BeiJer T10A User manual

T10A Installation Guide
1SafetyPrecautions
Both the installer and the owner and/or operator of the operator panel must read
and understand this installation manual.
1.1 General
•Read the safety precautions carefully.
•Check the delivery for transportation damage. If damage is found, notify the
supplier as soon as possible.
•Do not use the operator panel in an environment with high explosive hazards.
•The supplier is not responsible for modified, altered or reconstructed
equipment.
•Use only parts and accessories manufactured according to specifications of
the supplier.
•Read the installation and operating instructions carefully before installing,
using or repairing the operator panel.
•Never allow fluids, metal filings or wiring debris to enter any openings in the
operator panel. This may cause fire or electrical shock.
•Only qualified personnel may operate the operator panel.
•Storing the operator panel where the temperature is lower/higher than
recommended in this manual can cause the LCD display liquid to
congeal/become isotopic.
•The LCD display liquid contains a powerful irritant. In case of skin contact,
wash immediately with plenty of water. In case of eye contact, hold the eye
open, flush with plenty of water and get medical attention.
•Thefiguresinthismanualservesanillustrativepurpose. Becauseofthemany
variables associated with any particular installation, the supplier cannot
assume responsibility for actual use based on the figures.
•The supplier neither guarantees that the operator panel is suitable for your
particular application, nor assumes responsibility for your product design,
installation or operation.
•It is recommended to turn on and shut down the operator panel at least once
before installing any components/cards or before connecting the operator
panel to external devices, like for example serial devices.
1.2 During Installation
•The operator panel is designed for stationary installation on a plane surface,
where the following conditions are fulfilled:
–no high explosive risks
–no strong magnetic fields
–no direct sunlight
–no large, sudden temperature changes
•Install the product according to the accompanying installation instructions.
•Ground the product according to the accompanying installation instructions.
•Only qualified personnel may install the operator panel.
•Separate the high voltage, signal and supply cables.
•Make sure that the voltage and polarity of the power source is correct before
connecting the product to the power outlet.
•Peripheral equipment must be appropriate for the application and location.
1.3 During Use
•Keep the operator panel clean.
•Emergency stop and other safety functions may not be controlled from the
operator panel.
•Do not use too much force or sharp objects when touching the keys, touch
screen etc.
1.4 Service and Maintenance
•Only qualified personnel should carry out repairs.
•The agreed warranty applies.
•Before carrying out any cleaning or maintenance operations, disconnect the
equipment from the electrical supply.
•Clean the display and surrounding front cover with a soft cloth and mild
detergent.
•Replacing the battery incorrectly may result in explosion. Only use batteries
recommended by the supplier. During the warranty period, the battery needs
to be replaced by an authorized Beijer Electronics service center.
1.5 Dismantling and Scrapping
•The operator panel or parts thereof shall be recycled according to local
regulations.
•The following components contain substances that might be hazardous
to health and the environment: lithium battery, electrolytic capacitor and
display.
2Installation
2.1 Space Requirements
•Maximum installation plate thickness: 8 mm
•Space requirements when installing the operator panel:
100 mm
280 mm
100 mm
50 mm 50 mm 228 mm 100 mm
44 mm
Note:
The dimensions on the drawing are not proportional.
2.2 Installation Process
The following is needed:
•A Phillips/slot screwdriver
1. Unpack and check the delivery. If damage is found, notify the supplier.
Note:
Place the operator panel on a stable surface during installation.
Dropping it or letting it fall may cause damage.
2. Use the cut out dimensions that are included on the outline drawing to cut
a correct opening in the cabinet. A separate cut out drawing is available for
download from the Beijer Electronics web site.
3. Secure the operator panel in position using all the fastening holes and the
provided brackets and screws:
x 8 0.5 - 1.0
Nm
4. Connect the cables in the specified order, according to the drawing and steps
below.
Caution:
•Ensure that the operator panel and the controller system have the same
electrical grounding (reference voltage level), otherwise errors in
communication may occur.
•The operator panel must be brought to ambient temperature before it
is started up. If condensation forms, ensure that the operator panel is
dry before connecting it to the power outlet.
•Ensure that the voltage and polarity of the power source is correct.
•Use only shielded communication cables.
•Separate high voltage cables from signal and supply cables.
24V DC
RS232/
RS422/
RS485 24V DC
A
D
Controller
Power
B
Ethernet
C
–Connect cable A.
–Connect cable B, using an M5 screw and a grounding conductor (as
short as possible) with a cross-section of minimum 2.5 mm2.
–Connect cable C.
–Connect cable D. The recommended cross-section of the cable is 1.5
mm2.
5. Carefully remove the laminated film over the operator panel display, to avoid
static electricity that could damage the panel.
Note:
When connecting the operator panel to the power outlet for the first time,
make sure not to interrupt power for a minimum of 48 hours in order to charge
the battery completely. After that, the battery may be charged partly during
a shorter period of time.
2.2.1 Connections to the Controller
For information about the cables to be used when connecting the operator panel to
the controller, please refer to the help file for the driver in question.
2.2.2 Other Connections and Peripherals
Cables, peripheral equipment and accessories must be suitable for the application
and its environment. For further details or recommendations, please refer to the
supplier.
3TechnicalData
Parameter T10A
Frontpanel,WxHxD 280 x 228 x 7 mm
Mounting depth 44 mm (144 mm including clearance)
Standalone mounting VESA 75x75
Note: Maximum screw length for VESA
mounting is 4 mm. Usage of longer screws
may lead to damage.
Front panel seal IP 65
Rear panel seal IP 20
Touch screen material Polyester on glass, resistive.
Overlay: Autoflex EBA180L*.
Touch screen operations 1 million finger touch operations
Reverse side material Powder-coated aluminum
Frame material Powder-coated aluminum
Weight 1.5 kg
Serial port for COM1
RS232 and COM2
RS422/RS485
9-pinD-subcontactwithRS232RTS/CTS,
chassis-mounted female with standard
locking screws 4-40 UNC
Serial port for COM3
RS232 and COM4
RS422/RS485
9-pinD-subcontactwithRS422RTS,
chassis-mounted female with standard
locking screws 4-40 UNC
Ethernet 1 x 10 Base-T / 100 Base-T (shielded RJ 45)
USB 1 x USB Host 2.0, max output current 200 mA
Processor 400 MHz ARM9
External storage media 1 x SD card (optional)
Flash memory 128 MB SSD (Nand Flash)
Memory RAM 128 MB (DDR2)
LED 1xblue
Real time clock Yes (on chip)
Power consumption at
rated voltage
Normal: 400 mA
Fuse Internal DC fuse, 2.0 AT, 5 x 20 mm
Power supply +24 V DC (18–32 V DC), max. 2 A.
CE: The power supply must conform with the
requirements according to IEC 60950 and IEC
61558-2-4.
UL and cUL: The power supply must conform
with the requirements for class II power
supplies.
Display TFT-LCD. 640 x 480 pixels, 16.7 million colors
(true color)
LED backlight
Active area of display, W
xH
211.2 x 158.4 mm
Operating temperature -10 ° to +60 ° C
Storage temperature -20 ° to +70 °C
Relative humidity <85 % non-condensed
Approvals and
certifications
Information is available on the web site
www.beijerelectronics.com
* See section Chemical Resistance for more information.

4 Chemical Resistance
4.1 Metal Casing
The frame and casing material is powder-coated aluminum. This powder paint
withstands exposure to the following chemicals without visible change:
Acetic acid 10% Phosphoric acid 4%
Citric acid 10% Phosphoric acid 10%
Diesel Sea water
Distilled water Sodium chloride 2%
Edible oil Sodium chloride 20%
Fuel oil Sulphuric acid 20%
Hydrogen peroxide 3% Ta p w a t e r
The powder paint shows limited resistance to the following chemicals at room
temperature:
Butanol Nitric acid 3%
Hydrochloric acid 5% Nitric acid 10%
Isopropyl alcohol Phosphoric acid 43%
Na-hypochlorite 10% Turpentine
Note:
If exposure to any of the above chemicals is demanded, it is recommended to
first test the chemical on an “invisible” spot of the metal casing.
The powder paint shows little or no resistance to the following chemicals at room
temperature:
Acetic acid, conc. Methyl-ethyl ketone Toluene
Acetone Nitric acid 30% Trichlorethylene
Ammonia 5% Phenol Xylene
Ammonia, conc. Sodium hydroxide 5% 97 octan unleaded
petrol
Ethyl acetate Sodium hydroxide 30% 98 octan leaded petrol
4.2 Touch Screen and Overlay
4.2.1 Autoflex EBA 180L
Autoflex EBA 180L covers the overlay surrounding the touch screen.
Solvent Resistance
Autoflex EBA 180L withstands exposure of more than 24 hours duration under
DIN 42 115 Part 2 to the following chemicals without visible change:
Acetonitrile Diesel Downey /
Lenor1
Phosphoric acid (<30%)
Ajax / Vim in solution Ethanol Potassium
ferricyanide
Alkalicarbonate
solution1
Glycerine Potassium hydroxide
(<30%)
Ammonia (<40%)1Glycol Pure Turpentine
Acetic acid (<50%) Gumption1SBP 60/951
Ariel powder in
solution1
Hydrochloric acid
(<36%)
Sulfuric acid (<10%)
Bleach1Linseed oil Tomato ketchup
Castor oil Methanol Trichloroacetic acid
(<50%)
Caustic soda (<40%)1Nitric acid (<10%) White Spirit
Cutting oil Paraffinoil Windex
1
Cyclohexanol Persil powder in
solution1
Wisk
Diacetone alcohol Petroleum spirit1-
1Extremely faint glossing of the texture was noted.
Autoflex EBA 180L withstands DIN 42 115 Part 2 exposure of up to 1 hour
duration to glacial acetic acid without visible change.
Autoflex EBA 180L is not resistant to high pressure steam at over 100 °C or the
following chemicals:
Concentrated mineral acids Benzyl alcohol
Concentrated caustic solution Methylene chloride
4.2.2 Touch Screen Surface
The touch screen surface on the operator panel withstands exposure to the following
solvents without visible change:
Solvents Time
Acetone 10 minutes
Isopropanol 10 minutes
Toluene 5 hours
4.2.3 Autoflex EB
It is recommended to use the Autoflex EB touch display protection film, that can be
ordered from Beijer Electronics.
Outdoor Use
In common with all polyester based films Autotex EB is not suitable for use in
conditions of long term exposure to direct sunlight.
5 Operator Panel Drawings
5.1 Communication Ports
Serial port, 9-pin female Serial port, 9-pin female
PinCOM1COM2COM3COM4
1RS422 TX+
/RS485
TX+/RX+
RS422 TX+
/RS485
TX+/RX+
2RS232RX RS232RX
3 RS232 TX RS232 TX
4RS422 RX+ RS422 RX+
5GND GND GND GND
6 RS422 TX-
/RS485
TX-/RX-
RS422 TX-
/RS485
TX-/RX-
7RS232 RTS RS422 RTS+
8 RS232 CTS RS422 RTS-
9 RS422 RX- RS422 RX-
Note:
Drawing for external cable CAB109 (drawing # Z7100-029E) is available on the
web site: www.beijerelectronics.com
5.2 T10A Outline
280
228
max 8 mm
material thickness
7
44
262 99
209 99
USB host
SD memory
card slot
Expansion port
COM3 RS232 / COM4 RS422/RS485
COM1 RS232 / COM2 RS422/RS485
Ethernet 24 V DC
Note:
AStepCADfile is available on the web site www.beijerelectronics.com
Order no: MAEN017C
Copyright © 2012-04 Beijer Electronics AB. All rights reserved.
The information in this document is subject to change without notice and is
provided as available at the time of printing. Beijer Electronics AB, including
all its group companies, reserves the right to change any information without
updating this publication. Beijer Electronics AB, including all its group
companies, assumes no responsibility for any errors that may appear in this
document. Read the entire installation manual prior to installing and using
this equipment. Only qualified personnel may install, operate or repair this
equipment. Beijer Electronics AB, including all its group companies, are
not responsible for modified, altered or renovated equipment. Because the
equipment has a wide range of applications, users must acquire the appropriate
knowledge to use the equipment properly in their specific applications. Persons
responsible for the application and the equipment must themselves ensure that
each application is in compliance with all relevant requirements, standards and
legislation in respect to configuration and safety. Only parts and accessories
manufactured according to specifications set by Beijer Electronics AB, including
all its group companies, may be used.
BEIJER ELECTRONICS AB, INCLUDING ALL ITS GROUP
COMPANIES, SHALL NOT BE LIABLE TO ANYONE FOR ANY
DIRECT, INDIRECT, SPECIAL, INCIDENTALOR CONSEQUENTIAL
DAMAGES RESULTING FROM THE INSTALLATION, USE OR REPAIR
OF THIS EQUIPMENT, WHETHER ARISING IN TORT, CONTRACT,
OR OTHERWISE. BUYER'S SOLE REMEDY SHALL BE THE REPAIR,
REPLACEMENT, OR REFUND OF PURCHASE PRICE, AND THE
CHOICE OF THE APPLICABLE REMEDY SHALL BE AT THE SOLE
DISCRETION OF BEIJER ELECTRONICS AB, INCLUDING ALL ITS
GROUP COMPANIES.
Head office
Beijer Electronics AB
Box 426
201 24 Malmö, Sweden
www.beijerelectronics.com / [phone]
