Beko RSNE445E22 User manual

Lednice
Návod k použití
Холодильник
Посібник користувача
Používateľská príručka
Chladnička
RSNE445E22
EN / CZ / UK / SK
57 9959 0000/AF
1/2
Refrigerator
User manual

Please read this manual before using the product!
Dear Customer,
We'd like you to make the best use of our product, which has been manufactured in
modern facilities with care and meticulous quality controls.
Thus, we advice you to read the entire user manual before you use the product. In
case the product changes hands, do not forget to hand the guide to its new owner
along with the product.
This guide will help you use the product quickly and safely.
 Please read the user guide carefully before installing and operating the product.
 Always observe the applicable safety instructions.
 Keep the user guide within easy reach for future use.
 Please read any other documents provided with the product.
Keep in mind that this user guide may apply to several product models. The guide
clearly indicates any variations of different models.
CImportant information and
useful tips.
ARisk of life and property.
BRisk of electric shock.
The product’s packaging
is made of recyclable
materials, in accordance
with the National
Environment Legislation.

3 / 26 EN
Refrigerator/User Manual
1 Safety and environment
instructions 4
General safety ............................................... 4
Intended use .................................................. 6
Child safety ..................................................... 6
Compliance with WEEE Directive and
Disposing of the Waste Product ............ 6
Compliance with RoHS Directive.............7
Package information....................................7
2 Your refrigerator 8
3 Installation 9
Appropriate Installation Location.......... 9
Adjusting the Feet.....................................10
Electrical Connection................................10
4 Preparation 11
5 Operating the product 12
Freezing fresh food...................................14
Recommendations for preserving the
frozen food.................................................... 15
Deep-freeze information........................15
Placing the food..........................................16
Door open warning....................................16
Changing the door opening direction 16
6 Maintenance and cleaning 21
7 Troubleshooting 22

4 / 26 EN Refrigerator/User Manual
– catering and similar non-retail
applications.
1.1.General safety
 This product should not
be used by persons with
physical, sensory and mental
disabilities, without sufficient
knowledge and experience
or by children. The device
can only be used by such
persons under supervision
and instruction of a person
responsible for their safety.
Children should not be allowed
to play with this device.
 In case of malfunction, unplug
the device.
 After unplugging, wait at least
5 minutes before plugging in
again.
 Unplug the product when not
in use.
 Do not touch the plug with
wet hands! Do not pull the
cable to plug off, always hold
the plug.
 Do not plug in the refrigerator
if the socket is loose.
 Unplug the product during
installation, maintenance,
cleaning and repair.
 If the product will not be used
for a while, unplug the product
and remove any food inside.
 Do not use the product when
the compartment with circuit
cards located on the upper
back part of the product
(electrical card box cover) (1)
is open.
1. Safety and environment instructions
This section provides the safety
instructions necessary to prevent
the risk of injury and material
damage. Failure to observe these
instructions will invalidate all types
of product warranty.
Intended use
A
WARNING:
Keep ventilation openings,
in the appliance enclosure
or in the built-instructure,
clear of obstruction.
A
WARNING:
Do not use mechanical
devices or other means to
accelerate the defrosting
process, other than those
recommended by the
manufacturer.
AWARNING:
Do not damage the
refrigerant circuit.
A
WARNING:
Do not use electrical
appliances inside the food
storage compartments
of the appliance, unless
they are of the type
recommended by the
manufacturer.
This appliance is intended to be
used in household and similar
applications such as
– staff kitchen areas in shops,
offices and other working
environments;
– farm houses and by clients in
hotels, motels and other residential
type environments;
– bed and breakfast type
environments;

5 / 26 EN
Refrigerator/User Manual
Safety and environment instructions
1
1
 Do not use steam or steamed
cleaning materials for cleaning
the refrigerator and melting
the ice inside. Steam may
contact the electrified areas
and cause short circuit or
electric shock!
 Do not wash the product by
spraying or pouring water on
it! Danger of electric shock!
 In case of malfunction, do
not use the product, as it may
cause electric shock. Contact
the authorised service before
doing anything.
 Plug the product into an
earthed socket. Earthing
must be done by a qualified
electrician.
 If the product has LED
type lighting, contact the
authorised service for
replacing or in case of any
problem.
 Do not touch frozen food with
wet hands! It may adhere to
your hands!
 Do not place liquids in bottles
and cans into the freezer
compartment. They may
explode.
 Place liquids in upright
position after tightly closing
the lid.
 Do not spray flammable
substances near the product,
as it may burn or explode.
 Do not keep flammable
materials and products with
flammable gas (sprays, etc.) in
the refrigerator.
 Do not place containers
holding liquids on top of the
product. Splashing water on
an electrified part may cause
electric shock and risk of fire.
 Exposing the product to rain,
snow, sunlight and wind will
cause electrical danger. When
relocating the product, do
not pull by holding the door
handle. The handle may come
off.
 Take care to avoid trapping
any part of your hands or body
in any of the moving parts
inside the product.
 Do not step or lean on the
door, drawers and similar parts
of the refrigerator. This will
cause the product to fall down
and cause damage to the
parts.
 Take care not to trap the
power cable.

6 / 26 EN Refrigerator/User Manual
Safety and environment instructions
1.1.1 HC warning
If the product comprises a cooling
system using R600a gas, take
care to avoid damaging the
cooling system and its pipe while
using and moving the product.
This gas is flammable. If the
cooling system is damaged, keep
the product away from sources
of fire and ventilate the room
immediately.
C
The label on the inner
left side indicates the
type of gas used in the
product.
1.1.2 For models with
water dispenser
 Pressure for cold water inlet
shall be maximum 90 psi(6.2
bar). If your water pressure
exceeds 80 psi(5.5 bar), use a
pressure limiting valve in your
mains system. If you do not
know how to check your water
pressure, ask for the help of a
professional plumber.
 If there is risk of water
hammer effect in your
installation, always use a
water hammer prevention
equipment in your installation.
Consult Professional plumbers
if you are not sure that there
is no water hammer effect in
your installation.
 Do not install on the hot water
inlet. Take precautions against
of the risk of freezing of the
hoses. Water temperature
operating interval shall be
33°F (0.6°C) minimum and
100°F (38°C) maximum.
 Use drinking water only.
1.2.Intended use
 This product is designed for
home use. It is not intended
for commercial use.
 The product should be used to
store food and beverages only.
 Do not keep sensitive
products requiring controlled
temperatures (vaccines,
heat sensitive medication,
medical supplies, etc.) in the
refrigerator.
 The manufacturer assumes no
responsibility for any damage
due to misuse or mishandling.
 Original spare parts will
be provided for 10 years,
following the product
purchasing date.
1.3.Child safety
 Keep packaging materials out
of children’s reach.
 Do not allow the children to
play with the product.
 If the product’s door comprises
a lock, keep the key out of
children’s reach.
1.4. Compliance with WEEE
Directive and Disposing
of the Waste Product
This product complies with
EU WEEE Directive (2012/19/EU). This
product bears a classification symbol
for waste electrical and electronic
equipment (WEEE).
This product has been
manufactured with high
quality parts and materials
which can be reused and are
suitable for recycling. Do not
dispose of the waste product
with normal domestic and

7 / 26 EN
Refrigerator/User Manual
Safety and environment instructions
other wastes at the end of its service
life. Take it to the collection center for
the recycling of electrical and electronic
equipment. Please consult your local
authorities to learn about these
collection centers.
1.5.Compliance with
RoHS Directive
 This product complies with EU WEEE
Directive (2011/65/EU). It does
not contain harmful and prohibited
materials specified in the Directive.
1.6.Package information
 Packaging materials of the product
are manufactured from recyclable
materials in accordance with our
National Environment Regulations. Do
not dispose of the packaging materials
together with the domestic or other
wastes. Take them to the packaging
material collection points designated by
the local authorities.

8 / 26 EN Refrigerator/User Manual
2Your refrigerator
C
Figures that take place in this instruction manual are schematic and
may not correspond exactly with your product. If the subject parts are
not included in the product you have purchased, then it is valid for other
models.
 Indicator panel
 Butter & Cheese sections
 Water dispenser filling tank
 Egg section
 Water dispenser reservoir
 Bottle shelves
 Adjustable front feet
 Crispers
 Chiller
Chiller cover and glass
Movable shelves
Wine cellar
Fan
*May not be available in all models
1
*
2
*
6
8
9
10
11
12
13*
7
5
*3
4

9 / 26 EN
Refrigerator/User Manual
3Installation
3.1. Appropriate
Installation Location
Contact an Authorized Service for the
installation of the product. In order to
prepare the product for use, refer the
information in the user manual and
ensure that electrical installation and
water installation are appropriate. If not,
call a qualified electrician and technician
to have any necessary arrangements
carried out.
B
Manufacturer shall
not be held liable for damages
that may arise from procedures
carried out by unauthorized
persons.
B
WARNINGProduct must
not be plugged in during
installation. Otherwise, there
is the risk of death or serious
injury!
A
WARNING:
If the door clearance of the
room where the product shall
be place is so tight to prevent
passing of the product, remove
the door of the room and pass
the product through the door
by turning it to its side; if this
does not work, contact the
authorized service.
 
surface to prevent jolts.
 
away from heat sources such as hobs,
heater cores and stoves and at least 5
cm away from electrical ovens.
 
direct sun light and kept in humid
places.
 
provided around your product in order
to achieve an efficient operation. If the
product is to be placed in a recess in
the wall, pay attention to leave at least
5 cm distance with the ceiling and side
walls.
Installing the Plastic Wedges
Plastic wedges supplied with the
product are used to create the distance
for the air circulation between the
product and the rear wall.
 To install the wedges, remove the
screws on the product and use the
screws supplied together with the
wedges.
 Insert the 2 plastic wedges onto the
rear ventilation cover as illustrated in
the figure.

10 / 26 EN Refrigerator/User Manual
Installation
3.2. Adjusting the Feet
If the product stands unbalanced after
installation, adjust the feet on the front
by rotating them to the right or left.
3.3. Electrical Connection
AWARNING: Do not make
connections via extension
cables or multi-plugs.
B
WARNING:Damaged
power cable must be
replaced by the Authorized
Service Agent.
C
If two coolers are to be
installed side by side, there
should be at least 4 cm
distance between them.
 Our company shall not be liable
for any damages that will arise
when the product is used without
grounding and electrical connection
in accordance with the national
regulations.
 Power cable plug must be within easy
reach after installation.
 Connect your refrigerator to a
grounded outlet rated for a voltage
value of 220-240V /50 Hz. Outlet
shall have 10 to 16A fuse.
 Do not extension cords or cordless
multiple outlets between your
product and the wall outlet.
The condenser of your appliance is located on the back as shown below. In order
to achieve better energy efficiency with lower energy consumption, please pull
the condenser towards yourself as illustrated in picture below.
*may not be available in all models
better energy
efficiency
2-b
initial position
PULL
PULL

11 / 26 EN
Refrigerator/User Manual
4Preparation
 Your refrigerator should be installed at
least 30 cm away from heat sources
such as hobs, ovens, central heater
and stoves and at least 5 cm away
from electrical ovens and should not be
located under direct sunlight.
 The ambient temperature of the room
where you install your refrigerator
should at least be 5°C. Operating your
refrigerator under cooler conditions is
not recommended with regard to its
efficiency.
 Please make sure that the interior of
your refrigerator is cleaned thoroughly.
 If two refrigerators are to be installed
side by side, there should be at least 2
cm distance between them.
 When you operate your refrigerator
for the first time, please observe the
following instructions during the initial
six hours.
 The door should not be opened
frequently.
 It must be operated empty without any
food in it.
 Do not unplug your refrigerator. If
a power failure occurs out of your
control, please see the warnings in
the “Recommended solutions for the
problems” section.
 Original packaging and foam
materials should be kept for future
transportations or moving.
 The baskets/drawers that are
provided with the chill compartment
must always be in use for low energy
consumption and for better storage
conditions.
 Food contact with the temperature
sensor in the freezer compartment may
increase energy consumption of the
appliance. Thus any contact with the
sensor(s) must be avoided.
 In some models, the instrument panel
automatically turns off 5 minutes
after the door has closed. It will be
reactivated when the door has opened
or pressed on any key.
 Due to temperature change as a result
of opening/closing the product door
during operation, condensation on
the door/body shelves and the glass
containers is normal

12 / 26 EN Refrigerator/User Manual
CFigures in this user manual are schematic and may not match the product
exactly. If the subject parts are not included in the product you have
purchased, then those parts are valid for other models.
5Operating the product
1
78
12
10
11 9
235
4 6
13
1.On/Off Indicator:
This icon ( ) come on when the fridge
is turned off. All the other icons turn off.
2.Economic Usage Indicator:
This icon ( ) comes on when the
Fridge Compartment is set to 8°C which is
the most economical set value. Economic
Usage Indicator turns off when the Quick
Fridge or Quick Freeze function is selec-
ted.
3.Fridge Compartment Temperature
Setting Indicator:
Indicates the temperature set for the
Fridge Compartment.
4.Power failure/High temperature /
error warning indicator :
This light () illuminates during power
failure, high temperature failures and
error warnings. During sustained power
failures, the highest temperature that
the fridge compartment reaches will
flash on the digital display.
5. Vacation Indicator:
This icon ( )lights up when the
Vacation Function is active.
6.Key Lock Indicator:
This icon ( ) lights up when the Key
Lock mode is activated.
7.Key Lock Mode:
Press Key Lock ( ) button continuously
for 3 seconds. Key lock icon will light
up and key lock mode will be activated.
Buttons will not function if the Key Lock
mode is active. Press Key Lock button
continuously for 3 seconds again. Key
lock icon will turn off and the key lock
mode will be exite.

13 / 26 EN
Refrigerator/User Manual
Operating the product
8. Vacation Function:
When you press Vacation button,
vacation function ( ) is activated and
vacation indicator lights. You can use
this function when you will not use your
fridge for a long time. Note that there
should be no food inside your fridge,
otherwise fridge can not preserve your
food at Vacation mode.
If this function is activated, fridge
compartment temperature is kept at 15
C° in order to prevent bad smelling. Press
Vacation button again to deactivate
vacation function.
9. Fridge Set Function:
This function ( ) allows you to make
the Fridge compartment temperature
setting. Press this button to set the
temperature of the fridge compartment
to 8,7,6,5,4,3, and 1 respectively.
10. Quick Fridge Function:
Quick Fridge indicator ( ) turns on when
the Quick Fridge function is on. Press
Quick Fridge button again to cancel this
function. Quick Fridge indicator will turn
off and normal settings will be resumed.
Quick Fridge function will be cancelled
automatically 1 hours later if you do not
cancel it manually. If you want to cool
plenty amount of fresh food, press Quick
Fridge button before you place the food
into the fridge compartment.
11.On/Off Function:
This function ( ) allows you to make
the Fridge turn off when pressed for 3
seconds.The fridge could be turned on
by pressing On/Off button for 3 seconds
again .
12.Energy Saving Indicator :
If the product doors are kept closed
for a long time energy saving function
is automatically activated and energy
saving symbol is illuminated. ( )
When energy saving function is
activated, all symbols on the display
other than energy saving symbol will turn
off. When the Energy Saving function is
activated, if any button is pressed or the
door is opened, energy saving function
will be canceled and the symbols on
display will return to normal.
Energy saving function is activated
during delivery from factory and cannot
be canceled.
13.Quick Freeze Indicator :
This icon ( ) comes on when the Quick
Freeze function is on.

14 / 26 EN Refrigerator/User Manual
Operating the product
5.1. Freezing fresh food
 In order to preserve the quality of
the food, it shall be frozen as quickly
as possible when it is placed in the
freezer compartment, use the fast
freezing feature for this purpose.
 You may store the food longer in
freezer compartment when you
freeze them while they are fresh.
 Pack the food to be frozen and close
the packing so that it would not allow
entrance of air.
 Ensure that you pack your food
before putting them in the freezer.
Use freezer containers, foils and
moisture-proof papers, plastic bags
and other packing materials instead
of traditional packing papers.
 Label each pack of food by adding
the date before freezing. You may
distinguish the freshness of each
food pack in this way when you open
your freezer each time. Store the
food frozen before in the front side of
compartment to ensure that they are
used first.
CThe freezer compartment
defrosts automatically.
 Frozen food must be used
immediately after they are thawed
and they should not be re-frozen.
 Do not freeze too large quantities of
food at one time.

15 / 26 EN
Refrigerator/User Manual
Operating the product
Freezer
Compartment
Setting
Fridge
compartment
Setting
Remarks
-18°C 4°C This is the normal recommended setting.
-20,-22 or -24°C 4°C These settings are recommended when the
ambient temperature exceeds 30°C.
Quick Freeze 4°C
Use when you wish to freeze your food in a short
time. Your product will return to its previous
mode when the process is over.
-18°C or colder 2°C
Use these settings if you think that your fridge
compartment is not cold enough because of the
hot ambient conditions or frequent opening and
closing of the door.
5.2. Recommendations for
preserving the frozen food
Compartment shall be set to -18°C at least.
 Put packages in the freezer
as quickly as possible after purchase
without allowing the to thaw.
 Check whether the "Use By" and
"Best Before" dates on the packaging are
expired or not before freezing it.
 Ensure that the package of the
food is not damaged.
5.3. Deep-freeze
information
According to IEC 62552 standards, the
product shall freeze at least 4.5 kg of
food at 32°C ambient temperature to
-18°C or lower within 24 hours for every
100-litres of freezer volume.
It is possible to preserve the food for
a long time only at -18°C or lower
temperatures.
You can keep the freshness of food
for many months (at -18°C or lower
temperatures in the deep freeze).
Foods to be frozen should not be allowed
to come in contact with the previously
frozen items to prevent them from
getting thawed partially.
Boil the vegetables and drain their water
in order to store vegetables for a longer
time as frozen. After draining their
water, put them in air-proof packages
and place them inside the freezer. Food
such as bananas, tomatoes, lettuce,
celery, boiled eggs, potatoes are not
suitable for freezing. When these foods
are frozen, only their nutritional value
and taste shall be affected negatively.
They shall not be spoiled so that they
would create a risk for human health.

16 / 26 EN Refrigerator/User Manual
Operating the product
5.4. Placing the food
Freezer
compartment
shelves
Various frozen food
such as meat, fish,
ice cream, vegetables
and etc.
Refrigerator
compartment
shelves
Food in pans, covered
plates and closed
containers, eggs (in
closed container)
Door shelves
of fridge
compartment
Small and packaged
food or beverage
Crisper Vegetables and fruits
Fresh zone
compartment
Delicatessen
(breakfast food,
meat products that
shall be consumed in
a short time)
5.5. Door open warning
(This feature is optional)
An audio warning signal will be given
when the door of your product is left
open for at least 1 minute. This warning
will be muted when the door is closed
or any of the display buttons (if any) are
pressed.
Door open warning is given to user both
visually and acoustically. If the warning
continues for 10 minutes, interior lights
will be turned off.
5.6. Changing the door
opening direction
Door opening direction of your refrige-
rator can be changed according to the
place you are using it.If this is neces-
sary, please call your nearest Authorized
Service.
Above description is a general expressi-
on.For information on changing the ope-
ning direction of the door, you must refer
to the warning label located on the inner
side of the door.

17 / 26 EN
Refrigerator/User Manual
Operating the product
Using the water dispenser
* May not be available in all models
CIt is normal for the first few
glasses of water taken from
the dispenser to be warm.
CIf the water dispenser is
not used for a long period
of time, dispose of first few
glasses of water to obtain
fresh water.
1. Push in the lever of the water
dispenser with your glass. If you
are using a soft plastic cup, pushing
the lever with your hand will be
easier.
2. After filling the cup up to the level
you want, release the lever.
CPlease note, how much
water flows from the
dispenser depends on how
far you depress the lever. As
the level of water in your cup
/ glass rises, gently reduce
the amount of pressure on
the lever to avoid overflow.
If you slightly press the
arm, the water will drip; this
is quite normal and not a
failure.

18 / 26 EN Refrigerator/User Manual
Operating the product
Filling the water
dispenser's tank
Water tank filling reservoir is located
inside the door rack.
1. Open the cover of the tank.
2. Fill the tank with fresh drinking water.
3. Close the cover.
CDo not fill the water tank
with any other liquid except
for water such as fruit juices,
carbonated beverages or
alcoholic drinks which are not
suitable to use in the water
dispenser. Water dispenser
will be irreparably damaged
if these kinds of liquids are
used. Warranty does not cover
such usages. Some chemical
substances and additives
contained in these kinds of
drinks/liquids may damage the
water tank.
CUse clean drinking water only.

19 / 26 EN
Refrigerator/User Manual
Operating the product
CCapacity of the water tank is 3
litres; do not overfill.
Cleaning the water tank
1. Remove the water filling reservoir inside
the door rack.
2. Remove the door rack by holding from
both sides.
3. Grab the water tank from both sides and
remove it with an angle of 45°C.
4. Remove the cover of the water tank and
clean the tank.
CComponents ofthewatertank
and water dispenser should not
be washed in dishwasher.

20 / 26 EN Refrigerator/User Manual
Operating the product
Drip tray
Water that dripped while using the
water dispenser accumulates in the
spillage tray.
Remove the plastic filter as shown in
the figure.
With a clean and dry cloth, remove the
water that has accumulated.
