Beko CN 136220 D User manual

CN 136220 D
CN 136220 DS
CN 132100 DS
Refrigerator
Хладилник
Hladnjak
Réfrigérateur / Congelateur

Please read this manual first!
Dear Customer,
We hope that your product, which has been produced in modern plants and
checked under the most meticulous quality control procedures, will provide you
an effective service.
For this, we recommend you to carefully read the entire manual of your product
before using it and keep it at hand for future references.
This manual
• Will help you use your appliance in a fast and safe way.
• Read the manual before installing and operating your product.
• Follow the instructions, especially those for safety.
• Keep the manual in an easily accessible place as you may need it later.
• Besides, read also the other documents provided with your product.
Please note that this manual may be valid for other models as well.
Symbols and their descriptions
This instruction manual contains the following symbols:
CImportant information or useful usage tips.
AWarning against dangerous conditions for life and property.
BWarning against electric voltage.
This product is supplied with the selective sorting symbol for waste electrical
and electronic equipment (WEEE).
This means that this product must be handled pursuant to European Directive
2002/96/EC in order to be recycled or dismantled to minimise its impact on
the environment. For further information, please contact your local or regional
authorities.
Electronic products not included in the selective sorting process are potentially
dangerous for the environment and human health due to the presence of
hazardous substances.
Recycling
www.beko.com
This product was manufactured using the latest technology in environmentally friendly conditions.
CN 136220 D
CN 136220 DS
CN 132100 DS

EN
2
CONTENTS
1 Your refrigerator 3
2 Important Safety Warnings4
Intended use ..................................... 4
For products with a water dispenser;. 6
Child safety........................................ 6
HCA Warning .................................... 6
Things to be done for energy saving .. 7
3Installation 8
Points to be considered when re-
transporting your refrigerator ............. 8
Before operating your refrigerator ...... 8
Electric connection ............................ 8
Disposing of the packaging ............... 9
Disposing of your old refrigerator .......9
Placing and Installation ...................... 9
Changing the illumination lamp ....... 10
Adjusting the feet............................. 10
4 Preparation 11
5 Using your refrigerator 12
Indicator Panel................................. 12
Door Open Warning......................... 15
Dual cooling system: ....................... 15
Freezing fresh food .......................... 15
Recommendations for preservation of
frozen food ...................................... 16
Placing the food .............................. 16
Deep-freeze information .................. 17
Odour filter ...................................... 18
Hygiene - Ion .................................. 18
Zero temperature compartment.......18
Changing the door opening direction18
Water Dispenser .............................. 19
*optional .......................................... 19
6 Maintenance and
cleaning 22
Protection of plastic surfaces .......... 22
7 Recommended solutions
for the problems 23

EN
3
1Your refrigerator
11
3
9
9
8
*4
6
10
*7
*5
16
17
2
9
1
*12
14
*13
15
1. Interior light
2. Fan
3. Adjustable body shelves
4. Wine rack
5. Crisper
6. Crisper cover
7. Chill Compartment
8. Icebank tray
9. Deep-freeze compartment
10. Adjustable front feet
11. Control panel and temperature
control
12. Dairy compartment
13. Water dispenser
14. Egg holders
15. Fridge compartment door shelves
16. Fridge compartment
17. Freezer compartment
*OPTIONAL
Figures that take place in this instruction manual are schematic and may not
correspond exactly with your product. If the subject parts are not included in the
product you have purchased, then it is valid for other models.

EN
4
2Important Safety Warnings
Please review the following
information. Failure to observe this
information may cause injuries or
material damage. Otherwise, all
warranty and reliability commitments
will become invalid.
The usage life of the unit you
purchased is 10 years. This is the
period for keeping the spare parts
required for the unit to operate as
described.
Intended use
This product is intended to be used
– indoors and in closed areas such as
homes;
– in closed working environments such
as stores and offices;
– in closed accommodation areas such
as farm houses, hotels, pensions.
• This product should not be used
outdoors.
General safety
• When you want to dispose/scrap
the product, we recommend you
to consult the authorized service in
order to learn the required information
and authorized bodies.
• Consult your authorized service for
all your questions and problems
related to the refrigerator. Do not
intervene or let someone intervene to
the refrigerator without notifying the
authorised services.
• For products with a freezer
compartment; Do not eat cone ice
cream and ice cubes immediately
after you take them out of the freezer
compartment! (This may cause
frostbite in your mouth.)
• For products with a freezer
compartment; Do not put bottled and
canned liquid beverages in the freezer
compartment. Otherwise, these may
burst.
• Do not touch frozen food by hand;
they may stick to your hand.
• Unplug your refrigerator before
cleaning or defrosting.
• Vapor and vaporized cleaning
materials should never be used in
cleaning and defrosting processes of
your refrigerator. In such cases, the
vapor may get in contact with the
electrical parts and cause short circuit
or electric shock.
• Never use the parts on your
refrigerator such as the door as a
means of support or step.
• Do not use electrical devices inside
the refrigerator.
• Do not damage the parts, where
the refrigerant is circulating, with
drilling or cutting tools. The refrigerant
that might blow out when the gas
channels of the evaporator, pipe
extensions or surface coatings are
punctured causes skin irritations and
eye injuries.
• Do not cover or block the ventilation
holes on your refrigerator with any
material.
• Electrical devices must be repaired
by only authorised persons. Repairs
performed by incompetent persons
create a risk for the user.
• In case of any failure or during
a maintenance or repair work,
disconnect your refrigerator’s mains
supply by either turning off the
relevant fuse or unplugging your
appliance.

EN
5
• Do not pull by the cable when pulling
off the plug.
• Place the beverage with higher proofs
tightly closed and vertically.
• Never store spray cans containing
flammable and explosive substances
in the refrigerator.
• Do not use mechanical devices
or other means to accelerate the
defrosting process, other than those
recommended by the manufacturer.
• This product is not intended to be
used by persons with physical,
sensory or mental disorders or
unlearned or inexperienced people
(including children) unless they are
attended by a person who will be
responsible for their safety or who will
instruct them accordingly for use of
the product
• Do not operate a damaged
refrigerator. Consult with the service
agent if you have any concerns.
• Electrical safety of your refrigerator
shall be guaranteed only if the earth
system in your house complies with
standards.
• Exposing the product to rain, snow,
sun and wind is dangerous with
respect to electrical safety.
• Contact authorized service when
there is a power cable damage to
avoid danger.
• Never plug the refrigerator into
the wall outlet during installation.
Otherwise, risk of death or serious
injury may arise.
• This refrigerator is intended for only
storing food items. It must not be
used for any other purpose.
• Label of technical specifications is
located on the left wall inside the
refrigerator.
• Never connect your refrigerator to
electricity-saving systems; they may
damage the refrigerator.
• If there is a blue light on the
refrigerator, do not look at the blue
light with optical tools.
• For manually controlled refrigerators,
wait for at least 5 minutes to start the
refrigerator after power failure.
• This operation manual should be
handed in to the new owner of the
product when it is given to others.
• Avoid causing damage on power
cable when transporting the
refrigerator. Bending cable may cause
fire. Never place heavy objects on
power cable. Do not touch the plug
with wet hands when plugging the
product.
• Do not plug the refrigerator if the wall
outlet is loose.
• Water should not be sprayed directly
on inner or outer parts of the product
for safety purposes.
• Do not spray substances containing
inflammable gases such as propane
gas near the refrigerator to avoid fire
and explosion risk.
• Never place containers filled with
water on top of the refrigerator,
otherwise this may cause electric
shock or fire.
• Do not overload your refrigerator
with excessive amounts of food. If
overloaded, the food items may fall

EN
6
down and hurt you and damage
refrigerator when you open the door.
Never place objects on top of the
refrigerator; otherwise, these objects
may fall down when you open or
close the refrigerator's door.
• As they require a precise
temperature, vaccines, heat-sensitive
medicine and scientific materials
and etc. should not be kept in the
refrigerator.
• If not to be used for a long time,
refrigerator should be unplugged. A
possible problem in power cable may
cause fire.
• The plug's tip should be regularly
cleaned; otherwise, it may cause fire.
• The plug’s tip should be cleaned
regularly with a dry cloth; otherwise, it
may cause fire.
• Refrigerator may move if adjustable
legs are not properly secured on the
floor. Properly securing adjustable
legs on the floor can prevent the
refrigerator to move.
• When carrying the refrigerator, do not
hold it from door handle. Otherwise, it
may be snapped.
• When you have to place your product
next to another refrigerator or freezer,
the distance between devices should
be at least 8cm. Otherwise, adjacent
side walls may be humidified.
For products with a water
dispenser;
Pressure of water mains should be
minimum 1 bar. Pressure of water
mains should be maximum 8 bars.
• Use only potable water.
Child safety
• If the door has a lock, the key should
be kept away from reach of children.
• Children must be supervised to
prevent them from tampering with the
product.
HCA Warning
If your product's cooling system
contains R600a:
This gas is flammable. Therefore, pay
attention to not damaging the cooling
system and piping during usage and
transportation. In the event of damage,
keep your product away from potential
fire sources that can cause the
product catch a fire and ventilate the
room in which the unit is placed.
Ignore this warning if your
product's cooling system contains
R134a.
Type of gas used in the product is
stated in the type plate which is on the
left wall inside the refrigerator.
Never throw the product in fire for
disposal.

EN
7
Things to be done for energy
saving
• Do not leave the doors of your
refrigerator open for a long time.
• Do not put hot food or drinks in your
refrigerator.
• Do not overload your refrigerator so
that the air circulation inside of it is
not prevented.
• Do not install your refrigerator
under direct sunlight or near heat
emitting appliances such as ovens,
dishwashers or radiators.
• Pay attention to keep your food in
closed containers.
• For products with a freezer
compartment; You can store
maximum amount of food items in
the freezer when you remove the
shelf or drawer of the freezer. Energy
consumption value stated for your
refrigerator has been determined
by removing freezer shelf or drawer
and under maximum load. There
is no harm to use a shelf or drawer
according to the shapes and size of
food to be frozen.
• Thawing frozen food in fridge
compartment will both provide
energy saving and preserve the food
quality.

EN
8
3 Installation
BPlease remember that the
manufacturer shall not be held liable if
the information given in the instruction
manual is not observed.
Points to be considered
when re-transporting your
refrigerator
1.Your refrigerator must be emptied and
cleaned prior to any transportation.
2.Shelves, accessories, crisper and etc.
in your refrigerator must be fastened
securely by adhesive tape against any
jolt before repackaging.
3.Packaging must be tied with thick
tapes and strong ropes and the
rules of transportation printed on the
package must be followed.
Please do not forget…
Every recycled material is an
indispensable source for the nature
and for our national resources.
If you wish to contribute to recycling
the packaging materials, you can
get further information from the
environmental bodies or local
authorities.
Before operating your
refrigerator
Before starting to use your refrigerator
check the following:
1.Is the interior of the refrigerator dry and
can the air circulate freely in the rear
of it?
2.Please install the 2 plastic wedges
as illustrated in the figure. Plastic
wedges will provide the required
distance between your refrigerator
and the wall in order to allow the air
circulation. (The illustrated figure is
only an example and does not match
exactly with your product.)
3.Clean the interior of the refrigerator as
recommended in the “Maintenance
and cleaning” section.
4.You will hear a noise as the
compressor starts up. The liquid and
gases sealed within the refrigeration
system may also give rise to noise,
even if the compressor is not running
and this is quite normal.
5.Front edges of the refrigerator may feel
warm. This is normal. These areas
are designed to be warm to avoid
condensation
Electric connection
Connect your product to a grounded
socket which is being protected by a
fuse with the appropriate capacity.
Important:
• The connection must be in compliance
with national regulations.
• The power cable plug must be easily
accessible after installation.
• The specified voltage must be equal to
your mains voltage.
• Extension cables and multiway plugs
must not be used for connection.
BA damaged power cable must be
replaced by a qualified electrician.
BProduct must not be operated before
it is repaired! There is danger of
electric shock!

EN
9
in order to achieve an efficient
operation. If the refrigerator is to be
placed in a recess in the wall, there
must be at least 5 cm distance with
the ceiling and at least 5 cm with
the wall. If the floor is covered with
a carpet, your product must be
elevated 2.5 cm from the floor.
4. Place your refrigerator on an even floor
surface to prevent jolts.
Disposing of the packaging
The packing materials may be
dangerous for children. Keep the
packing materials out of the reach
of children or dispose of them by
classifying them in accordance
with the waste instructions. Do not
dispose of them along with the normal
household waste.
The packing of your refrigerator is
produced from recyclable materials.
Disposing of your old
refrigerator
Dispose of your old refrigerator without
giving any harm to the environment.
•You may consult your authorised dealer
or waste collection center of your
municipality about the disposal of
your refrigerator.
Before disposing of your refrigerator, cut
out the electric plug and, if there are
any locks on the door, make them
inoperable in order to protect children
against any danger.
Placing and Installation
AIf the entrance door of the room
where the refrigerator will be
installed is not wide enough for the
refrigerator to pass through, then call
the authorised service to have them
remove the doors of your refrigerator
and pass it sideways through the
door.
1. Install your refrigerator to a place that
allows ease of use.
2. Keep your refrigerator away from heat
sources, humid places and direct
sunlight.
3. There must be appropriate air
ventilation around your refrigerator

EN
10
Adjusting the feet
If your refrigerator is unbalanced;
You can balance your refrigerator by
turning the front legs as shown in the
illustration below. The corner where
the leg exists is lowered when you turn
it in the direction of black arrow and
raised when you turn in the opposite
direction. Taking help from someone to
slightly lift the refrigerator will facilitate
this process.
Changing the illumination
lamp
To change the lamp used for
illumination of your refrigerator, please
call your Authorized Service.

EN
11
4Preparation
CYour refrigerator should be installed at
least 30 cm away from heat sources
such as hobs, ovens, central heater
and stoves and at least 5 cm away
from electrical ovens and should not
be located under direct sunlight.
CThe ambient temperature of
the room where you install your
refrigerator should at least be 10°C.
Operating your refrigerator under
cooler conditions than this is not
recommended with regard to its
efficiency.
CPlease make sure that the interior
of your refrigerator is cleaned
thoroughly.
CIf two refrigerators are to be installed
side by side, there should be at least
2 cm distance between them.
CWhen you operate your refrigerator
for the first time, please observe the
following instructions during the initial
six hours.
- The door should not be opened
frequently.
- It must be operated empty without
any food in it.
- Do not unplug your refrigerator. If
a power failure occurs out of your
control, please see the warnings in
the “Recommended solutions for
the problems” section.
COriginal packaging and foam
materials should be kept for future
transportations or moving.

EN
12
5Using your refrigerator
Indicator Panel
1- Quick Freeze Function
Quick Freeze indicator turns on when
the Quick Freeze function is on. To
cancel this function press Quick Freeze
button again. Quick Freeze indicator
will turn off and return to its normal
settings. If you do not cancel it, Quick
Freeze will cancel itself automatically
after 4 hours or when the freezer
compartment reaches to the required
temperature.
If you want to freeze large amounts
of fresh food, press the Quick Freeze
button before putting the food into
the freezer compartment. If you press
the Quick Freeze button repeatedly
with short intervals, the electronic
circuit protection will be activated
and the compressor will not start up
immediately.
10
87
2
4
5
15
13
14
12
6
16
3
9
1
11

EN
13
This function is not recalled when
power restores after a power failure.
2- Quick Freeze Indicator
This icon flashes in an animated style
when the Quick Freeze function is
active.
3- Freezer Set Function
This function allows you to make the
freezer compartment temperature
setting. Press this button to set
the temperature of the freezer
compartment to -18, -20, -22 and -24
respectively.
4- Freezer Compartment
Temperature Setting Indicator
Indicates the temperature set for the
Freezer Compartment.
5- Freezer Compartment
Temperature Indicator
-24, -22, -20, -18 indicators light up
continuously.
6- Fridge Set Function
This function allows you to
make the fridge compartment
temperature setting. Press this
button to set the temperature of the
fridge compartment to 8, 6, 4, 2
respectively.
7- Fridge Compartment
Temperature Setting Indicator
Indicates the temperature set for the
Fridge Compartment.
8-Fridge Compartment
Temperature Indicator
8, 6, 4 and 2 indicators light up
continuously.
9- Quick Fridge Function
When you press Quick Fridge button,
the temperature of the compartment
will be colder than the adjusted values.
This function can be used for food
placed in the fridge compartment and
required to be cooled down rapidly.
If you want to cool large amounts of
fresh food, it is recommended to active
this feature before putting the food
into the fridge. Quick Fridge indicator
will remain lit when the Quick Fridge
function is enabled. To cancel this
function press Quick Fridge button
again. Quick Fridge indicator will turn
off and return to its normal settings.
If you do not cancel it, Quick Fridge
will cancel itself automatically after 2
hours or when the fridge compartment
reaches to the required temperature.
This function is not recalled when
power restores after a power failure.
10- Quick Fridge Indicator
This icon flashes in an animated style
when the Quick Fridge function is
active.
11- Eco-Fuzzy (Special Economic
Usage) Function
Press the Quick Freeze button for 3
seconds to activate the Eco Fuzzy
Function. Refrigerator will start
operating in the most economic mode

EN
14
at least 6 hours later and the economic
usage indicator will turn on when the
function is active. Press the Quick
Freeze button for 3 seconds again to
deactivate the Eco Fuzzy Function.
12- High Temperature/ Error
Warning Indicator
This light comes on during high
temperature failures and error
warnings.
13. Economic Usage Indicator
Economic Usage Indicator turns on
when the Freezer Compartment is set
to -18°C. Economic Usage Indicator
turns off when the Quick Fridge or
Quick Freeze function is selected.
14- Ionizer Indicator Light
Indicator light lights up continuously.
This light indicates that your
refrigerator is protected against the
bacteria.
15-Energy Saving Mode
When you press this button, Energy
saving icon will light up and Energy
Saving Function will be activated. If
energy saving function is active, all
icons on the display other than energy
saving icon will turn off. When the
Energy Saving Function is active, if
any button is pressed or the door is
opened, Energy Saving Function will
be exited and the icons on display will
return to normal.If you press this buton
again, Energy Saving icon will turn off
and Energy Saving Function will not be
active.
16-Key Lock Mode
Press Quick Freeze and FRZ Set
buttons concurrently for 3 seconds.
Key lock icon will light up and key lock
mode will be activated. Buttons will
not function if the Key Lock mode is
active. Press Quick Freeze and FRZ
Set buttons concurrently for 3 seconds
again. Key lock icon will turn off and
the key lock mode will be exited.

EN
15
Door Open Warning
A audio warning signal will be given
when the fridge compartment door of
your product is left open for at least
1 minute. This audio signal will mute
when any button on the indicator is
pressed or when the door is closed.
Dual cooling system:
Your refrigerator is equipped with
two separate cooling systems to
cool the fresh food compartment and
freezer compartment. Thus, air in the
fresh food compartment and freezer
compartment do not get mixed.
Thanks to these two separate cooling
systems, cooling speed is much higher
then other refrigerators. Odors in the
compartments do not get mixed. Also
additional power saving is provided
since the defrosting is performed
individually.
Freezer Compartment
Adjustment
Fridge
Compartment
Adjustment
Explanations
-18°C 4°C This is the normal recommended setting.
-20,-22 or -24°C 4°C These settings are recommended when the ambient
temperature exceeds 30°C.
Quick Freeze
4°C
Use when you wish to freeze your food in a short time.
Your refrigerator will return to its previous mode when
the process is over.
-18°C or colder 2°C
If you think that your fridge compartment is not cold
enough because of the hot conditions or frequent
opening and closing of the door.
-18°C or colder Quick Fridge
You can use it when your fridge compartment is
overloaded or if you wish to cool down your food
rapidly. It is recommended that you activate quick
fridge function 4-8 hours before placing the food.
Freezing fresh food
• It must be preferred to wrap or cover
the food before placing them in the
refrigerator.
• Hot food must cool down to the
room temperature before putting
them in the refrigerator.
• The foodstuff that you want to freeze
must be fresh and in good quality.
• Foodstuff must be divided into
portions according to the family’s
daily or meal based consumption
needs.
• The foodstuff must be packaged in
an airtight manner to prevent them
from drying even if they are going to
be kept for a short time.
• Materials to be used for packaging
must be tear-proof and resistant to
cold, humidity, odor, oils and acids
and they must also be airtight.
Moreover, they must be well closed
and they must be made from easy-

EN
16
to-use materials that are suitable for
deep freeze usage.
• Food to be frozen must be put in the
freezer compartment. (They should
not be allowed to come in contact
with the previously frozen items to
prevent their partial thawing. Freezing
capacity of our product is given in
the technical specifications of your
refrigerator.)
• Periods given in the information about
deep freeze must be obeyed for
storage times.
• Frozen food must be used
immediately after they are thawed
and they should never be re-frozen.
• Please observe the following
instructions to obtain the best results.
1. Do not freeze too large quantities
of food at one time. The quality of
the food is best preserved when it
is frozen right through to the core as
quickly as possible.
2. Placing warm food into the freezer
compartment causes the cooling
system to operate continuously until
the food is frozen solid.
3. Take special care not to mix already
frozen food and fresh food.
Recommendations for
preservation of frozen food
• Prepacked commercially frozen
food should be stored in accordance
with the frozen food manufacturer’s
instructions for a ( 4 star)
frozen food storage compartment.
• To ensure that the high quality
achieved by the frozen food
manufacturer and the food retailer is
maintained, the following should be
remembered:
1. Put packages in the freezer as quickly
as possible after purchase.
2. Ensure that contents are labeled and
dated.
3. Do not exceed “Use By”, “Best
Before” dates on the packaging.
If there is a power failure do not open
the freezer door. Even if the power
failure lasts up to the “Temperature
Increasing Time” indicated in the
“Technical specifications of your
refrigerator” section, frozen food
will not be affected. In case the
failure lasts longer, the food must be
checked and when necessary, must
be consumed immediately or must
be frozen after cooked.
Defrosting
The freezer compartment defrosts
automatically.
Placing the food
Freezer
compartment
shelves
Various frozen food
such as meat, fish,
ice cream, vegetables
and etc.
Egg holder Egg
Fridge
compartment
shelves
Food in pans, covered
plates and closed
containers
Fridge
compartment door
shelves
Small and packaged
food or drinks (such
as milk, fruit juice and
beer)
Crisper Vegetables and fruits
Freshzone
compartment
Delicatessen products
(cheese, butter, salami
and etc.)

EN
17
Deep-freeze information
Food must be frozen as rapidly as
possible when they are put in a
refrigerator in order to keep them in
good quality.
The TSE norm requires (according to
certain measurement conditions) the
refrigerator to freeze at least 4.5 kg of
foodstuff at 32°C ambient temperature
to -18°C or lower within 24 hours for
every 100-liters of freezer volume.
It is possible to keep the food for
a long time only at -18°C or lower
temperatures.
You can keep the freshness of food
for many months (at -18°C or lower
temperatures in the deep freeze).
WARNING! A
• Foodstuff must be divided into
portions according to the family’s daily
or meal based consumption needs.
• Foodstuff must be packaged in an
airtight manner to prevent them from
drying even if they are going to be kept
for a short time.
Materials necessary for packaging:
• Cold resistant adhesive tape
• Self adhesive label
• Rubber rings
• Pen
Materials to be used for packaging
the foodstuff must be tear-proof and
resistant to cold, humidity, odor, oils
and acids.
Foodstuff to be frozen should not be
allowed to come in contact with the
previously frozen items to prevent their
partial thawing.
Always follow the values in the tables
for storage periods.
Frozen food must be used immediately
after they are thawed and they should
never be re-frozen.

EN
18
Odour filter
Odour filter in the air duct of the fridge
compartment prevents the build-up of
unpleasant odours in the refrigerator.
Zero temperature
compartment
This compartment has been designed
to store frozen food which would be
thawed slowly (meat, fish, chicken,etc.)
as required.Zero temperature
compartment is the coldest place
of your refrigerator in which dairy
products (cheese, butter), meat,
fish or chicken may be kept at ideal
storage conditions.Vegetables and/
or fruits must not be placed in this
compartment.
Hygiene - Ion
Hygiene+: The photocatalyst filter in
the air channel of refrigerator helps
to clean the air inside. Also this filter
reduces bad smells.
Ion+: Ionizer, that is in the air channel
of refrigerator, ionizers the air. With the
help of this system airborne bacteria
and bad smells originated from these
bacteria will be reduced.
Changing the door opening
direction
Door opening direction of your
refrigerator can be changed according
to the place you are using it. If this is
necessary, please call your nearest
Authorized Service.

EN
20
damaged if these kinds of liquids are
used. Warranty does not cover such
usages. Some chemical substances
and additives contained in these
kinds of drinks/liquids may damage
the water tank.
• Use clean and pure drinking water only.
• Capacity of the water tank is 2.2 liters
(3.8 pints); do not overfill.
• Push the arm of the water dispenser
with a rigid glass. If you are using
disposable plastic glasses, push the
arm with your fingers from behind the
glass.
1
1
2
Cleaning the water tank
Release the tank cover from the water
tank by opening latches at both sides.
Remove the water tank and clean with
warm and clean water. Place the water
tank to its seating, install the tank
cover and close the latches.
3
Make sure that the parts removed
(if any) during cleaning are properly
attached to their original places.
Otherwise, water leakage may occur.
Important:
Components of the water tank and
