Behringer Europower PMH2000 User manual

Version 1.6 April 2007
Technical Specifications
EUROPOWER
PMH2000
ENGLISH

2
EUROPOWER PMH2000
PMH2000PMH2000
PMH2000PMH2000
PMH2000
EUROPOWER
2 x 250-Watt 10-Channel Power Mixer with 24-Bit Digital Effects Processor
V2 x 250-Watt (500 Watts bridge mode) power amp with full protection
VUltra-lownoiseULNdesign,highheadroom,ultra-transparentaudio
V10-channelmixer section features 6mono and 3 stereochannels plus separate tapereturns
V6state-of-the-art,studio-gradeIMP“Invisible”MicPreamps
VSwitchable+48Vphantompower for condenser microphones
V12balancedhigh-headroomlineinputs
VEffective, extremely musical 3-band EQ, switchable Pad and Peak LEDs on all mono channels
V9-bandstereo graphic EQ allowsprecisefrequency correction of monitorand main mixes
VMainleveland Monitor level controls withprecise,5-segmentLED level meter
VIntegrated24-bit digital stereo FXprocessor with 99 outstandingVIRTUALIZERpresets including reverb,
delay,chorus, flanger, vocaldistortion, vinylizer and moreplus 1 kHz test tone generator
VOptionalstereo(mainL/R) or double mono (main/monitor) operation possible
VMulti-functionalstereoPreamp outputs and stereopoweramp inputs for addedflexibility
VHigh-qualitycomponentsand exceptionally rugged construction ensurelonglife
VConceivedanddesignedbyBEHRINGERGermany
NEUTRIK®and SPEAKON®are registered trademarks of their respective owners and are not affiliated with
BEHRINGER®.

3
EUROPOWER PMH2000
BLOCK DIAGRAM

4
EUROPOWER PMH2000
SPECIFICATIONS
Mono inputs
Microphone inputs
Type XLR, electronically balanced,
discrete input circuit
Mic E.I.N. (20 Hz - 20 kHz)
@ 0 Ωsource resistance -122 dB / 125 dB A-weighted
@ 50 Ωsource resistance -122 dB / 125 dB A-weighted
@ 150 Ωsource resistance -121 dB / 124 dB A-weighted
Frequency response <10 Hz - 100 kHz (-1 dB),
<10 Hz - >200 kHz (-3 dB)
Gain +33 dB, +8 dB with pad
Max. input level +12 dBu @ +8 dB gain
Impedance approx. 2.2 kΩbalanced /
1.1 kΩ unbalanced
Signal-to-noise ratio 110 dB / 114 dB A-weighted
(-11 dBu In @ +33 dB gain)
Distortion (THD+N) 0.001% / 0.0008% A-weighted
Mono line inputs
Type 1/4" TRS connector, balanced
Impedance approx. 80 kΩbalanced,
40 kΩunbalanced
Max. input level 30 dBu
Stereo line inputs
Type 1/4" TRS connector, unbalanced
Impedance approx. 40 kΩunbalanced
Max. input level +28 dBu
EQ
Low 60 Hz / ±15 dB
Mid 700 Hz / ±15 dB
High 6 kHz / ±15 dB
Preamp outputs left/mono & right
Type 1/4" TRS connector, unbalanced
Impedance approx. 1.5 kΩ
Max. output level +21 dBu
Power amp inputs
Type 1/4" TRS connector, unbalanced
Impedance approx. 47 kΩ
Max. input level +21 dBu
Monitor output
Type 1/4" TRS connector, unbalanced
Impedance 1.5 kΩ
Max. output level +21 dBu
DSP 24-bit Texas InstrumentsTM
Converter 24-bitSigma-Delta,
64/128-times oversampling
Samplingrate 46.875 kHz
Main mix system data1
Noise
Main mix @ -oo,
Channel fader -oo -76 dB / -80 dB A-weighted
Main mix @ 0 dB,
Channel fader -oo -72 dB / -76 dB A-weighted
Main Mix @ 0 dB,
Channel fader @ 0 dB -71 dB / -75 dB A-weighted
Power amp specifications
Power amp output (Sine @ 1 % THD)
Stereo mode 250 Watts into 4 Ω
180 Watts into 8 Ω
Bridge mode 500 Watts into 8 Ω
Loudspeaker connections
Loudspeaker connector Professional speaker
connectors (compatible to
NEUTRIK®SPEAKON®)
Load impedance
Left/monitor 4/8/16 Ω
Right/monomain 4/8/16 Ω
Bridge 8/16 Ω
Power supply
Voltage USA/Canada
120 V~, 60 Hz
Europe/U.K./Australia
230 V~, 50 Hz
Japan
100 V~, 50 - 60 Hz
General export model
120/230 V~, 50 - 60 Hz
Power consumption max. 1 kW
Fuse 100 - 120 V~: T 12 A H 250 V
200 - 240 V~: T 5 A H 250 V
Mains connection Standard IEC receptacle
Physical/weight
Dimensions (H x W x D) approx. 11" (280 mm) x 18 1/8"
(460 mm) x 10 5/8" (270 mm)
Weight (net) approx. 30.9 lbs (14 kg)
Measuringconditions:
1: 20Hz - 20kHz; measured atpreampoutput.
Allchannels:level controls in center position; EQ flat.
Reference=0dBu.
BEHRINGERisconstantly striving to manintain the highest professional standards. Asa
resultoftheseefforts,modificationsmaybe madefromtimetotimetoexistingproductswithout
priornotice. Specificationsandappearance maydiffer from thoselisted orillustrated.
