Behringer Eurolive ELX215S User manual

BEHRINGER, a world leader in highest-
quality passive and active loudspeakers,
now brings its extreme value proposition
to the vertical line-array marketplace
with its new ELX Series loudspeakers.
Now small to medium sized venues,
such as houses of worship, community
centers, nightclubs, as well as rental
and touring applications can enjoy truly
professional-grade performance for a
fraction of the cost of competing systems.
What’s a Line-Array?
Although line array systems have
been around for more than 50 years,
they have only come into prominence
over the past few years, mainly due to
their use in large-scale concert venues.
Vertical line-arrays are created by stacking
or suspending identical loudspeaker
cabinets so the LF (Low-Frequency) and
HF (High-Frequency) drivers, are placed in
exact vertical alignment with each other.
This enables them to work together to
send sound waves much further than
a single driver could. The conguration
is designed so that you end up with a
column each of LF and HF drivers.
By using specially designed
waveguides or horns, horizontal
sound dispersion can be very wide,
while keeping the vertical alignment
extremely tight. The resulting sound
is smoother, with much more even
dispersion than that of traditional
horn-loaded loudspeaker systems.
Highest Quality Sound
BEHRINGER ELX Series loudspeakers
provide amazingly brilliant sound,
with rich and deep low-end,
smear-free mids and sparkling highs.
Capable of generating extremely high
sound pressure levels, ELX loudspeakers
utilize only the highest-quality
components and are constructed of
void-free birch plywood. The handmade
enclosures are then nished with a
special black or white DuraCoat nish,
recognized by many as the toughest
nish on the market.
EUROLIVE ELX215S — 2 x 15" Compact
Fly Ready Line Array Subwoofer
Ultra-compact, high-performance,
yready line array subwoofer for front
of house, side ll, or delay line use
Dual 15" 4th order bandpass
subwoofer design
Ground-rumbling frequency
response with frequency range that
runs to 29 Hz
Extremely high acoustic output with
133 dB Max SPL for room lling lows
High power handling
(1200 W RMS/2400 W
Program/3600 W Peak)
Fly ready for use above an ELX82
stack or behind the array. Fly two
subs together as part of any array
with a 12:1 load factor
Tour ready impact resistant 18 AWG
perforated grille
Void-free 18 mm Baltic Birch ply
with a nearly indestructible
DuraCoatnish
Easy grip ergonomic handle design
for hassle free handling
Integrated and intuitive suspension
hardware supports exible ground
stacking options
EUROLIVE ELX212S — Ultra-Compact
Fly Ready 2 x 12" Line Array Subwoofer
Ultra-compact, high-performance,
yready line array subwoofer for front
of house, side ll, or delay line use
Dual 12" 4th order band pass
subwoofer design
Ground-rumbling frequency
response with frequency range that
runs to 38 Hz
Continued on next page
EUROLIVE ELX215S/
ELX212S/ELX82/ELX42
Line Arrays

Page 2 of 4
Extremely high acoustic output with
131 dB Max SPL for room lling lows
High power handling
(600 W RMS/1200 W Program/
1800 W Peak)
Fly ready for use above an ELX82
stack or behind the array. Fly two
subs together as part of any array
with a 12:1 load factor
Tour ready impact resistant 18 AWG
perforated grille
Void-free 18 mm Baltic Birch ply
with a nearly indestructible
DuraCoatnish
Easy grip ergonomic handle design
for hassle free handling
Integrated and intuitive suspension
hardware supports exible ground
stacking options
EUROLIVE ELX82 — 2 x 8" Compact
Line Array Satellite
Ultra-compact, high-performance,
professional line array speaker for front
of house, side ll, or delay line use
Lightweight 2 x 8" Kevlar-coned
Neodymium low frequency drivers
with 2 x 1.35" Titanium domed
compression drivers
Incredible acoustic output
(Max SPL- 141 dB HF/133 dB LF)
perfect for medium to large format
performancevenues
High power handling (650 W
RMS/1300 W Program/2600 W Peak)
Wide coverage eld with
100° H x 10° V degree dispersion
Easy grip ergonomic handle design
for hassle free handling
Custom-Designed Transducers
Let's face it; the transducers
(woofers and tweeters) are the only part
of a sound system you actually hear,
so we don't cut any corners. While some
of our competitors are content to buy o-
the-shelf transducers and plug them into
their boxes, we custom-design and build
our transducers from scratch. This enables
us to control the quality, and frankly,
make better components, such as the
Kevlar-coned, neodymium LF and HF
compression drivers we deploy in each
and every ELX Series enclosure.
System Scalability
By their very nature, vertical
line-arrays are ideal when it comes to
system scalability. This allows a venue
to custom-tailor a system specically to
meet their needs. Should requirements
change, more enclosures and ampliers
can be added to expand the system.
Specially designed ying hardware allows
for multiple subs and mid/high packs to
be own in each array.
To Fly or Not to Fly
Venues with high ceilings, such as
sports arenas, concert halls and large
churches, etc., often prefer to “y” the
sound system. By suspending the
speaker array high above the audience,
oor space is maximized and nothing
comes between the audience and
the performance. Rigging points are
integrated into all ELX Series enclosures
for use with dedicated ying kits,
which we generously over-engineer
for the utmost in safety. All of our
line-arrays oer variable curvature for
custom-tailoring the sound coverage to
your specic venue. Alternately, the ELX
system can be stacked in front of the
performance area, if you have the
available oor space.
ELX215S
The ELX215S dual 15" bass-reex
subwoofer is the perfect complement
to the ELX82 mid-high pack. With its
powerful 15" woofers (with 4" voice coil),
the ELX215S is capable of frequencies as
low as 34 Hz and has a power handling
capacity of 2400-Watts per enclosure.
Maximum SPL is 131 dB. The ELX215S
weighs 180 lbs. (81.5 kg).
ELX212S
The ELX42 dual 12" bass-reex
subwoofer is the perfect complement
to the ELX42 mid/high pack. With its
powerful 12" woofers (with 4" voice coils),
the ELX212S is capable of frequencies as
low as 38 Hz and has a power handling
capacity of 1200-Watts per enclosure.
Maximum SPL is 126 dB and the ELX212S
weighs just 98 lbs. (44.5 kg).
ELX82
The ELX82 is an ultra-compact dual
8" line-array system with a power handling
capacity of 1300-Watts per enclosure.
The neodymium LF drivers feature special
deformation-resistant Kevlar cones that
provide bulletproof bass and superbly
accurate midrange. HF duties are
handled by two waveguide-mounted
1" neodymium compression drivers
with a combined dispersion pattern
of 100° H x 10° V. The ELX82 enclosure
weighs 61 lbs. (27.5 kg).
ELX42
The ELX42 is an ultra-compact dual
4" line-array system with a power handling
capacity of 550-Watts per enclosure.
The neodymium LF drivers feature special
deformation-resistant Kevlar cones that
provide bulletproof bass and superbly
accurate midrange. HF duties are handled
by a waveguide-mounted 1" neodymium
compression driver with a broad dispersion
pattern of 120° H x 10° V. The ELX42
enclosure weighs just 21 lbs. (9.6 kg).
Continued on next page
EUROLIVE
ELX215S/ELX212S/
ELX82/ELX42

Page 3 of 4
Intuitive and simple to use rigging for
up to 12 units with a 12:1 load factor
Tour ready impact resistant 18 AWG
perforated grille
Void-free 15 mm Baltic Birch ply with a
nearly indestructible DuraCoat nish
Ground stacking capability for
exible installation options
EUROLIVE ELX42 — Ultra-Compact
2 x 4" Line Array Speaker
Ultra-compact, high-performance,
professional line array speaker for front
of house, side ll, or delay line use
Lightweight 2 x 4" Kevlar-coned
Neodymium low frequency drivers
with 1 x 1.35" Titanium domed
compression drivers
Incredible acoustic output
(Max SPL - 134 dB HF/129 dB LF)
perfect for medium to large format
performancevenues
High power handling
(275 W RMS/550 W Program/
1100 W Peak)
Extra wide coverage eld with
120° H x 10° V degree dispersion
Easy grip ergonomic handle design
for hassle free handling
Intuitive and simple to use rigging for
up to 12 units with a 12:1 load factor
Tour ready impact resistant 18 AWG
perforated grille
Void-free 15 mm Baltic Birch ply with a
nearly indestructible DuraCoat nish
Ground stacking capability for
exible installation options
Value
When performance, features and
aordability come together you get
value. BEHRINGER has consistently
led the industry in providing
tremendous value, what we refer to
as “more bang for your buck!”We are
excited to oer this new premium-
grade loudspeaker line at an unheard
of price, and we back them up with
a comprehensive warranty program.
Once you try BEHRINGER, you'll buy
BEHRINGER every time.
EUROLIVE
ELX215S/ELX212S/
ELX82/ELX42

Page 4 of 4
Europe
MUSIC Group Services UK
Tel: [phone]
Email: [email protected]om
USA/Canada
MUSIC Group Services NV Inc.
Tel: [phone]
Email: [email protected]om
Japan
MUSIC Group Services JP K.K.
Tel.: [phone]
Email: [email protected]om
For service, support or more information contact the BEHRINGER location nearest you:
This device has not been authorized by the rules of the Federal Communications Commission.This device is not, and may not be, off ered for sale or lease, or sold or leased in the 50 U.S. states, the District of Columbia and U.S. possessions, until authorization is obtained.
Technical specifications and appearances are subject to change without notice and accuracy is not guaranteed. BEHRINGER is part of the MUSIC Group (music-group.com). All trademarks are the property of their respective owners. MUSIC Group accepts no liability for any loss
which may be suffered by any person who relies either wholly or in part upon any description, photograph or statement contained herein. Colors and specifications may vary from actual product. MUSIC Group products are sold through authorized fullfillers and resellers only.
Fullfillers and resellers are not agents of MUSIC Group and have absolutely no authority to bind MUSIC Group by any express or implied undertaking or representation.This manual is copyrighted. No part of this manual may be reproduced or transmitted in any form or by any
means, electronic or mechanical, including photocopying and recording of any kind, for any purpose, without the express written permission of MUSIC Group IP Ltd. ALL RIGHTS RESERVED. © 2012 MUSIC Group IP Ltd.Trident Chambers,Wickhams Cay, P.O. Box 146, RoadTown,
Tortola, BritishVirgin Islands.
Accessories
ELX42-FLY Flybar for ELX42
ELX82-FLY Flybar for ELX82
ELX212S-FLY Flybar for ELX212S
ELX215S-FLY Flybar for ELX215S
ELX42-CASE Flight Case for ELX42 (holds 4)
ELX82-CASE Flight Case for ELX82 (holds 4)
Specications
ELX215S
Type Dual 15", 4th order
bandpass subwoofer
Woofer 2 x 15" with 4" voice coil
Horn -
Compression Driver -
Frequency Range 34 Hz - 150 Hz
LF Power Handling 1200 W/2400 W/3600 W
(RMS/Continuous/Peak)
HF Power Handling -
(RMS/Continuous/Peak)
Recommend -
Crossover Frequency
SPL (HF/LF)1 W/1 m 100 dB (LF)
Max. SPL (HF/LF) 131 dB (LF)
Impedance 4 Ω
Dispersion -
Connectors 2 x Neutrik NL- 4
Protection -
Paint/Cabinet material DuraCoat LX/
18 mm Birch Plywood
Dimensions (W x H x D) 29.1 x 19.9 x 27.75"
740 x 506 x 705 mm
Weight 180 lbs./81.5 kg
ELX212S
Type Dual 12" bass-reex subwoofer
Woofer 2 x 12" woofer with 4" voice coils
Horn -
Compression Driver -
Frequency Range 38 Hz - 200 Hz
LF Power Handling 600 W/ 1200 W/ 1800 W
(RMS/Continuous/Peak)
HF Power Handling -
(RMS/Continuous/Peak)
Recommend
Crossover Frequency -
SPL (HF/LF)1 W/1 m 100 dB (LF)
Max. SPL (HF/LF) 126 dB (LF)
Impedance 8 Ω
Dispersion -
Connectors 2 x Neutrik NL- 4
Protection -
Paint/Cabinet material DuraCoat LX/18 mm Birch
Plywood DuraCoat LX
Dimensions (W x H x D) 18.35 x 21 x 24.4"
466 x 530 x 620 mm
Weight 98 lbs./44.5 kg
ELX82
Type Dual 8", 2-way line-array speaker
Woofer 2 x 8" neodymium
Horn 1" waveguide
Compression Driver 2 x 1" neodymium with
1.35" voice coil
Frequency Range 70 Hz - 19 kHz
LF Power Handling 500 W/1000 W/2000 W
(RMS/Continuous/Peak)
HF Power Handling 150 W/300 W/600 W
(RMS/Continuous/Peak)
Recommend 1.6 kHz
Crossover Frequency
SPL (HF/LF)1 W/1 m 113 dB/100 dB
Max. SPL (HF/LF) 141 dB/133 dB
Impedance 16 Ω
Dispersion 100° H x 10° V
Connectors 2 x Neutrik NL- 4
Protection Tweeter protection
Paint/Cabinet material DuraCoat LX/
18 mm Birch Plywood
Dimensions (W x H x D) 29.1 x 9.7 x 18.4"
740 x 247 x 467 mm
Weight 61 lbs./27.5 kg
ELX42
Type Dual 4", 2-way line- array speaker
Woofer 2 × 4" neodymium Kevlar
Horn 1" Wave Guide
Compression Driver 1" neodymium with
1.35" voice coil
Frequency Range 80 Hz -19 kHz
LF Power Handling 200 W/ 400 W/ 800 W
(RMS/Continuous/Peak)
HF Power Handling 75 W/150 W/300 W
(RMS/Continuous/Peak)
Recommend 2.1 kHz
Crossover Frequency
SPL (HF/LF)1 W/1 m 99 dB/90 dB
Max. SPL (HF/LF) 134 dB/129 dB
Impedance 16 Ω
Dispersion 120° H x 10° V
Connectors 2 x Neutrik NL- 4
Protection Tweeter protection
Paint/Cabinet material DuraCoat LX/
15 mm Birch Plywood
Dimensions (W x H x D) 19 x 5.5 x 10.27"
480 x 139 x 261 mm
Weight 21 lbs. / 9.6 kg
Please note these specifications are preliminary and conceptual in nature, and as such are subject
to change as product development progresses. This information is supplied for market research
purposes only and is not to be made public in any manner. This document is solely the property of
The MUSIC Group, or one of its subsidiaries, and must be surrendered upon request of the owner.
EUROLIVE
ELX215S/ELX212S/
ELX82/ELX42
