket
Cooling fans
Professional locking
speaker connections
“Touch-proof”
binding posts
speaker outputs
Built-in CROSSOVER
switch — dedicated
100 Hz CH1/CH2 or
FULLRANGE
MODE switch—
mono/stereo/bridge
LIMITER
on/o switch
INPUT accepts
balanced XLR,
¼" TRS, and
unbalanced
¼" TS and RCA
connections
Front Panel
Rear Panel
Continued on next page
EUROPOWER
EPX4000/EPX2800

Page 3 of 5
A panel of switches located on the back
oers an array of cool options applicable to
both channels. The switchable Clip Limiter
lets you get even more out of the amplier
without overdriving either it or your speaker
system. Built-in circuitry automatically
senses when the amp is being overdriven
into “clipping” and instantaneously reduces
the input level just enough to avoid
clipping distortion.
Built-In Crossover
The rear panel also contains a switch
that allows you to put these amps to work
in mono, stereo (two-channel mode)
or bridge mode, which is always mono.
A built-in CROSSOVER switch lets you put
the amp into biamp mode, which sends
low-frequency content (<100 Hz) to the
CH2 Output and the high-frequency
component to CH1 automatically,
no external hardware required.
Value
BEHRINGER’s EPX Series amps
are built for the working musician.
They are much lighter than conventional
power amps, pack massive power,
feature built-in crossover and limiter
circuits, and can withstand the rigors of
the road. Plus their light price tag will
leave money in your pocket to buy more
stu to amplify! Check out the EPX2800
and EPX4000 today to nd out why
BEHRINGER power amps are among the
most popular on Earth.
Stereo Mode
SX2442FX
Stereo Out
R
L
Input Channel 1
Input Channel 2
EUROPOWER EPX2800 (Stereo Mode)
EUROLIVE B1520 PRO
Mono Mode
0
-10
-20
SX2442FX
Mono Out
Input Channel 1
EUROPOWER EPX2800 (Mono Mode)
EUROLIVE B1520 PRO
EUROPOWER
EPX4000/EPX2800

Page 4 of 5
Stereo Out
RL
SX2442FX
EUROPOWER EPX4000 (Stereo Mode)EUROPOWER EPX4000 (Stereo Mode)
EUROLIVE B1800X-PRO
EUROLIVE B1520 PRO EUROLIVE B1800X-PROEUROLIVE B1520 PRO
Biamp Mode
EUROPOWER
EPX4000/EPX2800

Page 5 of 5
For service, support or more information contact the BEHRINGER location nearest you:
Technical specifications and appearances are subject to change without notice and accuracy is not guaranteed. BEHRINGER is part of the MUSIC Group (music-group.com). All trademarks are the property of their respective owners. MUSIC Group accepts no liability for any loss
which may be suffered by any person who relies either wholly or in part upon any description, photograph or statement contained herein. Colors and specifications may vary from actual product. MUSIC Group products are sold through authorized fullfillers and resellers only.
Fullfillers and resellers are not agents of MUSIC Group and have absolutely no authority to bind MUSIC Group by any express or implied undertaking or representation.This manual is copyrighted. No part of this manual may be reproduced or transmitted in any form or by any
means, electronic or mechanical, including photocopying and recording of any kind, for any purpose, without the express written permission of MUSIC Group IP Ltd. ALL RIGHTS RESERVED. © 2012 MUSIC Group IP Ltd.Trident Chambers,Wickhams Cay, P.O. Box 146, RoadTown,
Tortola, British Virgin Islands. 985-10000-00472
Europe
MUSIC Group Services UK
Tel: [phone]
Email: [email protected]om
USA/Canada
MUSIC Group Services NV Inc.
Tel: [phone]
Email: [email protected]om
Japan
MUSIC Group Services JP K.K.
Tel.: [phone]
Email: [email protected]om
Specications
Output Power
RMS Power
Stereo Mode (both channels driven)
EPX4000
8 Ω per channel, stereo 530 W
4 Ω per channel, stereo 870 W
2 Ω per channel, stereo 1440 W
EPX2800
8 Ω per channel, stereo 350 W
4 Ω per channel, stereo 600 W
2 Ω per channel, stereo 990 W
EPX4000
Bridged Mono
8 Ω / 1 kHz @ 0.1% THD 1800 W
4 Ω / 1 kHz @ 1% THD 3000 W
EPX2800
Bridged Mono
8 Ω / 1 kHz @ 0.1% THD 1220 W
4 Ω / 1 kHz @ 1% THD 2000 W
EPX4000
Peak Power
Stereo Mode (both channels driven)
8 Ω per channel, stereo 670 W
4 Ω per channel, stereo 1220 W
2 Ω per channel, stereo 2080 W
EPX2800
Peak Power
Stereo Mode (both channels driven)
8 Ω per channel, stereo 440 W
4 Ω per channel, stereo 800 W
2 Ω per channel, stereo 1400 W
EPX4000
Bridged Mono
8 Ω bridge mode 2450 W
4 Ω bridge mode 4000 W
EPX2800
Bridged Mono
8 Ω bridge mode 1620 W
4 Ω bridge mode 2800 W
EPX4000/EPX2800
Input Sensitivity 1 V
Distortion <0.01%
Frequency Response 20 Hz - 20 kHz, +0/-1 dB
Voltage Gain 35 dB
Damping Factor > 300 @ 8 Ω
Input impedance 10 kΩ unbalanced, 20 kΩ balanced
Signal-to-Noise > 100 dBA
Controls
Front POWER switch GAIN control
(channel 1 and 2)
Rear MODE switch X-over Switch,
BRIDGE MODE switch
EPX4000/EPX2800
Indicators
POWER Blue LEDs
CLIP (per channel) Blue LEDs
PROT (per channel) Blue LEDs
SIGNAL (per channel) White LEDs
-20dB~-10dB
SIGNAL (per channel) White LEDs
-10dB~ 0dB
Connectors
Inputs Balanced XLR, ¼" TRS , RCA
Outputs Speakon and “touch-proof’’
binding posts
EPX4000/EPX2800
Circuit protection
Cooling Continuously variable speed fan,
back to front air ow
Amplier protection Full short circuit, open circuit, thermal,
ultrasonic, RF protection. Stable into
reactive or mismatched loads
Output circuit type Class H
EPX4000
Power supply / Voltage (Fuses)
USA / Canada 120 V~, 60 Hz (T 30 A H 250 V)
UK / Australia 240 V~, 50 Hz (T 15A H 250 V)
Europe 230 V~, 50 Hz (T 15 A H 250 V)
Japan 100 V~, 50-60 Hz (T30 A H 250 V)
Power consumption 4500 W
Mains connector Standard IEC receptacle
EPX2800
Power supply / Voltage (Fuses)
USA / Canada 120 V~, 60 Hz (T 20 A H 250 V)
UK / Australia 240 V~, 50 Hz (T 10A H 250 V)
Europe 230 V~, 50 Hz (T 10 A H 250 V)
Japan 100 V~, 50-60 Hz (T 20 A H 250 V)
Power consumption 3000 W
Mains connector Standard IEC receptacle
EPX4000/EPX2800
Dimensions/weight
Dimensions (H x W x D) 3.46 x 19.01 x 14.68"
88 x 483 x 373 mm
Weight 22.26 lbs / 10.10 kg
