Beko CN151720 User manual

CN151720
CN151720DX
Refrigerator
Kühlschrank/Gefrierschrank
Congélateur/Réfrigérateur
Frižider
Hladnjak
Ψυγείο
Холодильники
Холодильник
Køl/Frys
Kyl/Frys
Kjøl/Frys
Jääkaappi/Pakastin

EN
1
Please read this manual first!
Dear Customer,
We hope that your product, which has been produced in modern plants and checked
under the most meticulous quality control procedures, will provide you an effective service.
For this, we recommend you to carefully read the entire manual of your product before
using it and keep it at hand for future references.
This manual
• Will help you use your appliance in a fast and safe way.
• Read the manual before installing and operating your product.
• Follow the instructions, especially those for safety.
• Keep the manual in an easily accessible place as you may need it later.
• Besides, read also the other documents provided with your product.
Please note that this manual may be valid for other models as well.
Symbols and their descriptions
This instruction manual contains the following symbols:
CImportant information or useful tips.
AWarning against dangerous conditions for life and property.
BWarning against electric voltage.

EN
2
CONTENTS
1 Refrigerator 3
2 Important Safety
Warnings 4
Intended use .....................................4
General safety ..................................4
For products with a water dispenser;.6
Child safety........................................6
Compliance with the AEEE Regulation
and Disposing of the Waste Product..6
Package information..........................6
HCA warning.....................................7
Things to be done for energy saving..7
Recommendations for the fresh food
compartment.....................................7
3 Installation 8
Points to be paid attention to when the
relocation of the cooler/freezer...........8
Before you start the cooler/freezer, ....8
Electrical connection..........................8
Disposing of the packaging ...............9
Disposing of your old cooler/freezer...9
Placing and Installation ......................9
Adjusting the legs ..............................9
Changing the illumination lamp .........9
4 Preparation 10
5 Using your refrigerator 11
Indicator Panel.................................11
Freezing fresh food..........................16
Door Open Warning.........................16
Recommendations for preservation of
frozen food ......................................17
Placing the food ..............................17
Water Dispenser..............................18
Dual cooling system: .......................20
Freezing fresh food..........................20
Placing the food ..............................20
Deep-freeze information ..................20
Recommendations for preservation of
frozen food ......................................21
Defrosting........................................21
Egg holder.......................................22
Blue light .........................................22
Deep-freeze information ..................23
Multi Zone Storage Compartment ..23
Telescopic Drawer ..........................24
Description and cleaning of odor
filter: ................................................24
6 Maintenance and
cleaning 25
Protection of plastic surfaces ..........25
7 Troubleshooting 26

EN
3
1Refrigerator
1. Egg holder
2. Fridge compartment shelf
3. Sliding and Rotary storage containers
4. Bottle shelf
5. Multizone Compartment's drawer
6. Freezer Compartment's drawer
7. Crisper (Snack Compartment)
8. Bottle holder
C Figures that take place in this instruction manual are schematic and may not correspond
exactly with your product. If the subject parts are not included in the product you have
purchased, then it is valid for other models.
1
2
11
15
14
10
*8
9
7*3
4
5
6
13
13
12
9. Illumination lens
10. Adjustable glass shelves
11. Fan
12. Ice container
13. Separators
14. Freezer compartment
15. Fridge compartment
* OPTIONAL

EN
4
2Important Safety Warnings
Please review the following information.
Failure to observe this information may cause
injuries or material damage. Otherwise, all
warranty and reliability commitments will
become invalid.
The service life of your product is 10 years.
During this period, original spare parts will
be available to operate the product properly.
Intended use
This product is intended to be used
• indoors and in closed areas such as
homes;
• in closed working environments such as
stores and offices;
• in closed accommodation areas such as
farm houses, hotels, pensions.
• It should not be used outdoors.
General safety
• When you want to dispose/scrap the
product, we recommend you to consult
the authorized service in order to learn
the required information and authorized
bodies.
• Consult your authorized service for all
your questions and problems related to
the cooler/freezer. Do not intervene or let
someone intervene to the cooler/freezer
without notifying the authorised services.
• For products with a freezer compartment;
Do not eat cone ice cream and ice cubes
immediately after you take them out of the
freezer compartment! (This may cause
frostbite in your mouth.)
• For products with a freezer compartment;
Do not put bottled and canned liquid
beverages in the freezer compartment.
Otherwise, these may burst.
• Do not touch frozen food by hand; they
may stick to your hand.
• Unplug your cooler/freezer before cleaning
or defrosting.
• Vapor and vaporized cleaning materials
should never be used in cleaning and
defrosting processes of your cooler/
freezer. In such cases, the vapor may get
in contact with the electrical parts and
cause short circuit or electric shock.
• Never use the parts on your cooler/freezer
such as the door as a means of support
or step.
• Do not use electrical devices inside the
cooler/freezer.
• Do not damage the parts, where the
refrigerant is circulating, with drilling or
cutting tools. The refrigerant that might
blow out when the gas channels of the
evaporator, pipe extensions or surface
coatings are punctured causes skin
irritations and eye injuries.
• Do not cover or block the ventilation holes
on your cooler/freezer with any material.
• Electrical devices must be repaired by only
authorised persons. Repairs performed
by incompetent persons create a risk for
the user.
• In case of any failure or during a
maintenance or repair work, disconnect
your cooler/freezer’s mains supply by
either turning off the relevant fuse or
unplugging your appliance.
• Do not pull by the cable when pulling off
the plug.
• Place the beverage with higher proofs
tightly closed and vertically.
• Never store spray cans containing
flammable and explosive substances in
the cooler/freezer.

EN
5
• Do not use mechanical devices or other
means to accelerate the defrosting
process, other than those recommended
by the manufacturer.
• This product is not intended to be used by
persons with physical, sensory or mental
disorders or unlearned or inexperienced
people (including children) unless they
are attended by a person who will be
responsible for their safety or who will
instruct them accordingly for use of the
product
• Do not operate a damaged cooler/freezer.
Consult with the service agent if you have
any concerns.
• Electrical safety of your cooler/freezer shall
be guaranteed only if the earth system in
your house complies with standards.
• Exposing the product to rain, snow, sun
and wind is dangerous with respect to
electrical safety.
• Contact authorized service when there is
a power cable damage to avoid danger.
• Never plug the cooler/freezer into the wall
outlet during installation. Otherwise, risk of
death or serious injury may arise.
• This cooler/freezer is intended for only
storing food items. It must not be used for
any other purpose.
• Label of technical specifications is located
on the left wall inside the cooler/freezer.
• Never connect your cooler/freezer to
electricity-saving systems; they may
damage the cooler/freezer.
• If there is a blue light on the cooler/freezer,
do not look at the blue light with optical
tools.
• For manually controlled cooler/freezers,
wait for at least 5 minutes to start the
cooler/freezer after power failure.
• This operation manual should be handed
in to the new owner of the product when it
is given to others.
• Avoid causing damage on power cable
when transporting the cooler/freezer.
Bending cable may cause fire. Never
place heavy objects on power cable.
• Do not touch the plug with wet hands
when plugging the product.
• Do not plug the cooler/freezer if the wall
outlet is loose.
• Water should not be sprayed on inner
or outer parts of the product for safety
purposes.
• Do not spray substances containing
inflammable gases such as propane gas
near the cooler/freezer to avoid fire and
explosion risk.
• Never place containers filled with water
on top of the cooler/freezer; in the event
of spillages, this may cause electric shock
or fire.
• Do not overload the cooler/freezer with
food. If overloaded, the food items may fall
down and hurt you and damage cooler/
freezer when you open the door.
• Never place objects on top of the cooler/
freezer; otherwise, these objects may fall
down when you open or close the cooler/
freezer's door.

EN
6
• As they require a precise temperature,
vaccines, heat-sensitive medicine and
scientific materials and etc. should not be
kept in the cooler/freezer.
• If not to be used for a long time, cooler/
freezer should be unplugged. A possible
problem in power cable may cause fire.
• The plug's tip should be cleaned regularly
with a dry cloth; otherwise, it may cause
fire.
• Cooler/freezer may move if adjustable
legs are not properly secured on the floor.
Properly securing adjustable legs on the
floor can prevent the cooler/freezer to
move.
• When carrying the cooler/freezer, do not
hold it from door handle. Otherwise, it may
be snapped.
• When you have to place your product
next to another cooler/freezer or freezer,
the distance between devices should be
at least 8cm. Otherwise, adjacent side
walls may be humidified.
For products with a water
dispenser;
Pressure of water mains should be
minimum 1 bar. Pressure of water mains
should be maximum 8 bars.
• Use only potable water.
Child safety
• If the door has a lock, the key should be
kept away from reach of children.
• Children must be supervised to prevent
them from tampering with the product.
Compliance with the AEEE
Regulation and Disposing of
the Waste Product
This product does not contain harmful
and forbidden materials described in the
"Regulation on the Control of the Waste
Electrical and Electronic Equipment" issued
by the T.R. Ministry of Environment and
City Planning. Complies with the AEEE
Regulation.
This product has been
manufactured with high
quality parts and materials
which can be reused and are
suitable for recycling.
Therefore, do not dispose the
product with normal domestic
waste at the end of its service life. Take it to
a collection point for the recycling of
electrical and electronic equipment. Please
consult your local authorities to learn the
nearest collection point. Help protect the
environment and natural resources by
recycling used products. For children's
safety, cut the power cable and break the
locking mechanism of the door, if any, so
that it will be non-functional before disposing
of the product.
Package information
Packaging materials of the product
are manufactured from recyclable
materials in accordance with our National
Environment Regulations. Do not dispose
of the packaging materials together with
the domestic or other wastes. Take them
to the packaging material collection points
designated by the local authorities.
Do not forget...
Anyrecycled substanceis an indispensable
matter for nature and our national asset
wealth.
If you want to contribute to the re-
evaluation of the packaging materials,
you can consult to your environmentalist
organizations or the municipalities where
you are located.

EN
7
Recommendations for the
fresh food compartment
*optional
• Do not allow the food to touch
the temperature sensor in fresh food
compartment. To allow the fresh food
compartment keep its ideal storage
temperature, sensor must not be hindered
by food.
• Do not place hot foods in the product.
temperature
sensor
food
MILK
juice
etc.
temperature
sensor
temperature
sensor
food
MILK
juice
etc.
temperature
sensor
HCA warning
If your product's cooling system
contains R600a:
This gas is flammable. Therefore, pay
attention to not damaging the cooling
system and piping during usage and
transportation. In the event of damage,
keep your product away from potential fire
sources that can cause the product catch a
fire and ventilate the room in which the unit
is placed.
Ignore this warning if your product's
cooling system contains R134a.
Type of gas used in the product is stated in
the type label which is on the left wall inside
the cooler/freezer.
Never throw the product in fire for disposal.
Things to be done for energy
saving
• Do not leave the doors of your cooler/
freezer open for a long time.
• Do not put hot food or drinks in your
cooler/freezer.
• Do not overload your cooler/freezer so
that the air circulation inside of it is not
prevented.
• Do not install your cooler/freezer under
direct sunlight or near heat emitting
appliances such as ovens, dishwashers or
radiators. Keep your cooler/freezer at least
30cm away from heat emitting sources
and at least 5cm from electrical ovens.
• Pay attention to keep your food in closed
containers.
• For products with a freezer compartment;
You can store maximum amount of food
items in the freezer when you remove
the shelf or drawer of the freezer. Energy
consumption value stated for your cooler/
freezer has been determined by removing
freezer shelf or drawer and under
maximum load. There is no harm to use
a shelf or drawer according to the shapes
and size of food to be frozen.
• Thawing frozen food in fridge
compartment will both provide energy
saving and preserve the food quality.

EN
8
3Installation
BIn case the information which are given
in the user manual are not taken into
account, manufacturer will not assume
any liability for this.
Points to be paid attention
to when the relocation of the
cooler/freezer
1. Your cooler/freezer should be unplugged.
Before transportation of your cooler/
freezer, it should be emptied and cleaned.
2. Before it is re-packaged, shelves,
accessories, crisper, etc. inside your
cooler/freezer should be fixed with
adhesive tape and secured against
impacts. Package should be bound
with a thick tape or sound ropes and
the transportation rules on the package
should be strictly observed.
3. Original packaging and foam materials
should be kept for future transportations
or moving.
Before you start the cooler/
freezer,
Check the following before you start to
use your cooler/freezer:
1. Attach 2 plastic wedges as illustrated
below. Plastic wedges are intended to
keep the distance which will ensure the
air circulation between your cooler/freezer
and the wall. (The picture is drawn up as
a representation and it is not identical with
your product.)
2. Clean the interior of the cooler/freezer as
recommended in the “Maintenance and
cleaning” section.
3. Connect the plug of the cooler/freezer to
the wall socket. When the fridge door is
opened, fridge internal lamp will turn on.
4. When the compressor starts to operate, a
sound will be heard. The liquid and gases
sealed within the refrigeration system
may also give rise to noise, even if the
compressor is not running and this is quite
normal.
5. Front edges of the cooler/freezer may
feel warm. This is normal. These areas
are designed to be warm to avoid
condensation.
Electrical connection
Connect your product to a grounded
socket which is being protected by a fuse
with the appropriate capacity.
Important:
The connection must be in compliance
with national regulations.
• The power plug must be easily accessible
after installation.
• Electrical safety of your cooler/freezer shall
be guaranteed only if the earth system in
your house complies with standards.

EN
9
• The voltage stated on the label located at
left inner side of your product should be
equal to your network voltage.
• Extension cables and multi plugs
must not be used for connection.
BA damaged power cable must be
replaced by a qualified electrician.
BProduct must not be operated before it is
repaired! There is the risk of electric shock!
Disposing of the packaging
The packing materials may be dangerous
for children. Keep the packing materials out
of the reach of children or dispose of them
by classifying them in accordance with
the waste instructions stated by your local
authorities. Do not throw away with regular
house waste, throw away on packaging
pick up spots designated by the local
authorities.
The packing of your cooler/freezer is
produced from recyclable materials.
Disposing of your old cooler/
freezer
Dispose of your old cooler/freezer without
giving any harm to the environment.
• You may consult your authorized dealer
or waste collection center of your
municipality about the disposal of your
cooler/freezer.
Before disposing of your cooler/freezer,
cut out the electric plug and, if there are any
locks on the door, make them inoperable in
order to protect children against any danger.
Placing and Installation
AIf the entrance door of the room where
the cooler/freezer will be installed is not
wide enough for the cooler/freezer to pass
through, then call the authorized service to
have them remove the doors of your cooler/
freezer and pass it sideways through the
door.
1. Install your cooler/freezer to a place that
allows ease of use.
2. Keep your cooler/freezer away from heat
sources, humid places and direct sunlight.
3. There must be appropriate air ventilation
around your cooler/freezer in order to
achieve an efficient operation. If the cooler/
freezer is to be placed in a recess in the
wall, there must be at least 5 cm distance
with the ceiling and at least 5 cm with the
wall. Do not place your product on the
materials such as rug or carpet.
4. Place your cooler/freezer on an even floor
surface to prevent jolts.
Adjusting the legs
If your refrigerator is unbalanced;
You can balance your refrigerator by
turning its front legs as illustrated in the
figure. The corner where the leg exists is
lowered when you turn in the direction of
black arrow and raised when you turn in
the opposite direction. Taking help from
someone to slightly lift the refrigerator will
facilitate this process.
Changing the illumination
lamp
To change the Bulb/LED used for
illumination of your refrigerator, call your
Authorized Service.

EN
10
4Preparation
• Your cooler/freezer should be installed at
least 30 cm away from heat sources such
as hobs, ovens, central heater and stoves
and at least 5 cm away from electrical
ovens and should not be located under
direct sunlight.
• The ambient temperature of the room
where you install your cooler/freezer
should at least be 10°C. Operating your
cooler/freezer under cooler conditions
is not recommended with regard to its
efficiency.
• Please make sure that the interior of your
cooler/freezer is cleaned thoroughly.
• If two cooler/freezers are to be installed
side by side, there should be at least 2 cm
distance between them.
• When you operate your cooler/freezer for
the first time, please observe the following
instructions during the initial six hours.
• The door should not be opened
frequently.
• It must be operated empty without any
food in it.
• Do not unplug your cooler/freezer.
If a power failure occurs out of your
control, please see the warnings in
the “Recommended solutions for the
problems” section.
• Original packaging and foam materials
should be kept for future transportations
or moving.

EN
11
Indicator Panel
Indicator panel aids in using your refrigerator with its audio and visual functions.
1. Ioniser Indicator
2. Fridge Compartment Indicator
3. Error Status Indicator
4. Temperature Indicator
5. Temperature Setting / Vacation Button
1. Ioniser Indicator
Indicator light lights up continuously.
This light indicates that your refrigerator is
protected against the bacteria.
2. Fridge Compartment Indicator
Fridge compartment light illuminates
when adjusting the fridge compartment
temperature.
5Using your refrigerator
Indicator panels may vary depending on your product's model.
1 2 3 4
56789
6. Refrigerator Compartment Selection
Button
7. Multizone Compartment Indicator
8. Freezer Compartment Indicator
9. Economy Mode Indicator
3. Error Status Indicator
If your refrigerator does not cool adequately
or if there is a sensor failure, this indicator
will be activated. When this indicator is
active, temperature indicator will display "e"
and the numbers 1,2,3... These numbers
on the indicator provide information about
the error to the service personnel.
C Figures that take place in this instruction manual are schematic and may not correspond
exactly with your product. If the subject parts are not included in the product you have
purchased, then it is valid for other models.

EN
12
4. Temperature Indicator
Indicates the temperatures of fridge,
freezer multizone compartment.
5. Temperature Setting / Vacation
Button
After selecting the compartment for which
you will set the temperature, perform the
temperature setting by means of pressing
this button.
Press and hold the same button for 3
seconds to activate the Vacation function for
the fridge compartment. Press this button
again to deactivate the selected function.
If this function is active, "- -" appears
on the temperature indicator of the
fridge compartment and no cooling is
performed in the fridge compartment. Other
compartments will be cooled in accordance
with the temperature set for them.
6. Refrigerator Compartment Selection
Button
Press Refrigerator Compartment Selection
Button to switch between fridge, freezer
and multizone compartments.
7. Multizone Compartment Indicator
Multizone compartment light illuminates
when adjusting the multizone compartment
temperature.
8. Freezer Compartment Indicator
Freezer compartment light illuminates
when adjusting the freezer compartment
temperature.
9. Economy Mode Indicator
Indicates that the refrigerator is running
in energy-efficient mode. This indicator
will be active if the temperature of Freezer
Compartment is set to -18 and energy
efficient cooling is being performed.

EN
13
1. Freezer compartment setting button
2. Multizone compartment setting button
3. Fridge compartment setting button
4. Error status indicator
5. Key lock indicator
6. Eco Extra Function indicator
7. Eco Extra / Vacation Button
8. Vacation function indicator
9. Economic usage indicator
1
3
2
4
5
6
10
9
8
7
16
15
14
12
13
11
10. Quick fridge function indicator
11. Quick fridge function button
12. Freezer compartment temperature setting
indicator
13. Multizone compartment temperature
setting indicator
14. Fast freeze function button
15. Fridge compartment temperature setting
indicator
16. Fast Freeze Function Indicator
C Figures that take place in this instruction manual are schematic and may not correspond
exactly with your product. If the subject parts are not included in the product you have
purchased, then it is valid for other models.

EN
14
1- Freezer Compartment Setting
This function allows you to set the freezer
compartment temperature. Press this
button to set the temperature of the freezer
compartment to -18,-19, -20,-21,-22,-23
and -24, respectively.
2. Multi Zone Storage Compartment
Temperature Setting Button
You can set the Multi Zone Storage
Compartment either as a Freezer or a
Cooler. Press and hold this button for 3
seconds to set the Multi Zone Storage
Compartment either as a Freezer or a
Cooler. This compartment is set as a
Freezer Compartment at factory.
If the Multi Zone Storage Compartment
is set as a Freezer, then the temperature of
the Multi Zone Storage Compartment will
change as -18,-19,-20,-21,-22,-23,-24,
-18... respectively each time you press this
button. If the Multi Zone Compartment is
set as a Fridge, then the temperature of the
Multi Zone Compartment will change as 10,
8, 6, 4, 2, 0, -6, ... respectively each time
you press this button.
3- Fridge Compartment Setting Button
This function allows you to make the
fridge compartment temperature setting.
Press this button to set the temperature
of the fridge compartment to 8,7,6,5,4,3,2
respectively.
4-. Error Status Indicator
If your refrigerator does not cool
adequately or if there is a sensor failure,
this indicator will be activated. When this
indicator is active, Freezer Compartment
Temperature indicator will display "E" and
Fridge Compartment Temperature Indicator
will display numbers such as "1,2,3…".
These numbers on the indicator provide
information about the error to the service
personnel.
When you place hot food into the freezer
compartment or if you leave the door open
for a long time, exclamation mark can
illuminate for some time. This is not a failure;
this warning will disappear when the food
cools down.
5. Key Lock Indicator
Use this function if you do not want your
refrigerator temperature setting changed.
To activate this function, you should press
and hold Fast Freeze and Quick Fridge
buttons together for 3 seconds.
6-. Eco Extra Function Indicator
It indicates that the Eco-Extra function is
active.
If this function is active, your refrigerator
will automatically detect the least usage
periods and energy-efficient cooling will be
performed during those times. Economy
indicator will be active while energy-efficient
cooling is performed.
Press the relevant button again to
deactivate this function.
7-. Eco Extra / Vacation Button
Press this button briefly to activate the Eco
Extra function. Press and hold this button
for 3 sec. to activate the Vacation function.
Press this button again to deactivate the
selected function.
8-. Vacation Function Indicator
Indicates that the vacation function is
active.
If this function is active, "- -" appears
on the temperature indicator of the
fridge compartment and no cooling is
performed in the fridge compartment. Other
compartments will be cooled in accordance
with the temperature set for them.
Press the relevant button again to
deactivate this function.
9- Economy Mode Indicator
Indicates that the refrigerator is running
in energy-efficient mode. Freezer
Compartment temperature
This indicator will be active if the function
is set to -18 or the energy efficient cooling is
being performed due to Eco-Extra function.

EN
15
10- Quick Fridge Indicator
This icon flashes in an animated style
when the Quick Fridge function is active.
11- Quick Fridge Function
When you press the Quick Fridge button,
the temperature of the compartment will be
colder than the adjusted values.
This function can be used for food placed
in the fridge compartment and required to
be cooled down rapidly.
If you want to cool large amounts of fresh
food, it is recommended to activate this
feature before putting the food into the
fridge.
Quick Fridge indicator turns on when the
Quick Fridge function is on. To cancel this
function, press Quick Fridge button again.
If you do not cancel it, Quick Fridge will
cancel itself automatically after 2 hours or
when the fridge compartment reaches to
the required temperature.
This function is not recalled when power
restores after a power failure.
12- Freezer Compartment
Temperature Setting Indicator
Indicates the temperature set for the
Freezer Compartment.
13-Multi Zone Storage Compartment
Temperature Indicator
Indicates the temperature set for Multi
Zone storage compartment.
14- Fast Freeze Function
Fast Freeze indicator turns on when the
Fast Freeze function is active. To cancel
this function, press Fast Freeze button
again. Fast Freeze indicator will turn off
and return to its normal settings. If you
do not cancel it, Fast Freeze will cancel
itself automatically after 8 hours or when
the freezer compartment reaches to the
required temperature.
If you want to freeze large amounts of
fresh food, press the Fast Freeze button
before putting the food into the freezer
compartment.
If you press the Fast Freeze button
repeatedly with short intervals, the electronic
circuit protection will be activated and the
compressor will not start up immediately.
This function is not recalled when power
restores after a power failure.
15- Fridge Compartment Temperature
Setting Indicator
Indicates the temperature set for the
Fridge Compartment.
16- Fast Freeze Indicator
This icon flashes in an animated style
when the Fast Freeze function is active.

EN
16
Freezing fresh food
• Wrap or cover the food before placing
them in the refrigerator.
• Hot food must cool down to the room
temperature before putting them in the
refrigerator.
• The foodstuff that you want to freeze must
be fresh and in good quality.
• Foodstuff must be divided into portions
according to the family’s daily or meal
based consumption needs.
• The foodstuff must be packaged in an
airtight manner to prevent them from
drying even if they are going to be kept for
a short time.
• Materials to be used for packaging
must be tear-proof and resistant to cold,
humidity, odor, oils and acids and they
must also be airtight. Moreover, they
must be well closed and they must be
made from easy-to-use materials that are
suitable for deep freeze usage.
• Frozen food must be used immediately
after they are thawed and they should
never be re-frozen.
• Please observe the following instructions
to obtain the best results.
1. Do not freeze too large quantities of food
at one time. The quality of the food is best
preserved when it is frozen right through
to the core as quickly as possible.
2. Placing warm food into the freezer
compartment causes the cooling system
to operate continuously until the food is
frozen solid.
3. Take special care not to mix already frozen
food and fresh food.
Freezer
Compartment
Setting
Fridge
Compartment
Setting
Explanations
-18°C 4°C This is the normal recommended setting.
-20,-22 or -24°C 4°C These settings are recommended when the ambient temperature exceeds 30°C.
Quick Freeze 4°C Use when you wish to freeze your food in a short time. Your refrigerator will return to its previous mode
when the process is over.
-18°C or colder 2°C If you think that your fridge compartment is not cold enough because of the hot conditions or frequent
opening and closing of the door.
-18°C or colder Quick Fridge You can use it when your fridge compartment is overloaded or if you wish to cool down your food
rapidly. It is recommended that you activate quick fridge function 4-8 hours before placing the food.
Door Open Warning
(This feature may vary depending
on the door of the product and may
not exist in some models.)
An audio warning signal will be given when
the door of your product is left open for at
least 1 minute. This warning will be muted
when the door is closed or any of the display
buttons (if any) are pressed.

EN
17
Recommendations for
preservation of frozen food
• Prepacked commercially frozen food
should be stored in accordance with the
frozen food manufacturer's instructions
for a ( 4 star) frozen food storage
compartment.
• To ensure that the high quality achieved by
the frozen food manufacturer and the food
retailer is maintained, the following should
be remembered:
1. Put packages in the freezer as quickly as
possible after purchase.
2. Ensure that contents are labeled and
dated.
3. Do not exceed "Use By", "Best Before"
dates on the packaging.
Defrosting
The freezer compartment defrosts
automatically.
Placing the food
Freezer compartment shelves Various frozen food such as meat,
fish, ice cream, vegetables and etc.
Egg holder Egg
Fridge compartment shelves Food in pans, covered plates and
closed containers
Fridge compartment door
shelves
Small and packaged food or drinks
(such as milk, fruit juice and beer)
Crisper Vegetables and fruits
Freshzone compartment Delicatessen products (cheese,
butter, salami and etc.)

EN
18
Water Dispenser
(in some models)
Water dispenser is a very useful feature
based on reaching cold water without
opening the door of your refrigerator. As you
will not have to open your refrigerator door
frequently, you will have saved energy.
Filling the water dispenser's tank
Water tank filling reservoir is located inside
the door rack. Open the reservoir cover and
fill in clean potable water. And then, close
the lid.
Using the water spring
Push the arm of the water dispenser
with your glass. The dispenser will cease
operating once you release the arm.
When operating the water dispenser,
maximum flow can be obtained by pressing
the arm fully. Please remember that the
amount of flow from the dispenser is subject
to the degree you press the arm.
As the level of the water in your glass/
container rises, slightly lessen the pressure
on the arm to prevent the overspill. If you
slightly press the arm, the water will drip;
this is quite normal and not a failure.
Warning!
• Do not fill the water tank with any other
liquid except for water such as fruit
juices, carbonated beverages or alcoholic
drinks which are not suitable to use in
the water dispenser. Water dispenser will
be irreparably damaged if these kinds of
liquids are used. Warranty does not cover
such usages. Some chemical substances
and additives contained in these kinds of
drinks/liquids may damage the water tank.

EN
19
• Use clean and pure potable water only.
• Capacity of the water tank is 3 liters; do
not overfill.
• Push the arm of the water dispenser with
a rigid glass. If you are using disposable
plastic glasses, push the arm with your
fingers from behind the glass.
Cleaning the water tank
• Remove the water filling reservoir inside
the door rack.
• Remove the door rack by holding from
both sides.
• Grab the water tank from both sides and
remove it with an angle of 45°C.
• Clean the water tank by removing its lid.
Important:
Components of the water tank and
water dispenser should not be washed in
dishwasher.
Water tray
Water that dripped while using the water
dispenser accumulates in the spillage tray.
Take out the plastic strainer as shown in
the figure.
With a clean and dry cloth, remove the
water that has accumulated
CAUTION: Connect only to a potable
water line.
