Behringer DIGITAL REVERB DR600 User manual

DIGITAL REVERB DR600
Digital Stereo Reverb Eects Pedal
Thank you for showing your condence in us by purchasing the BEHRINGER DIGITAL REVERB DR600.
This ultimate eects pedal is specically designed to deliver 24-bit high-resolution stereo reverbs
comparable to state-of-the-art studio processors. Thanks to six renowned modes and extensive parameter
control for maximum creativity you’ll have plenty of cool sounds at your disposal for every situation.
1. Controls
(1) The LEVEL control adjusts the output level.
(2) The TONE controlallows you to shape your overall sound.
(3) The TIME control determines the rever time.
(4) The MODE control lets you chose between six dierent reverb sounds:
SPRING: Simulates classic spring reverberation.
PLATE: Simulates the sound of plat reverberation.
HALL: Very bright reverb that simulates the reections of a concert hall.
GATE: This eect snthetically cuts o reverberation after a period of time.
ROOM: Clearly hear natural room acoustics.
MODULATE: By detuning the reverb tail it creates spacious, almost choir-like reverb that reminds a
little bit of a chorus eect.
(5) The ON/BATT LED illuminates when the eect is activated. It also serves as a battery level indicator.
(6) Use the footswitch to activate/deactivate the eect.
(7) Use the two ¼" TS connectors IN A and IN B to plug in a stereo input signal. For mono use just plug
in IN A.
(8) The two ¼" TS connectors OUT A and OUT Bsend the signal to your amp. Use both connectors if
you want to achieve full stereo eect. For mono use just plug in OUT A.
(1)
(2)
(4)
(5)
(6)
(3)
(8) (7)

DIGITAL REVERB DR600
MUSIC Tribe accepts no liability for any loss which may be suered by any person who relies either wholly or in part upon any description, photograph,
or statement contained herein. Technical specications, appearances and other information are subject to change without notice. All trademarks are the property
of their respective owners. MIDAS, KLARK TEKNIK, LAB GRUPPEN, LAKE,TANNOY, TURBOSOUND,TC ELECTRONIC,TC HELICON, BEHRINGER, BUGERA and COOLAUDIO
are trademarks or registered trademarks of MUSIC Tribe Global Brands Ltd. © MUSIC Tribe Global Brands Ltd. 2018 All rights reserved.
Use the DC IN connection to plug in a 9 V power supply (not included).
The BATTERY COMPARTMENT is located underneath the pedal cover. To install or replace the 9 V battery
(not included), press the hinges with a ballpoint pen and remove the pedal cover. Be careful not to
scratch the unit.
◊ The DR600 has no on/o switch. As soon as you insert the jack into the IN connector,
the DR600 begins running. When not using the DR600, remove the jack from the IN
connector. This extends the life of the battery.
The SERIAL NUMBER is located at the bottom.
2. Safety Instructions
Do not use near water, or install near heat sources. Use only authorized attachments/accessories.
Do not service product yourself. Contact our qualied servicing personnel for servicing or repairs,
especially when power supply cord or plug is damaged.
3. Limited Warranty
For the applicable warranty terms and conditions and additional information regarding
MUSIC Tribe’s Limited Warranty, please see complete details online at musictri.be/warranty.
4. Specications
In A
Connector ¼" TS
Impedance 500 kΩ
Impedane mono 250 kΩ
In B
Connector ¼" TS
Impedance 500 kΩ
Out A
Connector ¼" TS
Impedance 1 kΩ
Out B
Connector ¼" TS
Impedance 1 kΩ
Power Supply
9 V𝌂, 1.7 A regulated
BEHRINGER PSU-HSB ALL
U.S./Canada 120 V~, 60 Hz
China/Korea 220 V~, 50 Hz
U.K./Australia 240 V~, 50 Hz
Euope 230 V~, 50 Hz
Japan 100 V~, 50 - 60 Hz
Power connector 2 mm DC jack, negative center
Battery 9 V type 6LR61
Power consumption 130 mA
Physical/Weight
Dimensions approx. 2 ⁄ x 2 ¾ x 4 ⁄"
(H x W x D) approx. 54 x 70 x 123 mm
Weight approx. 0.73 lbs / 0.33 kg
