Beko WTL 6019 P User manual

WTL 6019 P
Washing Machine
User’s Manual

This product was manufactured using the latest technology in environmentally friendly conditions.
Please read this user manual first!
Dear Customer,
Thank you for prefering an %HNR product. We hope that you get the best results from your product which
has been manufactured with high quality and state-of-the-art technology. Therefore, please read this
entire user manual and all other accompanying documents carefully before using the product and keep
it as a reference for future use. If you handover the product to someone else, give the user manual as
well. Follow all warnings and information in the user manual.
Remember that this user manual is also applicable for several other models. Differences between
models will be identified in the manual.
Explanation of symbols
Throughout this user manual the following symbols are used:
CImportant information or useful hints
about usage.
AWarning for hazardous situations with
regard to life and property.
BWarning for electric shock.
Packaging materials of the product
are manufactured from recyclable
materials in accordance with our
National Environment Regulations.
Do not dispose of the packaging materials together with the domestic or other wastes. Take them to the
packaging material collection points designated by the local authorities.

3 / EN
TABLE OF CONTENTS
1 Important instructions for safety and
environment 4
1.1 General safety . . . . . . . . . . . . . . . . . . . . . . .4
1.2 Intended use . . . . . . . . . . . . . . . . . . . . . . . .5
1.3 Children's safety. . . . . . . . . . . . . . . . . . . . . .5
1.4 Package information. . . . . . . . . . . . . . . . . . .6
1.5 Disposing of the waste product . . . . . . . . . . .6
1.6 Compliance with WEEE Directive. . . . . . . . . .6
2 Your washing machine 7
2.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . .7
2.2 Technical specifications . . . . . . . . . . . . . . . .8
3 Installation 9
3.1 Appropriate installation location. . . . . . . . . . .9
3.2 Connecting water supply. . . . . . . . . . . . . . . .9
3.3 Connecting to the drain. . . . . . . . . . . . . . . .10
3.3.1 Connecting to the drain without pump . . . . . 10
3.3.2 Connecting to the drain with pump. . . . . . . . 11
3.4 Adjusting the feet . . . . . . . . . . . . . . . . . . . .11
3.5 Electrical connection. . . . . . . . . . . . . . . . . .12
3.6 Connection of inlet hose connector and tap 12
3.7 Connecting to the water supply. . . . . . . . . .
. . . . . . . . . .
13
3.8 Using detergent /softener and bleach nector13
3.9 Put rat guard into the machine13
4 Preparation 14
4.1 Sorting the laundry . . . . . . . . . . . . . . . . . . .14
4.2 Preparing laundry for washing. . . . . . . . . . .15
4.3 Things to be done for energy saving . . . . . .15
4.4 Correct load capacity . . . . . . . . . . . . . . . . .16
4.5 Loading the laundry . . . . . . . . . . . . . . . . . .16
4.6 Using detergent and softener . . . . . . . . . . .16
4.6.1 Advanced detergent drawer. . . . . . . . . . . . . 17
4.6.2 Simple detergent drawer . . . . . . . . . . . . . . . 17
5 Operating the product 18
5.1 Control panel . . . . . . . . . . . . . . . . . . . . . . .18
5.2 Preparing the machine . . . . . . . . . . . . . . . .19
5.3 Main programmes . . . . . . . . . . . . . . . . . . .20
5.4 Auxiliary function selection . . . . . . . . . . . . .22
6 Maintenance and cleaning 23
6.1 Cleaning the detergent drawer . . . . . . . . . .23
6.2 Cleaning the body and control panel . . . . . .23
6.3 Cleaning the water intake filters . . . . . . . . .23
6.4 Draining remaining water and cleaning the
pump filter. . . . . . . . . . . . . . . . . . . . . . . .24
7 Troubleshooting 25

4 / EN Washing Machine /User’s Manual
1 Important instructions for safety and environment
This section contains safety instructions that will help protect from risk of
personal injury or property damage. Failure to follow these instructions shall
void any warranty.
1.1 General safety
• This product can be used by children at and above 8 years old and by persons
whose physical, sensory or mental capabilities were not fully developed or
who lack experience and knowledge provided that they are supervised or
trained on the safe usage of the product and the risks it brings out. Children
must not play with the product. Cleaning and maintenance works should not
be performed by children unless they are supervised by someone.
• Never place the product on a carpet-covered floor. Otherwise, lack of airflow
beneath the machine will cause electrical parts to overheat. This will cause
problems with your product.
• If the product has a failure, it should not be operated unless it is repaired by
the Authorized Service Agent. There is the risk of electric shock!
• This product is designed to resume operating in the event of powering on after
a power interruption. If you wish to cancel the programme, see "Cancelling
the programme" section.
• Connect the product to a grounded outlet protected by a 6 A fuse. Do not
neglect to have the grounding installation made by a qualified electrician. Our
company shall not be liable for any damages that will arise when the product
is used without grounding in accordance with the local regulations.
• The water supply and draining hoses must be securely fastened and remain
undamaged. Otherwise, there is the risk of water leakage.
• Never remove the filter while there is still water in the drum. Otherwise, risk of
flooding and injury from hot water will occur.
• Unplug the product when not in use.
• Never wash the product by spreading or pouring water onto it! There is the
risk of electric shock!
• Never touch the plug with wet hands! Never unplug by pulling on the cable,
always pull out by grabbing the plug.
• Use detergents, softeners and supplements suitable for automatic washing
machines only.
• Follow the instructions on the textile tags and on the detergent package.
• The product must be unplugged during installation, maintenance, cleaning
and repairing procedures.

Washing Machine /User’s Manual 5 / EN
Important instructions for safety and environment
ŘAlways have the installation and repairing procedures carried out by the
Authorized Service Agent. Manufacturer shall not be held liable
for damages that may arise from procedures carried out by unauthorized
persons.
ŘIf the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similary qualified persons in order to avoid a hazard.
ŘIf the power cable is damaged, it must be replaced by the manufacturer,
after sales service or a similarly qualified person (preferably an electrician) or
someone designated by the importer in order to avoid possible risks.
ŘPlace the product on a rigid, flat and level surface.
ŘDo not place it on a long-pile rug or similar surfaces.
ŘDo not place the product on a high platform or near the edge on a cascaded
surface.
ŘDo not place the product on the power cable.
ŘNever use sponge or scrub materials. These will damage the painted, chrome
plated and plastic surfaces.
1.2 Intended use
ŘThis product has been designed for domestic use. It is not suitable for
commercial use and it must not be used out of its intended use.
ŘThe product must only be used for washing and rinsing of laundry that are
marked accordingly.
ŘThe manufacturer waives any responsibility arisen from incorrect usage or
transportation.
ŘThe service life of your product is 10 years. During this period, original spare
parts will be available to operate the appliance properly.
1.3 Children's safety
ŘPackaging materials are dangerous to children. Keep packaging materials in a
safe place away from reach of the children.
ŘElectrical products are dangerous for the children. Keep children away from
the product when it is in use. Do not let them to tamper with the product. Use
child lock to prevent children from intervening with the product.
Please do not put your finger
into gap between this cover and lid!

6 / EN Washing Machine /User’s Manual
1.4 Package information
ŘPackaging materials of the product are manufactured from recyclable
materials in accordance with our National Environment Regulations. Do
not dispose of the packaging materials together with the domestic or other
wastes. Take them to the packaging material collection points designated by
the local authorities.
1.5 Disposing of the waste product
ŘThis product has been manufactured with high quality parts and materials
which can be reused and are suitable for recycling. Therefore, do not dispose
the product with normal domestic waste at the end of its service life. Take it
to a collection point for the recycling of electrical and electronic equipment.
Please consult your local authorities to learn the nearest collection point. Help
protect the environment and natural resources by recycling used products. For
children's safety, cut the power cable and break the locking mechanism of the
lid so that it will be non-functional before disposing of the product.
1.6 Compliance with WEEE Directive
This product complies with EU WEEE Directive (2012/19/EU).
This product bears a classification symbol for waste electrical
and electronic equipment (WEEE).
This product has been manufactured with high quality parts
and materials which can be reused and are suitable for
recycling. Do not dispose of the waste product with normal
domestic and other wastes at the end of its service life. Take
it to the collection center for the recycling of electrical and
electronic equipment. Please consult your local authorities to
learn about these collection centers.
Compliance with RoHS Directive:
The product you have purchased complies with EU RoHS Directive (2011/65/
EU). It does not contain harmful and prohibited materials specified in the
Directive.
ŘDo not forget to close the lid when leaving the room where the product is
located.
Ř
Ř
Store all detergents and additives in a safe place away from the reach of
the children by closing the cover of the detergent container or sealing the
detergent package.
Children of less than 3 years should be kept away unless continuously
supervised.
Important instructions for safety and environment

Washing Machine /User’s Manual 7 / EN
2 Your washing machine
2.1 Overview
1- Power cable
2- Loading door
3- Detergent drawer
4- Control panel
5- Drain hose
6- Adjustable feet
Washing Machine /User’s Manual 7 / EN
1
2
4
5
3
6
7

8 / EN Washing Machine /User’s Manual
Your washing machine
2.2 Technical specifications
Technical specifications may be changed without prior notice to improve the quality of the product.
Figures in this manual are schematic and may not match the product exactly.
Values stated on the product labels or in the documentation accompanying it are obtained in laboratory
conditions in accordance with the relevant standards. Depending on operational and environmental
conditions of the product, these values may vary.
WTL 6019 P
6.0
85
53
55.5
32
260
750
9916
Models (EN)
Maximum dry laundry capacity (kg)
Height (cm)
Width (cm)
Depth (cm)
Net weight (±4 kg.)
Electrical input (V/Hz)
Total power (W)
Spin speed (rpm/ min., max.)
Main model code
85
55.5
230V~ / 50Hz
750

Washing Machine /User’s Manual 9 / EN
3 Installation
Refer to the nearest Authorised Service Agent for
installation of the product. To make the product
ready for use, review the information in the user
manual and make sure that the electricity, tap
water supply and water drainage systems are
appropriate before calling the Authorized Service
Agent. If they are not, call a qualified technician
and plumber to have any necessary arrangements
carried out.
CPreparation of the location and electrical,
tap water and waste water installations
at the place of installation is under
customer's responsibility.
BWARNING: Installation and electrical
connections of the product must be
carried out by the Authorized Service
Agent. Manufacturer shall not be held
liable for damages that may arise from
procedures carried out by unauthorized
persons.
AWARNING: Prior to installation, visually
check if the product has any defects on
it. If so, do not have it installed. Damaged
products cause risks for your safety.
CMake sure that the water inlet and
discharge hoses as well as the power
cable are not folded, pinched or crushed
while pushing the product into its place
after installation or cleaning procedures.
3.1 Appropriate installation location
• Place the machine on a rigid floor. Do not place
it on a long pile rug or similar surfaces.
• Place the product on a solid and flat floor that
has sufficient load carrying capacity!
• Do not place the product on the power cable.
• Do not install the product at places where
temperature may fall below 0ºC.
• Place the product at least 1 cm away from the
edges of other furniture.
3.2 Connecting water supply
CThe water supply pressure required to run
the product is between 1 to 10 bars (0.1
– 1 MPa). It is necessary to have 10 – 80
liters of water flowing from the fully open
tap in one minute to have your machine
run smoothly. Attach a pressure reducing
valve if water pressure is higher.
CIf you are going to use the double water-
inlet product as a single (cold) water-inlet
unit, you must install the supplied stopper
to the hot water valve before operating the
product. (Applies for the products supplied
with a blind stopper group.)
AWARNING: Models with a single water
inlet should not be connected to the hot
water tap. In such a case the laundry will
get damaged or the product will switch to
protection mode and will not operate.
AWARNING: Do not use old or used water
inlet hoses on the new product. It may
cause stains on your laundry.
1. Connect the special hoses supplied with the
product to the water inlets on the product. Red
hose (left) (max. 90 ºC) is for hot water inlet,
blue hose (right) (max. 25 ºC) is for cold water
inlet.
AWARNING: Ensure that the cold and
hot water connections are made correctly
when installing the product. Otherwise,
your laundry will come out hot at the end
of the washing process and wear out.
2. Tighten all hose nuts by hand. Never use a tool
when tightening the nuts.
3. Open the taps completely after making the
hose connection to check for water leaks at
the connection points. If any leaks occur, turn
off the tap and remove the nut. Retighten the
nut carefully after checking the seal. To prevent
water leakages and damages caused by them,
keep the taps closed when the machine is not
in use.

10 / EN Washing Machine /User’s Manual
Installation
3.3 Connecting to the drain
ŘThe end of the drain hose must be directly
connected to the wastewater drain or to the
washbasin.
WARNING: Your house will be flooded
if the hose comes out of its housing
during water discharge. Moreover, there
is risk of scalding due to high washing
temperatures! To prevent such situations
and to ensure smooth water intake and
discharge of the machine, fix the end
of the discharge hose tightly so that it
cannot come out.

Washing Machine /User’s Manual 11 / EN
Installation
3.3.2 Connecting to the drain with pump
•The hose should be attached to a height of at
least 65 cm, and 100 cm at most.
•In case the hose is elevated after laying it on
the floor level or close to the ground (less than
65 cm above the ground), water discharge
becomes more difficult and the laundry may
come out excessively wet. Therefore, follow the
heights described in the figure.
•To prevent flowing of dirty water back into the
machine and to allow for easy discharge, do not
immerse the hose end into the dirty water or do
not drive it in the drain more than 15 cm. If it is
too long, cut it short.
•The end of the hose should not be bent, it
should not be stepped on and the hose must
not be pinched between the drain and the
machine.
•If the length of the hose is too short, use it by
adding an original extension hose. Length of the
hose may not be longer than 3.2 m. To avoid
water leak failures, the connection between
the extension hose and the drain hose of the
product must be fitted well with an appropriate
clamp as not to come off and leak.
3.4 Adjusting the feet
•The two front feet of washing machine can
adjust the positive, when the washing machine
is not level, you can up the front of washing
machine for a little, then left or right rotation to
adjustable the feet, make it level.You can check
the level by the help of the indicator on top
cover.
Adjusting foot by checking leveler.
•Remarking : there may be no leveler for some
types machine.
65

12 / EN Washing Machine /User’s Manual
Installation
3.5 Electrical connection
Connect the product to a grounded outlet
protected by a 6 A fuse. Our company shall not
be liable for any damages that will arise when the
product is used without grounding in accordance
with the local regulations.
• Connection must comply with national
regulations.
• Power cable plug must be within easy reach
after installation.
• If the current value of the fuse or breaker in
the house is less than 6 Amps, have a qualified
electrician install a 6 Amp fuse.
• The voltage specified in the "Technical
specifications" section must be equal to your
mains voltage.
• Do not make connections via extension cables
or multi-plugs.
BWARNING: Damaged power cables
must be replaced by the Authorized
Service Agents.
Transportation of the product
1. Unplug the product before transporting it.
2. Remove water drain and water supply
connections.
3. Drain all water that has remained in the
product.
4. Install all styrofoams and then pcakage the
machine.
AWARNING: Packaging materials are
dangerous to children. Keep packaging
materials in a safe place away from
reach of the children.
3.6 Connection of inlet hose
connector and tap
1. Tighten all hose nuts by hand. Never use a tool
when tightening the nuts.
2. Open the taps completely after making the
hose connection to check for water leaks at
the connection points. If any leaks occur, turn
off the tap and remove the nut. Retighten the
nut carefully after checking the seal. To prevent
water leakages and damages caused by them,
keep the taps closed when the machine is not
in use.

Washing Machine /User’s Manual 13 / EN
Installation
3.7 Connecting to the water supply
Important:
•The water supply pressure required to run the
machine must be 1-10 bar (0,1 – 1 MPa).
•Connect the special hoses supplied with the
machine to the water intake valves on the
machine.
•Applies for the products supplied with a blind
stopper group.
•Models with a single water inlet should not be
connected to the hot water tap.
•When returning the appliance to its place after
maintenance or cleaning, care should be taken
not to fold, squeeze or block the hoses.
3.8 Using detergent /softener
and bleach nector
When using detergent, softener, starch, fabric dye,
bleachor limescale remover read the manufacturer’s
instruction the package carefully and follow
the suggested dosagevalues. Use measuring cup
if available.
1
3
2
Type1
Type1:
1.for laundry detergent
2.for softener
3.for bleach
1
2
Type2
Type2:
1.for laundry detergent
2.for bleach
1
2
Type3
Type3:
1.putting laundry
detergent into drum
2.for bleach
directly
( a )
( b )
( c )
3.9 Put rat guard into the machine
If you want to put rat guard into the machine ,
you should take the screw out ,then assemble rat
guard into the machine ,the last step is putting the
screw to fix the rat guard .

14 / EN Washing Machine /User’s Manual
4 Preparation
4.1 Sorting the laundry
• Sort laundry according to type of fabric, colour, and degree of soiling and allowable water
temperature.
• Always obey the instructions given on the garment tags.
LAUNDRY WASH SYMBOLS
Machine
Wash
Symbols
Normal wash No Iron Sensitive- Delicate wash Hand wash Not washable No Spin
WASH Water
Temperatures
Maximum 950C70
0C60 0C50 0C40 0C30 0C
Symbol(s) zzz
zzz
zzz
zz
zz
zz
zzz zzz
Drying
Symbols Suitable for
dryer No Iron Sensitive /
Delicate dry
Do not dry
with dryer
Do not dry Do not dry-
clean
DRYING
Drying
Settings
At any temperature At high temperature At medium temperature At low temperature Without heating Hang to dry Lay to dry Hang wet to dry Lay in shadow to dry Dry-cleanable
Iron -
IRON Dry or Steam
Iron at high
temperature
Iron at medium
temperature
Iron at low
temperature
Do not iron Iron without steam Maximum temperature 200 0C 150 0C 110 0C
All bleaches are allowed
Bleach (sodium
hypochlorite)
can be used
Bleach is not
allowed
Only bleaches without
chlorine are allowed
BLEACH

Washing Machine /User’s Manual 15 / EN
Preparation
4.2 Preparing laundry for washing
• Laundry items with metal attachments such as,
underwired bras, belt buckles or metal buttons
will damage the machine. Remove the metal
pieces or wash the clothes by putting them in a
laundry bag or pillow case.
• Take out all substances in the pockets such as
coins, pens and paper clips, and turn pockets
inside out and brush. Such objects may damage
the product or cause noise problem.
• Put small size clothes such as infant's socks
and nylon stockings in a laundry bag or pillow
case.
• Place curtains in without compressing them.
Remove curtain attachment items.
• Fasten zippers, sew loose buttons and mend
rips and tears.
• Wash “machine washable” or “hand washable”
labeled products only with an appropriate
programme.
• Do not wash colours and whites together. New,
dark coloured cottons release a lot of dye. Wash
them separately.
• Tough stains must be treated properly before
washing. If unsure, check with a dry cleaner.
• Use only dyes/colour changers and limescale
removers suitable for machine wash. Always
follow the instructions on the package.
• Wash trousers and delicate laundry turned
inside out.
• Keep laundry items made of Angora wool in the
freezer for a few hours before washing. This will
reduce pilling.
• Laundry that are subjected to materials such as
flour, lime dust, milk powder, etc. intensely must
be shaken off before placing into the machine.
Such dusts and powders on the laundry may
build up on the inner parts of the machine in
time and can cause damage.
4.3 Things to be done
for energy saving
Following information will help you use the
product in an ecological and energy-efficient
manner.
• Operate the product in the highest capacity
allowed by the programme you have selected,
but do not overload; see, "Programme and
consumption table".
• Always follow the instructions on the detergent
packaging.
• Wash slightly soiled laundry at warm or cold
water..
• Use faster programmes for small quantities of
lightly soiled laundry.
• Do not use soaking and hot water for laundry
that is not heavily soiled or stained.
• If you plan to dry your laundry in a dryer, select
the longer spin time recommended during
washing process.
• Do not use detergent in excess of the amount
recommended on the detergent package.

16 / EN Washing Machine /User’s Manual
Preparation
4.4 Correct load capacity
The maximum load capacity depends on the type
of laundry, the degree of soiling and the washing
programme desired.
The machine automatically adjusts the amount
of water according to the weight of the loaded
laundry.
AWARNING: Follow the information in the
“Programme and consumption table”.
When overloaded, machine's washing
performance will drop. Moreover, noise
and vibration problems may occur.
Laundry type Weight (g)
Bathrobe 1200
Napkin 100
Duvet cover 700
Bed Sheet 500
Pillowcase 200
Tablecloth 250
Towel 200
Hand towel 100
Evening gown 200
Underclothing 100
Men’s overalls 600
Men’s shirt 200
Men’s pajamas 500
Blouses 100
4.5 Loading the laundry
1. Open the lid.
2. Place laundry items loosely into the machine.
3.Close the lid and; Ensure all loads inside well
distributed.
AWARNING: In case of misplacing the
laundry, noise and vibration problems may
occur in the machine.
4.6 Using detergent and softener
Detergent, softener and other cleaning agents
• Add detergent and softener before starting the
washing programme.
• Never leave the detergent drawer open while
the washing programme is running!
• Place the detergent bag or the dispensing ball
directly among the laundry in the machine if
you use them.
Choosing the detergent type
The type of detergent to be used depends on the
type and colour of the fabric.
• Use different detergents for coloured and white
laundry.
• Wash your delicate clothes only with special
detergents (liquid detergent, wool shampoo,
etc.) used solely for delicate clothes.
• Wash woolens with special detergent made
specifically for woolens.
AWARNING: Use only detergents
manufactured specifically for washing
machines.
WARNING: Do not use soap powder.
Adjusting detergent amount
The amount of washing detergent to be used
depends on the amount of laundry, the degree of
soiling and water hardness.
• Pour the detergent into the main wash
compartment of the detergent drawer. If your
machine is without detergent drawer, pour the
detergentdirectlyoverthelaundryinthetub.
• Do not use amounts exceeding the dosage
quantities recommended on the detergent
package to avoid problems of excessive foam,
poor rinsing, financial savings and finally,
environmental protection.
• Use less detergent for small amounts or lightly
soiled clothes.

Washing Machine /User’s Manual 17 / EN
Preparation
Using softeners
Pour the softener into the softener compartment
of the detergent drawer. If your machine is without
detergent drawer or with simple detergent drawer
(detergent drawer that does not include softener
department) softener can be put at the dedicated
compartment on the balance ring.
Ř'RQRWH[FHHGWKH!PD[OHYHOPDUNLQJLQWKH
softener compartment.
Ř,IWKHVRIWHQHUKDVORVWLWVfluidity, dilute it with
water before putting it in the detergent drawer.
Using liquid detergent
Ř/LTXLGGHWHUJHQWVWDLQV\RXUFORWKHVZKHQXVHG
ZLWK'HOayed Start function. If you are going to
XVHWKH'HOayed Start function,GRQRWXVHOLTXLG
detergent.
Using gel and tablet detergent
Apply the following instructions when using tablet,
gel and similar detergents.
Ř,IWKHJHOGHWHUJHQWWKLFNQHVVLVfluidal, put the
gel detergent into the main wash detergent
compartment during first waWHULQWDNH
Ř,IWKHJHOGHWHUJHQWWKLFNQHVVLVQRWfluidal or in
the shape of caSVXOHOLTXLGWablet, put it directly
into the drum before washing.
Ř3XWWablet detergents into the main wash
compartment or directly into the drum before
washing.
Tablet detergents may leaYHUHVLGXHV
in the detergent compartment. If you
encounter such a case, place the tablet
detergent between the laundry, close to the
lower part of the drum in future washings.
Using starch
Ř $GGOLTXLGVWDUFK, powder starch or the fabric
dye into the softener compartment.
Ř'RQRWXVHVRIWHQHUDQGVWDUFKWRJHWKHULQD
washing cycle.
Ř Wipe the inside of the machine with a damp
and clean cloth after using starch.
Using bleaches
Ř Add the bleaching agent to the dedicated
FRPSDUWPHQWRQWKHWRSFRYHr.
Ř'RQRWXVHEOHDFKLQJagent and detergent by
PL[LQJWKHP
Ř8VHMXVWDOLWWOHDPRXQWRIEOHDFKLQJagent
DQGULQVHWKHFORWKHVYHry well as it causes
VNLQLUULWation.'RQRWSRXUWKHEOHDFKLQJagent
onto the clothes and do not use it for coloured
clothes.
4.6.1 Advanced detergent drawer
The detergent drawer is composed of three
compartments:
– (1) for main wash
– (2) for softener
– (*) in addition, there is siphon piece in the
softener compartment.
4.6.2 Simple detergent drawer
This detergent drawer has one compartment
– (1) for main wash
(1)
(1)
(2)
(*)

18 / EN Washing Machine /User’s Manual
1 - On / Off button
2 - Start / Pause button
3 - Air Turbo button
4 - Auxiliary Function button
5 - Water Level button
6 - Delayed Start Time button
7 - Function button
8 - Remaining Time / Delay Start Time / Error Display
5 Operating the product
5.1 Control panel
1
2
34567
8

Washing Machine /User’s Manual 19 / EN
Operating the product
5.2 Preparing the machine
Figures in this manual are schematic and
may not match the product exactly.
ōPower Button
Press this button once to
operate. Press it again to
turn the power off.
ō6WDUWPause Button
Use to pause and restart
the operation. To change
the washing procedure
during an operation,
press this button to stop,
and again to restart after
changing the procedure.
ō3URJUDP6HOHFW%XWWRQ
Each time the button is
pressed, the washing
program changes.
ō5HPDLQLQJTime,'HOD\6WDUWTime, Error
'LVSOD\
Displays the remaining
wash time. Displays the
reserved delay start time.
Displays the error state if
a problem occurs in the
washing machine so that
you can take action.
ō'HOD\6WDUWTime Button
Adjusts delay start time.
max. 18 h
ōWDWHU/HYHO%XWWRQ
The water level is
automatically adjusted.
However, you can select
the water level manually
by pressing this button.
The water level button
only can be active during
standby status, water level
can be changed before
start to running; and you
can press the start/pause
button then change water
level while machine is
running, press start/pause
again back to work after
finish water level setting.
Displays selected
program’s default water
level.
Low / Few / Medium /
High

20 / EN Washing Machine /User’s Manual
Operating the product
• Function Button
With every press of this
button, the function
changes.
• Air Turbo Button
Press this button to speed
dry your laundry.
This function can only be
selected if a spin cycle
is set.
The air Turbo button only
can be active during
standby status, this
function can be changed
before start to running;
and you can press
the start/pause button
then change time while
machine is running, press
start/pause again back
to work after finish water
level setting.
• Rinse Hold
Rinse hold will be selectable
from 'air dry' function
button.2 LED's will be ON
together during rinse hold
selection.
After the last rinse, water
will not drain out. It will be
kept in the machine.
Machine pause at the step,
and led1 and led2 always
blink.
When the customer wants
to drain the water, they need
press the pause start button
again to continue spin with
default time.
• Child Lock
This is a device to protect
children from being
accidentally hurt while
playing with the washer.
How to start the Child-Lock function:
- Press the “Water level” button and ‘’Function’’
button at the same time for 3 sec.
- If Child Lock function is activated, ‘’CL’’ will be
written in the display for 3 sec.
To release the function of Child-Lock: In case
the “Child-Lock” is programmed, press both
the “Water level” and “Function” buttons at the
same time.
