Beko RCNA365K20W User manual

RCNA365K20W
Refrigerator / Freezer
ł a / Zamrażarki kraizdohC
Frigorifer / Ngrirës

Please read this user manual first!
Dear Customer,
We hope that your product, which has been produced in modern plants and
checked under the most meticulous quality control procedures, will provide you
an effective service.
Therefore, read this entire user manual carefully before using the product and
keep it as a reference. If you handover the product to someone else, give the user
manual as well.
The user manual will help you use the product in a fast and safe way.
• Read the manual before installing and operating the product.
• Make sure you read the safety instructions.
• Keep the manual in an easily accessible place as you may need it later.
• Read the other documents given with the product.
Remember that this user manual is also applicable for several other models.
Differences between models will be identified in the manual.
Explanation of symbols
Throughout this user manual the following symbols are used:
CImportant information or useful tips.
AWarning against dangerous conditions for life and property.
BWarning against electric voltage.

EN
2
CONTENTS
1 Your refrigerator 3
2 Important Safety
Warnings 4
Intended use .....................................4
General safety ..................................4
For products with a water dispenser;.6
Child safety........................................6
Compliance with the WEEE Regulation
and Disposing of the Waste Product..6
Package information..........................7
HCA warning.....................................7
Things to be done for energy saving..7
3 Installation 8
Points to be paid attention to when the
relocation of the refrigerator...............8
Before you start the refrigerator,.........8
Disposing of the packaging ...............9
Disposing of your old refrigerator .......9
Placing and Installation ......................9
Adjusting the legs ............................10
Changing the illumination lamp .......10
4 Preparation 12
5 Using your refrigerator 13
Using interior compartments............13
Freezing fresh food..........................14
Recommendations for preservation of
frozen food ......................................14
Placing the food ..............................15
Deep-freeze information ..................15
6 Maintenance and
cleaning 16
Protection of plastic surfaces ..........16
7 Troubleshooting 17

EN
3
1Your refrigerator
1. Setting knob and interior light
2. Fan
3.
Shelves
Crisper
4. Crisper cover
5.
6. Icebank tray
7. Compartment for quickly freezing
8.
Adjustable front feet
10. Dairy compartment*
11. Shelf for jars
12. Shelf for bottles
13. Freezer fan
*OPTIONAL
Figures that take place in this instruction manual are schematic and may not
correspond exactly with your product. If the subject parts are not included in the
product you have purchased, then it is valid for other models.
9. Compartment for frozen quickly freezing

EN
4
2Important Safety Warnings
Pleasereviewthefollowinginformation.
Failure to observe this information may
cause injuries or material damage.
Otherwise, all warranty and reliability
commitments will become invalid.
The service life of your product is 10
years. During this period, original spare
parts will be available to operate the
product properly.
Intended use
This product is intended to be used
• indoors and in closed areas such as
homes;
• in closed working environments such
as stores and offices;
• in closed accommodation areas such
as farm houses, hotels, pensions.
• It should not be used outdoors.
General safety
• When you want to dispose/scrap
the product, we recommend you to
consult the authorized service in order
to learn the required information and
authorized bodies.
• Consult your authorized service for
all your questions and problems
related to the refrigerator. Do not
intervene or let someone intervene to
the refrigerator without notifying the
authorised services.
• For products with a freezer
compartment; Do not eat cone ice
cream and ice cubes immediately
after you take them out of the freezer
compartment! (This may cause
frostbite in your mouth.)
• For products with a freezer
compartment; Do not put bottled and
canned liquid beverages in the freezer
compartment. Otherwise, these may
burst.
• Do not touch frozen food by hand;
they may stick to your hand.
• Unplug your refrigerator before
cleaning or defrosting.
• Vapor and vaporized cleaning
materials should never be used in
cleaning and defrosting processes of
your refrigerator. In such cases, the
vapor may get in contact with the
electrical parts and cause short circuit
or electric shock.
• Never use the parts on your
refrigerator such as the door as a
means of support or step.
• Do not use electrical devices inside
the refrigerator.
• Do not damage the parts, where
the refrigerant is circulating, with
drilling or cutting tools. The refrigerant
that might blow out when the gas
channels of the evaporator, pipe
extensions or surface coatings are
punctured causes skin irritations and
eye injuries.
• Do not cover or block the ventilation
holes on your refrigerator with any
material.
• Electrical devices must be repaired
by only authorised persons. Repairs
performed by incompetent persons
create a risk for the user.

EN
5
• In case of any failure or during
a maintenance or repair work,
disconnect your refrigerator’s mains
supply by either turning off the
relevant fuse or unplugging your
appliance.
• Do not pull by the cable when pulling
off the plug.
• Place the beverage with higher proofs
tightly closed and vertically.
• Never store spray cans containing
flammable and explosive substances
in the refrigerator.
• Do not use mechanical devices
or other means to accelerate the
defrosting process, other than those
recommended by the manufacturer.
• This product is not intended to be
used by persons with physical,
sensory or mental disorders or
unlearned or inexperienced people
(including children) unless they are
attended by a person who will be
responsible for their safety or who will
instruct them accordingly for use of
the product
• Do not operate a damaged
refrigerator. Consult with the service
agent if you have any concerns.
• Electrical safety of your refrigerator
shall be guaranteed only if the earth
system in your house complies with
standards.
• Exposing the product to rain, snow,
sun and wind is dangerous with
respect to electrical safety.
• Contact authorized service when
there is a power cable damage to
avoid danger.
• Never plug the refrigerator into
the wall outlet during installation.
Otherwise, risk of death or serious
injury may arise.
• This refrigerator is intended for only
storing food items. It must not be
used for any other purpose.
• Label of technical specifications is
located on the left wall inside the
refrigerator.
• Never connect your refrigerator to
electricity-saving systems; they may
damage the refrigerator.
• If there is a blue light on the
refrigerator, do not look at the blue
light with optical tools.
• For manually controlled refrigerators,
wait for at least 5 minutes to start the
refrigerator after power failure.
• This operation manual should be
handed in to the new owner of the
product when it is given to others.
• Avoid causing damage on power
cable when transporting the
refrigerator. Bending cable may cause
fire. Never place heavy objects on
power cable.
• Do not touch the plug with wet hands
when plugging the product.
• Do not plug the refrigerator if the wall
outlet is loose.
• Water should not be sprayed on inner
or outer parts of the product for safety
purposes.

EN
6
•Do not spray substances containing
inflammable gases such as propane
gas near the refrigerator to avoid fire
and explosion risk.
•Never place containers filled with
water on top of the refrigerator; in the
event of spillages, this may cause
electric shock or fire.
•Do not overload the refrigerator with
food. If overloaded, thefood items
may fall downand hurt you and
damage refrigerator when you open
the door.
•Never place objects on top of the
refrigerator; otherwise, these objects
may fall downwhen you open or
close the refrigerator's door.
•As they require a precise temperature,
vaccines, heat-sensitive medicine and
scientific materialsand etc. should not
be kept in the refrigerator.
•If not to be used for a longtime,
refrigerator should be unplugged. A
possible problem in power cable may
cause fire.
•Theplug's tip should be cleaned
regularly with a dry cloth; otherwise, it
may causefire.
•Refrigerator may move ifadjustable
legs are not properly secured on the
floor. Properly securing adjustable
legs on the floor can prevent the
refrigerator to move.
•When carrying the refrigerator, do not
hold it from door handle. Otherwise, it
may be snapped.
•When you have to place your product
next toanother refrigerator or freezer,
the distance between devices should
be at least 8cm. Otherwise, adjacent
side walls may be humidified.
For products with a water
dispenser;
Pressure of water mains should be
minimum 1 bar. Pressure of water
mains should be maximum8 bars.
•Use only potable water.
Child safety
•If the door has a lock, the key should
be kept awayfrom reach of children.
•Children must besupervised to
prevent them from tampering with the
product.
Compliance with the WEEE
Regulation and Disposing of
the Waste Product
Complies with the WEEE Regulation.
This product has been
manufactured with high
quality parts and materials
which can be reused and
are suitable for recycling.
Therefore, do not dispose
the product with normal
domestic waste at the end of its service
life. Take it to a collection point for the
recycling of electrical and electronic
equipment. Please consult your local
authorities to learn the nearest collection
point. Help protect the environment
and natural resources by recycling used
products. For children's safety, cut the
power cable and break the locking
mechanism of the door, if any, so that it
will be non-functional before disposing
of the product.

EN
7
Package information
Packaging materials of the product
are manufactured from recyclable
materials in accordance with our
National Environment Regulations. Do
not dispose of the packaging materials
together with the domestic or other
wastes. Take them to the packaging
material collection points designated
by the local authorities.
Do not forget...
Any recycled substance is an
indispensable matter for nature and our
national asset wealth.
If you want to contribute to the re-
evaluation of the packaging materials,
you can consult to your environmentalist
organizations or the municipalities
where you are located.
HCA warning
If your product's cooling system
contains R600a:
This gas is flammable. Therefore, pay
attention to not damaging the cooling
system and piping during usage and
transportation. In the event of damage,
keep your product away from potential
fire sources that can cause the product
catch a fire and ventilate the room in
which the unit is placed.
Ignore this warning if your
product's cooling system contains
R134a.
Type of gas used in the product is
stated in the type label which is on the
left wall inside the refrigerator.
Never throw the product in fire for
disposal.
Things to be done for energy
saving
• Do not leave the doors of your
refrigerator open for a long time.
• Do not put hot food or drinks in your
refrigerator.
• Do not overload your refrigerator so
that the air circulation inside of it is not
prevented.
• Do not install your refrigerator
under direct sunlight or near heat
emitting appliances such as ovens,
dishwashers or radiators. Keep your
refrigerator at least 30cm away from
heat emitting sources and at least
5cm from electrical ovens.
• Pay attention to keep your food in
closed containers.
• For products with a freezer
compartment; You can store
maximum amount of food items in
the freezer when you remove the
shelf or drawer of the freezer. Energy
consumption value stated for your
refrigerator has been determined
by removing freezer shelf or drawer
and under maximum load. There
is no harm to use a shelf or drawer
according to the shapes and size of
food to be frozen.
• Thawing frozen food in fridge
compartment will both provide energy
saving and preserve the food quality.

EN
8
3Installation
BIn case the information which are
given in the user manual are not taken
into account, manufacturer will not
assume any liability for this.
Points to be paid attention
to when the relocation of the
refrigerator
1. Your refrigerator should be
unplugged.Before transportation of
your refrigerator, it should be emptied
and cleaned.
2. Before it is re-packaged, shelves,
accessories, crisper, etc. inside your
refrigerator should be fixed with
adhesive tape and secured against
impacts. Package should be bound
with a thick tape or sound ropes
and thetransportation rules on the
package should be strictly observed.
3. Original packaging and foam
materials should be kept for future
transportations or moving.
Before you start the
refrigerator,
Check the following before you start
to use your refrigerator:
1. Attach 2 plastic wedges as illustrated
below. Plastic wedges are intended
to keep the distance which will ensure
the air circulation betweenyour
refrigerator and the wall. (The picture
is drawn up asa representation and it
is not identical with your product.)
2. Clean the interior of the refrigerator as
recommended in the “Maintenance
and cleaning” section.
3. Connect the plug of the refrigerator to
the wall socket. When thefridge door
is opened, fridge internal lamp will turn
on.
4. When the compressor starts to
operate,asound will be heard. The
liquid and gases sealed within the
refrigeration system may also give rise
to noise, even if the compressor is not
running and this is quite normal.
5. Front edges of the refrigerator may
feel warm.This is normal. These areas
are designed to be warm to avoid
condensation.
6. Electrical connection
Connect your product to a grounded
socket which is being protected by a
fuse with the appropriate capacity.
Important:
The connection must be in compliance
with national regulations.
•The power plug must be easily
accessible after installation.
•Electrical safety of your refrigerator
shall be guaranteed only if the earth
system in your house complies with
standards.
•The voltage stated on the label
located at left inner side of your
product should be equal to your
network voltage.

EN
9
Placing and Installation
AIf the entrance door of the room
where the refrigerator will be installed is
not wide enough for the refrigerator to
pass through, then call the authorized
service to have them remove the doors
of your refrigerator and pass it sideways
through the door.
1. Install your refrigerator to a place that
allows ease of use.
2. Keep your refrigerator away from heat
sources, humid places and direct
sunlight.
3. There must be appropriate air
ventilation around your refrigerator in
order to achieve an efficient operation.
If the refrigerator is to be placed in a
recess in the wall, there must be at
least 5 cm distance with the ceiling
and at least 5 cm with the wall. Do not
place your product on the materials
such as rug or carpet.
4. Place your refrigerator on an even
floor surface to prevent jolts.
• Extension cables and multi plugs
must not be used for connection.
BA damaged power cable must be
replaced by a qualified electrician.
BProduct must not be operated before
it is repaired! There is the risk of
electric shock!
Disposing of the packaging
The packing materials may be
dangerous for children. Keep the
packing materials out of the reach
of children or dispose of them by
classifying them in accordance with the
waste instructions stated by your local
authorities. Do not throw away with
regular house waste, throw away on
packaging pick up spots designated by
the local authorities.
The packing of your refrigerator is
produced from recyclable materials.
Disposing of your old
refrigerator
Dispose of your old refrigerator without
giving any harm to the environment.
• You may consult your authorized
dealer or waste collection center of
your municipality about the disposal of
your refrigerator.
Before disposing of your refrigerator,
cut out the electric plug and, if there
are any locks on the door, make them
inoperable in order to protect children
against any danger.

EN
10
Adjusting the legs
If your refrigerator is unbalanced;
You can balance your refrigerator by
turning its front legs as illustrated in the
figure. The corner where the leg exists is
lowered when you turn in the direction
of black arrow and raised when you
turn in the opposite direction. Taking
help from someone to slightly lift the
refrigerator will facilitate this process.
Changing the illumination
lamp
To change the Bulb/LED used for
illumination of your refrigerator, call your
Authorized Service.
The lamp(s) used in this appliance is not
suitable for household room illumination.
The intended purpose of this lamp is to
assist the user to place foodstuffs in
the refrigerator/freezer in a safe and
comfortable way.
The lamps used in this appliance have
to withstand extreme physical conditions
such as temperatures below -20°C.

EN
11

EN
12
4Preparation
• Your refrigerator should be installed at
least 30 cm away from heat sources
such as hobs, ovens, central heater
and stoves and at least 5 cm away
from electrical ovens and should not
be located under direct sunlight.
• Please make sure that the interior of
your refrigerator is cleaned thoroughly.
• If two coolers are to be installed side
by side, there should be at least 2 cm
distance between them.
• When you operate your refrigerator
for the first time, please observe the
following instructions during the initial
six hours.
• Its door should not be opened
frequently.
• It must be operated empty without
placing any food in it.
• Do not unplug your refrigerator. If
a power failure occurs out of your
control, please see the warnings in
the “Recommended solutions for the
problems” section.
• This product has been designed to
function at ambient temperatures
up to 43 °C (90 SDgrF). Even if the
ambient temperature falls to -15
°C, frozen food in the freezer does
not thaw thanks to its Advanced
Electronic Temperature Control
System. For the first installation, the
product should NOT be placed under
low ambient temperatures. This is
because the freezer cannot go down
to standard operation temperature.
When reaching continuous operation,
the product can be moved to another
place. Thus, later you can place your
product in the garage or an unheated
room without the concern of causing
frozen food to get rotten. However,
it is likely that above mentioned low
temperatures may cause the freezing
of the food in the fridge compartment;
thus, please consume the food items
in the fridge in a controlled way as
needed. When ambient temperature
goes back to normal, you may
change button setting according to
your need.
• If the ambient temperature is below
0°C, the food in fridge compartment
will freeze. Therefore, we recommend
not using the fridge compartment
in such low ambient temperatures.
You may continue to use the freezer
compartment as usual.

EN
13
5Using your refrigerator
Using interior compartments
Body shelves: Distance
Thermostat setting button
The interior temperature of your
refrigerator changes for the following
reasons;
• Seasonal temperatures,
• Frequent opening of the door and
leaving the door open for long periods,
• Food put into the refrigerator without
cooling down to the room temperature,
• The location of the refrigerator in the
room (e.g. exposing to sunlight).
• You may adjust the varying interior
temperature due to such reasons by
using the thermostat. Numbers around
the thermostat button indicates the
cooling degrees.
• If the ambient temperature is higher
than 32°C, turn the thermostat button to
maximum position.
• If the ambient temperature is lower than
25°C, turn the thermostat button to
minimum position.
between
the shelves can be adjusted when
necessary.
Crisper: Vegetables and fruits can be
stored in this compartment for long
periods without decaying.
Bottle shelf: Bottles, jars and tins can
be placed in these shelves.

EN
14
Freezing fresh food
• It must be preferred to wrap or cover
the food before placing them in the
refrigerator.
• Hot food must cool down to the room
temperature before putting them in
the refrigerator.
• The foodstuff that you want to freeze
must be fresh and in good quality.
• Foodstuff must be divided into
portions according to the family’s daily
or meal based consumption needs.
• The foodstuff must be packaged in an
airtight manner to prevent them from
drying even if they are going to be
kept for a short time.
• Materials to be used for packaging
must be tear-proof and resistant to
cold, humidity, odor, oils and acids
and they must also be airtight.
Moreover, they must be well closed
and they must be made from easy-
to-use materials that are suitable for
deep freeze usage.
• Frozen food must be used
immediately after they are thawed and
they should never be re-frozen.
• Please observe the following
instructions to obtain the best results.
1. Do not freeze too large quantities
of food at one time. The quality of
the food is best preserved when it
is frozen right through to the core as
quickly as possible.
2. Placing warm food into the freezer
compartment causes the cooling
system to operate continuously until
the food is frozen solid.
3. Take special care not to mix already
frozen food and fresh food.
Recommendations for
preservation of frozen food
• Prepacked commercially frozen food
should be stored in accordance
with the frozen food manufacturer's
instructions for a ( 4 star)
frozen food storage compartment.
• To ensure that the high quality
achieved by the frozen food
manufacturer and the food retailer is
maintained, the following should be
remembered:
1. Put packages in the freezer as quickly
as possible after purchase.
2. Ensure that contents are labeled and
dated.
3. Do not exceed "Use By", "Best
Before" dates on the packaging.
Defrosting
The freezer compartment defrosts
automatically.

EN
15
Placing the food
Freezer compartment
shelves
Various frozen food such
as meat, fish, ice cream,
vegetables and etc.
Egg tray Egg
Fridge compartment
shelves
Food in pans, covered
plates and closed containers
Fridge compartment
door shelves
Small and packaged food
or drinks (such as milk, fruit
juice and beer)
Crisper Vegetables and fruits
Freshzone
compartment
Delicatessen products
(cheese, butter, salami
and etc.)
Deep-freeze information
Food must be frozen as rapidly
as possible when they are put in a
refrigerator in order to keep them in
good quality.
The TSE norm requires (according to
certain measurement conditions) the
refrigerator to freeze at least 4.5 kg of
foodstuff at 32°C ambient temperature
to -18°C or lower within 24 hours for
every 100-liters of freezer volume.
It is possible to keep the food for
a long time only at -18°C or lower
temperatures.
You can keep the freshness of food
for many months (at -18°C or lower
temperatures in the deep freeze).
WARNING! A
• Foodstuff must be divided into
portions according to the family’s daily
or meal based consumption needs.
• Foodstuff must be packaged in an
airtight manner to prevent them from
drying even if they are going to be
kept for a short time.
• Materials necessary for packaging:
• Cold resistant adhesive tape
• Self adhesive label
• Rubber rings
• Pen
Materials to be used for packaging
the foodstuff must be tear-proof and
resistant to cold, humidity, odor, oils
and acids.
Foodstuff to be frozen should not be
allowed to come in contact with the
previously frozen items to prevent their
partial thawing.
Frozen food must be used immediately
after they are thawed and they should
never be re-frozen.

EN
16
6Maintenance and cleaning
ANever use gasoline, benzene or similar
substances for cleaning purposes.
BWe recommend that you unplug the
appliance before cleaning.
BNever use any sharp abrasive
instrument, soap, household cleaner,
detergent and wax polish for cleaning.
CUse lukewarm water to clean the
cabinet of your refrigerator and wipe it
dry.
CUse a damp cloth wrung out in
a solution of one teaspoon of
bicarbonate of soda to one pint of
water to clean the interior and wipe it
dry.
BMake sure that no water enters the
lamp housing and other electrical
items.
BIf your refrigerator is not going to be
used for a long periodof time, unplug
the power cable, remove all food,
cleanit and leave the door ajar.
CCheck door seals regularly to ensure
they are cleanand free from food
particles.
ATo remove door racks, remove all the
contents and then simply push the
door rack upwards from thebase.
ANever use cleaning agents or water
that contain chlorineto clean the
outer surfaces and chromium coated
parts of the product. Chlorine causes
corrosion on such metal surfaces.
Protection of plastic
surfaces
CDo not put the liquid oils or oil-cooked
meals in your refrigerator in unsealed
containers as they damage the plastic
surfaces of your refrigerator. In case of
spilling or smearing oil on theplastic
surfaces, clean and rinsethe relevant
part of the surface at once with warm
water.

EN
17
7Troubleshooting
Please review this list before calling the service. It will save your time and
money. This list includes frequent complaints that are not arising from defective
workmanship or material usage. Some of the features described here may not
exist in your product.
The refrigerator does not operate.
•Theplugis not inserted into the socket correctly. >>>Insert the plug intothe
socket securely.
•Thefuseof thesocket which your refrigerator is connected to or the main fuse
have blown out. >>>Check thefuse.
Condensation on the side wall of the fridge compartment (MULTIZONE, COOL
CONTROL and FLEXI ZONE).
•Ambient is very cold. >>>Do not install the refrigerator in places where the
temperature falls below 10 °C.
•Door has beenopened frequently. >>>Do not open and close thedoor of
refrigerator frequently.
•Ambient is very humid. >>>Do not install your refrigerator into highlyhumid
places.
•Food containing liquid is stored in open containers.>>>Do not store food with
liquid content in open containers.
•Door of the refrigerator is left ajar. >>>Close thedoor of the refrigerator.
•Thermostat is set to averycold level. >>>Set the thermostat to a suitable level.
•Compressor is not running
•Protective thermic of the compressor will blow out duringsudden power
failures or plug-out plug-ins as the refrigerant pressure in the cooling system
of the refrigerator has not been balancedyet. The refrigerator will start running
approximately after 6 minutes. Please call the service if the refrigerator does not
startup at the end of this period.
•Thefridge isin defrost cycle. >>>This is normal for a full-automatically defrosting
refrigerator. Defrosting cycle occurs periodically.
•The refrigerator is not plugged intothe socket. >>>Makesure that the plug is fit
intothe socket.
•Temperature settings are not made correctly. >>>Select thesuitable temperature
value.
•There is a power outage. >>>Refrigerator returns to normal operation when the
power restores.
The operation noise increases when the refrigerator is running.
•The operating performance of the refrigerator may change due to the changes in
the ambient temperature. It is normal and not a fault.

EN
18
The refrigerator is running frequently or for a long time.
•New product may be wider than the previous one. Larger refrigerators operate for
a longer period of time.
•The room temperature may behigh.>>>It is normal that the product operates for
longer periods in hot ambient.
•The refrigerator might be plugged in recently ormight be loaded with food.
>>>When the refrigerator is plugged in or loaded with food recently, it will take
longer for it to attain theset temperature. This is normal.
•Large amounts of hot food might be put in the refrigerator recently. >>>Donot
put hot food intothe refrigerator.
•Doors might be opened frequently or left ajar for a longtime. >>>The warm
air that has entered into the refrigerator causes the refrigerator torun for longer
periods.Do not open thedoors frequently.
•Freezer or fridge compartment door might be left ajar. >>>Check if thedoors are
closed completely.
•The refrigerator is adjusted to a very low temperature. >>>Adjust the refrigerator
temperature to a warmer degree and wait untilthe temperature is achieved.
•Door seal of the fridge or freezer may be soiled, worn out, broken or not
properly seated. >>>Clean or replace the seal. Damaged/broken seal causes
the refrigerator to run for a longer period of time in order to maintain the current
temperature.
Freezer temperature is very low while the fridge temperature is sufficient.
•The freezer temperature is adjusted to a very low value.>>>Adjust the freezer
temperature to a warmer degree and check.
Fridge temperature is very low while the freezer temperature is sufficient.
•The fridge temperature is adjusted to a very low value. >>>Adjust thefridge
temperature to a warmer degree and check.
Food kept in the fridge compartment drawers is frozen.
•The fridge temperature is adjusted to a very highvalue. >>>Adjust the fridge
temperature to a lower value and check.
