Beko DRYPOINT ACC 46 User manual

EN
Instruction & Technical Manual
46 - 110
BEKO TECHNOLOGIES CORP. 900 Great SW Parkway, Atlanta, Georgia 30336, USA
[phone] Phone [phone] Fax [email protected] www.bekousa.com

The product to which this manual refers must not be supplied, installed, used,
operated or serviced until the contents of the manual has been fully read and
understood by all relevant personnel.
Please complete the following information at the time of installation
found on the rating label on the upper right hand side of dryer
Model Number
Serial Number
Inlet Pressure
Filtration present with Dryer
Inlet Flow of Dryer
Supply Voltage
When contacting the manufacturer regarding this product, please have
the above stated information at hand to speed up your query.

Contents
1Safety 5
Safety Guidelines 5
Symbols 6
2General Description 7
Function of the Dryer 7
Controller Options 7
Package Contents 8
Primary Components 9 - 10
3Technical Data 10
Environmental Conditions 10
Dimensional Specications 11
Sizing 12
4Mechanical Installation 13
Orientation 15
Conguration of the inlet /outlet ports 16
Connecting the pre-lter to the dryer 17
Connecting the post-lter to the dryer 17
Conguring the purge orice 18
5Electrical Installation 20
Controller power supply options 20
Controller specications 21
How to wire a DIN connector 22
Alarm connection details 23

6Operation 24
Background / Function of the Dryer 24
Detailed operational description 24
Start-up procedure 25
Shut-down procedure 25
Operational schematics 26 - 30
7Energy Management 31
Overview 31
Developing a purge control strategy 31
Using a manual switch for purge control 31
Using a standard pressure switch for purge control 31
Using an electronic pressure switch for purge control 33
Using a hygrometer and process controller for purge control 34
Making connections between a switching device and dryer EM contact 34
8Maintenance 36
9Spares Information 37
Service kits 37 - 41
Accessory kits 42
10 Component Parts 43
11 Troubleshooting 46
12 Warranty 49

5Heatless Desiccant Dryers |Instruction Manual
The following safety guidelines must be strictly observed.
• Leave this manual at the place of installation of the product.
• It is essential that only the manufacturer or its appointed agents carry out
maintenance and servicing work.
Users, maintenance and servicing personnel must be familiar with:
• Accident prevention regulations.
• Safety information (general and specic to the unit).
• Safety devices of the unit.
• Measures to be taken in case of an emergency.
• Allow only suitably trained persons to be involved with installation, start-
up, operation, servicing and maintenance of the product.
• It is the responsibility of the installer to ensure that the pipe work to and
from the dryer is suitable, in accordance with applicable legislation and
subject to inspection and testing prior to being put into service. All piping
must be adequately supported.
• Before carrying out any maintenance or servicing work the unit must be
taken out of operation. Users and others will be exposed to risk if work is
carried out while the unit is running. This means electrical disconnection
plus isolation from the compressed air supply and full depressurisation.
• Only trained and competent persons familiar with the electrical
requirements of the unit as laid out in this manual and electrical safety
rules and regulations should be allowed to carry out work on the
electrical components and power supply to the unit.
• When carrying out any work on the unit, use only correctly sized
appropriate tools in good condition.
• Only use original spare parts and accessories from the manufacturer.
There is no guarantee that non-original parts have been designed
and manufactured to meet the safety and operational requirements
of the unit. The manufacturer assumes no liability for any equipment
malfunction resulting from the use of non-approved parts.
• If carrying out installation work above head height, use suitable and safe
working platforms or other means of working access.
• Do not make any constructional changes to the product. Any changes or
modications may only be carried out by the manufacturer.
• Any faults or defects that could affect safety must be put right fully
before using the unit.
• Used items and materials must be disposed of in the correct manner,
complying with local laws and regulations, in particular the desiccant
cartridge.
Safety
Section 1: Safety

6Heatless Desiccant Dryers |Instruction Manual
Risk of Danger
Risk of High Pressure
Equipment Protected by Double
Insulation
Risk of Electric Shock
Warning
Important Note
Section 1: Safety
Figure 1.1: Denition of symbols
Manual Handling
As with all areas of the workplace, Health and Safety is of great
importance and must be given due care and attention. While working
with this equipment, manual handling regulations must be considered
and adhered to.
Full advice, support and guidance should be detailed in your Health and
Safety Policy and Manual Handling guide, please take the time to familiarize
yourself with these documents.
The Manual Handling Operations Regulations apply to a wide range of
manual handling activities, including lifting, lowering, pushing, pulling or
carrying.
We ask every person handling this product to take the responsibility for their
own Health and Safety and the Health and Safety of others around them. If
you feel there is a signicant risk, you must take steps to either remove the
risk altogether, or reduce the risk prior to carrying out the activity. If you need
further support or guidance with this, please consult your line manager or
the HR Department.
There are safe systems of work and correct procedures in relation to manual
handling, please consult these documents available within the workplace.
We ask everyone handling this product to:
• Follow appropriate systems of work laid down for their safety.
• Make proper use of any equipment provided for their safety.
• Inform the company if they identify hazardous handling activities.
• Take care to ensure that their activities do not put others at risk.
If in doubt, please seek further advice and ensure you always follow the
correct procedures and guidance.
A 3 amp fuse should be tted as per the wiring diagram.
For more information please see our Health and Safety
manual attached.

7Heatless Desiccant Dryers |Instruction Manual
Function of the Dryer
The dryer is designed to provide a smooth, controlled and uninterrupted
delivery of dry compressed air. Wet air passes through a pre-lter and travels
down to the bottom valve assembly. The air is then fed through the bottom
of the desiccant bed and moves through the high performance desiccant
until it becomes dry. On exit from the desiccant cartridge, the air is passed
through the outlet valve assembly.
During this process, the dryer control system cycles the process air between
the two desiccant towers. While one tower is on stream removing
water vapor, the other is being carefully depressurized in preparation for
regeneration. The desiccant bed is regenerated by expanding a small amount
of dry process air, or purge air, through the saturated desiccant.
Purge air passes to atmosphere through the silencer, which is tted to an
exhaust valve. The tower is then repressurized, with the control system
assuring each tower is at full operational pressure prior to changeover.
This ensures a reliable and efcient operation. The air stream is switched and
the cycle repeats on a continuous basis.
General Description
Section 2: General Description
This manual is valid for the following dryer models
ACC 46
ACC 56
ACC 75
ACC 90
ACC 110
Controller Options
Figure 2.1: Digital Display Controller
RESET
Standard Running Mode
-
Hours Run 1234
Service History # 0
Features:
• PLC based design.
• 115-240 VAC, 50-60 Hz or 24 VDC.
• Energy Management Feature (EM).
• Alarm Outputs.
Desiccant Cartridge Options:
Standard / Medical Cartridge:
• Standard default cartridge option.
• Non oxygen depleting.
• Capable of supporting outlet dewpoint levels of -4°F, -22°F & -40°F
(-20°C, -30°C & -40°C) with appropriate sizing per factors provided on
page 12.
High Performance Cartridge:
• Capable of supporting outlet dewpoint levels of -4°F, -22°F, -40°F, -94°F
& -100°F (-20°C, -30°C, -40°C, -70°C & -74°C) with appropriate sizing per
factors provided on page 12.

8Heatless Desiccant Dryers |Instruction Manual
Controller Options
Package Contents
The dryer is delivered in protective packaging. Take care when transporting, loading and unloading the unit. The package contains the following items
(refer to gure 2.2):
Figure 2.2: Package contents (All dryer models)
1. Dryer unit
2. Pre-filter and Post-filter, 0.01 micron, shipped loose
3. Instruction manual
4. Lifting Eyelet(s)
5. Purge Kit
Section 2: General Description
Instruction manual
Pre-filter and post-filter, 0.01 micron, shipped loose
Note: All dryers come equipped with eyebolts to facilitate
removing the dryer from its crate. Simplex dryers include
one eyebolt.
Note: All dryers include spare orice components to
allow the dryer to be modied from the factory 100 psig
(7 barg) pressure setting to any pressure within the specied
operating range. The internal purge valves within models
45 SCFM & 55 SCFM can be modied to suit all pressure
settings while models 75 SCFM to 110 SCFM require
additional components (which are supplied with the dryer).
Figure 2.3: Strongly Recommended
041705 001 01 R a
1
7
6
2
3
4
5
1
7
6
2
3
4
5
6 7 8 9
6 7 8 9
6 7 8 9
6 7 8 9
6 7 8 9
1
7
6
2
3
4
5
6
7 8 9
Recommended Preltration:
Water Separator (Critical)
1.0 micron Optional
0.01 micron Critical
WS
1.0µ
0.01µ

9Heatless Desiccant Dryers |Instruction Manual
5
4
6
7
89
12
13
14
15
16
17
11
3
2
DMC Models
1
To Dryer Inlet
19
18
10 Optional
Figure 2.4: Primary Components (Simplex Models 45 SCFM - 110 SCFM)
Section 2: General Description
1. Front panel
2. Digital Display Controller
3. Top trim cover
4. Extrusion cover
5. Top extrusion tower plug
6. Tower Spacer
7. Desiccant cartridge
8. Extrusion tower
9. Top manifold assembly
10. Water Separator (recommended)
11. Downpipe
12. Exhaust silencer
13. Bottom manifold assembly
14. Dryer stand
15. Bottom extrusion tower plug
16. Tower circlip
17. Bottom trim cover
18. Pre-lter (general purpose) 1.0 µ
19. Pre-lter (high efciency) 0.01 µ

10 Heatless Desiccant Dryers |Instruction Manual
Technical Data
Section 3: Technical Data
Environmental Conditions
All dryers are designed to be safe under the following conditions:
• Indoor use
• Altitude up to 6560 ft.
• Ambient temperature 41°F (5°C ) to 122°F (50°C)
• Mains supply voltage uctuations not to exceed +/- 10% of nominal
For operation extended from the above conditions, please contact the manufacturer.
Rated Conditions
Measurement Performance
Inlet pressure 100 psig 7 barg
Inlet temperature 95°F 35°C
Relative humidity of air at inlet 95%
Pressure dewpoint, standard version -40°F -40°C
Specied Limitation for Operation
Measurement Performance
Maximum inlet air pressure 188.5 psig 13 barg
Minimum inlet air pressure 58 psig 4 barg
Maximum ambient air temperature 122°F 50°C
Minimum ambient air temperature 41°F 5°C
Pressure dewpoint* -4°F to -100°F -20°C to -74°C
Electrical supply voltage 115 - 240 VAC 50-60 Hz or 24 VDC
Excessive vibrations from external sources may cause failure
of this product.
* Pressure dewpoint dependant upon dryer sizing (see page 12). High performance cartridges required for -100°F (-74°C) operation.

11 Heatless Desiccant Dryers |Instruction Manual
Section 3: Technical Data 45 SCFM - 110 SCFM
Dryer
model
Dryer
Pipe
size
Inlet ow rate* Dimensions Inches (mm) Weight
lbs (kg)
No. of
cartridges Dryer cong. Filter
pipe size
SCFM Nm³/hr A B C D E F
ACC 46
1 45 77 25.7 (655) 14.0 (380) 12.2 (310) 3.0 (76) 1.96 (50) 23.6 (600) 101 (46) 2simplex ½
ACC 56
1 55 94 28.9 (735) 14.0 (380) 12.2 (310) 3.0 (76) 1.96 (50) 27.5 (700) 112 (51) 2simplex ½
ACC 75
1 75 128 35.6 (905) 14.0 (380) 12.2 (310) 3.0 (76) 1.96 (50) 33.4 (850) 137 (62) 2simplex ¾
ACC 90
1 90 153 40.55 (1030) 14.0 (380) 12.2 (310) 3.0 (76) 1.96 (50) 39.3 (1000) 155 (70) 2simplex 1
ACC 110
1 110 187 49.6 (1260) 14.0 (380) 12.2 (310) 3.0 (76) 1.96 (50) 27.5 (700) 187 (85) 4simplex 1
*Stated ows are for an inlet pressure of 100 psig (7 barg) with reference to -4°F, 14.50 psig (abs.), 0% relative water vapor pressure. For ow at other pressures apply the appropriate correction factors,
temps and dewpoint.
6 - PD0360
A
C
B
A
6.89”
(175 mm)
F
E
D
BC
F
E
D
6.89”
(175 mm)
6.89”
(175 mm)
6.89”
(175 mm)
4.17”
(106 mm)(106 mm)
4.17” 7.44”
(189 mm)
7.44”
(189 mm)
Models 45 SCFM-110 SCFM

12 Heatless Desiccant Dryers |Instruction Manual
Technical notes
1. Pre-ltration, including a Water Separator is essential to maintain dryer performance.
2. An appropriate Water Separator must be installed. If bulk water enters the adsorption dryer it can cause heat expansion to the
desiccant, substantial rise in the dryer differential pressure, poor outlet dewpoint, potentially resulting in dryer failure.
3. The manufacturer recommends tting a reverse ow 0.01 micron dust lter to the outlet.
4. Call your nearest manufacturer sales team for further information.
Operating pressure (PCF)
psig 58 72 87 100 115 130 145 160 174 189
barg 4 5 6 7 8 9 10 11 12 13
Correction factor 0.62 0.75 0.87 1.0 1.12 1.25 1.37 1.50 1.62 1.75
Temperature (TCF)
Farenheit °F 68 77 86 95 104 113 122
Celcius °C 20 25 30 35 40 45 50
Correction factor 1.3 1.2 1.1 1.0 0.75 0.65 0.45
Pressure dewpoint (DCF)
Farenheit °F -4 -22 -40 -94* -100*
Celcius °C -20 -30 -40 -70 -74
Correction factor 1.23 1.2 1.0 0.8 0.77
Dryer correction factors
Section 3: Technical Data 45 SCFM - 110 SCFM
To correctly select the dryer model suitable for your application the following information is required: Minimum Inlet Pressure, Maximum Inlet
Temperature, Maximum Compressor Inlet Flow and Required Pressure Dewpoint (PDP).
Requirements Correction Factor
Maximum compressor inlet ow 56 scfm -
Actual minimum inlet pressure
to the dryer 87 psig PCF = 0.87
Maximum inlet temperature 77°F (25°C) TCF = 1.2
Pressure dewpoint (PDP) -100°F (-74°C) DCF = 0.77
Corrected dryer ow rate
Appropriate Dryer Size Dryer model is selected based on the corrected ow rate, i.e. 75 SCFM.
Inlet ow rate
PCF x TCF x DCF
56
(0.87 x 1.2 x 0.77)
69.7 scfm
(118 Nm³/hr)
= =
Dryer Sizing Example
* Only achievable when utilizing High Performance cartridges

13 Heatless Desiccant Dryers |Instruction Manual
Figure 4.1: Typical installation
Water Separator 1.0 µ
Optional
0.01 µ
Critical
0.01 µ
0.01 µ
(reverse flow)
Non-return
(Check) Valve
Figure 4.2: Level ground
Mechanical Installation
Section 4: Mechanical Installation
To prevent back ow into the dryer a non-return valve should be placed in-line, downstream of the dryer. This is essential when more than
one dryer is used in a single application.

14 Heatless Desiccant Dryers |Instruction Manual
Section 4: Mechanical Installation
Figure 4.4: Hard piped installation
Figure 4.5 Exposure to heat
Figure 4.3: Location
Max 122OF (50OC) >Max 122OF (50OC)
Max 122OF (50OC) >Max 122OF (50OC)
Max 122OF (50OC)
>Max 122OF (50OC)
Max 122OF (50OC)
>Max 122OF (50OC)
Max 122OF (50OC) >Max 122OF (50OC)
Max 122OF (50OC) >Max 122OF (50OC)

15 Heatless Desiccant Dryers |Instruction Manual
Section 4: Mechanical Installation
Figure 4.6: Drainage (all tubing should be secured up to the point of drain to prevent whipping during discharge)
Orientation
Figure 4.7: The range of dryers is designed to operate in both vertical and horizontal orientation.
16 Heatless Desiccant Dryers |Instruction Manual
Section 4:Mechanical Installation
Figure 4.6: Drainage (all tubing should be secured up to the point of drain to prevent whipping during discharge)
Orientation
Figure 4.7: The range of dryers is designed to operate in both vertical and horizontal orientation.

16 Heatless Desiccant Dryers |Instruction Manual
Section 4: Mechanical Installation
Re conguration of the inlet / outlet ports
45 SCFM - 110 SCFM models
• Dryer can be recongured to interchange position of inlet and outlet
ports as per gure 4.8.
• The dryer has two inlet ports (A and B) and two outlet ports (C and D).
Either (A or B) can be used for inlet and (C or D) for outlet. Make sure
the un-used ports are blanked off with provided pressure plugs.
Figure 4.8: Inlet/outlet ports
A
C
B
D
Either of the two outlet ports can be used. Please ensure
that the outlet ow does not exceed specication. Please
adhere to regional regulations.
It is strongly advised to install a non-return (check) valve to
the outlet port of the dryer.
Only use one inlet port at any one time.
Ensure original seals are in place.
Check dryer is leak-free prior to operation.
Ensure that any surges in ow do not exceed the dryers
rated ow capacity.
Tools required
• Adjustable wrench
• Ratchet with 17mm Hexagonal connection
(45 SCFM - 110 SCFM)

17 Heatless Desiccant Dryers |Instruction Manual
Figure 4.9: Connecting a pre-lter
Section 4: Mechanical Installation
18
||
•
•
•
•
•
•
s
.
All tubing should be secured up to the point of drain to
prevent whipping during discharge.
Figure 4.9: Connecting a pre-filter
Section 4: Mechanical Installation
•
•
• .
Available on DMC models only.
• Install optional solenoid drain valve onto pipe adapter(s)
etched into the side of the drain valve body.
•
All tubing should be secured up to the point of drain to
prevent whipping during discharge.
Figure 4.10: Connecting filter drain
Pipe away condensate with tubing from drain outlet.
Ensure condensate is drained into an oil/water separator.
Connecting the pre-lter to the dryer
45 SCFM - 110 SCFM models
• Attach CLEARPOINT pre-lter (shipped loose for eld installation)
utilizing a pipe nipple and/or pipe adapter (user supplied).
• Pipe away condensate with tubing from drain outlet. Ensure
condensate is drained into an oil/Water Separator.
• Fit any additional ltration and/or ancillary equipment.
• Pre-lter is typically supplied with a oat drain installed in the bowl
drain port. This can be replaced with the optional BEKOMAT®drain.
• It is recommended that a bypass line including an 0.01 micron lter is
installed, as per gure 4.1.
All tubing should be secured up to the point of drain to
prevent whipping during discharge.
Connecting the post-lter to the dryer
45 SCFM - 110 SCFM models
• Attach CLEARPOINT post-lter (shipped loose for eld installation)
utilizing a pipe nipple and/or pipe adapter (user supplied).
• Fit any additional ltration and/or ancillary equipment.
• Post-lter is typically supplied with a manual drain installed in the bowl
drain port.
Figure 4.10: Connecting a post-lter

18 Heatless Desiccant Dryers |Instruction Manual
Section 4: Mechanical Installation
Purge Orice Size Identication
• Reference gure 4.11 and the Purge Plug Identication Table.
• Each dryer is pre-set with the correctly sized purge valve for an operating pressure of 100 psig (7 barg) at point of order.
• The lettering (A through S), located on the purge valve body, indicates the orice size selected to suit the operating pressure of the dryer per the chart
below.
• If the inlet pressure to the dryer will be different than the pre-set orice size, the purge valve can be adjusted.
• Dryers use a single orice purge valve represented by the Red and Blue single letter references in the table below.
• To select the correct orice size, locate the appropriate dryer model at the left side of the table and then the operating pressure at the top.
• Make sure that the correct orice disc (01, 02) has been supplied with the dryer. The discs have the number (01, 02) stamped out at the top.
Every dryer is shipped with a purge orice set up for 100 psig (7 barg) operation. The dryer will also include the necessary purge valve components
to congure the dryer to operate at any pressure from 58 psig (4 barg) to 189 psig (13 barg). For example: A 110 SCFM dryer will be supplied with a
single hole purge assembly with an 02 purge disc installed and indexed to position A. Additional purge valve components will be included to allow
the dryer to be congured to purge settings,
CK, M, G, C, B, A, S, S and P.
Appropriate purge plug selection is very important for function of the dryer. Failure to comply with this may affect your warranty.
Purge Plug Identication
Operating
pressure psig (barg) 58 (4) 73 (5) 86 (6) 102 (7) 116 (8 131 (9) 145 (10) 160 (11) 174 (12) 189 (13)
Dryer
ACC 46 M K I H G F E E E D
ACC 56 P M LK J I H G F F
ACC 75 B S P M L L K I I H
ACC 90 C A P P N LK J I H
ACC 110 I E C A P M K K J I
HYG-BLEED 1 ½ 1 1/41 1/41 ½ 1 ½ 3/43/43/43/41/2
Disc
01
02

19 Heatless Desiccant Dryers |Instruction Manual
Section 4: Mechanical Installation
21
|
Section 4: Mechanical Installation
Figure 4.13 Purge valve assembly
Purge Valve Assembly
20, the
purge valve may be assembled.
The index letters locate
Place the valve stem O-ring(s) into their corresponding recesses on the back of the valve stem.
Align the holes in the purge sealing gasket with the corresponding holes in the valve stem.
in the
valve stem.
Press the assembly together and fasten with the M4 screw.
•
•
•
•
•
•
•
•
•
1
2
3
4
5
6
7
8
Orifice
Discs
Valve
Body
(Common to all dryers)
1 Hole Valve
Stem
2 Hole Valve Stem
Valve Control Spring
M4 Screw
3 Hole Valve Stem
Valve Stem O-ring(s)
(Fit into recess in
Valve Stem(s))
Index reference letters
Purge Sealing Gasket(s)
(1, 2 or 3 hole)
Disc
I.D.
Number
(01, 02, 03, 04)
Alignment
notches
Alignment
notches
Gasket and Valve Stem are
rotated to align with index reference
letters on Valve Body
Gasket and Valve Stem are
rotated to align with index reference
letters on Valve Body
Orifice
Discs
Valve
Body
(Common to all dryers)
1 Hole Valve
Stem
2 Hole Valve Stem
Valve Control Spring
M4 Screw
3 Hole Valve Stem
Valve Stem O-ring(s)
(Fit into recess in
Valve Stem(s))
Index reference letters
Purge Sealing Gasket(s)
(1, 2 or 3 hole)
Disc
I.D.
Number
(01, 02, 03, 04)
Alignment
notches
Alignment
notches
Purge Sealing Gasket
Orifice
Discs
Orifice discs
I.D.
Number
(01, 02)
Alignment
notches
Valve Control Spring
Index reference letters
1 Hole Valve
Stem
M4 Screw
Valve Stem O-ring(s)
(Fit into recess in
Valve Stem(s))
Alignment
notches
Valve
Body
(Common to all dryers)
Figure 4.11 Purge valve assembly
Purge Valve Assembly
• Reference gure 4.11 and the Purge Plug Identication Table on Page 18.
• Once the correct orice disc (01 or 02) has been selected per the instructions on Page 18, the purge valve may be assembled.
• The index letters located on the purge valve body correspond with the selected orice sizes per the Table on Page 18.
• Place the appropriate orice disc onto the valve body, taking care to align the notches. The disc will only t in one position.
• Place the valve stem O-ring into its corresponding recess on the back of the valve stem.
• Align the hole in the purge sealing gasket with the corresponding hole in the valve stem.
• Rotate the valve stem assembly so that the correct orice letter(s) aligns with the notches corresponding to the hole in the valve stem.
• Press the assembly together and fasten with the M4 screw.
• Double check to make sure that the open orice hole corresponds with the correct orice selection as identied earlier.

20 Heatless Desiccant Dryers |Instruction Manual
Section 5: Electrical Installation
Electrical Installation
Controller power supply options
Models 45 SCFM - 110 SCFM
• The dryer is designed to operate on either AC or DC supply voltage.
• Dryers are supplied with AC power supply and attached 115VAC USA
power cord. The power supply may be removed to allow 24VDC to be
supplied directly to the controller. Reference Figure 5.1 for details on
controller power supply connections.
