Behringer DISTORTION-X XD300 User manual

DISTORTION-X XD300
Thank you for showing your confidence in us by purchasing the BEHRINGER DISTORTION-X
XD300. This high-quality effects pedal enables you to produce super thick, tube-like
distortion plus endless sustain. Thanks to its high-performance features you can achieve
the typical hard rock or heavy metal distortion sounds.
1. CONTROLS
Top view
The LEVEL control adjusts the output level.
The CONTOUR control modifies the tone of the signal to achieve everything from
traditional to super-modern sounds. Turning it to the right will create a milder sound
while turning it to the left provides heavier and sharper sounds.
The PUNCH control adds aggressive mid-frequency punch to the signal for more
distinctive distortion sounds.
The DIST(ortion) control adjusts the amount of distortion effect.
The ON/BATT LED illuminates when the effect is activated. It also serves as a
battery level indicator.
Use the footswitch to activate/deactivate the effect.
Use this 1/4" TS IN connector to plug in the instrument cable.
The 1/4" TS OUT connector sends the signal to your amp.
Use the DC IN connection to plug in a 9 V power supply (not included).
The BATTERY COMPARTMENT is located underneath the pedal cover. To install or
replace the 9 V battery (not included), press the hinges with a ballpoint pen and remove
the pedal cover. Be careful not to scratch the unit.
The XD300 has no on/off switch. As soon as you insert the plug into the IN
connector, the XD300 is on. When not in use, remove the plug from the IN
connector. This extends the life of the battery.
The SERIAL NUMBER is located at the underside.

DISTORTION-X XD300
2. WARRANTY
For our current warranty terms, please refer to our website at http://www.behringer.com.
3. SPECIFICATIONS
In Connector 1/4" TS
Impedance 500 kΩ
Out Connector 1/4" TS
Impedance 1 kΩ
Power supply 9 V , 100 mA regulated
BEHRINGERPSU-SB
USA/Canada 120 V~, 60 Hz
Europe/U.K./Australia 230 V~, 50 Hz
China 220 V~, 50 Hz
Korea 220 V~, 60 Hz
Japan 100 V~, 50/60 Hz
Power connector 2 mm DC jack, negative center
Battery 9 V type 6LR61
Power consumption 30 mA
Dimensions (H x W x D) approx. 54 mm (2 1/8") x 70 mm (2 3/4") x 123 mm (4 4/5")
Weight approx. 0.33 kg (0.73 lbs)
BEHRINGERisconstantlystrivingtomaintainthehighestprofessionalstandards.Asaresultoftheseefforts,modificationsmay
bemadefromtimetotimetoexistingproductswithoutpriornotice.Specificationsandappearancemaythereforedifferfromthose
listedorshown.
4. SAFETY INSTRUCTIONS
Do not use near water, or install near heat sources. Use only authorized attachments/accessories. Do not service product yourself.
Contact our qualified servicing personnel for servicing or repairs, especially when power supply cord or plug is damaged.
No utilizar cerca de agua o instalar cerca de fuentes de calor. Utilice sólo accesorios y aditamentos autorizados. No intenté reparar
el producto usted mismo. Contacte a nuestro personal técnico cualificado para servicio y reparaciones, especialmente cuando la
fuente o el cable de alimentación estén dañados.
Не эксплуатируйте прибор вблизи от источников воды и тепла. Применяйте только авторизованные дополнительные
устройства. Никогда не ремонтируйте прибор самостоятельно. Ремонт может производить только квалифицированный
специализированный персонал, особенно при повреждениях сетевого провода или сетевой вилки.
