Beko WM 5140 S User manual

WM 5140 W
WM 5140 S
Automatic
washing machine

Please read this manual first!
Dear Customer,
We hope that your product which has been manufactured in modern facilities
and passed through a strict quality control procedure will give you the best
results.
Therefore, we advise you to read through this manual carefully before using
your product and keep it for future reference.
This operation manual will…
…help you use your machine in a fast and safe way.
 •PleasereadtheOperationManualbeforeinstallingandstartingyour
machine.
 •Particularlyfollowtheinstructionsrelatedtosafety.
 •KeepthisOperatingManualwithineasyreach.Youmayneeditinthe
future.
 •Pleasereadalladditionaldocumentssuppliedwiththismachine.
PleasenotethatthisOperatingManualmaybeapplicableforseveralother
models. Differences between models will be identified in the manual.
Explanation of symbols
ThroughoutthisOperationManualthefollowingsymbolsareused:
CImportant information or useful hints about usage.
AWarning for hazardous situations with regard to life and property.
BWarning for supply voltage.
This appliance’s packaging material is recyclable. Help recycle it and protect
the environment by dropping it off in the municipal receptacles provided for this
purpose.Yourappliancealsocontainsagreatamountofrecyclablematerial.
It is marked with this label to indicate the used appliances that should not be
mixed with other waste. This way, the appliance recycling organised by your
manufacturer will be done under the best possible conditions, in compliance
with European Directive 2002/96/EC on Waste Electrical and Electronic
Equipment. Contact your town hall or your retailer for the used appliance
collection points closest to your home. We thank you doing your part to
protect the environment.

EN
3
TABLE OF CONTENTS
1 Your Washing Machine 4
Overview 4
Specifications 5
2 Warnings 6
General Safety 6
First Use 6
Intended use 6
Safety instructions 6
If there are children in your house... 7
Electrical connection 7
3 Installation 9
Removing packaging reinforcement 9
Openingthetransportationlocks 9
Appropriate installation location 9
Adjusting the feet 9
Connecting to the water supply. 10
Connecting to the drain 10
Electrical connection 11
Destroying the packaging material 11
Disposing of the old machine 11
4 Initial preparations for
washing 12
Sorting the laundry 12
Preparingclothesforwashing 12
Correct load capacity 12
Loading door 13
Detergents and softeners 13
5 Selecting a Program and
Operating Your Machine 15
Control panel 15
Turning the machine on 16
Programselection 16
Spin Speed selection 17
Extra Rinse 18
Programselectionandconsumption
table 18
Auxiliary functions 19
Time delay 19
StartingtheProgram 20
Progressingaprogram 20
Changing the program after the program
has started 20
Child-proof lock 21
Ending the program through canceling
21
End of program 21
6 Quick instructions for
daily use 22
7 Cleaning and care 23
Detergent drawer 23
The door and the drum 23
Outercabinetandcontrolpanel 23
Inlet water filters 23
Draining any remaining water and
cleaning the pump filter 24
8 Troubleshooting 26
9 Guarantee 34
10 Service 35

EN
4
Top Lid
Detergent Drawer
ControlPanel
Height-adjustable Feet
Door
Filter Cap
1
2
3
4
5
6
Overview
1 Your Washing Machine
Figure 1
1
2
3
4
5
6

EN
5
Specifications
Specifications of this appliance may change without notice to improve the quality of
the product. Figures in this manual are schematic and may not match your product
exactly.
Values stated on the machine labels or in the documentation accompanying it are
obtained in laboratory in accordance with the relevant standards. Depending on
operational and environmental conditions of the appliance, values may vary.
Models
Maximumdrylaundrycapacity(kg)
Height(cm)
Width(cm)
Depth(cm)
NetWeight(kg)
Electricity(V/Hz.)
TotalCurrent(A)
TotalPower(W)
Spinningcycle(rpmmax.)
WM5140W WM5140S
5 5
84 84
60 60
45 45
61 61
230 V / 50hz 230 V / 50hz
10 10
2200 2200
1400 1400

EN
6
Pleasereadthefollowinginformation.
Otherwise,theremaybetheriskof
personal injury or material damage.
Moreover,anywarrantyandreliability
commitment will become void.
General Safety
• Neverplaceyourmachineona
carpetcoveredfloor.Otherwise,
lack of airflow from below your
machine may cause electrical
parts to overheat. This may cause
problems with your washing
machine.
• Ifthepowercableormainsplugis
damaged you must call Authorized
Service for repair.
• Checkwaterhosesforwear.Do
not use old/used water inlet hoses.
These may cause stains on your
laundry.
• Fitthedrainhoseinto the waste
water system securely to prevent
any water leakage and to allow
machine to take in and discharge
water as required. It is very
important that the water intake
and drain hoses are not folded,
squeezed, or broken when the
appliance is pushed into place after
it is installed or cleaned.
• Yourwashingmachineisdesigned
not to continue operating in the
eventofapowerinterruption.You
cannot cancel any program by
pressingthe“On/Offbutton.”Your
machine will not resume its program
whenthepowerrestores.Press
the“Start/Pause/Cancel”buttonfor
3 seconds to cancel the program
(See,CancellingaProgram)
• Theremaybesomewaterinyour
machine when you receive it. This is
from the quality control process and
is normal. It is not harmful to your
machine.
• Someproblemsyoumayencounter
may be caused by the software.
Press“Start/Pause/Cancel”button
for 3 seconds to cancel the program
set in your machine before calling
the authorized service.
First Use
• Toprepareyourmachinefor
washing, carry out your first washing
process without loading your
machine and with detergent under
“Cottons90°C”program.
• Ensurethatthecoldwater
connections has been made
correctly when installing your
machine.
• Ifthecurrentfuseorcircuitbreaker
is less than 15 Amperes, please
have a qualified electrician install a
15 Ampere fuse or circuit breaker.
• Tomakeyourmachinereadyfor
use, please be sure that the tap
water supply and water drainage
systems are appropriate before
calling the authorized service. If they
are not, call a qualified plumber to
have any necessary arrangements
carried out.
Intended use
• Thisproducthasbeendesignedfor
home use.
• Theappliancemayonlybeusedfor
washing and rinsing of textiles that
are marked accordingly.
• Onlydetergents,softenersand
supplements suitable for washing
machines may be used.
• Observethecareinstructions
labelled on textile products and
any other instructions given by
companies that produce detergents
for your machine.
Safety instructions
• Thisappliancemustbeconnected
to an earthed outlet protected by a
fuse of suitable capacity.
• Thesupplyanddraininghosesmust
2 Warnings

EN
7
always be securely fastened and
remain in an undamaged state.
• Fitthedraininghoseto a washbasin
or waste system securely before
starting up your machine. There may
be a risk of being scalded due to
high washing temperatures!
• Neveropenthedoororremovethe
filter while there is still water in the
drum.Otherwise,theremaybethe
risk of flooding and possible injury
due to the hot water.
• Neverforceopenthelockeddoor!
The door will be ready to open just a
few minutes after the washing cycle
comes to an end.
• Unplugthemachinewhenitisnotin
use.
• Neverwashdowntheappliance
with a water hose! There is the risk
of electric shock! Always disconnect
from the mains by unplugging before
cleaning.
• Nevertouchtheplugwithwet
hands. Never unplug by pulling
on the cable, always pull out from
the plug only. Do not operate the
machine if the power cord or plug is
damaged.
• Neverattempttorepairthemachine
yourself.Otherwise,youmaybe
putting yours and other’s lives in
danger.
• Formalfunctionsthatcannot
be solved by information in the
operatingmanual:
Turn off the machine, unplug it, turn
off the water tap and contact an
authorized service agent.
If there are children in your
house...
• Electricalappliancesmaybe
dangerousforthechildren.Keep
children away from the machine
when it is operating. Do not let them
tamper with the machine.
• Closethedoorwhenyouleavethe
area where the machine is located.
• Storealldetergentsinasafeplace
out of reach of the children.
Electrical connection
Makesurethatyouhaveanearthed
power outlet socket rated at 13 amps
(minimum).
Attention!
If you use your machine as built-in,
the socket must be reachable after
installation,oraseparateswitch(which
candisconnectthetwopoles)mustbe
used in the installation.
Connect the power cord to the
appropriate electrical socket with an
equivalent current rating indicated on the
rating plate at the front of the machine
behind the kick plate.
After removing the plug from its transit
position, please insert the plug seal
to prevent water spillage entering the
machine.
Electrical requirements
Before you insert the plug into the wall
socket make sure that the voltage and
the frequency shown in the rating label
corresponds to your electricity supply.
We recommend that this appliance be
connected to the mains supply via a
suitable switched and fused socket in a
readily accessible position.
Should the mains lead of the appliance
become damaged or need replacing
at any time, it must be replaced by a
special purpose made mains lead which
can only be obtained from a Authorised
Service Agent.
B This appliance must be earthed
If the fitted moulded plug is not suitable
for your socket, then the plug should be
cut off and an appropriate plug fitted.
Destroy the old plug, which is cut off as
a plug with a bared cord could cause a
shock hazard if inserted into a socket
elsewhere in the house.
The moulded plug on this appliance
incorporates a 13A fuse. Should the fuse
need to be replaced an ASTA approved
BS1362 fuse of the same rating must
be used. Do not forget to refit the fuse

EN
8
cover. In the event of losing the fuse
cover, the plug must not be used until a
replacement fuse cover has been fitted.
Colour of the replacement fuse cover
must be the same colour as that visible
on the pin face of the plug. Fuse covers
are available from any good electrical
store.
Important
Fitting a different plug
As the colours of the wires in the
mains lead of this appliance may not
correspond with the coloured markings
identifying the terminals on your plug,
proceedasfollows:
1 Connect the green - yellow or green
(earth)wiretotheterminalinthe
plug marked ‘E’ or with the symbol
f or coloured green and yellow or
green.
2 Connecttheblue(neutral)wireto
the terminal in the plug marked ‘N’
or coloured black.
3 Connectthebrown(live)wiretothe
terminal in the plug marked ‘L’ or
coloured red.
With the alternative plugs a 13A fuse
must be fitted either in the plug or
adaptor or in the main fuse box. If in
doubt contact a qualified electrician.

EN
9
Removing packaging
reinforcement
Tilt the machine to remove the
packaging reinforcement. Remove the
packaging reinforcement by pulling the
ribbon.
Opening the transportation
locks
CTransportation safety bolts must
be removed before operating the
washingmachine!Otherwise,the
machine will be damaged!
1. Loosen all the bolts with a spanner
untiltheyrotatefreely(“C”)
2. Remove transportation safety bolts
by turning them gently.
3. Fitthecovers(suppliedinthebag
withtheOperationManual)intothe
holesontherearpanel.(“P”)
C Keepthetransportationsafety
bolts in a safe place to reuse when
the washing machine needs to be
moved again in the future.
CNever move the appliance without
the transportation safety bolts
properly fixed in place!
Appropriate installation
location
Install the appliance in environments
which have no risk of freezing, in a
stable and level position.
CThe floor must be capable of
carrying the load on it!
C If the washing machine and a drier
are placed on top of each other,
their approximate weight together
may reach 180 kg when they are
full.
Important:
• Donotplacetheapplianceontopof
the power cable.
• Keepatleast1cmdistancefromthe
edges of other furniture.
• Placethemachineonafirmsurface;
do not position it on a long pile rug
or such like surfaces.
Adjusting the feet
CDo not use any tools to loosen the
locknuts.Otherwise,theycanbe
damaged.
1. Manually(byhand)loosenthelock
nuts on the feet.
3 Installation

EN
10
2. Adjust them until the machine
stands level and firm.
3. Important:Tightenalllocknutsup
again.
Connecting to the water
supply.
Important:
• Thewatersupplypressurerequired
to run the machine must be 1-10
bar(0,1–1MPa).(Practically,itis
necessarytohave10–80liters
of water flowing from the tap in
one minute to have your machine
runsmoothly.)Attachapressure-
reducing valve if the water pressure
is higher.
• Connectthespecialhosesupplied
with the machine to the water intake
valves on the machine.
• Inordertopreventwaterleakage
that may occur at the connection
points,therearerubberseals(4
seals for the models with double
water inlet and 2 seals for other
models)attachedtothehoses.
These seals should be used at the
tap and machine connection ends of
the hoses. The plain end of the hose
fitted with a filter must be attached
to the tap and the elbowed end
must be attached to the machine.
Tighten the nuts of the hose well by
hand;neverusewrenchestotighten
the nuts.
• Openthetapscompletelyafter
making the hose connection to
check if there is any water leakage
at the connection points. Turn off
the tap and remove the nut in case
of any leakage. Retighten the nut
carefully after checking the seal.
To prevent any water leakage and
any other damage to be caused by
it, keep the taps closed when the
machine is not in use.
• Modelswithasinglewaterinlet
should not be connected to the
hot water tap. Laundry may be
damaged or the appliance may
switch to protection mode and not
work.
When returning the appliance to its
place after maintenance or cleaning,
care should be taken not to fold,
squeeze or block the hoses.
Connecting to the drain
The water discharge hose can be
attached to the edge of a washbasin
or waste water system. The drain hose
should be firmly fitted into the drain as
to not loosen in its housing.
Important:
• Theendofthedrainhosecan
be directly connected to the
wastewater drain or to the
washbasin. The fitting must be
secured in all types of connections.
Yourhousemaybefloodedifthe

EN
11
hose falls out of its housing during
water discharging.
• Thehoseshouldbeattachedtoa
height of at least 40 cm, and 100
cm at most.
• Incasethehoseiselevated
after laying it on the floor level or
closetotheground(lessthan
40cmabovetheground),water
discharge becomes more difficult
and the laundry may come out wet.
Therefore, the heights described in
the figure should be followed.
• Topreventdirtywaterrefillingthe
machine, and to allow for easy
discharge, the end of the hose
must not be submerged in the drain
water. The end of the hose must be
able to take in air. The hose should
be pushed into the drainage for
more than 15 cm. If it is too long
you may have it shortened.
• Theendofthehoseshouldnotbe
bent, it should not be stepped on
and it must not be folded between
the drain and the machine.
• Thelengthofthehoseistooshort,
you may add an extension hose
to the original section. The length
of the hose must not be longer
than 3.2 m after coming out of the
machine. To avoid water leakage
failures, the connection between the
extension hose and the drain hose
of the product must be fitted well
with an appropriate clamp as not to
come off and leak.
Electrical connection
Connect the machine to an earthed
outlet protected by a fuse of suitable
capacity.
Important:
• Connectionshouldcomplywith
national regulations.
• Powercordplugmustbewithin
easy reach after installation.
• Thevoltageandtheallowedfuse
protection are specified in the
section“TechnicalSpecifications”.
• Thespecifiedvoltagemustbeequal
to your mains voltage.
• Connectionviaextensioncordsor
multi-plugs should not be made.
BA damaged power cable must be
replaced by a qualified electrician.
BThe appliance must not be operated
whilst faulty until it as been repaired!
There is the risk of electric shock!
Destroying the packaging
material
Packagingmaterialcanbedangerousto
children.Keepthepackagingmaterials
out of reach of children or dispose
them by classifying according to waste
directives. Do not dispose of them
together with normal domestic waste.
Packagingmaterialsofyourmachineare
manufactured from recyclable materials.
Disposing of the old machine
Dispose of your old appliance in an
environmental friendly manner.
• Youmayrefertoyourlocalagentor
solid waste collection center in your
municipality to learn how to dispose
of your machine.
Before disposing of your old washing
machine, cut off the mains plug and
make the door lock unusable.

EN
12
Sorting the laundry
• Sortthelaundryaccordingtotype
of fabric, color, and degree of soiling
and permissible water temperature.
Always follow the advice on the
garment labels.
Preparing clothes for washing
Laundry items with metal attachments
such as, bras, belt buckles and metal
buttons will damage the machine.
Remove metal attachments or place the
items in a clothing bag, pillow case, or
something similar.
• Emptypocketsandremoveall
foreign objects such as coins, pens
and paper clips. If possible, turn
pockets out and brush.
• Placesmallitemslikeinfants’
socks and nylon stockings, etc.
in a laundry bag, pillow case or
something similar. This will also save
your laundry from getting lost.
• Placecurtainsinthemachinewith
care. Remove curtain rails and
pullers.
• Fastenzippers,sewloosebuttons
and mend rips and tears.
• Wash“machinewashable”or“hand
washable”labelledproductsonly
with an appropriate program.
• Donotwashcoloursandwhites
together. New, dark coloured
cottons may release a lot of dye.
Wash them separately.
• Toughstainsmustbetreated
properly before washing. If you are
not sure, check with a dry cleaner.
• Useonlydyes/colourchangersand
lime removers suitable for machine
wash. Always follow the instructions
on the packaging.
• Washtrousersanddelicateclothes
turned inside out.
• KeeplaundryitemsmadeofAngora
wool in the freezer for a few hours
before washing. This will reduce
pilling.
Correct load capacity
• Themaximumloadcapacity
depends on the type of laundry, the
degree of soiling and the washing
program you wish to use.
CThe machine adjusts the amount of
water according to the amount of
laundry placed inside.
C Pleasefollowtheinformationinthe
"ProgramSelectionTable".Washing
results will degrade when the
machine is overloaded.
Suitable for
drier Do not dry with drier
Can be ironed
with hot iron Can be ironed with
warm iron
Dry on a
hanger
Do not iron
Washing water
temperature
Do not use
bleach
Bleach can be
used
Non machine-
washable
Hang without
spinning
Do not
dry-clean
Dry
horizontally
Do not wash
Dry-cleanable
Wash with
sensitive, short
programs.
4 Initial preparations for washing

EN
13
Following weights are given as
examples.
Laundry type Weight(gr.)
Bathrobe 1200
Napkin 100
Duvet cover 700
Bed Sheet 500
Pillowcase 200
Tablecloth 250
Towel 200
Evening gown 200
Underclothing 100
Men’soveralls 600
Men’sshirt 200
Men’spyjamas 500
Blouse 100
Loading door
The door is locked during program
operation. The door can be opened after
some time following the program end.
• Openthedoor.
• Placelaundryitemslooselyinthe
machine.
• Pushthedooruntilitclicksinto
place tightly. Ensure that no items
are caught in the door.
Detergents and softeners
Detergent drawer
The detergent drawer is composed of
threecompartments:
The detergent dispenser may be in two
different types according to the model of
your machine.
-(I)forprewash
-(II)formainwash
-(III)siphon
–( )forsoftener
Detergent, softener and other
cleaning agents
Add detergent and softener before
starting the washing program.
Never open the detergent dispenser
drawer while the washing program is
running!
When using a program without pre-
wash, no detergent should be put
into the pre-wash compartment
(Compartmentno.I).
A program without pre-wash should
not be selected if a detergent bag or
a dispensing ball is going to be used.
Youcanplacethedetergentbagor
the dispensing ball directly among the
laundry in your machine.
Choosing the detergent type
The type of detergent to be used
depends on the type and colour of
fabric.
• Usedifferentdetergentsforcoloured
and white clothes.
• Washwoolenswithaspecial
detergent specifically for woolens.
• Useonlydetergentsmanufactured
specifically for washing machines.
Detergent quantity
The amount of washing detergent to
be used depends on the amount of
laundry, the degree of soiling and water
hardness.
• Donotuseamountsexceeding
the quantities recommended on
the package to avoid problems
of excessive foam, poor rinsing,
financial savings and finally,
environmental protection.
• Usesmallamountsofdetergentata
suitable measure for small amounts
of laundry or for only slightly soiled
laundry.
• Useexactmeasuresforhighly
concentrated detergents.

EN
14
Detergent
quantity
for prewashing 1/2 measure
for main
washing 1 measure
with hard water an additional
1/2 measure
Softener
Putthesoftenerintothesoftener
compartment of the detergent
dispenser.
• Usetheproportionsrecommended
on the packet.
• Neverexceedthe(>max<)level
marking;otherwise,thesoftenerwill
be wasted without being used.
• Ifthesoftenerhaslostitsfluidity,
dilute dense softener with water
before placing it in the detergent
drawer.
Liquid detergent
When using liquid or gel washing
detergents,pleasenotethefollowing:
• Theliquiddetergentmayleave
stains on your laundry if time delay
feature is selected.
• Donotuseliquiddetergentifyou
want to wash using the time delay
feature.
• Donotuseliquiddetergentforthe
main wash in a cycle with pre-wash.
• Usethedetergentmanufacturer’s
measuring cup and follow the
instructions on the package.
Starch
• Addliquidstarch,powderstarch
or the dyestuff into the softener
compartment as instructed on the
package.
• Neverusefabricsoftenerandstarch
together in the same washing cycle.
• Wipetheinsideofthedrumafter
using starch.
Eliminating lime formation
• Whenrequired,useonlyappropriate
lime removers developed specifically
for washing machines and always
follow the instructions on the
package.

EN
15
1-On/OffButton
2-TemperatureAdjustmentKnob*
3-ProgramFollow-upIndicator*
4-Child-proofLockIndicator*
5-SpinSpeedAdjustmentKnob*
6-ProgramSelectionKnob
7-TimeDelayingButton*
8-AuxiliaryFunctionKeys
9-Start/Pause/CancelButton
*Accordingtoyourmachine’smodel
Control panel
Figure 2
5 Selecting a Program and Operating Your Machine
Time
Delay
3h
6h
9h
Ready Wash Spin/End
Prewash Extra Rinse
Start / Pause
Cancel
On/Off
40°
Delicates
Cold
Hand Wash
Drain
Spin
Rinse
30°
40º
Synthetics
Woollens
60°
40°
30°
Cottons
60°
90°
40°
No
Spin
800
1000
600
1200
1400
Quick
Wash
Intensive
40°
Intensive &
Stain 60°
1
6
93
58
7

EN
16
Turning the machine on
Preparethemachineforprogram
selectionbypressingthe“On/Off”
button.When“On/Off”buttonis
pressed,“Ready”lightilluminates
indicating that the door is ready to be
opened.Pressthe“On/Off”buttonagain
to shut down the machine.
C Pressingthe“On/Off”buttondoes
not necessarily mean the program
hasstarted.Press“Start/Pause/
Cancel”buttontoallowthemachine
start the program.
Program selection
Select the appropriate program from the
program table and the following washing
temperature table according to type,
amount and degree of soiling of the
laundry. Select the desired program with
the program selection button.
C Each of these main programmes
comprise of a complete washing
process, including washing, rinsing
and, if required, spin cycles.
90˚C
Normally soiled, white
cottonsandlinens.(Ex.:
coffee table covers,
tablecloths, towels, bed
sheets)
60˚C
Normally soiled, fade proof
colored linens, cottons
or synthetic clothes
(Ex.:shirts,nightgowns,
pajamas)andlightlysoiled
whitelinenclothes(Ex.:
underwear)
40˚C-
30°C-
Cold
Fordelicateclothes(Ex.:
lacecurtains),blended
clothes including synthetics
and woolens.
C Programsarelimitedwiththe
highest spin speed appropriate for
that particular type of cloth.
C Sort the laundry according to type
of fabric, color, degree of soiling and
permissible water temperature when
choosing a program.
C Always select the lowest required
temperature. Higher temperature
means higher power consumption.
C For further program details, see,
“ProgramSelectionTable”
Main programs
Depending on the type of textile, the
followingmainprogramsareavailable:
•Cottons
Youcanwashyourdurableclotheswith
this program. Washes with vigorous
washing movements in a longer
washing cycle. It is recommended for
yourcottonitems(suchasbedsheets,
duvet and pillowcase sets, bathrobes,
underclothing,etc.).
•Synthetics
Youcanwashyourlessdurableclothes
on this program. Washes with gentler
washing movements and in shorter
washing cycles. It is recommended for
yoursyntheticclothes(suchasshirts,
blouses, synthetic/cotton blended
garments,etc.).Forcurtainsandlace,
usingthe“Synthetic40”programwith
pre-wash and anti-creasing functions
selected is recommended. Detergent
should not be put in the pre-wash
compartment. Less detergent should be
put in the main wash compartment as
looseknitfabrics(lace)foamtoomuch
due to its meshed structure.
•Delicates
Youcanwashyourdelicateclothes
on this program. It has more sensitive
washing movements and does not make
intermediate spinning compared to the
synthetic program. It must be used for
clothes for which sensitive washing is
recommended.
•Woollens
Youcanwashyourmachine-washable
woolen garments on this program. Wash
by selecting the proper temperature
according to the labels of your clothes.
It is recommended to use appropriate
detergents for woolens.
•Hand Wash
Youcanwashyourwoolen/delicate

EN
17
clothes that bear “not machine-
washable”labelsforwhichhandwash
is recommended on this program. It
washes the laundry with very tender
washing movements without damaging
your clothes.
Additional programs
For special cases, there are also extra
programsavailable:
CAdditional programs may differ
according to the model of your
machine.
• Baby
Increased hygiene is provided by a
longer heating period and an additional
rinse cycle. It is recommended for baby
clothes and clothes worn by allergic
people.
• Intensive
Youcanwashyourdurableandheavily
soiled clothes on this program. This
program washes for a longer time
and an extra rinse cycle will be made
comparedtothe“Cottons”program.
Youcanuseitforyourheavilysoiled
clothes that you wish to be rinsed gently.
• Duo
Youcanusethisprogramtowash
cottons and synthetics together without
needing to sort them.
• Mini
This program is used to quickly wash
a small number of lightly soiled cotton
garments.
Special programs
For specific applications, you can select
anyofthefollowingprograms:
• Rinse
This program is used when you want to
rinse or starch separately.
• Spin
This program spins with maximum
possible rpm in the default setting.
C Youshouldusealowerspinspeed
for delicate laundries.
• Pump
This program is used to discharge the
water of the clothes soaked into water in
the machine.
Spin Speed selection
Youcanhaveyourclothesspunat
the maximum rpm selection on your
machine by using the selection knob in
models equipped with an rpm selection
knob. In order to protect your clothes,
your machine will not spin above 800
rpm on synthetic programs and 600 rpm
on woolens program. Furthermore, if
you want to skip the spin cycle and take
your clothes out, turn the rpm selection
knobto“nospin”position.
CYoucanusenospinfunctioninorder
to drain the water without spinning
at the end of the program.

EN
18
Programme
Max.Load(kg) ProgrammeDuration(~min) WaterConsumption(l) EnergyConsumption(kWh) Prewash Quick Wash RinsePlus Anti-Creasing Rinse Hold Spin speed reduction No Spin
Cottons 90 5 150 50 1.70 •••••••
Cottons 60** 5 140 47 0.95 •••••••
Cottons 40 5 120 47 0.65 •••••••
Intensive 60 5 160 55 1.00 • • • •
Synthetics 60 2.5 115 50 0.95 •••••••
Synthetics 40 2.5 100 50 0.50 •••••••
Synthetics 30 2.5 90 50 0.30 •••••••
Delicate 40 2 70 55 0.35 •••••
Woollens 40 1.5 55 45 0.30 • • • •
Hand wash 30 1 40 35 0.15 • •
Program selection and consumption table
•:Selectable
*:Automaticallyselected,notcancellable.
**:EnergyLabelprogramme(EN60456)
Water and power consumption and program duration may differ from the table
subject to changes in water pressure, water hardness and temperature, ambient
temperature, type and amount of laundry, selection of auxiliary functions, and
changes in electric voltage.
CThe auxiliary functions in the table may differ according to the model of your
machine.
Extra Rinse

EN
19
Auxiliary functions
Auxiliary function selection keys
Select the required auxiliary functions
before starting the program.
CAuxiliary function buttons may differ
according to the model of your
machine.
Auxiliary function selection
If an auxiliary function that should not
be selected together with a previously
selected function is chosen, the first
selected function will be cancelled and
the last auxiliary function selection will
remain active.
Forexample:Ifyouwanttoselectpre-
wash first and then quick wash, pre-
wash will be cancelled and quick wash
will remain active.
Auxiliary function that is not compatible
with the program cannot be selected.
(see“ProgramSelectionTable”)
Pre-wash
A pre-wash is only worthwhile for heavily
soiled laundry. Without pre-wash you
save energy, water, detergent and time.
C Pre-washwithoutdetergentis
recommended for lace and curtains.
Less detergent should be put in the
main wash compartment as loose
knitfabrics(lace)foamtoomuch
due to its meshed structure.
Time Save
This function can be used for cottons
and synthetics programs. It decreases
the washing times for lightly soiled
laundries and also the number of rinsing
steps. Shortens the program time
approximately 45 minutes.
Extra rinse
With this function, you can increase the
number of current rinsing steps. Thus,
sensitive skins’ risk of being affected by
the remainder detergent on the clothes
will be decreased.
Rinse hold
If you do not want to unload your
clothes immediately after the cotton,
synthetics, woolen and delicate fabrics
program, you may release your clothes
inside the machine in the last rinsing
water by pressing the rinse hold button
in order to prevent your clothes become
wrinkled.Youcanspinbypressing
“Start/Pause/Cancel”buttonafterthis
process.
Anti-creasing
This function reduces drum movement
and limits the spinning speed to prevent
creasing. In addition, washing is carried
out at a higher water level.
CUse this function for delicate
laundries that crease easily.
CWhenever you select this auxiliary
function, load your machine with half
of the maximum laundry specified in
the program table.
Reducing Speed
Youmayusethespeedreduction
button whenever you wish to spin
your clothes below the maximum spin
speed. When speed reduction button
is pressed, spin speed will be at the
minimum rpm given on the panel.
No spin
Youmayusethisprogramifyoudonot
want to spin your clothes at the end of
cottons, synthetics, woolen or delicate
programs.
Time delay
Applies for models with time delay function
If you wish to wash your clothes at a
later time, with the time delay function
you can delay the program start up 3
hours, 6 hours or 9 hours.
1. Opentheloadingdoor,placethe
laundry inside and fill detergent
drawer.
2. Set the washing program,
temperature, spin speed and, if
required, the auxiliary functions.
3. When the time delaying button is
pressed once, a 3 hour delay is
selected and the relevant led lights.
When the same button is pressed
again,6hours;andifpressed
once more, 9 hours delay will be
selected. If the time delaying button
is pressed one more time, time
delaying function will be cancelled.

EN
20
Set the time delay as you require.
4. Delayed operation of the selected
program is started by pressing the
“Start/Pause/Cancel”buttonafter
making the time delay selection.
C Morelaundrymaybeloaded/
removed during the time delay
period.
Changing and canceling the time
delay.
1. Pressthe“Start/Pause/Cancel”
button to switch the machine to
“Pause”mode.
2. Press“Start/Pause/Cancel”button
to start the program after making
the new time delay selection.
CIn the event that any of the lights
of 3-6-9 options does not light up
after selecting the new time delay,
it means that time delay function is
cancelled.
Starting the Program
1. Press“Start/Pause/Cancel”button
to start the program.
2. “Start/Pause/Cancel”buttonwill
light up to indicate that the program
has started.
3. Thedoorislockedandthe“Ready”
light fades.
Progressing a program
Progressofarunningprogramisshown
through the program follow-up indicator.
At the beginning of every program step,
the relevant indicator lamp will illuminate
and the light of the completed step
will turn off. The symbol that is lit up
at the far right of the series of symbols
indicates the step that is being carried
out.
The“Wash”lightontheprogramfollow-
up indicator illuminates when “Start/
Pause/Cancel”buttonispressedafter
selectingthewashingprogram.“Spin”
lamp will light up at the final spin step.
The“Ready”lampwilllightupagain
when the program is over and the door
is unlocked.
Youcanputyourmachineinto“Pause”
modebypressingthe“Start/Pause/
Cancel”buttonwhenitisoperating.In
thiscase,“Start/Pause/Cancel”lightwill
flash.
CIf the machine is not spinning, the
program may be in rinse hold mode
or the automatic spin correction
system has been activated because
of unbalanced distribution of laundry
in the machine.
Changing the program after
the program has started
Youcanusethisfeatureafteryour
machine has started to wash different
textile groups in the same batch
of clothes under higher or lower
temperatures.
Forexample;
Pressandholdthe“Start/Pause/
Cancel”buttonfor3secondsto
“Cancel”theprograminorderto
select“Cottons40”programinsteadof
“Cottons60”program.
Selectthe“Cottons40”programby
rotating the program knob.
Press“Start/Pause/Cancel”buttonto
start the program.
CThe program which is selected
first will go on even if the program
selection button is moved and
another program mode is selected
while the machine is operating.
Youmustcanceltheongoing
program in order to change the
washingprogram.(See,Cancelinga
Program)
Selecting or cancelling an auxiliary
function/temperature/spin speed
1. Pressthe“Start/Pause/Cancel”
button to switch the machine to
“Pause”mode.
2. Change the auxiliary function’s
temperature and spin speed.
3. Press“Start/Pause/Cancel”button
to start the program.
CThe selection to be made must be
appropriate. For example, if your
machine is on the main wash cycle,
you may select additional rinse
