Chapter 1. Switch Overview
1.1. Introduction
Overview
The JetNet 3905 Series, comprising the JetNet 3905, JetNet 3905f-s, and JetNet 3905f-m models,
offers DNV marine certification. This certification enables the utilization of JetNet 3905 switches in
various marine applications, ensuring network redundancy and security. Specifically designed to
meet the rigorous demands of DNV marine certification, these switches exhibit exceptional
resistance to corrosion, vibration, extreme temperatures, humidity, and shock. With enhanced EMC
and reliability design features, the JetNet 3905 Series is perfectly suited for boat applications,
providing unmatched performance and durability.
Main Features
The JetNet 3905 Series support the features. All features are not available in each model. For device
specific features review the device’s datasheet to obtain further details.
•5 RJ45 ports for 10/100Base-TX Ethernet Ports (JetNet3905)
•4 RJ45 ports for 10/100Base-TX Ethernet Ports and 1 100Base FX (JetNet3905f)
•Industrial Slim Size Design
•Broadcast storm protection
•Support 802.1p QoS (CoS, DSCP)
•Supports AC 1.5KV Hi-port isolation protection
•DNV Certificate

JetNet 3905 Installation Guide
Page 11 of (35)
JetNet 3905 Series Installation Guide
Switch Models
The JetNet 3905 series is available in the following models.
Switch Model
Description
JetNet 3905
JetNet 3905 (left): Industrial 5 x 10/100 base TX
RJ45 Ethernet ports
JetNet 3905f
JetNet 3905f: Industrial 4 x 10/100 base TX RJ45
Ethernet ports

JetNet 3905 Installation Guide
Page 12 of (35)
JetNet 3905 Series Installation Guide
1.2. Technical Specifications
Specifications
Description
Interface
Enclosure Port
JetNet 3905
•5-port 10/100BaseT(X) RJ-45Ethernet Port
•Non-blocking Switching Performance
•Auto negotiation speed, Full/Half duplex mode and auto MDI/MDI-X
connection
JetNet 3905f
•4-port 10/100T(X) RJ-45Ethernet Port
•Non-blocking Switching Performance
•Auto negotiation speed, Full/Half duplex mode and auto MDI/MDI-X
connection
Fiber Port
JetNet 3905f
1-port 100Base F(X)
Ethernet
Cable
100Base-TX: 4-pair Cat.5e / Cat.6 UTP/STP cable, 100Meters
LEDs
JetNet 3905 / 3905f
•1x Power (Green on)
•Ethernet Port:
100Mbps Link (Green on)
100Mbps Activity (Green blinking)
10Mbps link (Amber on)
10Mbps Activity (Amber blinking)
JetNet 3905f
•1x Fiber:
Link (Green on)
Activity (Green blinking)
Power
Requirements
System power
Power inputs
Voltage
10-60 VDC
Power
Consumption
2 W
Connection
1 x removable 2-contact terminal block
Technology
IEEE Standards
•IEEE 802.3 10Base-T
•IEEE 802.3u100Base-TX/100Bae-Fx
•IEEE 802.3x Flow Control
•IEEE 802.1p QoS
Performance
Switch
Technology
Store and Forward technology
MAC Address
1K MAC address table
Packet Buffer
448 Kbits packet buffer

JetNet 3905 Installation Guide
Page 13 of (35)
JetNet 3905 Series Installation Guide
Specifications
Description
Transfer
packet size
64 Bytes ~ 1536 Bytes
Transfer
Performance
14,880 pps for 10 Mbps, 148,800 pps for 100 Mbps
Broadcast
Storm Control
Default enabled
Mechanical
Installation
DIN-Rail mounting
Case
IP30 grade metal case
Dimensions
Without DIN rail clip –W x D x H
89.4 x 30 x 111.8 mm / 3.52 x 1.18 x 4.40 in.
Weight
Packaged
0.35 kg / 12.34 oz
Without package
0.35 kg / 32.63 oz
Environmental
Operating
Temperature
-40 ~ 75°C / -40°F ~ 167°F
Operating
Humidity
0% ~ 100%, non-condensing
Storage
Temperature
-40 ~ 85°C / -40°F ~ 185°F
Regulatory
EMC
IEC/EN61000-6-2, IEC/EN61000-6-4 Heavy Industrial EMC
EMI: FCC Class A, CE/Class A
EMS: IEC/EN61000-4-2, IEC/EN61000-4-3, IEC/EN61000-4-4,
IEC/EN61000-4-5, IEC/EN61000-4-6, IEC/EN61000-4-8
Shock
Compliance with IEC 60068-2-27
Vibration
Compliance with IEC 60068-2-6
Free Fall
Compliance with IEC 60068-2-32
Marine
DNV
Warranty
5 years

JetNet 3905 Installation Guide
Page 14 of (35)
JetNet 3905 Series Installation Guide
1.3. Front Panel
Described in this section are the front panel components of the JetNet 3905 series switches.
JetNet 3905
The LEDs and ports for the JetNet 3905 are located on the front panel of the switch as illustrated in
the following illustrations.
Figure 1: Front Panel of JetNet 3905
No.
Item
Description
1.
System LEDs
See Front Panel LEDs on page 16 for further details
2.
ETH ports
RJ45 Ethernet ports, 10 Mbps and 100 Mbps on Cat 5e cables

JetNet 3905 Installation Guide
Page 15 of (35)
JetNet 3905 Series Installation Guide
JetNet 3905f
The LEDs and ports for the JetNet 3905f are located on the front panel of the switch as illustrated in
the following illustrations.
Figure 2: Front Panel of JetNet 3905f
No.
Item
Description
1.
Fiber LED
See Front Panel LEDs on page 16 for further details
2.
System LED
3.
RJ-45 console ports
Console/Terminal Port (RJ45) for device management/debug
4.
Fiber port
100BASE SC Type Fiber
3905f-s:Single-mode 30km
3905f-m:Multi-mode 2 km

JetNet 3905 Installation Guide
Page 16 of (35)
JetNet 3905 Series Installation Guide
Front Panel LEDs
The system LEDs are used to monitor the switch activity and performance. The following illustration
depicts the front panel on a JetNet 3905 Series. A specific LED panel is dependent on a specific
JetNet model.
Figure 3: Front Panel LEDs for JetNet 3905 Series
No.
LED
Description
1.
Power
Solid green: Device is powered on
Off: Device is powered off
2.
FX
JetNet 3905f
Solid green: fiber connector is connected
Flashing green: fiber interface is transmitting / receiving
Off: Link is inactive
3.
1000 Mbps
Solid green: Port is operating at 100 Mbps speed
Blinking green: Packet transmitting / receiving at 100 Mbps speed
Off: Port is inactive
4.
Link / Act
Solid amber: Port is operating at 10 Mbps speed
Blinking amber: Packet transmitting / receiving at 10 Mbps speed
Off: Link is inactive

JetNet 3905 Installation Guide
Page 17 of (35)
JetNet 3905 Series Installation Guide
1.4. Rear View
The following rear view illustrates the rear view of a JetNet 3905 Series device. For demonstration
purposes a single sample is illustrated. Varying models may differ in shape and form.
Figure 4: Rear Panel of JetNet 3905 Series
No.
Item
Description
1.
DIN rail plate
Connect to DIN rail for mounting

JetNet 3905 Installation Guide
Page 18 of (35)
JetNet 3905 Series Installation Guide
1.5. Bottom View
The following bottom view illustrates the bottom view of a JetNet 3905 Series device. The power
inputs and relay connectors are located on the bottom panel of the switch as illustrated in the
following illustrations. For demonstration purposes a single sample is illustrated. Varying models
may differ in shape and form.
Figure 5: Bottom View of JetNet 3905 Series
Item
Description
1.
Ground terminal
Connect to a ground source to provide local earth potential.
2.
Terminal block
receptor
Connect a terminal block for power

JetNet 3905 Installation Guide
Page 19 of (35)
JetNet 3905 Series Installation Guide
1.6. Dimensions
The power inputs and relay connectors are located on the rear panel of the switch as illustrated in
the following illustrations.
JetNet 3905
Figure 6: Dimensions of 5-Port JetNet 3905

JetNet 3905 Installation Guide
Page 20 of (35)
JetNet 3905 Series Installation Guide
JetNet 3905f
Figure 7: Dimensions of 5-Port JetNet 3905f
