BEJOAN X3-US Series User manual

Zhejiang Xingxing BianjieBao Co.,LTD.
Address: Building A7, Hongjiaxingxing Electronic Industrial Park, Jiaojiang District,
Taizhou City, Zhejiang Province, China
Hotline:[phone]
Instructions for use of smart toilet seat
[ X3-US series smart toilet seat]
7.06.07.419-01

Important safeguards
When using electrical products, especially when children are present,
basic safety precautions should always be followed, including the
following:
READ ALL INSTRUCTIONS BEFORE USING
DANGER‒ To reduce the risk of electrocution:
1.Do not use while bathing.
2.Do not place or store product where it can fall or be pulled into a tub or
sink.
3.Do not place in or drop into water or other liquid.
4.Do not reach for a product that has fallen into water. Unplug immediately.
WARNING ‒ To reduce the risk of burns, electrocution, fire, or injury to
persons.
1.Close supervision is necessary when this product is used by, on, or near
children or invalids.
2.Use this product only for its intended use as described in this manual.
Do not use attachments not recommended by the manufacturer.
3.Never operate this product if it has a damaged cord or plug, if it is not
working properly, if it has been dropped or damaged, or dropped into
water. Return the product to a service center for examination and repair.
4.Keep the cord away from heated surfaces.
5.Never block the air openings of the product or place it on a soft surface,
such as a bed or couch, where the air openings may be blocked. Keep the
air openings free of lint, hair, and the like.
6.Never use while sleeping or drowsy.
7.Never drop or insert any object into any opening or hose.
8.Do not use outdoors or operate where aerosol (spray) products are being
used or where oxygen is being administered.
9.Connect this product to a properly grounded outlet only. See Grounding
Instructions.
SAVE THESE INSTRUCTIONS
01

02
Grounding instructions
This product should be grounded. In the event of an electrical short circuit,
grounding reduces the risk of electric shock by providing an escape wire for the
electric current. This product is equipped with a cord having a grounding wire with
a grounding plug. The plug must be plugged into an outlet that is properly
installed and grounded.
DANGER‒ Improper use of the grounding plug can result in a risk of electric
shock.
If repair or replacement of the cord or plug is necessary, do not connect the
grounding wire to either flat blade terminal. The wire with insulation having an
outer surface that is green with or without yellow stripes is the grounding wire.
Check with a qualified electrician or serviceman if the grounding instructions are
not completelyunderstood, or if in doubt as to whether the product is properly
grounded.
This product is for use on a nominal 120 V circuit, and has a grounding plug that
looks like the plug illustrated in sketch A in Figure 75.1. A temporary adapter,
which looks like the adapter illustrated in sketches B and C, may be used to
connect this plug to a 2-pole receptacle as shown in sketch B if a properly
grounded outlet is not available. The temporary adapter should be used only until
a properly grounded outlet (sketch A) can be installed by a qualified electrician.
The green colored rigid ear, lug, and the like extending from the adapter must be
connected to a permanent ground such as a properly grounded outlet box cover.
Whenever the adapter is used, it must be held in place by the screw.
If it is necessary to use an extension cord, use only a three wire extension cord that
has a three blade grounding plug, and a three-slot receptacle that will accept the
plug on the product. Replace or repair a damaged cord.

Installation announcements
03
Do not plug or unplug the power plug with wet hands.
• Doing so may cause electrical shock.
Do not get any water or cleaning products on the main unit or power plug.
• Doing so may cause a fi re, electrical shock, heat or a short.
• Doing so can cause the product to crack rerulting in injury or water damage.
Never disassemble, repair or alter.
• Doing so may cause a fi re, electrical shock, heat or a short.
Do not install the Washlet on moving vehicles such as RV's or boats.
• Doing so could cause a fi re, electric shock, a short or malfunction.
• The toilet seat, lid, main unit or other part might come loose and fall apart, resulting in injury.
Do not use the Washlet if a malfunction occurs.
In the following cases, unplug the plug out from the outlet and close the water supply valve.
Possible malfunctions:
－Water is leaking from a pipe or the main unit
－The product is cracked or broken.
－The product makes a strange noise or emits a strange odor.
－The product emits smoke.
－The product is abnormally hot.
－The toilet seat cushion is out of place.
• Continued use after malfunction could cause a fi re, electrical shock, heat, short, injury or water
Only use tap water or potable well water (underground water). Do not use
seawater.
• Doing so may cause irritation to the skin and malfunction.
Do not touch the power plug during thunderstorms.
• Doing so may cause electrical shock.
Do not allow the water supply hose to touch the power plug or outlet.
• Doing so may cause condensation resulting in a fi re, electrical shock, heat or a short.
Do not do anything that could damage the power cord, power plug or toilet
seat cord.
Do not strike, yank, twist, excessively bend, damage, alter, or heat the electrical cords. Also, do
not place anything heavy, bind or pinch the electrical cords.
• Using a damaged electrical cord may result in a fi re, electrical shock, heat or short.

04
Do not use a loose or faulty electrical outlet.
• Doing so could cause a fi re or a short.
Do no use any outlet or wiring equipment beyond its specified rating
• Plugging too many plugs into the same outlet, for example using outlet splitters, can cause fi re
due to heat.
Do not use any power supply other than the one specified.
AC 120 V, 60Hz
• Doing so could cause a fi re or excessive heat.
Do not stick a finger or anything else into the warm air outlet.
Do not place anything on the warm air outlet or drape clothes over it.
Beware of low-grade burns
• Improper use of heated toilet seats could cause a low-grade burn.
When sitting for a long time on the toilet seat, switch the toilet seat temperature adjustment to
"OFF".
When any of the following persons use a heated seat or warm air drying, someone should switch
the toilet seat temperature adjustment to "OFF" and switch the drying air temperature to "Low".
－Young children, the aged and other users unable set the temperature appropriately themselves
－The ill, physically disabled and others who do not have freedom of movement
－Those using any medicines that cause drowsiness (sleeping medicine or cold medicine), those
who have been drinking heavily, anyone severely fatigued and anyone else liable to fall asleep
Always connect the Washlet to the cold water supply.
• Connecting to hot water supply may result in burns and equipment damage.
Make sure that a properly grounded (3 prong) outlet has been installed.
• Failure to install a grounded outlet could cause electrical shock in the event of a malfunction or
short circuit.
Do not unplug by pulling the cord.
To unplug, hold the plug, not the cord.
• Pulling on the cord may cause damage and result in fi re or heat.
This is an electrical product. Do not install it anywhere water is likely to
get on the product or anywhere with humidity high enough that water is
likely to form on the surface of this product. When using the product in a
bathroom, install a fan or ventilation port and ensure good air flow through
the bathroom.

Installation announcements
05
• Failure to do so could cause a fi re or electrical shock.
If the electric cord is damaged, avoid danger by having the manufacturer’s
repair department or equivalent specialist replace it.
Insert the power plug securely into the outlet.
• Failure to do so could cause a fi re, heat or a short.
Periodically remove dust and dirt from the electrical plug and make sure
it is securely plugged into the wall outlet.
• Failure to do so could cause a fi re, heat or a short.
Pull the plug out from the outlet and wipe clean with a dry cloth.
Always unplug the plug from the outlet before cleaning or maintenance.
• Failure to do so may cause electrical shock.
• Except when using “Wand cleaning”
Always unplug the plug from the outlet before removing the main unit.
• Failure to do so could cause a fi re or electrical shock.
Keep cigarettes and other open flames away from this product.
• Failure to do so could cause a fi re.
When cleaning or maintaining the plastic parts (main unit etc.) or the water
supply hose, use a kitchen cleaner diluted with water. Do not use any of the
following.
Toilet cleaner, household cleaner, benzene, paint thinner, powdered cleanser or nylon
scrubbing pads.
• These items could damage or crack the plastic and cause injury or malfunction.
• These items could damage the water supply hose and cause a water leak.
Do not apply strong force, mechanical shock, step on or stand on the toilet
seat, toilet lid or main unit. Also do not place any heavy object on the toilet
seat, toilet lid or main unit.
• Doing so could cause cracking or cause the main unit to come loose and fall resulting in injury.
• Doing so could damage the product and cause injury or water damage.
Do not lift up this product by the toilet seat or lid.
Do not raise the toilet seat or lid while objects are resting on top of the toilet.
• Doing so could cause the main unit to come loose and fall resulting in injury.

06
Do not fold or crush the water supply hose.
• Doing so could cause water leaks.
To prevent a sudden water leak, do not remove the water filter drain valve
when the water supply valve is open.
• Doing so will cause water to spurt out.
Refer to Page 37 for instructions on cleaning the water fi lter drain valve.
Do not install the base plate, which is not attached, to the Washlet.
• Doing so could cause a fi re or damage.
Do not use the product if the main unit is unstable.
If a water leak should occur, always close the water supply valve.
Preventing damage to pipes and hoses due to freezing
• Frozen water pipes could cause the main unit and the pipes to break, resulting in a water leak.
Regulate the room temperature to prevent the pipes and hoses from freezing during cold months.
When not using the Washlet over an extended period of time, drain the water
out of the Washlet and the water supply hose, and pull the electrical plug
from the outlet.
When using the product again, allow the product to refi ll with water fi rst.
• Otherwise, the water in the tank might become contaminated and cause skin infl ammation or
other problems.
• Leaving the power ON might cause a fi re or heat.
When installing the water filter drain valve, make sure that it is securely
tightened in its proper position.
• Failure to securely tighten it might cause water leaks.
Push the main unit securely on to the base plate.
After pushing the main unit until a click sound is heard, pull it slightly toward you to make sure that
the product does not detach.
• Failure to do so could cause the main unit to come loose and fall resulting in injury.

07
Packing list
Power plug
Inlet connector
Toilet lid
Product ontology
Heated seat
Nozzle
Safety instructions
Control panel

08
complete machine
Appearance in kind prevail
instructions
Mounting bracket / Rubber fixing sleeve/
Cross cup head machine screw M6*45
Water Supply Hose / Gasket / Adapter
Metal snap Remote control

Installation method(Main body installation)
Installation of intelligent toilet and ceramic body
Press and hold the disassembly
button, pull down the machine
mounting plate, and take out the
machine mounting plate from
the machine;
Pull down the machine mounting plate lightly
Disassembly button
Place the machine mounting plate, mounting bracket, and cross cup head machine
screw 6*45 above the mounting hole of the ceramic body;
Cross cup head
machine screw M6*45
Mounting bracket
Machine mounting plate
Screw the cross cup head machine
screw M6*45 into the rubber fixing
sleeve, fix the mounting bracket and
the whole mounting plate on the
ceramic body;
Align the bottom of the toilet with the
direction of the machine mounting plate,
lift the back of the body upwards, and
then slide it toward the machine mounting
plate until you hear a "click" sound.
Screw the cross cup head machine screw
M6*45 out of the rubber fixing sleeve, and
then put the rubber fixing sleeve into the
whole mounting plate on the ceramic body;
09

Water Supply Hose and intelligent toilet body installation
Water supply hose and water diversion
valve
installation:
①Close the water Supply valve and
remove the water supply hose
connected to the ceramic;
②Install adapters at both ends of the
water diversion valve;
③Install the water diversion valve on
the water supply valve;
④Install the ceramic-connected inlet
pipe on the water diversion valve.
Note：
Be sure to tighten it during installation, otherwise it may cause water leakage.
Make sure that the O-ring part of the water
supply hose is not attached with dust, and
insert it straight into the connection part on
the body side.
Note:
Make sure that the front of the water supply hose
is equipped with an O-ring.
Do not cut the water supply hose.
Do not use the old water supply hose, otherwise it
will leak due to aging.
Do not allow the water supply hose to be
scratched by sharps.
The water supply hose must be inserted straight to
avoid the O-ring being engaged by the body
connection.
Body
connector
O-ring
Water supply hose
A
10
Water diversion
valve
Gasket
Water supply valve
Water Supply Hose
To the
smart toilet
To ceramics
Adapter
Gasket
Adapter

Installation method(Main body installation)
Water Supply Hose and intelligent toilet body installation
Insert the metal snap into the connection between the water supply hose and
the body connector. (until hearing a "bang" sound).
When holding the water supply hose, turn the metal snap slightly, and make
sure that there is no obstacle when turning.
If there is obstacle when turning, it is indicated that the installation is not
correct.
Metal snap insert connection part
After installation,
turn slightly, and
make sure
whether the
installation is
successful.
Metal snap
C
11

Water Supply Hose and intelligent toilet body installation
Confirm whether the metal snap is
firmly fixed. Slightly pull the water
supply hose and confirm that the
water supply hose will not be
separated from the main body.
Confirm that all the interfaces have
been connected, please turn on the
water supply valve.
Prompt：
If the toilet is narrow, and after installing the body, if it is difficult to install the
water supply hose, the water supply hose can be installed into the body, and
then the body is installed to the ceramic.
The Water supply valve
should be prepared
by the customer.
12
Water supply valve Axis
Water supply hose of toilet
Water supply hose of ceramic
Water diversion
valve

Installation method(Main body installation)
Acceptance inspection items after installation completed
Periodic spot inspection (please check once a month)
After the installation is completed, it must be commissioned and checked one by one
according to the inspection items.
Press the "Test" key to confirm that the indicator
light goes out and confirm that the product will
stop working.
If there is no problem with the above content,
press the "Reset" key and the product will
restart.
Whether it can connect to a power outlet that can provide 120V to 60Hz and 15A
safety ground or not.
Whether the power plug is loose.
Whether the main water supply valve of the water pipe is open.
Whether each joint is tightened and fixed .
Whether the power indicator lights up.
Whether the functions of the product are normal：Whether the rear and bidet
(including water pressure adjustment), dryer (including warm air intensity
adjustment), water temperature and seat temperature adjustment, nozzle
self-cleansing, automatic deodorization are normal
.
Appearance in kind prevail
Reset
Test
13

Remote control instructions
① Installed in cold weather, keep the product in a warm room for 2 hours before
installation.
② The company shall be not responsible for any accident or injury as it is installed not
according to the method stipulated in installation instruction or the specified part is not
used.
Note
Installation of Main Remote Control
Select a suitable and dry surface, tear off the sponge double-sided adhesive, and
fix the remote control hanger.
Insert remote control into the hanger. (It is recommended to fix the remote control in a
ventilated and easy-to-use position；remove
the battery in case of long-time idle.)
Remote control
hanger
14

Failure analysis and processing
Insufficient Cleaning Water
Please confirm: Whether the water pressure is set at Low gear.
Solution: Re-adjust water pressure.
Please confirm: Whether the filter is blocked by dirt. Solution: Clean the filter.
Please confirm: Whether the water nozzle is blocked by dirt.
Solution: Clean the nozzle.
Please confirm: Whether a cloth cover or cushion or other item is used on the sensing
area of the seat ring. Solution: Remove the cloth cover or cushion or other items.
Please confirm: Whether there is a power cut.
Solution: Wait till the power restored.
Please confirm: Whether the plug is loose or in bad contact.
Solution: Connect well the plug to insure a good supply of power.
Please confirm: Whether the power button is pressed. Solution: Press the power
button of the toilet.
Fail To Work
Washed Without Water
Please confirm: Whether the water supply is cut-off.
Solution: Wait till the water supply is restored. Please confirm: Whether the inlet
valve is open.
Solution: Open the inlet valve.
Please confirm: Whether the filter is blocked by dirt.
Solution: Clean the filter.
Please confirm: Whether the inlet hose is blocked due to bending.
Solution: Restore the bending of inlet hose.
15

Water Cut-off While Washing
Please confirm: The machine will stop automatically in 4 mins after pressing the
Rear or Bidet button. Solution: Re-press Rear or Bidet button.
Please confirm: Whether left the seat while washing. Solution: Re-press Rear or
Bidet button.
Water Temperature Is Not Hot Enough
Please confirm: Whether the water temperature is set at Low or Normal Temp.
Solution: Reset water temperature.
Please confirm: Whether the seat ring Temp is set a Low gear or Turn-off status.
Solution: Reset seat ring Temp following the
Remote-Cotrol Instructions.
Please confirm: Whether it is set at Economy status. Solution: Press Economy
button on the Control to exit the status.
Please confirm: Whether there is a blackout.
Solution: Wait till the power restored.
Seat Ring Temperature Is Not Hot
Air Cut-off While Dryer
Please confirm: The machine will stop automatically in 4 mins after pressing the
Dryer button.
Solution: Re-press Dryer button.
Please confirm: Whether left the seat while dryer. Solution: Re-press Dryer button.
Warm-air Temperature Is Not Hot
Please confirm: Whether the air temp. is set at low gear or off status.
Solution: Reset air temp. following the Remote-Con trol Instructions.
16

Remote control instructions
Bidet
When sitting, press this key to start the function of "bidet";
The cleaning time of this function is 4 minutes;
When the cleaning function is on:
Press the "bidet" again to turn on / off the "reciprocating cleaning"
function;
Press "massaging" key to turn on / off the massaging function;
Press the "position∧∨" key to adjust the cleaning position;
Press the "water temp." key to adjust the water temperature;
Press the "water pressure+ /-" key to adjust the water pressure.
When sitting, press this key to start the function of "rear";
The cleaning time of this function is 4 minutes;
When the cleaning function is on:
Press the "rear" key again to turn on / off the "reciprocating cleaning"
function;
Press "massaging" key to turn on / off the massaging function;
Press the "position∧∨" key to adjust the cleaning position;
Press the "water temp." key to adjust the water temperature;
Press the "water pressure+ /-" key to adjust the water pressure.
Rear
Press this key to start the "cold & hot spa" function.
The cleaning time of this function is 4 minutes. Warm water or water of
room temp will squirt alternatively from the hip wash to achieve
the effect of alternating cold & hot massaging.
When the cleaning function is on:Press the "cold & hot spa" key again
to turn on / off the "reciprocating cleaning" function;
Press the "position∧∨" key to adjust the cleaning position;
Press the "water pressure+ /-" key to adjust the water pressure.
Cold & hot SPA
Press and hold the "air temp." key for 3 seconds to turn on / off the
function of deodorization.
Deodorization
17

Children cleansing
Press this key to start the "children cleansing" function when sitting；
The cleaning time of the function is 4 minutes, and the state of low-level
water temperature, low-level water pressure and the front of pipe position
is maintained;
Note: in order to ensure safety, the water temperature, water pressure, pipe
position, massaging and reciprocation cannot be adjusted after the function is
turned on.
Stop/Stand by
It is used to stop the running function of the whole machine;
Press and hold the "stop" key for more than 5 seconds when the seat is not
in place to turn on / off the power of the whole machine.
Dryer
When sitting, press this key to start the "dryer" function;
The dryer function is 4 minutes;
When the dryer function is on:
Press the "air temp." key to adjust the air temperature.
Massaging
This function can only be used when the cleaning function is turned on
(except for cold & hot SPA and children cleansing). After it is turned on,The
cleaning water pressure changes automatically to achieve massaging effect;
Press "massaging" key to turn on / off the massaging function.
Reciprocating cleaning
This function can only be used when the cleaning function is turned on
(except for children cleansing). After it is turned on, the cleaning pipe will
do small-scale reciprocating motion based on the current pipe position.
Press the cleaning function key again to start the reciprocating cleaning mode.
Night light
Long press the "energy saver/NL" key for 3 seconds to turn on / off the
night light function; when it is turned on, the white soft light at the
bottom of the product will be on;Turn on for 10 minutes and then turn
on or off automatically according to the brightness of the room.
18

Remote control instructions
Water pressure
In the cleaning mode, press the "water pressure+ /-" key to adjust the
water pressure(except for children cleansing). The range of water
pressure adjustment is 1-3.
Position
In the cleaning mode, press the "position∧∨" key to adjust the
cleaning position. The pipe position adjustment range is 1-3 gears. It
can be adjusted according to its own body feeling. This function is
only applicable to rear, bidet,cold & hot SPA.
Seat temp.
Used to adjust the temperature of the seat ring;
Press the "seat temp." key to adjust the seat temperature. The seat
temperature adjustment range is 0-3 (when the seat temperature is 0,
it is not heated). When the indicator lights are all off, the gear 0 is not
heated.
Air temp.
In the dryer mode, press the "air temp." key to adjust the air
temperature. The range of air temperature adjustment is 0-3 (0 is
normal temperature).When the indicator lights are all off, the gear 0 is
not heated.
Water temp.
Used to adjust the temperature of water temperature;
In the cleaning mode, press the "water temp." key to adjust the water
temperature. The range of water temperature adjustment is 0-3 (when
the water temperature is 0, it is not heated). When the indicator lights
are all off, the gear 0 is not heated.
Press and hold the "water temp." key for 3 seconds to turn on / off the
prewetting function of the toilet bowl.
Prewetting of toilet bowl
19
