Beko WMB 51011 FS User manual

WMB 51011 F
WMB 50811 F
WMB 51011 FS
WMB 51211 F
Washing Machine
Перална машина
Perilica rublja
Plně automatická pračka

2 - EN
1 Warnings
General Safety
• Neverplaceyourmachineonacarpet
coveredfloor.Otherwise,lackofairflowfrom
belowofyourmachinemaycauseelectrical
partstooverheat.Thismaycauseproblems
withyourwashingmachine.
• Ifthepowercableormainsplugisdamaged
youmustcallAuthorizedServiceforrepair.
• Fitthedrainhoseintothedischargehousing
securelytopreventanywaterleakageand
toallowmachinetotakeinanddischarge
waterasrequired.Itisveryimportantthat
thewaterintakeanddrainhosesarenot
folded,squeezed,orbrokenwhenthe
applianceispushedintoplaceafteritis
installedorcleaned.
• Yourwashingmachineisdesignedto
continueoperatingwhenthepowerrestores
afterapowerinterruption.Themachine
willresumeitsprogramwhenthepower
restores.Pressthe“Start/Pause/Cancel”
buttonfor3secondstocanceltheprogram
(See,CancelingaProgram)
• Theremaybesomewaterinyourmachine
whenyoureceiveit.Thisisfromthequality
controlprocessandisnormal.Itisnot
harmfultoyourmachine.
• Someproblemsyoumayencountermaybe
causedbytheinfrastructure.Press“Start/
Pause/Cancel”buttonfor3secondsto
canceltheprogramsetinyourmachine
beforecallingtheauthorizedservice.
First Use
• Carryoutyourfirstwashingprocesswithout
loadingyourmachineandwithdetergent
under“Cottons90°C”program.
• Ensurethatthecoldandhotwater
connectionsaremadecorrectlywhen
installingyourmachine.
• Ifthecurrentfuseorcircuitbreakerisless
than16Amperes,pleasehaveaqualified
electricianinstalla16Amperefuseorcircuit
breaker.
• Whileusingwithorwithoutatransformer,
donotneglecttohavethegrounding
installationlaidbyaqualifiedelectrician.Our
companyshallnotbeliableforanydamages
thatmayarisewhenthemachineisusedon
alinewithoutgrounding.
• Keepthepackagingmaterialsoutofreach
ofchildrenordisposethembyclassifying
accordingtowastedirectives.
Intended use
• Thisproducthasbeendesignedforhome
use.
• Theappliancemayonlybeusedforwashing
andrinsingoftextilesthataremarked
accordingly.
• Thisapplianceisnotintendedforuseby
persons(includingchildren)withreduced
physical,sensoryormentalcapabilities,
orlackofexperienceandknowledge,
unlesstheyhavebeengivensupervisionor
instructionconcerninguseoftheappliance
byapersonresponsiblefortheirsafety.
Safety instructions
• Thisappliancemustbeconnectedto
anearthedoutletprotectedbyafuseof
suitablecapacity.
• Thesupplyanddraininghosesmustalways
besecurelyfastenedandremaininan
undamagedstate.
• Fitthedraininghosetoawashbasinor
bathtubsecurelybeforestartingupyour
machine.Theremaybeariskofbeing
scaldedduetohighwashingtemperatures!
• Neveropentheloadingdoororremovethe
filterwhilethereisstillwaterinthedrum.
• Unplugthemachinewhenitisnotinuse.
• Neverwashdowntheappliancewitha
waterhose!Thereistheriskofelectric
shock!
• Nevertouchtheplugwithwethands.Do
notoperatethemachineifthepowercord
orplugisdamaged.
• Formalfunctionsthatcannotbesolvedby
informationintheoperatingmanual:
• Turnoffthemachine,unplugit,turnoff
thewatertapandcontactanauthorized
serviceagent.Youmayrefertoyourlocal
agentorsolidwastecollectioncenterinyour
municipalitytolearnhowtodisposeofyour
machine.
If there are children in your house...
• Keepchildrenawayfromthemachinewhen
itisoperating.Donotletthemtamperwith
themachine.
• Closetheloadingdoorwhenyouleavethe
areawherethemachineislocated.

3- EN
2 Installation
Removing packaging reinforcement
Tiltthemachinetoremovethepackaging
reinforcement.Removethepackaging
reinforcementbypullingtheribbon.
Opening the transportation locks
A
Transportationsafetyboltsmustbe
removedbeforeoperatingthewashing
machine!Otherwise,themachinewillbe
damaged!
1. Loosenalltheboltswithaspanneruntilthey
rotatefreely(“C”)
2. Removetransportationsafetyboltsby
turningthemgently.
3. Fitthecovers(suppliedinthebagwiththe
OperationManual)intotheholesontherear
panel.(“P”)
C
Keepthetransportationsafetyboltsinasafe
placetoreusewhenthewashingmachine
needstobemovedagaininthefuture.
C
Nevermovetheappliancewithoutthe
transportationsafetyboltsproperlyfixedin
place!
Adjusting the feet
A
Donotuseanytoolstoloosenthelocknuts.
Otherwise,theycanbedamaged.
1. Manually(byhand)loosenthelocknutson
thefeet.
2. Adjustthemuntilthemachinestandslevel
andfirmly.
3. Important:Tightenalllocknutsupagain.
Connecting to the water supply.
Important:
• Thewatersupplypressurerequiredtorun
themachinemustbe1-10bar(0,1–1
MPa).
• Connectthespecialhosessuppliedwiththe
machinetothewaterintakevalvesonthe
machine.
• Ifyouaregoingtouseyourdoublewater-
inletmachineasasingle(cold)water-inlet
unit,youmustinstallthestopper*,supplied
withyourmachinetothehotwatervalve.
• Ifyouwanttousebothwaterinletsofthe
product,youcanconnectthehotwater
hoseafterremovingthestopperandgasket
groupfromthehotwatervalve.
*Appliesfortheproductssuppliedwithablind
stoppergroup.
• Modelswithasinglewaterinletshouldnot
beconnectedtothehotwatertap.
Whenreturningtheappliancetoitsplaceafter
maintenanceorcleaning,careshouldbetaken
nottofold,squeezeorblockthehoses.
Connecting to the drain
Thewaterdischargehosecanbeattachedtothe
edgeofawashbasinorbathtub.Thedrainhose
shouldbefirmlyfittedintothedrainastonotget
outofitshousing.
Important:
• Theendofthedrainhosemustbedirectly
connectedtothewastewaterdrainortothe
washbasin.
• Thehoseshouldbeattachedtoaheightof
atleast40cm,and100cmatmost.
• Incasethehoseiselevatedafterlayingit
onthefloorlevelorclosetotheground
(lessthan40cmabovetheground),water
dischargebecomesmoredifficultandthe
laundrymaycomeoutwet.
• Thehoseshouldbepushedintothe
drainageformorethan15cm.Ifitistoo
longyoumayhaveitshortened.
• Themaximumlengthofthecombinedhoses
mustnotbelongerthan3.2m.
Electrical connection
Connectthemachinetoanearthedoutlet
protectedbyafuseofsuitablecapacity.
Important:
• Connectionshouldcomplywithnational
regulations.
• Thevoltageandtheallowedfuseprotection
arespecifiedinthesection“Technical
Specifications”.

4- EN
• Thespecifiedvoltagemustbeequaltoyour
mainsvoltage.
• Connectionviaextensioncordsormulti-
plugsshouldnotbemade.
B
Adamagedpowercablemustbereplaced
byaqualifiedelectrician.
B
Theappliancemustnotbeoperatedunless
itisrepaired!Thereistheriskofelectric
shock!
3 Initial preparations for washing
Preparing clothes for washing
Laundryitemswithmetalattachmentssuchas,
bras,beltbucklesandmetalbuttonswilldamage
themachine.Removemetalattachmentsor
placetheitemsinaclothingbag,pillowcase,or
somethingsimilar.
• Sortthelaundryaccordingtotypeoffabric,
color,anddegreeofsoilingandpermissible
watertemperature.Alwaysfollowtheadvice
onthegarmentlabels.
• Placesmallitemslikeinfants’socksand
nylonstockings,etc.inalaundrybag,pillow
caseorsomethingsimilar.Thiswillalsosave
yourlaundryfromgettinglost.
• Wash“machinewashable”or“hand
washable”labeledproductsonlywithan
appropriateprogram.
• Donotwashcolorsandwhitestogether.
New,darkcoloredcottonsmayreleasealot
ofdye.Washthemseparately.
• Useonlydyes/colorchangersandlime
removerssuitableformachinewash.Always
followtheinstructionsonthepackaging.
• Washtrousersanddelicateclothesturned
insideout.
Correct load capacity
C
Pleasefollowtheinformationinthe
"ProgramSelectionTable".Washing
resultswilldegradewhenthemachineis
overloaded.
Loading door
Thedoorlocksduringprogramoperationandthe
DoorLockedSymbollightsup.Thedoorcanbe
openedwhenthesymbolfadesout.
Detergents and softeners
Detergent Drawer
Thedetergentdraweriscomposedofthree
compartments:
Thedetergentdispensermaybeintwodifferent
typesaccordingtothemodelofyourmachine.
–(I)forprewash
–(II)formainwash
-(III)siphon
–( )forsoftener
Detergent, softener and other cleaning
agents
Adddetergentandsoftenerbeforestartingthe
washingprogram.
Neveropenthedetergentdispenserdrawerwhile
thewashingprogramisrunning!
Whenusingaprogramwithoutpre-wash,no
detergentshouldbeputintothepre-wash
compartment(Compartmentno.I).
Detergent quantity
Theamountofwashingdetergenttobeused
dependsontheamountoflaundry,thedegreeof
soilingandwaterhardness.
• Donotuseamountsexceedingthe
quantitiesrecommendedonthepackage
toavoidproblemsofexcessivefoam,
poorrinsing,financialsavingsandfinally,
environmentalprotection.
• Neverexceedthe(>max<)levelmarking;
otherwise,thesoftenerwillbewasted
withoutbeingused.
• Donotuseliquiddetergentifyouwantto
washusingthetimedelayfeature.

5- EN
4 Selecting a program and operating your machine
Control panel
1-SpinSpeedAdjustmentKnob*
2-TemperatureAdjustmentKnob*
3-Start/Pause/CancelButton
4-AuxiliaryFunctionButtons
5-ProgramSelectionKnob
Turning the machine on
Youcanpreparethemachineforprogram
selectionbypressingthe“On/Off”button.When
the“On/Off”buttonispressed,the“Ready”light
illuminatesindicatingthatthedoorisulocked.
Pressthe“On/Off”buttonagaintoshutdownthe
machine.
Program selection
Selecttheappropriateprogramfromtheprogram
tableandthefollowingwashingtemperature
tableaccordingtotype,amountanddegreeof
soilingofthelaundry.Selectthedesiredprogram
withtheprogramselectionbutton.
C
Eachoftheseprogramsconsistofa
completewashingprocess,includingwash,
rinseand,ifrequired,spincycles.
90˚C Normallysoiled,whitecottonsand
linens.
60˚C Normallysoiled,fadeproofcolored
linens,cottonsorsyntheticclothes
andlightlysoiledwhitelinens
40˚C
30°C
Cold
Blendedclothesincluding
syntheticsandwoolensaswellas
delicateclothes.
C
Programsarelimitedwiththehighestspin
speedappropriateforthatparticulartypeof
cloth.
Main programs
Dependingonthetypeoftextile,thefollowing
mainprogramsareavailable:
• Cottons
Youcanwashyourdurableclotheswiththis
program.Yourlaundrywillbewashedwith
vigorouswashingmovementsduringalonger
washingcycle.
• Synthetics
Youcanwashyourlessdurableclothesonthis
6-On/OffButton
7-ProgramFollow-upIndicators
8-Child-proofLockIndicator*
*Accordingtoyourmachine’smodel
6 57 1
43

6- EN
program.Gentlerwashingmovementsanda
shorterwashingcycleisusedcomparedto
the“Cottons”program.Itisrecommendedfor
yoursyntheticclothes(suchasshirts,blouses,
synthetic/cottonblendedgarments,etc.).For
curtainsandlace,the“Synthetic40”program
withpre-washandanti-creasingfunctions
selectedisrecommended.
• Woollens
Youcanwashyourmachine-washablewoolen
garmentsonthisprogram.Washbyselecting
thepropertemperatureaccordingtothelabels
ofyourclothes.Itisrecommendedtouse
appropriatedetergentsforwoolens.
Additional programs
Forspecialcases,therearealsoextraprograms
available:
C
Additionalprogramsmaydifferaccordingto
themodelofyourmachine.
• Delicate
Youcanwashyourdelicateclothesonthis
program.Ithasmoresensitivewashing
movementsanddoesnotmakeintermediate
spinningcomparedto“Synthetic”program.
• Hand wash
Youcanwashyourwoolen/delicateclothesthat
bear“notmachine-washable”labelsforwhich
handwashisrecommendedonthisprogram.
Itwashesthelaundrywithverytenderwashing
movementswithoutdamagingyourclothes.
• Mini 30
Thisprogramisusedtoquicklywash(30
minutes)asmallamountoflightlysoiledcotton
garments.
• Super
Thisprogramwashesforalongerperiodat40°C
andgivesthesameresultasthe“Cottons60°C”
program,thusitsavesenergy.Itissuitablefor
clothesforwhichyoucannotusethe“Cotton
60°C”program.
Special programs
Forspecificapplications,youcanselectanyof
thefollowingprograms:
• Rinse
Thisprogramisusedwhenyouwanttorinseor
starchseparately.
• Spin + Drain
Thisprogramspinswithmaximumpossiblerpm
inthedefaultsettingafterthewaterdrainsfrom
themachine.
C
Youshouldusealowerspinspeedfor
delicatelaundries.
Spin Speed selection
Youcanhaveyourclothesspunatthemaximum
rpmselectiononyourmachinebyusingthe
selectionknobinmodelsequippedwithanrpm
selectionknob.Inordertoprotectyourclothes,
yourmachinewillnotspinabove800rpmon
syntheticprogramsand600rpmonwoolens
program.Furthermore,ifyouwanttoskipthe
spincycleandtakeyourclothesout,turnthe
rpmselectionknobto“nospin”position.
Inmachinesnotequippedwithaspinspeed
selectionknob,themachinewillspininthe
maximumpossiblerpminthedefaultsettingof
theselectedprogram.

7 - EN
Program selection and consumption table
•:Selectable
*:Automaticallyselected,notcancellable.
**:EnergyLabelprogramme(EN60456)
Waterandpowerconsumptionandprogrammedurationmaydifferfromthetableshown,subjectto
changesinwaterpressure,waterhardnessandtemperature,ambienttemperature,typeandamount
oflaundry,selectionofauxiliaryfunctions,andfluctuationsinthesupplyvoltage.
C
Theauxiliaryfunctionsinthetablemaydifferaccordingtothemodelofyourmachine.
EN 2
Programme
Max.Load(kg) ProgrammeDuration(~min) WaterConsumption(l) EnergyConsumption(kWh) Prewash RinsePlus RinseHold Spinspeedreduction NoSpin NoHeat
Cottons 90 5 133 45 1.65 • • • • • •
Cottons 60** 5 145 49 0.85 • • • • • •
Cottons 40 5 142 49 0.69 • • • • • •
Super 40 5 165 45 0.78 • • •
Synthetics 60 2.5 113 52 0.92 • • • • • •
Synthetics 40 2.5 125 52 0.56 • • • • • •
Delicate 30 265 45 0.36 • • • • •
Woollens 40 1.5 60 45 0.36 • • • • •
Handwash 30 1 45 32 0.21 • • •
Mini30 30 2.5 30 43 0.17 • • •

8 - EN
Auxiliary functions
Auxiliary function selection keys
Selecttherequiredauxiliaryfunctionsbefore
startingtheprogram.
C
Auxiliaryfunctionbuttonsmaydiffer
accordingtothemodelofyourmachine.
Auxiliary function selection
Ifanauxiliaryfunctionthatshouldnotbeselected
togetherwithapreviouslyselectedfunction
ischosen,thefirstselectedfunctionwillbe
cancelledandthelastauxiliaryfunctionselection
willremainactive.
Forexample:Ifyouwanttoselectpre-washfirst
andthenquickwash,pre-washwillbecancelled
andquickwashwillremainactive.
Auxiliaryfunctionthatisnotcompatiblewiththe
programcannotbeselected.(see“Program
SelectionTable”)
• Prewash
Apre-washisonlyworthwhileforheavilysoiled
laundry.Withoutpre-washyousaveenergy,
water,detergentandtime.Pre-washwithout
detergentisrecommendedforlaceandcurtains.
• Rinse Plus
Withthisfunction,youcanincreasethenumber
ofcurrentrinsingsteps.Thus,sensitiveskins’
riskofbeingaffectedbytheremainderdetergent
ontheclotheswillbedecreased.
• Rinse Hold
Ifyoudonotwanttounloadyourclothes
immediatelyafterthecotton,synthetics,woolen
anddelicatefabricsprogram,youmayrelease
yourclothesinsidethemachineinthelastrinsing
waterbypressingtherinseholdbuttoninorder
topreventyourclothesbecomewrinkled.After
thisprocessyoumayspinyourlaundryby
pressing“Start/Pause/Cancel”buttonoryou
mayendtheprogrambypressing“Start/Pause/
Cancel”buttonfor3sec.
• Inthemachinesequippedwithspinspeed
selectionknoborbutton,youcanspinby
selectingthedesiredspinspeedandpress
“Start/Pause/Cancel”button.
• Asformachinesnotequippedwithaspin
speedselectionknob,youcanendthe
programwithoutaspincyclebypressing
the“Start/Pause/Cancel”buttonand
drainingthewater.Ifyouwishyourclothes
bespun,youcanspinthembyselecting
“pump+spin”program.
• No Heat
Ifyouwishtowashyourclothesincoldwater,
youcanusethisprogram.
• No Spin
Youmayusethisprogramifyoudonotwant
tospinyourclothesattheendofcottons,
synthetics,woolenordelicateprograms.
• Spin speed reduction
Youmayusethespeedreductionbutton
wheneveryouwishtospinyourclothesbelow
themaximumspinspeed.Whenspeedreduction
buttonispressed,spinspeedwillbeatthe
minimumrpmgivenonthepanel.
Starting the Program
Press“Start/Pause/Cancel”buttontostartthe
program.“Start/Pause/Cancel”buttonwilllight
uptoindicatethattheprogramhasstarted.The
doorislockedandthe“Lid”lightfades.
Progressing a program
Progressofarunningprogramisshownthrough
theprogramfollow-upindicator.Atthebeginning
ofeveryprogramstep,therelevantindicator
lampwilllightupandlightofthecompletedstep
willturnoff.
C
Ifthemachineisnotspinning,theprogram
maybeinrinseholdmodeortheautomatic
spincorrectionsystemhasbeenactivated
becauseofexcessiveunbalanced
distributionoflaundryinthemachine.
Changing the selections after the
program has started
Youcanusethisfeatureafteryourmachinehas
startedtowashdifferenttextilegroupsinthe
samebatchofclothesunderhigherorlower
temperatures.Youmustcanceltheongoing
programinordertochangethewashing
program.
Forexample,pressandholdthe“Start/Pause/
Cancel”buttonfor3secondsto“Cancel”the
programinordertoselect“Cottons40”program
insteadof“Cottons60”program.Selectthe
“Cottons40”programbyrotatingtheprogram
knob.Press“Start/Pause/Cancel”buttontostart
theprogram.
Switching the machine to standby
mode
Press“Start/Pause/Cancel”buttonmomentarily
toswitchyourmachinetothestandbymode.
Auxiliaryfunctionscanbecancelledorselected
inaccordancewiththesteptheprogramisat.
Thedoorcanbeopenedifthewaterlevelis
suitable.Laundrymaybeadded/takenoutby
openingthedoor.
Child-proof lock
Youcanprotecttheappliancefrombeing
tamperedbychildrenbymeansofthechild-proof
lock.Inthiscase,nochangecanbemadeinthe
runningprogram.
Thisfunctionprotectstheappliancefrombeing
tamperedbychildren.Inthiscase,allofthe
buttonsareinactiveexceptOn/Offbutton;by
On/Offbuttonyoucanwhetherstoporresume
(whilechild-lockon)theprogramofyour
machine.

9- EN
Themachineisswitchedtochild-lockby
pressingthe1stand2ndauxiliaryfunctionsfrom
theleftfor3sec.1stauxiliaryfunctionlightwill
flashcontinuously.Todeactivatethechild-proof
lock,pressthesamebuttonsfor3sec.
Ending the program through canceling
Inordertocanceltheselectedprogram,press
the“Start/Pause/Cancel”buttonfor3seconds.
Themachinestartstodischargethewater.
“Wash”and“ProgramFinished”lightswilllight
up.“Start/Pause/Cancel”and“Wash”lightswill
gooffafterdischargingprocessisoverandthe
“Lid”lightwillstartflashing.“Lid”lampwilllight
upcontinuouslywhenthedoorisunlocked.
Iftheprogramiscancelledinthemiddleof
theprocess,“Wash”and“ProgramFinished”
lightswilllightup.Themachinecandrainallthe
waterorcantakeinwaterfor3timesatmost
tocooldowntheclothesandcompletedraining
process.Whenthewaterdischargingprocess
iscompleted,the“Wash”lightwillgooff,the
“ProgramFinished”lightwilllightupandthe
“Lid”lightwillcontinuouslyflashuntilthedooris
unlocked.
End of program
The“ProgramFinished”lampontheprogram
follow-upindicatorwilllightupwhentheprogram
comestoanend.Thelidisunlocked2minutes
later,the“ProgramFinished”and“Lid”lampswill
lightupcontinuously.Themachineisnowready
forasecondcycle.
Ifanykeyispressedwhenthemachineisat
theendoftheprogramorifthepositionof
theselectionknobischanged,the“Program
Finished”lightwillgooffandonlythe“Lid”lamp
willremainaslit.Ifthedoorisstilllocked,the
“Lid”lightwillcontinueflashinguntilthedooris
unlocked.
Pressthe“On/Off”buttontoshutdownthe
machine.
5 Maintenance and cleaning
Detergent Drawer
Removeanypowderresiduebuildupinthe
drawer.Todothis;
1. Pressthedottedpointonthesiphoninthe
softenercompartmentandpulltowardsyou
untilthecompartmentisremovedfromthe
machine.
C
Ifmorethananormalamountofwater
andsoftenermixturestartstogatherinthe
softenercompartment,thesiphonmustbe
cleaned.
2. Washthedispenserdrawerandthe
siphonwithplentyoflukewarmwaterina
washbasin.
3. Replacethedrawerintoitshousingafter
cleaning.Checkifthesiphonisinitsoriginal
location.
Inlet water filters
Thereisafilterattheendofeachwaterintake
valveatthebacksideofthemachineandalso
attheendofeachwaterintakehosewherethey
areconnectedtothetap.Thesefiltersprevent
theforeignsubstancesanddirtinthewaterto
enterintothemachine.Filtersshouldbecleaned
astheygetdirty.
• Closethetaps.
• Removethenutsofthewaterintakehoses
tocleanthesurfacesofthefiltersonthe
waterintakevalveswithanappropriate
brush.
• Ifthefiltersareverydirty,youcanpullthem
outbymeansofpliersandcleanthem.
• Takeoutthefiltersontheflatendsof
thewaterintakehosestogetherwith
thegasketsandcleanthoroughlyunder
streamingwater.
• Replacethegasketsandfilterscarefullyto
theirplacesandtightenthehosenutsby
hand.

10 - EN
bypullingouttheplugattheendofthe
hose.Iftheamountofwatertobedrained
offisgreaterthanthevolumeofthe
container,replacetheplug,pourthewater
out,thenresumethedrainingprocess.
• Afterdrainingprocessiscompleted,replace
theplugintotheendofthehoseandfitthe
hosebackintoitsplace.
Ifyourproductisnotsuppliedwithanemergency
drainhose,dothefollowingasshowninthe
figurebelow:
• Placealargecontainerinfrontofthefilterto
receivewaterflowingfromthefilter.
• Loosenpumpfilter(anticlockwise)untilwater
startstoflowoutofit.Directtheflowing
waterintothecontaineryouhaveplaced
infrontofthefilter.Youcanuseapieceof
clothtoabsorbanyspilledwater.
• Whenthereisnowaterleft,turnthepump
filteruntilitiscompletelylooseandremove
it.
• Cleananyresiduesinsidethefilteraswellas
fibers,ifany,aroundthepropellerregion.
• Ifyourproducthasawaterjetfeature,be
suretofitthefilterintoitshousinginthe
pump.Neverforcethefilterwhilereplacing
itintoitshousing.Fitthefilterfullyintoits
housing;otherwise,watermayleakfromthe
filtercap.
4-Closethefiltercap.
Closethetwo-piecefiltercapofyourproductby
pushingthetabonit.
Closetheone-piecefiltercapofyourproductby
fittingthetabsonthebottomintotheirpositions
andpushingtheupperpartofit.
Draining any remaining water and
cleaning the pump filter
Yourproductisequippedwithafiltersystem
whichensuresacleanerwaterdischargethat
extendspumplifebypreventingsoliditemssuch
asbuttons,coinsandfabricfibersfromclogging
thepumppropellerduringdischargeofthe
washingwater.
• Ifyourmachinefailstodrainthewater,the
pumpfiltermaybeclogged.Youmayhave
tocleanitevery2yearsorwheneveritis
plugged.Watermustbedrainedofftoclean
thepumpfilter.
Inaddition,watermayhavetobedrainedoff
completelyinthefollowingcases:
• beforetransportingthemachine(e.g.when
movinghouse)
• whenthereisthedangeroffrost
Inordertocleanthedirtyfilteranddischargethe
water;
1-Unplugthemachinetocutoffthesupply
power.
A
Theremaybewaterat90°Cinthemachine.
Therefore,thefiltermustbecleanedonly
aftertheinsidewateriscooleddownto
avoidhazardofscalding.
2-Openthefiltercap.Thefiltercapmaybe
composedofoneortwopiecesaccordingtothe
modelofyourmachine.
Ifitiscomposedoftwopieces,pressthetabon
thefiltercapdownwardsandpullthepieceout
towardsyourself.
Ifitiscomposedofonepiece,holditfromboth
sidesandopenitbypullingout.
3-Anemergencydrainhoseissuppliedwith
someofourmodels.Othersarenotsupplied
withthisitem.
Ifyourproductissuppliedwithanemergency
drainhose,dothefollowingasshowninthe
figurebelow:
• Pulloutthepumpoutlethosefromits
housing.
• Placealargecontainerattheendofthe
hose.Drainthewateroffintothecontainer
