Beko HSA46330 Instruction Manual

Chest Freezer
Instruction of use
HSA46330
EN

WARNING!
In order to ensure a normal operation of your refrigerating appliance, which uses a completely
environmentally friendly refrigerant the R600a (flammable only under certain conditions) you
must observe the following rules:
Do not hinder the free circulation of the air around the appliance.
Do not use mechanical devices in order to accelerate the defrosting, others than the ones
recommended by the manufacturer.
Do not destroy the refrigerating circuit.
Do not use electric appliances inside the food keeping compartment, other than those that
might have been recommended by the manufacturer.
Advice for recycling of the old appliance /1
Packing Recycling /2
Transport instructions /2
Warnings and special advice /2
Setting up /3
Electric connection /4
Switching off /4
Appliance description /4
Freezer operation /5
Advise for food conservation /5
Defrosting of the appliance /6
Cleaning of the appliance /7
Replacing the interior light bulb /7
Troubleshooting /8
EN Content

1
Figures that take place in this instruction manual are schematic and may not
correspond exactly with your product. If the subject parts are not included in the
product you have purchased, then it is valid for other models.

2
3
4
6
5

Congratulations on your choice!
The chest freezer you have purchased is in the BEKO products
range and represents a harmonious joining between the
refrigeration technique with the aesthetical outlook. It has a new
and attractive design and is built according to the European and
national standards which guarantee its operation and safety
features. At the same time, the used refrigerant, R600a, is
environment-friendly and it does not affect the ozone layer.
In order to get the best out of your freezer, we advise you to
read carefully the information in these user instructions.
Advice for recycling your old appliance
If your newly purchased appliance replaces an older appliance,
you must consider a few aspects.
The old appliances are not valueless scrap. Their disposal,
while preserving the environment, allows the recovery of
important raw materials.
Make your old appliance useless :
- disconnect the appliance from the supply;
- remove the supply cord (cut it);
- remove the eventual locks on the door to avoid the blocking of
children inside, while playing, and the endangering of their lives.
The refrigerating apliances contain insulating materials and
refrigerants which require a proper recycling.
1
EN Instruction for use
This appliance is not intended for use by person with reduced physical, sensory or mental
capabilities or lack of experience and knowledge unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.

Packing Recycling
WARNING!
Do not allow children to play with the
packing or with parts of it. There is the
risk of suffocation with parts of
corrugated cardboard and with plastic
film.
In order to get to you in good condition,
the appliance was protected with a
suitable packing. All the materials of the
packing are compatible with the
environment and recyclable. Please help
us recycle the packing while protecting the
environment !
IMPORTANT!
Before putting the appliance in operation,
read carefully and entirely these
instructions. They contain important
information concerning the setting up, use
and maintenance of the apliance.
The manufacturer is free of any
responsibility if the information in this
document are not observed. Keep the
instructions in a safe place in order to
reach them easily in case of need. They
can also be useful subsequently by another
user.
ATTENTION!
This appliance must be used only for
its intended purpose, (household use),
in suitable areas, far from rain,
moisture or other weather conditions.
Transport instructions
The appliance must be transported, as
much as possible, only in vertical position.
The packing must be in perfect condition
during transport.
If during transport the appliance was put in
horizontal position (only according to the
markings on the packing), it is advised
that, before putting it into operation, the
appliance is left to rest for 4 hours in order
to allow the settling of the refrigerating
circuit.
The failure to to observe these instructions
can cause the breakdown of the motor
compressor and the cancellation of its
warranty.
Warnings and general advice
Do not plug in the appliance if you
noticed a failure.
The repairs must be done only by
qualified personnel.
In the following situations please unplug
the appliance from the mains:
- when you defrost completely the
appliance;
- when you clean the appliance.
To unplug the appliance, pull by the
plug, not by the cable!
Ensure the minimum space between the
appliance and the wall against which it is
placed.
Do not climb on the appliance.
Do not allow the children to play or hide
inside the appliance.
Never use electric appliances inside the
freezer, for defrosting.
Do not use the appliance near heating
appliances, cookers or other sources of
heat and fire.
Do not leave the freezer door open more
than it is necessary to put in or take out the
food.
Do not leave the food in the appliance if
it is not working.
2
EN Instruction for use

Do not keep inside products containing
flammable or explosive gases.
Do not keep inside fizzy drinks (juice,
mineral water, champagne, etc.) in the
freezer: the bottle can explode! Do not
freeze drinks in plastic bottles.
Do not eat ice cubes or icecream
immediately after having taken them out of
the freezer because they may cause
„freezer burns”.
Never touch cold metal parts or frozen
food with wet hands because your hands
can quickly freeze on the very cold
surfaces.
For the protection of the appliance
during warehousing and transport, it is
provided with spacers between the door
and the cabinet (in the front and rear side).
These spacers will be removed before
putting the appliance into operation.
Excess deposit of ice on the frame and
the baskets should be removed regularly
with the plastic scraper provided. Do not
use any metal parts to remove the ice.
The presence of this ice build-up makes
impossible to close the door correctly.
If you do not use your appliance for a
few days, it is not advisable to switch it off.
If you do not use it for a longer period,
please proceed as follows :
- unplug the appliance;
- empty the freezer;
- defrost it and clean it;
- leave the door open to avoid the
formation of unpleasant smells.
If the supply cord is damaged, it must
be replaced by the manufacturer, its
service agent or similarly qualified persons
in order to avoid a hazard.
If your appliance has a lock, keep it
locked and store the key in a safe place,
out of the reach of children. If you are
discarding an appliance with lock, make
sure that, is made ineffective. This is very
important so as to avoid children being
trapped inside, which may cause their loss
of life.
Setting up
This appliance was designed to operate at
an ambient temperature between +100C
and +430C (SN-T class). If the ambient
temperature is above +430C, inside the
appliance the temperature can increase.
Set up the appliance far from any source
of heat and fire. Placing it in a warm room,
the direct exposure to sunbeams or near a
heat source (heaters, cookers, ovens), will
increase the energy consumption and
shorten the product life.
Please observe the following minimun
distances:
100 cm from the cookers working with
coal or oil;
150 cm from the electric and gas
cookers.
Ensure the free circulation of the air
around the appliance, by observing the
distances shown in Item 2.
Assemble on the condenser (in the rear
side) the supplied spacers. (Item 3).
Place the appliance in a perfectly even,
dry and well ventilated place.
Assemble the supplied accessories.
3
EN Instruction for use

4
EN Instruction for use
Switching off
The switching off must be possible by
taking the plug out of the socket or by
means of a mains two-poles switch placed
before the socket.
Operation
Before putting into operation, clean the
inside of the appliance (see chapter
„Cleaning").
After finishing this operation please
plug in the appliance, adjust the
thermostat knob to an average
position. The green and red LEDs in the
signalling block must light. Leave the
appliance work for about 2 hours
without putting food inside it.
The freezing of the fresh food is
possible after min. 20 hours of
operation.
Appliance description
(Item. 1)
1. Door handle
2. Door
3. Lamp housing
4. Baskets
5. Tray
6. Thermostat box
7. Spacer for transport
Electric connection
Your appliance is intended to operate at a
single-phase voltage of 220-240V/50 Hz.
Before plugging in the appliance, please
make sure that the parameters of the mains
in your house (voltage, currect type,
frequency) comply to the operation
parameters of the appliance.
The information concerning the supply
voltage and the absorbed power is given on
the marking label placed in the back side of
the freezer.
The electric installation must comply
with the law requirements.
The earthing of the appliance is
compulsory. The manufacturer has no
responsibility for any damage to
persons, animals or goods which may
arise from the failure to observe the
specified conditions.
The appliance is endowed with a supply
cord and a plug (Australian type, marked
10/16A) with double earthing contact for
safety. If the socket is not the same type
with the plug, please ask a specialised
electrician to change it.
Do not use extension pieces or multiple
adapters.

Freezer operation
Temperature adjustment
The temperature of the freezer is adjusted
by means of the knob assembled on the
thermostat (item. 4), position „MAX” being
the lowest temperature.
The achieved temperatures can vary
according to the conditions of use of the
appliance, such as: place of the appliance,
ambient temperature, frequency of door
opening, extent of filling with food of the
freezer. The position of the thermostat
knob will change according to these
factors. Normally, for an ambient
temperature of approx. 320C, the
thermostat will be adjusted on an average
position.
The signalling system is placed on the
front side of the freezer (Item 5).
It includes:
1. Thermostat adjustment knob –the
inside temperature is adjusted.
2. green LED –shows that the appliance
is supplied with electric energy.
3. red LED –damage –lights if the
temperature in the freezer is too high.
The LED will operate 15-45 minutes
after the putting into operation of the
freezer, then it must go off. If the LED
goes on during the operation, this
means that defects have occurred.
4. LED Orange–fast freeze function
activated –by setting the knob to
Superfreeze position the orange led
goes on, showing that the appliance
entered into the "fast freeze" mode.
The exit of this mode is done
automatically after 50 hours then the
appliance runs in economic mode, and
the orange led goes off.
The three LEDs give information about the
mode of operation of the freezer.
Advise for food conservation
The freezer is intended to keep the frozen
food for a long time, as well as to freeze
fresh food.
One of the main elements for a successful
food freezing is the packing.
The main conditions that the packing must
fulfill are the following: to be airtight, to be
inert towards the packed food, to resist to
low temperatures, to be proof to liquids,
grease, water vapours, smells, to be able to
be washed.
These conditions are fulfilled by the
following types of packings: plastic or
aluminium film, plastic and aliminium
vessels, waxed cardboard glasses or
plastic glasses.
IMPORTANT!
- For freezing the fresh food please use
the supplied baskets of the appliance.
- Do not place into the freezer a too large
quantity of food at a time. The quality of
the food is best kept if they are deeply
frozen as quickly as possible. This is why
it is advisable not to exceed the freezing
capacity of the appliance specified in the
"Product Fiche".
- The fresh food must not come into
contact with the food already frozen.
- The frozen food you have bought can be
placed into the freezer without having to
adjust the thermostat.
- If the freezing date is not mentioned on
the packing, please take into consideration
a period of max. 3 months, as a general
guide.
- The food, even partially defrosted,
cannot be frozen again, it must be
consumed immediately or cooked and
then refrozen.
- The fizzy drinks will not be kept in the
freezer.
- In case of a power failure, do not open
the door of the appliance. The frozen food
will not be affected if the failure lasts less
than 36 hours.
5
EN Instruction for use

Defrosting of the appliance
We advise you to defrost the freezer at
least twice a year or when the ice layer
has an excessive thickness.
The ice build-up is a normal
phenomenon.
The quantity and the rapidity of ice
build-up depends on the ambient
conditions and on the frequency of the
door opening.
We advise you to defrost the appliance
when the quantity of frozen food is the
least.
Before defrosting, adjust the thermostat
knob to a higher position so that the food
stores more cold.
- Unplug the appliance.
- Take out the frozen food, wrap it in
several sheets of paper and put them in
refrigerator or a cool place.
Take the separator panel and put it under
the freezer in the direction of the dripping
tube. Take out the obstructing plug. The
water which results will be collected in the
special tray (separator panel). After the
melting of the ice and the run-off of the
water please wipe with a cloth or with a
sponge, then dry well. Put the obstruction
plug back in its place. (Item. 6)
For a fast thaw please leave the door
open.
Do not use sharp metal objects to
remove the ice.
Do not use hairdryers or other electric
heating appliances for defrosting.
EN Instruction for use
6
Freezing with Superfrost
• Place the knob to super frost position.
The Superfrost lamp comes on.
• Wait 24 hours.
• Place the fresh food in the freezer. In
order to achieve fast freezing, food should
be in contact with the interior walls when it
is placed in the freezer.
• The Superfrost facility automatically
switches the fast freezing procedure off
after 50 hours.
Important
When you place the knob to Superfrost
position, the compressor might not
switch on for a few minutes. This is due
to the integrated rise-delay switch
which is designed to increase the life
span of the refrigeration unit.
You should not switch on the Superfrost
function:
- when placing frozen food in the freezer;
- when freezing up to approx. 2 kg fresh
food daily.

Replacing the interior light bulb
If the lamp burns out, disconnect the
appliance from the mains. Take out the
lamp trim. Make sure the lamp is screwed
correctly. Plug in the appliance again. If
the lamp still does not go on, replace it
with another one model E14-15W. Mount
back the lamp trim in its place.
The lamp(s) used in this appliance is not
suitable for household room illumination.
The intended purpose of this lamp is to
assist the user to place foodstuffs in the
refrigerator/freezer in a safe and
comfortable way.
The lamps used in this appliance have to
withstand extreme physical conditions
such as temperatures below -20°C.
7
EN Instruction for use
Inside cleaning
Before starting the cleaning, unplug the
appliance from the mains.
It is advisable to clean the appliance
when you defrost it.
Wash the inside with lukewarm water
where you add some neutral detergent. Do
not use soap, detergent, gasoline or
acetone which can leave a strong odour.
Wipe with a wet sponge and dry with a
soft cloth.
During this operation, avoid the excess of
water, in order to prevent its entrance into
the thermal insulation of the appliance,
which would cause unpleasant odours.
Do not forget to clean also the door gasket
especially the bellow ribs, by means of a
clean cloth.
Outside cleaning
Clean the outside of the freezer by
means of a sponge soaked in soapy warm
water, wipe with a soft cloth and dry.
The cleaning of the outside part of the
refrigerating circuit (motorcompressor,
condenser, connection tubes) will be done
with a soft brush or with the vacuum-
cleaner. During this operation, please take
care not to distort the tubes or detach the
cables.
Do not use scouring or abrasive
materials !
After having finished the cleaning,
replace the accessories at their places
and plug in the appliance.

Noises during operation
In order to keep the temperature at the
value you have adjusted, the compressor
of the appliance starts periodically.
The noises which can be heard in such
situation are normal.
They are redced as soon as the appliance
reaches the operation temperature.
The humming noise is made by the
compressor. It can become a little stronger
when the compressor starts.
The bubbling and gurgling noises coming
from the refrigerant circulating in the pipes
of the appliance, are normal operating
noises.
Warning !
Never try to repair yourself the appliance
or its electric components. Any repair
made by an unauthorised person is
dangerous for the user and can result in
the warranty cancellation.
Troubleshooting
The appliance does not work.
There is a power failure.
The plug of the supply cord is not
inserted well into the socket.
The fuse is blown.
The thermostat is in „OFF” position.
The temperatures are not low
enough(red LED on).
The food prevents the door closing.
The appliance was not placed correctly.
The appliance is placed too close to a
heat source.
The thermostat knob is not in the correct
position.
Excessive ice build-up
The door was not closed properly.
The inside lighting does not
work
The lamp is blown. Unplug the appliance
from the mains, take out the lamp and
replace it with a new one.
The following are not defects
Possible noddings and cracks coming
from the product: circulation of the
refrigerant in the system.
8
EN Instruction for use
The symbol on the product or on packaging indicates that this product may not
be treated as household waste. Instead it shall be handed over to the applicable
collection point for the recycling of electrical and electronic equipment. By ensuring this
product is disposed of correctly, you will help prevent potential negative consequences
for the environment and human health, which could otherwise be otherwise be caused
by inappropriate waste handling of this product. For more detailed information about
recycling of this product, please contact your local city office, you household waste
disposal service or the shop where you purchased the product.
