Toto REI S TX492SRS User manual

"REI S" SINGLE LEVER SHOWER COLUMN SET TX492SRS
600
-7
420
268.5
909
Ø68
75.5
20 G½
Ø8
40
Ø250
115
67
WALL
150±10
2 x Ø8
Holes
7
34
Packing
Packing
Flexible Hose
Hand Shower
Pipe
Pipe
2. CONNECTING
NUT
5
Body
Hanger
Holder
Drill
Bolt
Hex.
Key
3. NUT
6
Packing
Shower
Head
Flow Regulator inside
(Don t remove)
21 MOUNT CONNECTORS
PARALLEL WITH THE WALL
Screw
Packing
Cover
Body
4. BOLT
FlowRegulator
Inside
(Don t remove)
1. NOZZLES
Nut *
* Tighten thenut
Watersupply pressure : 0.05 ~0.75 MPa
Ensure that water supply is clean( No Sand,Dirt, Etc.).
1.
2.
Use Seal tape
(Not Include)
SPECIFICATIONS
S060221Z R9
INSTALLATION TROUBLESHOOTING
OPERATING CONDITIONS ATTENTION
MAINTENANCE
All Finishes : Clean the finish with mild soapand warm water. Wipe
entire surface completely dry with clean soft cloth. Many cleaners
maycontainchemicals, such as ammonia, chlorine, toilet cleaneretc.
which could adversely affect the finish and are not recommended for
cleaning
Don t use abrasive cleaners orsolvents on faucets and fittings.
FlowRegulator should not be remove because it could damage
the system
As the product model is constantly updated, the actual product
maynot lookthe same as it shown in the diagram, but the basic
installation principles are the same.
The hot watersupply side of the faucets is ina condition of high
temperature.Do not allow skin to contact with the hardware
surface directly. Otherwise,
scalding may occur.
1.
2.
3.
4.
150
150±10
Hot
Water
Supply
Cold
Water
Supply
Leg
Fastener*
* Turn the fastener to the left to
loos en and right to tighten
Sleeve Anchor
Bracket
w/ Oring
Cover
PROBLEM CHECK
POINT SOLUTION
Water leaks around the nut
Clean
Tighten
1
2
Handle is loose
Unsatisfactory spray
Tighten
3
Water leaks around the handle Tighten
4

SPESIFIKASI PEMASANGAN
PERHATIAN
KONDISI OPERASIONAL
PEMELIHARAAN
1. Tekanan sumber air: 0,05 ~ 0,75 Mpa
2. Pastikan kondisi sumber air adalah bersih
(Tanpa Pasir, Kotoran, Dll).
PEMASANGAN KONEKTOR
SEJAJAR DENGAN DINDING * Kencangkan Nut
"REI S" SINGLE LEVER SHOWER COLUMN SET TX492SRS
600
-7
420
268.5
909
Ø68
75.5
20 G½
Ø8
40
Ø250
115
67
WALL
150±10
2 x Ø8
Holes
7
34
Packing
Packing
Flexible Hose
Hand Shower
Pipe
Pipe
2. CONNECTING
NUT
5
Body
Hanger
Holder
Drill
Bolt
Hex.
Key
3. NUT
6
Packing
Shower
Head
21
Screw
Packing
Cover
Body
4. BOLT
1. NOZZLES
Nut *
Use Seal tape
(Not Include)
S060221Z R9
150
150±10
Hot
Water
Supply
Cold
Water
Supply
Leg
Fastener*
Sleeve Anchor
Bracket
w/ Oring
Cover
Seluruh lapisan: Bersihkan lapisan akhir dengan sabun lembut dan
air hangat. Lap seluruh permukaanhinggabenar-benarkering
dengan kain lembut yang bersih. Kebanyakanbahan pembersih
mungkin mengandung bahan kimia, seperti amonia, klorin,
pembersih toilet,dll. yang dapat mempengaruhi hasil akhir dan tidak
disarankan untuk membersihkan
Jangan gunakan pembersih atau pelarut abrasif pada faucet dan
fitting.
FlowRegulator tidak boleh dilepas karena dapat merusak sistem
Karena model produk terus mengalami pembaharuan, aktual
produk mungkin tidaksamadengan gambar, tapiprinsip dasar
pemasangan adalah sama.
Sisipasokanair panas pada kran faucet berada dalam kondisi
suhu tinggi. Janganbiarkankulit menyentuh permukaanbenda
secara langsung. Kalautidak, bisaterjadi kepanasan.
1.
2.
3.
4.
Flow Regulator
inside
(Jangan dilepas)
* Putar Fastene r ke kiri untuk
mengendorkan dan ke kanan untuk
mengencangkan
MASALAH POIN
PERIKSA SOLUSI
Air bocor disekitar nut
Bersihkan
Kencangkan
1
2
Handle longgar
Pacaran tidak memuaskan
Kencangkan
3
Air bocor disekitar handle Kencangkan
4
PENYELESAIAN MASALAH
