Beko WMB 71231B User manual

2820521853/25-08-15.(9:15)Document Number=
Washing Machine
User Manual
WMB 71231B
WMB 71231S
WMB 71231W
EN

Please read this user manual first!
Dear Customer,
Thank you for prefering an Beko product. We hope that you get the best results from your product
which has been manufactured with high quality and state-of-the-art technology. Therefore,
please read this entire user manual and all other accompanying documents carefully before using
the product and keep it as a reference for future use. If you handover the product to someone
else, give the user manual as well. Follow all warnings and information in the user manual.
Remember that this user manual is also applicable for several other models. Differences between
models will be identified in the manual.
Explanation of symbols
Throughout this user manual the following symbols are used:
C
Important information or useful hints
about usage.
A
Warning for hazardous situations with
regard to life and property.
B
Warning for electric shock.
Packaging materials of the product
are manufactured from recyclable
materials in accordance with our
National Environment Regulations.
Do not dispose of the packaging materials together with the domestic or other wastes. Take them
to the packaging material collection points designated by the local authorities.
Service
This product was manufactured using the latest technology in environmentally friendly conditions.

Washing Machine / User‘s Manual
3 / EN
TABLE OF CONTENTS
1 Important instructions for
safety and environment 4
1.1 General safety . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.2 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.3 Children's safety . . . . . . . . . . . . . . . . . . . . . . . . 6
1.4 Package information . . . . . . . . . . . . . . . . . . . 6
1.5 Disposing of the waste product . . . . . . . . 6
1.6 Compliance with WEEE Directive . . . . . . . 7
2 Your washing machine 8
2.1 Technical specifications . . . . . . . . . . . . . . . . 8
2.2 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.3 Package Contents . . . . . . . . . . . . . . . . . . . . . 10
3 Installation 11
3.1 Appropriate installation location . . . . . . 11
3.2 Removing packaging reinforcement . . 11
3.3 Removing the transportation locks . . . 11
3.4 Connecting water supply. . . . . . . . . . . . . . 12
3.5 Connecting to the drain . . . . . . . . . . . . . . . 13
3.6 Adjusting the feet. . . . . . . . . . . . . . . . . . . . . 13
3.7 Electrical connection . . . . . . . . . . . . . . . . . . 14
4 Preparation 16
4.1 Sorting the laundry. . . . . . . . . . . . . . . . . . . . 16
4.2 Preparing laundry for washing . . . . . . . . 17
4.3 Things to be done for energy saving . . 17
4.4 Initial use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.5 Correct load capacity . . . . . . . . . . . . . . . . . . 18
4.6 Loading the laundry. . . . . . . . . . . . . . . . . . . 18
4.7 Using detergent and softener. . . . . . . . . 18
4.8 Tips for efficient washing. . . . . . . . . . . . . 21
5 Operating the product 22
5.1 Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . 22
5.2 Preparing the machine . . . . . . . . . . . . . . . . 22
5.3 Programme selection . . . . . . . . . . . . . . . . . 22
5.4 Main programmes . . . . . . . . . . . . . . . . . . . . 23
5.5 Additional programmes . . . . . . . . . . . . . . . 23
5.6 Special programmes . . . . . . . . . . . . . . . . . .24
5.7 Temperature selection . . . . . . . . . . . . . . . .24
5.8 Spin speed selection . . . . . . . . . . . . . . . . . .24
5.9 Programme and consumption table. . . 25
5.10 Auxiliary function selection. . . . . . . . . . 26
5.11 Starting the programme . . . . . . . . . . . . . 27
5.12 Child Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
5.13 Progress of programme . . . . . . . . . . . . . .28
5.14 Loading door lock . . . . . . . . . . . . . . . . . . . .28
5.15 Changing the selections after
programme has started. . . . . . . . . . . . . .28
5.16 Canceling the programme. . . . . . . . . . . . 29
5.17 End of programme . . . . . . . . . . . . . . . . . . . 29
5.18 Your machine is equipped with a
“Standby Mode”. . . . . . . . . . . . . . . . . . . . . . 29
6 Quick User Guide 30
6.1 Preparing the machine . . . . . . . . . . . . . . . . 30
6.2 Programme selection . . . . . . . . . . . . . . . . . 30
6.3 Auxiliary function selection . . . . . . . . . . . 30
6.4 Starting the programme . . . . . . . . . . . . . . 30
6.5 Canceling the programme. . . . . . . . . . . . . 30
7 Maintenance and cleaning 31
7.1 Cleaning the detergent drawer. . . . . . . . 31
7.2 Cleaning the loading door and the drum31
7.3 Cleaning the body and control panel . . 32
7.4 Cleaning the water intake filters . . . . . . 32
7.5 Draining remaining water and cleaning
the pump filter. . . . . . . . . . . . . . . . . . . . . . . 32
8 Troubleshooting 34

4/ EN
Washing Machine / User‘s Manual
1 Important instructions for safety and environment
This section contains safety instructions that will help protect from risk of perso-
nal injury or property damage. Failure to follow these instructions shall void any
warranty.
1.1 General safety

whose physical, sensory or mental capabilities were not fully developed or who
lack experience and knowledge provided that they are supervised or trained on
the safe usage of the product and the risks it brings out. Children must not play
with the product. Cleaning and maintenance works should not be performed by
children unless they are supervised by someone. Children of less than 3 years
should be kept away unless continuously supervised.

beneath the machine will cause electrical parts to overheat. This will cause pro-
blems with your product.

Authorized Service Agent. There is the risk of electric shock!

power interruption. If you wish to cancel the programme, see "Cancelling the pro-
gramme" section.
-
glect to have the grounding installation made by a qualified electrician. Our com-
pany shall not be liable for any damages that will arise when the product is used
without grounding in accordance with the local regulations.
-
glect to have the grounding installation made by a qualified electrician. Our com-
pany shall not be liable for any damages that will arise when the product is used
without grounding in accordance with the local regulations.
-
damaged. Otherwise, there is the risk of water leakage.

drum. Otherwise, risk of flooding and injury from hot water will occur.

just a few minutes after the washing cycle comes to an end. In case of forcing the
loading door to open, the door and the lock mechanism may get damaged.


electric shock!

Washing Machine / User‘s Manual
5 / EN
Important instructions for safety and environment

always pull out by grabbing the plug.
-
chines only.


repairing procedures.

Authorized Service Agent. Manufacturer shall not be held liable for da-
mages that may arise from procedures carried out by unauthorized persons.

agent or similary qualified persons in order to avoid a hazard.

sales service or a similarly qualified person (preferably an electrician) or someone
designated by the importer in order to avoid possible risks.


-
ce.

-
ted and plastic surfaces.
1.2 Intended use

use and it must not be used out of its intended use.

6/ EN
Washing Machine / User‘s Manual
Important instructions for safety and environment
-
ked accordingly.
-
portation.
1.3 Children's safety

place away from reach of the children.

product when it is in use. Do not let them to tamper with the product. Use child
lock to prevent children from intervening with the product.

is located.

children by closing the cover of the detergent container or sealing the detergent
package.
While washing the laundry at high temperatures, the loading door
glass becomes hot. Therefore, keep especially the children away
from the loading door of the machine while the washing opera-
tion is in progress.
1.4 Package nformaton

in accordance with our National Environment Regulations. Do not dispose of the
packaging materials together with the domestic or other wastes. Take them to
the packaging material collection points designated by the local authorities.
1.5 Dsposng of the waste product

can be reused and are suitable for recycling. Therefore, do not dispose the pro-
duct with normal domestic waste at the end of its service life. Take it to a collec-
tion point for the recycling of electrical and electronic equipment. Please consult

Washing Machine / User‘s Manual
7 / EN
Important instructions for safety and environment
your local authorities to learn the nearest collection point. Help protect the envi-
ronment and natural resources by recycling used products. For children's safety,
cut the power cable and break the locking mechanism of the loading door so that
it will be non-functional before disposing of the product.
1.6 Complance wth WEEE Drectve
This product complies with EU WEEE Directive (2012/19/EU).
This product bears a classification symbol for waste electrical
and electronic equipment (WEEE).
This product has been manufactured with high quality parts
and materials which can be reused and are suitable for recycling.
Do not dispose of the waste product with normal domestic and
other wastes at the end of its service life. Take it to the collection
center for the recycling of electrical and electronic equipment.
Please consult your local authorities to learn about these collec-
tion centers.
Compliance with RoHS Directive:
The product you have purchased complies with EU RoHS Directive (2011/65/EU). It
does not contain harmful and prohibited materials specified in the Directive.

8/ EN
Washing Machine / User‘s Manual
2 Your washing machine
2.1 Technical specifications
Complying Commission Delegated Regulation (EU) No 1061/2010
Supplier name or trademark Beko Beko Beko
Model name WMB71231B WMB71231S WMB71231W
Rated capacity (kg) 7 7 7
Energy efficiency class / Scale from A+++ (Highest Efficiency) to D (Lowest Efficiency) A+ A+ A+
Annual Energy Consumption (kWh) (1) 210 210 210
Energy consumption of the standard 60°C cotton programme at full load (kWh) 1.103 1.103 1.103
Energy consumption of the standard 60°C cotton programme at partial load (kWh) 0.875 0.875 0.875
Energy consumption of the standard 40°C cotton programme at partial load (kWh) 0.699 0.699 0.699
Power consumption in ‘off-mode’ (W) 0.250 0.250 0.250
Power consumption in ‘left-on mode’ (W) 1.000 1.000 1.000
Annual Water Consumption (l) (2) 9020 9020 9020
Spin-drying efficiency class / Scale from A (Highest Efficiency) to G (Lowest Efficiency) B B B
Maximum spin speed (rpm) 1200 1200 1200
Remaining moisture Content (%) 53 53 53
Standard cotton programme (3) Cotton Eco 60°C and 40°C
Programme time of the standard 60°C cotton programme at full load (min) 160 160 160
Programme time of the standard 60°C cotton programme at partial load (min) 145 145 145
Programme time of the standard 40°C cotton programme at partial load (min) 130 130 130
Duration of the left-on mode (min) N/A N/A N/A
Airborne acoustical noise emissions washing/spinning (dB) 57/74 57/74 57/74
Built-in No No No
Height (cm) 84 84 84
Width (cm) 60 60 60
Depth (cm) 54 54 54
Net weight (±4 kg.) 71 71 71
Single Water inlet / Double Water inlet
• / - • / - • / -
• Available
Electrical input (V/Hz) 230 V / 50Hz 230 V / 50Hz 230 V / 50Hz
Total current (A) 10 10 10
Total power (W) 2200 2200 2200
Main model code 9211 9211 9211
(1) Energy Consumption based on 220 standard washing cycles for cotton programmes at 60°C and 40°C at full and partial load, and the consumption of the low-power
modes. Actual energy consumption will depend on how the appliance is used.
(2) Water consumption based on 220 standard washing cycles for cotton programmes at 60°C and 40°C at full and partial load. Actual water consumption will depend on how
the appliance is used.
(3) “Standard 60°C cotton programme” and the “standard 40°C cotton programme” are the standard washing programmes to which the information in the label and the fiche
relates and these programmes are suitable to clean normally soiled cotton laundry and that they are the most efficient programmes in terms of combined energy and water
consumption.
Technical specifications may be changed without prior notice to improve the quality of the product.

Washing Machine / User‘s Manual
9 / EN
Your washing machine
2.2 Overview
7
3
4
6
5
2
1
8
1- Power cable
2- Top panel
3- Control panel
4- Filter cap
5- Adjustable feet
6- Loading door
7- Detergent drawer
8- Drain hose

10 / EN
Washing Machine / User‘s Manual
Your washing machine
2.3 Package Contents
1
2
3 4
abc
5
6
7
8
1- Power cable
2- Drain hose
3- Transportation safety bolts *
4- Mains water inlet hose (One of the following filter types is used for the mains hose connection.)
a- Electronical water shut-off
b- Mechanical water shut-off
c- Standard
5- Liquid detergent container**
6- User Manual
7- Blind plug***
8- Plastic plug group
* Number of transportation safety bolts may change depending on the model of your machine.
** This may be supplied with the machine depending on the model of your machine.
*** This is supplied if your machine is equipped with double water inlet.

Washing Machine / User‘s Manual
11 / EN
3 Installation
Refer to the nearest Authorised Service Agent
for installation of the product. To make the
product ready for use, review the information
in the user manual and make sure that the
electricity, tap water supply and water drainage
systems are appropriate before calling the
Authorised Service Agent. If they are not, call
a qualified technician and plumber to have any
necessary arrangements carried out.
CPreparation of the location and
electrical, tap water and waste
water installations at the place of
installation is under customer's
responsibility.
Make sure that the water inlet and
discharge hoses as well as the power
cable are not folded, pinched or
crushed while pushing the product
into its place after installation or
cleaning procedures.
B
WARNING: Manufacturer shall not
be held liable for damages that may
arise from procedures carried out by
unauthorised persons.
A
WARNING: Prior to installation,
visually check if the product has any
defects on it. If so, do not have it
installed. Damaged products cause
risks for your safety.
3.1 Appropriate installation location
 
place it on a long pile rug or similar surfaces.
 
dryer -with full load- when they are placed
on top of each other reaches to approx. 180
kilograms. Place the product on a solid and
flat floor that has sufficient load carrying
capacity!
 
 
temperature may fall below 0ºC.
 
edges of other furniture.
3.2 Removing packaging
reinforcement
Tilt the machine backwards to remove
the packaging reinforcement. Remove the
packaging reinforcement by pulling the ribbon.
3.3 Removing the transportation
locks
A
WARNING: Do not remove the
transportation locks before taking out
the packaging reinforcement.
WARNING: Remove the
transportation safety bolts before
operating the washing machine!
Otherwise, the product will be
damaged.
1. Loosen all the bolts with a suitable spanner
until they rotate freely (C) .
2. Remove transportation safety bolts by
turning them gently.

12 / EN
Washing Machine / User‘s Manual
Installation
3. Attach the plastic covers supplied in the User
Manual bag into the holes on the rear panel.
(P)
C
in a safe place to reuse when the
washing machine needs to be moved
again in the future.
Never move the product without the
transportation safety bolts properly
fixed in place!
3.4 Connecting water supply
CThe water supply pressure required
to run the product is between 1 to 10
bars (0.1 – 1 MPa). It is necessary to
have 10 – 80 liters of water flowing
from the fully open tap in one minute
to have your machine run smoothly.
Attach a pressure reducing valve if
water pressure is higher.
If you are going to use the double
water-inlet product as a single
(cold)
water-inlet unit, you must install the
supplied stopper to the hot water
valve before operating the product.
(Applies for the products supplied
with a blind stopper group.)
A
WARNING: Models with a single
water inlet should not be connected
to the hot water tap. In such a case
the laundry will get damaged or the
product will switch to protection
mode and will not operate.
WARNING: Do not use old or used
water inlet hoses on the new product.
It may cause stains on your laundry.
1. Connect the special hoses supplied with the
product to the water inlets on the product.
Red hose (left) (max. 90 ºC) is for hot water
inlet, blue hose (right) (max. 25 ºC) is for cold
water inlet.
A
WARNING: Ensure that the cold and
hot water connections are made
correctly when installing the product.
Otherwise, your laundry will come out
hot at the end of the washing process
and wear out.
2. Tighten all hose nuts by hand. Never use a
tool when tightening the nuts.
3. Open the taps completely after making the
hose connection to check for water leaks at
the connection points. If any leaks occur, turn
off the tap and remove the nut. Retighten
the nut carefully after checking the seal. To
prevent water leakages and damages caused
by them, keep the taps closed when the
machine is not in use.

Washing Machine / User‘s Manual
13 / EN
Installation
3.5 Connecting to the drain
 
connected to the wastewater drain or to the
washbasin.
 
stand pipe or sink siphon connected to the
foul water drain, do not connect to surface
water drains.
A
WARNING: Your house will be
flooded if the hose comes out of
its housing during water discharge.
Moreover, there is risk of scalding
due to high washing temperatures!
To prevent such situations and to
ensure smooth water intake and
discharge of the machine, fix the end
of the discharge hose tightly so that
it cannot come out.
 
least 40 cm, and 100 cm at most.
 
it on the floor level or close to the ground
(less than 40 cm above the ground), water
discharge becomes more difficult and the
laundry may come out excessively wet.
Therefore, follow the heights described in
the figure.
100cm
40cm
 
the machine and to allow for easy discharge,
do not immerse the hose end into the dirty
water or do not drive it in the drain more than
15 cm. If it is too long, cut it short.
 
should not be stepped on and the hose must
not be pinched between the drain and the
machine.
 
by adding an original extension hose. Length
of the hose may not be longer than 3.2 m.
To avoid water leak failures, the connection
between the extension hose and the drain
hose of the product must be fitted well with
an appropriate clamp as not to come off and
leak.
3.6 Adjusting the feet
A
WARNING: In order to ensure that
the product operates more silently
and vibration-free, it must stand level
and balanced on its feet. Balance
the machine by adjusting the feet.
Otherwise, the product may move
from its place and cause crushing and
vibration problems.
1. Loosen the lock nuts on the feet by hand.
2. Adjust the feet until the product stands level
and balanced.
3. Tighten all lock nuts again by hand.
A
WARNING: Do not use any tools
to loosen the lock nuts. Otherwise,
they will get damaged.

14 / EN
Washing Machine / User‘s Manual
Installation
3.7 Electrical connection
Connect the product to a grounded outlet
protected by a 13 A fuse. Our company shall
not be liable for any damages that will arise
when the product is used without grounding in
accordance with the local regulations.
 
regulations.
 
after installation.
 
in the house is less than 13 Amps, have a
qualified electrician install a 13 Amp fuse.
 
specifications" section must be equal to your
mains voltage.
 
cables or multi-plugs.
B
WARNING: Damaged power cables
must be replaced by the Authorised
Service Agents.
Electrcal requrements
Before you insert the plug into the wall socket
make sure that the voltage and the frequency
shown in the rating label corresponds to your
electricity supply.
We recommend that this appliance be
connected to the mains supply via a suitable
switched and fused socket in a readily
accessible position.
Should the mains lead of the appliance become
damaged or need replacing at any time, it
must be replaced by a special purpose made
mains lead which can only be obtained from a
Authorised Service Agent.
B
WARNING: This appliance must be
earthed
If the fitted moulded plug is not suitable for
your socket, then the plug should be cut off
and an appropriate plug fitted.
Destroy the old plug, which is cut off as a plug
with a bared cord could cause a shock hazard if
inserted into a socket elsewhere in the house.
The moulded plug on this appliance
incorporates a 13A fuse. Should the fuse need
to be replaced an ASTA approved BS1362 fuse
of the same rating must be used. Do not forget
to refit the fuse cover. In the event of losing the
fuse cover, the plug must not be used until a
replacement fuse cover has been fitted. Colour
of the replacement fuse cover must be the
same colour as that visible on the pin face of
the plug. Fuse covers are available from any
good electrical store.
Important
Fttng a dfferent plug
As the colours of the wires in the mains lead
of this appliance may not correspond with the
coloured markings identifying the terminals on
your plug, proceed as follows:
1 Connect the green - yellow or green (earth)
wre to the termnal n the plug marked ‘E’
or wth the symbol f or coloured green and
yellow or green.
2 Connect the blue (neutral) wre to the
termnal n the plug marked ‘N’ or coloured
black.
3 Connect the brown (lve) wre to the termnal
n the plug marked ‘L’ or coloured red.

Washing Machine / User‘s Manual
15 / EN
Installation
Wth the alternatve plugs a 13A fuse must be
ftted ether n the plug or adaptor or n the
man fuse box. If n doubt contact a qualfed
electrcan.
Transportation of the product
1. Unplug the product before transporting it.
2. Remove water drain and water supply
connections.
3. Drain all water that has remained in the
product. See 6.5
4. Install transportation safety bolts in the
reverse order of removal procedure; see 3.3.
CNever move the product without the
transportation safety bolts properly
fixed in place!
A
WARNING: Packaging materials

packaging materials in a safe place
away from reach of the children.

16 / EN
Washing Machine / User‘s Manual
4 Preparation
4.1 Sorting the laundry
 
temperature.
 
LAUNDRY WASH SYMBOLS
Machine
Wash
Symbols
Normal wash No Iron Sensitive- Delicate wash Hand wash Not washable No Spin
WASH Water
Temperatures
Maximum 950C700C600C500C400C300C
Symbol(s) 


 


   
Drying
Symbols Suitable for
dryer No Iron Sensitive /
Delicate dry
Do not dry
with dryer
Do not dry Do not dry-
clean
DRYING
Drying
Settings
At any temperature At high temperature At medium temperature At low temperature Without heating Hang to dry Lay to dry Hang wet to dry Lay in shadow to dry Dry-cleanable
Iron -
IRON Dry or Steam
Iron at high
temperature
Iron at medium
temperature
Iron at low
temperature
Do not iron Iron without steam Maximum temperature 200 0C150 0C110 0C
All bleaches are allowed
Bleach (sodium
hypochlorite)
can be used
Bleach is not
allowed
Only bleaches without
chlorine are allowed
BLEACH

Washing Machine / User‘s Manual
17 / EN
Preparation
4.2 Preparing laundry for washing
 
as, underwired bras, belt buckles or metal
buttons will damage the machine. Remove
the metal pieces or wash the clothes by
putting them in a laundry bag or pillow case.

as coins, pens and paper clips, and turn
pockets inside out and brush. Such objects
may damage the product or cause noise
problem.
 
and nylon stockings in a laundry bag or pillow
case.
 
Remove curtain attachment items.
 
rips and tears.
 
washable” labeled products only with an
appropriate programme.
 
New, dark coloured cottons release a lot of
dye. Wash them separately.
 
washing. If unsure, check with a dry cleaner.
 
removers suitable for machine wash. Always
follow the instructions on the package.
 
inside out.
 
the freezer for a few hours before washing.
This will reduce pilling.
 
as flour, lime dust, milk powder, etc. intensely
must be shaken off before placing into the
machine. Such dusts and powders on the
laundry may build up on the inner parts of
the machine in time and can cause damage.
4.3 Things to be done for energy
saving
Following information will help you use the
product in an ecological and energy-efficient
manner.
 
capacity allowed by the programme you
have selected, but do not overload; see,
"Programme and consumption table".
 
detergent packaging.
 
temperatures.
 
of lightly soiled laundry.
 
for laundry that is not heavily soiled or
stained.
 
select the highest spin speed recommended
during washing process.
 
amount recommended on the detergent
package.
4.4 Initial use
Before starting to use the product, make sure
that all preparations are made in accordance
with the instructions in sections “Important
safety instructions” and “Installation”.
To prepare the product for washing laundry,
perform first operation in Drum Cleaning
programme. If your product is not equipped
with Drum Cleaning programme, perform the
Initial Use procedure in accordance with the
methods described under “7.2 Cleaning the
loading door and the drum” section of the user
manual.

18 / EN
Washing Machine / User‘s Manual
Preparation
C
Use an anti-limescale suitable for the
washing machines.
C
Some water might have remained in
the product due to the quality control
processes in the production. It is not
harmful for the product.
4.5 Correct load capacity
The maximum load capacity depends on the
type of laundry, the degree of soiling and the
washing programme desired.
The machine automatically adjusts the amount
of water according to the weight of the loaded
laundry.
A
WARNING: Follow the information
in the “Programme and consumption
table”. When overloaded, machine's
washing performance will drop.
Moreover, noise and vibration problems
may occur.
Laundry type Weight (g)
Bathrobe 1200
Napkin 100
Duvet cover 700
Bed Sheet 500
Pillowcase 200
Tablecloth 250
Towel 200
Hand towel 100
Evening gown 200
Underclothing 100
Men’s overalls 600
Men’s shirt 200
Men’s pajamas 500
Blouses 100
4.6 Loading the laundry
1. Open the loading door.
2. Place laundry items loosely into the machine.
3. Push the loading door to close until you hear
a locking sound. Ensure that no items are
caught in the door.
C
The loading door is locked while a
programme is running. The door can
only be opened a while after the
programme comes to an end.
A
WARNING: In case of misplacing the
laundry, noise and vibration problems
may occur in the machine.
4.7 Using detergent and softener
C
When using detergent, softener, starch,
fabric dye, bleach or limescale remover
read the manufacturer's instructions
on the package carefully and follow
the suggested dosage values. Use
measuring cup if available.
Detergent Drawer
The detergent drawer is composed of three
compartments:
– (1) for prewash
– (2) for main wash
– (3) for softener
– (*) in addition, there is siphon piece in the
softener compartment.
1
23
Detergent, softener and other cleaning
agents
 
the washing programme.
 
the washing programme is running!
 
do not put any detergent into the prewash

Washing Machine / User‘s Manual
19 / EN
Preparation
compartment (compartment nr. "1").
 
put liquid detergent into the prewash
compartment (compartment nr. "1").
 
you are using a detergent bag or dispensing
ball. Place the detergent bag or the
dispensing ball directly among the laundry in
the machine.
 
forget to place the liquid detergent cup into
the main wash compartment (compartment
nr. "2").
Choosing the detergent type
The type of detergent to be used depends on
the type and colour of the fabric.
 
white laundry.
 
detergents (liquid detergent, wool shampoo,
etc.) used solely for delicate clothes.
 
quilts, it is recommended to use liquid
detergent.
 
specifically for woolens.
A
WARNING: Use only detergents
manufactured specifically for washing
machines.
A
WARNING: Do not use soap powder.
Adjusting detergent amount
The amount of washing detergent to be used
depends on the amount of laundry, the degree
of soiling and water hardness.
 
quantities recommended on the detergent
package to avoid problems of excessive foam,
poor rinsing, financial savings and finally,
environmental protection.
 
lightly soiled clothes.
Using softeners
Pour the softener into the softener
compartment of the detergent drawer.

the softener compartment.

with water before putting it in the detergent
drawer.
Using liquid detergents
If the product contains a liquid detergent
cup:
 
detergent cup in compartment nr. "2".

dilute it with water before putting in the
detergent cup.
If the product does not contain a liquid
detergent cup:
 
in a programme with prewash.
 
used with Delayed Start function. If you are
going to use the Delayed Start function, do
not use liquid detergent.
Using gel and tablet detergent
Apply the following instructions when using
tablet, gel and similar detergents.
 
your machine does not contain a special
liquid detergent cup, put the gel detergent
into the main wash detergent compartment
during first water intake. If your machine
contains a liquid detergent cup, fill the

20 / EN
Washing Machine / User‘s Manual
Preparation
detergent into this cup before starting the
programme.
 
or in the shape of capsule liquid tablet, put it
directly into the drum before washing.
 
compartment (compartment nr. "2") or
directly into the drum before washing.
C
Tablet detergents may leave residues
in the detergent compartment. If you
encounter such a case, place the tablet
detergent between the laundry, close
to the lower part of the drum in future
washings.
C
Use the tablet or gel detergent without
selecting the prewash function.
Using starch
 
dye into the softener compartment.
 
washing cycle.
 
and clean cloth after using starch.
Using bleaches
 
the bleaching agent at the beginning of
the prewash. Do not put detergent in the
prewash compartment. As an alternative
application, select a programme with extra
rinse and add the bleaching agent while the
machine is taking water from the detergent
compartment during first rinsing step.
 
mixing them.
 
bleaching agent and rinse the clothes very
well as it causes skin irritation. Do not pour
the bleaching agent onto the clothes and do
not use it for coloured clothes.
 
a programme that washes at a lower
temperature.
 
with detergents; however, if its thickness
is not the same with the detergent, put the
detergent first into the compartment nr. "2"
in the detergent drawer and wait until the
detergent flows while the machine is taking
in water. Add the bleaching agent from the
same compartment while the machine is still
taking in water.
Using limescale remover

manufactured specfcally for washng
machnes only.
