Beko RCNE590E35ZXP User manual

RCNE590E35ZXP
EN/HE/AR
58 7092 0000/AB- EN- HE-AR
Refrigerator
User Manual

שמתשמל ךירדמ


Dear Customer,
Please read this manual before using the product.
Thank you for choosing this product. We would like you to achieve the optimal efficiency
from this high quality product which has been manufactured with state of the art tech-
nology. To do this, carefully read this manual and any other documentation provided
before using the product and keep it as a reference.
Heed all information and warnings in the user manual. This way, you will protect yourself
and your product against the dangers that may occur.
Keep the user manual. Include this guide with the unit if you hand it over to someone
else.
The following symbols are used in the user guide:
Hazard that may result in death or injury.
NOTICE A hazard that may cause material damage to the product or its
surroundings
Important information or useful tips on operation.
Read the user manual.
Risk of fire / Flammable materials

2 /26 EN Refrigerator / User Guide
1 Safety Instructions 3
1.1 Purpose of usage . . . . . . . . . . . . . . . . . 3
1.2 Safety of children, vulnerable persons and
pets. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.3 Electrical safety. . . . . . . . . . . . . . . . . . . 4
1.4 Handling Safety. . . . . . . . . . . . . . . . . . . 4
1.5 Installation Safety . . . . . . . . . . . . . . . . . 4
1.6 Operational safety . . . . . . . . . . . . .5
1.7 Maintenance and cleaning safety. . . . . . 6
1.8HomeWhiz . . . . . . . . . . . . . . . . . . . . . . . 7
1.9 Lighting . . . . . . . . . . . . . . . . . . . . . . . . 7
2 Environmental instructions 8
2.1 Compliance with the WEEE Directive and
Disposing of the Waste Product: . . . . . . . . 8
2.2 Compliance with RoHS Directive . . . . . . . . . . 8
2.3 Package information. . . . . . . . . . . . . . . . . . . 8
3 Your Refrigerator 9
4 Installation 10
4.1 The right place for installation . . . . . . . . . . . 10
4.2 Attaching the plastic wedges . . . . . . . . . . . 10
4.3 Adjustment of the feet. . . . . . . . . . . . . . . . . 11
4.4 Changing the door opening direction . . . . . . 11
4.5 Electrical connection. . . . . . . . . . . . . . . . . . 11
5 Preparation 12
5.1 What to do for energy saving . . . . . . . . . . . 12
5.2 First operation . . . . . . . . . . . . . . . . . . . . . . 12
6 Operating the Product 13
6.1 Turning off the product . . . . . . . . . . . . . . . . 13
6 Operation of the Product 14
6.2 Indicator panel . . . . . . . . . . . . . . . . . . . . . . 14
6.3 Humidity controlled crisper (EverFresh+) . . . 16
6.4 Blue Light/HarvestFresh . . . . . . . . . . . . . . 16
6.5 Anti-Odour Module . . . . . . . . . . . . . . . . . . . 17
(FreshGuard) . . . . . . . . . . . . . . . . . . . . . . . . . . 17
6.6 Ice bucket . . . . . . . . . . . . . . . . . . . . . . . . . 18
6.7 The dairy (cold storage) bin . . . . . . . . . . . . 18
6.8 Crisper . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
6.9 Movable Body shelf: . . . . . . . . . . . . . . . . . . 19
6.10 Freezing fresh food. . . . . . . . . . . . . . . . . . 20
6.11Recommendations for storing frozen foods in
the freezer compartment . . . . . . . . . . . . . 20
6.12Deep freezer details . . . . . . . . . . . . . . . . . 21
6.13 Placing food . . . . . . . . . . . . . . . . . . . . . . . 21
6.14 Door open alert . . . . . . . . . . . . . . . . . . . . 21
6.15 Illumination lamp . . . . . . . . . . . . . . . . . . . 21
7 Maintenance and cleaning 22
7.1 Stainless Steel External Surfaces. . . . . . . . . 22
7.2 Cleaning of the Products with Glass Doors. . 22
7.3 Preventing Odours. . . . . . . . . . . . . . . . . . . 23
7.4 Protecting Plastic Surfaces . . . . . . . . . . . . 23
7 Maintenance and cleaning 23
8 Troubleshooting 24

3 / 26 EN
Refrigerator / User Guide
1 Safety Instructions
 This section includes the safety
instructions necessary to prevent
the risk of personal injury or material
damage.
 Our company shall not be held
responsible for damages that may
occur if these instructions are not
observed.
Installation and repair operations shall always
be performed by Authorized Service.
Always use genuine spare parts and
accessories.
Original spare parts will be provided for
10 years, following the product purchasing date.
Do not repair or replace any part of the
product unless specified expressly in the user
manual.
Do not perform any modifications on the
product.
1.1 Purpose of usage
 This product is not intended for
commercial use and it shall not be
used out of its intended purpose.
This product is intended for operating interiors,
such as households or similar.
For example;
- In the staff kitchens of the stores, offices and
other working environments,
- In farm houses,
- In the units of hotels, motels or other resting
facilities that are used by the customers,
- In hostels, or similar environments,
- In catering services and similar non-retail ap-
plications.
This product shall not be used in open or enclosed
external environments such as vessels, balconies
or terraces. Exposing the product to rain, snow,
sunlight and wind may cause risk of fire.
1.2 Safety of children,
vulnerable persons and pets
 This product may be used by children
aged 8 years and older and persons
with underdeveloped physical,
sensory or mental capabilities or
lack of experience and knowledge
if they have been given supervision
or instruction concerning use of the
appliance in a the product safe way
and the hazards involved.
 Children between 3 and 8 years are
allowed to put and take out food to/
from the cooler product.
 Electrical products are dangerous for
children and pets. Children and pets
must not play with, climb on, or enter
the product.
 Cleaning and user maintenance
should not be performed by children
unless there is someone overseeing
them.
 Keep the packaging materials away
from children. Risk of injury and
suffocation.
 Before disposing of old products that
shall not be used any more:
1. Unplug the power cord from the mains socket.
2. Cut the power cord and remove it from the appli-
ance together with the plug.
3. Do not remove the racks and drawers from the
product to prevent children from getting inside the
appliance.
4. Remove the doors.
5. Store the product so that it shall not be tipped over.
6. Do not allow children to play with the scrapped
product.
 Do not dispose of the product by
throwing it into fire. Risk of explosion.

4 /26 EN Refrigerator / User Guide
Important safety and environment instructions
 If there is a lock available in the
product’s door, keep the key out of
children’s reach.
1.3 Electrical safety
 The product shall not be plugged
into the outlet during installation,
maintenance, cleaning, repair, and
transportation operations.
 If the power the cord is damaged,
it shall be replaced by authorized
service only to avoid any risk that
may occur.
 Do not tuck the power cord under the
product or to the rear of the product.
Do not put heavy items on the power
cord. The power cord should not be
bent, crushed, and come into contact
with any heat source.
 Do not use an extension cord, multi-
plug or adaptor to operate your
product.
 Portable multisockets or portable
power supplies may overheat and
cause fire. Thus, do not have a multi-
plug behind or in the vicinity of the
product.
 The plug shall be easily accessible.
If this is not possible, a mechanism
that meets the electrical legislation
and that disconnects all terminals
from the mains (fuse, switch, main
switch, etc.) shall be available on the
electrical installation.
 Do not touch the plug with wet
hands.
 When unplugging the appliance, don’t
hold the power cord, but the plug.
 When positioning the appliance,
ensure the supply cord is not trapped
or damaged.
 Do not locate multiple portable
socket-outlets or portable power
supplies at the rear of the appliance.
1.4 Handling Safety
 This product is heavy, do not handle it
by yourself.
 Do not hold the product from its door
while handling the product.
 Be careful not to damage the cooling
system and the pipes while handling
the product. Do not operate the
product if the pipes are damaged, and
contact an authorized service.
1.5 Installation Safety
 Contact the Authorized Service
for the product’s installation. To
prepare the product for installation,
see the information in the user
guide and make sure the electric
and water utilities are as required.
If the installation is not suitable, call
a qualified electrician and plumber
to have them make the necessary
arrangements. Otherwise, electric
shock, fire, issues with the product or
injuries may occur.
 Check for any damage on the product
before installing it. Do not have the
product installed if it is damaged.
 Place the product on a level and
hard surface and balance with the
adjustable legs. Otherwise, the
refrigerator may tip over and cause
injuries.
 The product shall be installed in a
dry and ventilated environment.
Do not keep carpets, rugs or similar
floor covers under the product. This
may cause risk of fire as a result of
inadequate ventilation!
 Do not block or cover ventilation
holes. Otherwise, power consumption
may be increased and damage to your
product may occur.
 Do not connect the product to supply
systems such as solar power supplies.

5 / 26 EN
Refrigerator / User Guide
Important safety and environment instructions
Otherwise, damage to your product
may occur as a result of the abrupt
voltage fluctuations!
 The more refrigerant a refrigerator
contains, the bigger its installation
room shall be. In very small rooms,
a flammable gas-air mixture may
occur in case of a gas leak in the
cooling system. At least 1 m3of
volume is required for each 8 grams
of refrigerant. The amount of the
refrigerant available in your product is
specified in the Type Label.
 The installation place of the product
shall not be exposed to direct sunlight
and it shall not be in the vicinity of a
heat source such as stoves, radiators,
etc.
If you cannot prevent installation of the product in
the vicinity of a heat source, you shall use a suitable
insulation plate and the minimum distance to the
heat source shall be as specified below.
- At least 30 cm away from heat sources such
as stoves, heating units and heaters, etc.,
- And at least 5 cm away from electric ovens.
 Your product has the protection
class of I. Plug the product in a
grounded socket that conforms with
the Voltage, Current and Frequency
values specified in the type label. The
socket outlet shall be equipped with a
fuse with a rating of 10 A – 16 A. Our
company shall not be responsible for
the damages that shall be incurred
as a result of operating the product
without ensuring ground and electrical
connections made as per local or
national regulations.
 The product’s power cable must
be unplugged during installation.
Otherwise, risk of electric shock and
injury may occur!
 Do not plug the product to loose, broken, dirty,
greasy sockets or sockets that has come out their
seats or sockets with a risk of water contact.
 Place the power cord and hoses (if available) of
the product so that they shall not cause a risk
of tripping over.
 Penetration of humidity to live parts or to the
power cord may cause short circuit. Thus, do
not use the product in humid environments or
in areas where water may splash (e.g. garage,
laundry room, etc.) If the refrigerator is wet
by water, unplug it and contact an authorized
service.
 Do not connect your refrigerator to power sav-
ing devices. These systems are harmful for the
product.
1.6 Operational safety
 Do not use chemical solvents on the product.
These materials contain an explosion risk.
 In case of a failure of the product, unplug it and
do not operate until it is repaired by the author-
ized service. There is a risk of electric shock!
 Do not place a source of flame (e.g. candles,
cigarettes, etc.) on the product or in the vicinity
of it.
 Do not get on the product. Risk of falling and
injury!
 Do not cause damage to the pipes of the cool-
ing system using sharp and piercing tools. The
refrigerant that sprays out in case of puncturing
the gas pipes, pipe extensions or upper surface
coatings may cause irritation of skin and inju-
ries of the eyes.
 Do not place and operate electric appliances
inside the refrigerators/deep freezer unless it is
advised by the manufacturer.
 Do not jam any parts of your hands or your
body to the moving parts inside the product.
Be careful to prevent jamming of your fingers
between the refrigerator and its door. Be careful
while opening or closing the door if there are
children around.
 Do not put ice cream, ice cubes or frozen food
to your mouth as soon as you take them out of
the freezer. Risk of frostbite!
 Do not touch the inner walls, metal
parts of the freezer or food kept
inside the refrigerator with wet
hands. Risk of frostbite!

6 /26 EN Refrigerator / User Guide
Important safety and environment instructions
 Do not place soda cans or cans
and bottles that contain fluids
that may be frozen to the freezer
compartment. Cans or bottles may
explode. Risk of injury and material
damage!
 Do not use or place materials
sensitive against temperature
such as flammable sprays,
flammable objects, dry ice or other
chemical agents in the vicinity of
the refrigerator. Risk of fire and
explosion!
 Do not store explosive materials
such as aerosol cans with flammable
materials inside the product.
 Do not place cans containing fluids
over the product. Splashing of water
on an electrical part may cause the
risk of an electric shock or a fire.
 This product is not intended for
storage and cooling of medicines,
blood plasma, laboratory preparations
or similar materials and products that
are subject to the Medical Products
Directive.
 If the product is used against its
intended purpose, it may cause
damage to or deterioration of the
products kept inside.
 If your refrigerator is equipped with
blue light, do not look at this light
with optical devices. Do not stare
directly at UV LED light for a long
time. Ultraviolet rays may cause eye
strain.
 Do not fill the product with more food
than its capacity. Injuries or damages
may occur if the contents of the
refrigerator falls when the door is
opened. Similar problems may occur
when an object is placed over the
product.
 Ensure that you have removed any
ice or water that may have fallen to
the floor to prevent injuries.
 Change the locations of the racks/
bottle racks on the door of your
refrigerator while the racks are
empty only. Danger of physical injury!
 Do not place objects that may fall/
tipped over on the product. These
objects may fall while opening or
closing the door and cause injuries
and/or material damages.
 Do not hit or exert excessive pressure
on glass surfaces. Broken glass
may cause injuries and/or material
damages.
 The cooling system in your product
contains R600a refrigerant. The
refrigerant type used in the product
is specified in the the type label.
This gas is flammable. Therefore, be
careful not to damage the cooling
system and the pipes while operating
the product. In case of damage to the
pipes;
- do not touch the product or the power cord,
- Keep the product away from potential sources
of fire that may cause the product to catch fire.
- ventilation the area where the product is
placed. Do not use a fan.
- Contact authorized service.
 If the product is damaged and you
observe gas leak, please stay away
from the gas. Gas may cause frostbite
if it contacts your skin.
1.7 Maintenance and
cleaning safety
 Do not pull by the door handle if you
shall move the product for cleaning
purposes. Handle may cause injuries
if it is pulled too hard.

7 / 26 EN
Refrigerator / User Guide
Important safety and environment instructions
 Do not clean the product by spraying
or pouring water on the product and
inside the product. Risk of electric
shock and fire.
 Do not use sharp or abrasive tools
to clean the product. Do not use
materials such as household cleaning
agents, detergents, gas, gasoline,
alcohol, wax, etc.
 Use cleaning and maintenance
agents that are not harmful for food
only inside the product.
 Do not use steam or steamed
cleaning materials for cleaning the
product and thawing the ice inside it.
Steam contacts the live areas in your
refrigerator and causes short circuit
or electric shock!
 Take care to keep water away from
the electronic circuits or lighting of
the product.
 Use a clean, dry cloth to wipe the dust
or foreign material on the tips of the
plugs. Do not use a wet or damp piece
of cloth to clean the plug. Otherwise,
risk of fire or electric shock may occur.
1.8HomeWhiz
(May not be applicable for all models)
 Follow the safety warnings even if
you are away from the product while
operating the product via HomeWhiz
app. Also, pay attention to the
warnings in the app.
1.9 Lighting
(May not be applicable for all models)
 Contact an authorized service when
you shall replace the LED / bulb using
for lighting.

8 /26 EN Refrigerator / User Guide
2 Environmental instructions
2.1 Compliance with the WEEE
Directive and Disposing
of the Waste Product:
This product complies with EU WEEE Directive
(2012/19/EU). This product bears a classification
symbol for waste electrical and electronic equip-
ment (WEEE).
This symbol indicates that this product
shall not be disposed with other house-
hold wastes at the end of its service life.
Used device must be returned to offical
collection point for recycling of electrical
and electronic devices. To find these collection sys-
tems please contact to your local authorities or re-
tailer where the product was puchased. Each
household performs important role in recovering
and recycling of old appliance. Appropriate disposal
of used appliance helps prevent potential negative
consequences for the environment and human
health.
2.2 Compliance with RoHS Directive
The product you have purchased complies with EU
RoHS Directive (2011/65/EU). It does not contain
harmful and prohibited materials specified in the
Directive.
2.3 Package information
Packaging materials of the product are
manufactured from recyclable materials
in accordance with our National
Environment Regulations. Do not dis-
pose of the packaging materials together with the
domestic or other wastes. Take them to the pack-
aging material collection points designated by the
local authorities.

9 / 26 EN
Refrigerator / User Guide
3 Your Refrigerator
C*Optional: Figures in this user guide are schematic and may not be exactly match your product. If your
product does not comprise the relevant parts, the information pertains to other models.
*May not be available in all models
1- Cooler compartment door shelves
2- Egg Holder
3- Bottle shelf
4- Adjustable stands
5- Freezer compartment drawers
6- The dairy (cold storage) compartment bin
7- Crisper
8- Glass shelves
9- Movable body shelf
10- Cooler compartment
11- Freezer compartment
*1
*1
*1 *1
*1
3
4
4
6
*7
*8
*9
10
11
2
5
5

10 /26 EN Refrigerator / User Guide
4 Installation
4.1 The right place for installation
Your product requires adequate air circulation to
function efficiently. If the product will be placed in an
alcove, remember to leave at least 5 cm clearance
between the product and the ceiling, rear wall and
the side walls.
If the product will be placed in an alcove, remember
to leave at least 5 cm clearance between the
product and the ceiling, rear wall and the side
walls. Check if the rear wall clearance protection
component is present at its location (if provided with
the product). If the component is not available, or
if it is lost or fallen, position the product so that at
least 5 cm clearance shall be left between the rear
surface of the product and the wall of the room.
The clearance at the rear is important for efficient
operation of the product.
AWARNING: Do not use extension or multi
sockets in power connection.
BWARNING: The manufacturer assumes
no responsibility for any damage caused
by the work carried out by unauthorized
persons.
BWARNING: The product's power cable
must be unplugged during installation.
Failure to do so may result in death or
serious injuries!
A
WARNING: : If the door span is too
narrow for the product to pass, remove
the door and turn the product sideways; if
this does not work, contact the authorized
service.

vibration.

the heater, stove and similar sources of heat
and at least 5 cm away from electric ovens.

keep in damp environments.

function efficiently. If the product will be placed
in an alcove, remember to leave at least 5 cm
distance between the product and the ceiling
and the walls.
4.2 Attaching the plastic wedges
*May not be applicable for all models
Use the plastic wedges in the provided with
the product to provide sufficient space for air
circulation between the product and the wall.
1. To attach the wedges, remove the screws on
the product and use the screws provided with the
wedges.
2. Attach 2 plastic wedges on the ventilation cover as
shown in the figure.
Read the “Safety Instructions” section first!

11 / 26 EN
Refrigerator / User Guide
Installation
4.3 Adjustment of the feet
If the product is not in balanced position, adjust the
front adjustable stands by rotating right or left.
4.5 Electrical connection
AWARNING: Do not use extension or
multi sockets in power connection.
BWARNING: Damaged power cable
must be replaced by Authorized
Service.
 Our firm will not assume responsibility for any
damages due to usage without earthing and
power connection in compliance with national
regulations.
 The power cable plug must be easily
accessible after installation.
C
Hot surface warning!
The side walls of your product are
equipped with cooler pipes to enhance
the cooling system. High pressure fluid
may flow through these surfaces, and
cause hot surfaces on the side walls.
This is normal and it does not require
servicing. Be careful when you contact
these areas.
4.4 Changing the door
opening direction
Door opening direction of your refrigerator can
be changed according to the place you are using
it. If this is necessary, please call your nearest
Authorized Service.

12 /26 EN Refrigerator / User Guide
5 Preparation
5.1 What to do for energy saving
mehmet
AConnecting the product to electronic
energy-saving systems is harmful, as it
may damage the product.
 Do not keep the refrigerator doors open for
long periods.
 Do not place hot food or beverages into the
refrigerator.
 Do not overfill the refrigerator; blocking the
internal air flow will reduce cooling capacity.
 Depending on the product's features;
defrosting frozen foods in the cooler
compartment will ensure energy saving and
preserve food quality.
 Food shall be stored using the drawers in the
cooler compartment in order to ensure energy
saving and protect food in better conditions.
 Since hot and humid air will not directly
penetrate into your product when the doors are
not opened, your product will optimize itself
in conditions sufficient to protect your food.
In this energy saving function, functions and
components such as compressor, fan, heater,
defrost, lighting, display and so on will operate
according to the needs to consume minimum
energy while maintaining the freshness of your
foodstuff.
 In case of multiple options are present glass
shelves must be placed so that the air outlets
at the backwall are not blocked, prefably air
outlets are remaining below the glass shelf.
This combination may help impoving air
distribution and energy efficiency.
5.2 First operation
Before using your refrigerator, make sure the
necessary preparations are made in line with
the instructions in "Safety and environment
instructions" and "Installation" sections.
 Keep the product running without placing any
food inside for 12 hours and do not open the
door, unless absolutely necessary.
CA sound will be heard when the
compressor is engaged. It is normal to
hear sound even when the compressor is
inactive, due to the compressed liquids
and gasses in the cooling system.
CIt is normal for the front edges of the
refrigerator to be warm. These areas are
designed to warm up in order to prevent
condensation.
CFor some models, indicator panel turns
off automatically 1 minutes after the door
closes. It will be reactivated when the door
is open or any button is pressed.
ARead the “Safety Instructions” section first!

13 / 26 EN
Refrigerator / User Guide
6 Operating the Product
 Do not use any mechanical tools or any
other tools than the recommendations of the
manufacturer to speed up the thawing operation.
 Do not use parts of your refrigerator such
as the door or drawers as a support or a step.
This may cause the product to trip over or its
components to be damaged.
 The product shall be used for storing food
only.
 Turn off the water valve if you will be away
from home (e.g. at vacation) and you will not be
using the Ice Maker or the water dispenser for a
long period of time. Otherwise, water leaks may
occur.
6.1 Turning off the product

period;
- unplug it,
- remove the food to prevent odours,
- wait until the ice is thawed,
- clean the inside and wait until it is dried.
- leave the doors open to prevent damage to internal
body plastics.

14 /26 EN Refrigerator / User Guide
6 Operation of the Product
6.2 Indicator panel
Indicator panels may vary depending on the model of your product.
Audial and visual functions of the indicator panel will assist in using the refrigerator.
1*
7*
2
*356 4
C*Optional: Shown functions are optional, there may be differences of shape and location in
functions found on your device’s display panel.
Read the “Safety Instructions” section first!
1- Cooling Compartment OFF (Vacation) Function Key
2- Cooling Compartment Temperature Setting Key
3- Quick Freezing Key/Handle Light Function Setting Key
4- Energy Saving (Display Off) Indicator
5- Freezing Compartment Temperature Setting Key
6- Fault Condition Indicator
7- Compartment Conversion Key

15 / 26 EN
Refrigerator / User Guide
Using the product
1. Cooling Compartment OFF (Vacation)
Function Key
To activate vacation function ( ), press the
button for 3 seconds. The vacation mode will
be activated and the LED on the button will
be lit. “- -” shall be displayed on the Cooling
Compartment temperature indicator and the
cooling compartment does not actively perform
cooling. You shall not keep your food in the cooling
compartment when this function is activated. The
other compartments continue to cool according to
the set temperatures. Press the key for 3 seconds
again to cancel this function.
2. Cooling Compartment Temperature Setting
Key
Allows setting of temperature for cooler
compartment ( ). Pressing this key will enable
the cooling compartment temperature to be set at
8,6,4,2 °C.
3. Quick Freezing Key
When the quick freeze key is pressed, the LED
on the key is illuminated and the quick freeze
function shall be activated. Freezing compartment
temperature is set to -27 Celcius. Press the
key again to cancel function. The quick freezing
function shall be automatically cancelled after 24
hours. To freeze a large amount of fresh food,
press the quick freeze key before placing the food
in the freezer compartment.
*Handle Light Function Setting Key
Handle light function might be switched between open
and closed modes by pressing quick freezing button
( ) for 3 seconds. In the closed mode, the handle
light is only activated when the appliance door is
opened and it goes out after a while after the door is
closed. In the open mode, the handle light is activated
when the appliance door is opened, the handle light
stays on dimly after a while after the door is closed.
The handle light function is set to the ex-factory closed
mode.
4. Energy Saving (Display Off) Indicator
Energy saving function is enabled automatically
and the energy saving symbol ( ) is displayed
when the door of the product is not opened or
closed for some period of time. When the energy
saving function is active, all symbols on the screen
other than the energy saving symbol shall be
turned off. When the energy-saving function is
active, pressing any key or opening the door will
deactivate the energy-saving function and the
display signals will return to normal. The energy-
saving function is a function activated ex-factory
and cannot be cancelled.
5. Freezing Compartment Temperature
Setting Key
Temperature setting is made for cooler
compartment. Pressing the key ( ) will enable
the freezer compartment temperature to be set at
-18,-20,-22,-24 °C.
6. Fault Condition Indicator
This indicator ( ) shall be active when your
refrigerator cannot perform adequate cooling
or in case of any sensor error. On the freezer
compartment temperature indicator the letter
“E” and on the cooler compartment temperature
indicator the numbers 1, 2, 3 will be displayed.
The numbers on the indicator specifies the service
regarding the failure. If you place hot food in the
freezer compartment or leave its door open for a
prolonged time, an exclamation mark can be lit.
This is not a fault, this warning shall be removed
when the food is cooled down or when any key is
pressed.
7. Compartment Conversion Key
Pressing compartment conversion key ( ) for
3 seconds, the freezer section switches between
cooler, off and freezer modes. If it is operated
as the cooler compartment, the temperature is
set to 4 Celcius degrees. In case of OFF mode,
compartment temperature indicator shall display
“- -”.

16 /26 EN Refrigerator / User Guide
Using the product
6.3 Humidity controlled
crisper (EverFresh+)
(Optional)
Thanks to the humidity controlled crisper,
vegetables and fruits may be stored for a longer
period at an environment with ideal humidity
conditions. With the humidity setting system with
3 options in front of your crisper, you may control
the humidity inside the compartment as per the
food you store. We recommend you to store your
food by selecting vegetable option when you store
vegetables only, fruit option when you store fruit
only and mixed option when you store mixed food.
We recommend that the vegetables and fruits
shall not be stored in bags to improve the storage
period of the food and to better benefit from the
humidity control system. Leaving them in plastic
bags causes vegetables to rot in a short time.
We recommend that cucumbers and broccolis,
in particular, are not stored in closed bags. In
situations where contact with other vegetables is
not preferred, use packaging materials such as
paper that has a certain level of porosity in terms
of hygiene.
When placing the vegetables, place heavy and
hard vegetables at the bottom and light and soft
ones on the top, taking into account the specific
weights of vegetables.
Do not put fruits that have a high ethylene gas
production such as pear, apricot, peach and
particularly apple in the same crisper with other
vegetables and fruits. The ethylene gas coming out
of these fruits might cause other vegetables and
fruits to mature faster and rot in a shorter period
of time.
6.4 Blue Light/HarvestFresh
(Optional)
For Blue light,
Vegetables and fruit stored in crispers illuminated
with blue light continue to perform photosynthesis
and retain their levels of C vitamin thanks to the
effect of the wavelength of the blue light.
For HarvestFresh,
Vegetables and fruit stored in crispers illuminated
with HarvestFresh technology retain their vitamin
levels (vitamins A and C) for a longer period thanks
to the cycles of blue, green, red lights and dark
that simulate the cycle of the day.
When the door of your refrigerator is opened dur-
ing the dark period of the HarvestFresh technology,
your refrigerator shall sense this automatically and
illuminate the crisper with one of the blue, green
or red lights respectively for your convenience. The
dark period shall be continued when you close the
door of your refrigerator so that it shall represent
the night period of the day cycle.

17 / 26 EN
Refrigerator / User Guide
Using the product
6.5 Anti-Odour Module
(FreshGuard)
(This feature is optional)
Anti-odour module removes odour that occur
inside your refrigerator before it permeates on the
surfaces. Thanks to this module positioned on
the roof the fresh food compartment, bad odour is
removed while the air is actively passed through
the odour filter, and the air cleaned in the filter
is directed back to the fresh food compartment.
Thus, undesired odour that may occur during the
storage of food inside the refrigerator is removed
from the environment before it permeates on the
surfaces.
This feature is provided with the fan, LED and
odour filter placed inside the module. Anti-
odour module shall be automatically activated
periodically. If the door of the fresh food
compartment is opened while the module is
active, fan is stopped temporarily, and it continues
to operate when the door is closed. In case of a
power failure, anti-odour module starts to operate
when the power is restored.
İnfo: To prevent bad odours that may occur with
the mixture of odours from different food, we
recommend you to store aromatic food such as
cheese, olives and delicatessen in their packaging
and with their lids closed. For the safety of other
food stored and to prevent bad odours, we
recommend you to remove the food that you have
observed to be spoilt from the refrigerator as soon
as possible.

18 /26 EN Refrigerator / User Guide
Using the product
6.6 Ice bucket
(This feature is optional)
Ice bucket allows you take ice easily from the
refrigerator.
Using the ice bucket
1. Take the ice bucket from the freezer
compartment.
2. Fill the ice bucket with water.
3. Place the ice bucket into the freezer
compartment. The ice will be ready after
approximately two hours.
4. Take the ice bucket from the freezer
compartment and bend in slightly over the holder
that you are going to serve. Ice will easily pour into
the serving holder.
6.7 The dairy (cold storage) bin
The dairy (cold storage) bin ” provides lower
temperature within the refrigerator compartment.
Use this bin to store delicatessen (salami, sausages,
dairy products and etc. ) that requires lower storage
temperature or meat, chicken or fish products for
immediate consumption. Do not store fruits and
vegetables inside this bin.
6.8 Crisper
The refrigerator's crisper is designed to keep
vegetables fresh by preserving humidity. For
this purpose, the overall cold air circulation
is intensified in the crisper. Keep fruits and
vegetables in this compartment. Keep the green-
leaved vegetables and fruits separately to prolong
their life.

19 / 26 EN
Refrigerator / User Guide
Using the product
6.9 Movable Body shelf:
*optional
Manually movable body shelf is an option
enabling the usage of interior shelf volume of the
refrigerator in a flexible way.
When you want to store an item which is taller
than the distance between two shelves, slide the
manually movable body shelf holding it from its
grips as shown in the figure and this will enable
you to move the shelf upwards. By sliding the grip
to the right, you can move the manual body shelf
only 45 mm upwards.
The manually movable body shelf can only be
moved with max 10 kg load on it.
If more than 10 kg will be loaded, then it should be
used as a fixed shelf like others. In this case, if it is
required to adjust the shelf height, first empty the
food stuff, adjust it as per your height requirement
and then load it with the food stuff. The shelf is
intended to carry max. 40 kg while used as a fixed
shelf.
