Belling SANDRINGHAM User manual

SANDRINGHAM/COOKCENTRE/FARMHOUSE
User manual - Gas (90 cm)

2
COUNTRIES OF DESTINATION:
GB - Great Britain
IE - Ireland
DE - Germany
ES - Spain
FR - French
IT - Italy
PL - Poland
NL - Netherlands
SE - Sweden
CN - China
NZ - New Zealand
AU - Australia
TO CONTACT BELLING ABOUT YOUR
APPLIANCE, PLEASE CALL:
Customer Care Helpline
0344 815 3746
In case of diculty within the UK
Warranty Registration
0800 952 1068
Spares Store
0344 815 3745
To register your appliance online:
www.belling.co.uk
To contact us by email:
[e-mail]
To register your appliance by mail: Please
complete the warranty card and return to
the address supplied
Alternatively general, spares and service
information is available from our website
at: www.belling.co.uk
Calls are charged at the basic rate, please check with
your telephone service provider for exact charges
Your new appliance comes with our 12-month
guarantee (UK only), protecting you against electrical
and mechanical breakdown. To register, please
complete the registration form included, register
online or by phone. For full terms & conditions of the
manufacturer’s guarantee, please refer to the website
above. In addition, you may wish to purchase an
extended warranty. A leaflet explaining how to do this
is included with your appliance.
Our policy is one of constant development and
improvement, therefore we cannot guarantee
the strict accuracy of all of our illustrations and
specifications. Changes may have been made
subsequent to publishing.
Glen Dimplex Home Appliances, Stoney Lane,
Prescot, Merseyside, L35 2XW

3
INTRODUCTION 
SAFETY 
GETTING TO KNOW YOUR PRODUCT 
USING YOUR APPLIANCE 
USING THE GRILL 
USING THE MAIN OVEN  GAS 
USING THE TALL FANNED OVEN 
COOKING GUIDE 
BAKING GUIDE 
ROASTING GUIDE 
CLOCKPROGRAMMER 
REMOVING SHELF RUNNERS 
CLEANING YOUR APPLIANCE 
TECHNICAL DATA 
CONTENTS

4
INTRODUCTION
Thank you for buying this British-built appliance from
us.
This user guide book is designed to help you through
each step of owning your new product.
Please read it carefully before you start using your
appliance, as we have endeavored to answer as many
questions as possible, and provide you with as much
support as we can.
General information, spares and service information is
available from our website.
If you should find something missing from your
product or have any questions that are not covered
in this user guide, please contact us (see contact
information inside the front cover).
EUROPEAN DIRECTIVES
As a producer and a supplier of cooking appliances we
are committed to the protection of the environment
and are in the compliance with the WEEE directive.
All our electric products are labelled accordingly with
the crossed out wheeled bin symbol. This indicates, for
disposal purposes at end of life, that these products
must be taken to a recognized collection points, such
as local authority sites/local recycling centres.
This appliance Complies with European Community
Directives (CE) for household and similar electrical
appliances and Gas appliances where applicable.
This appliance conforms to European Directive
regarding Eco design requirements for energy-related
products. Our policy is one of constant development
and improvement, therefore we cannot guarantee
the strict accuracy of all of our illustrations and
specifications – changes may have been made
subsequent to publishing.
DISPOSAL OF PACKAGING
MATERIAL
The packaging materials used with this
appliance can be recycled. Please dispose of
the packaging materials in the appropriate
container at your local waste disposal
facilities.
6GAS WARNING! - If you smell gas: Do
not try to light any appliance, Do not
touch any electrical switch. Contact your
local gas supplier immediately.

5
SAFETY
WARNING
6Never put items directly on the base
of the oven or cover the oven with foil,
as this can cause the base element to
overheat.
6Accessible parts may become hot when
the grill is in use. Children should be kept
away
6Do not place articles on or against the
appliance.
6Always switch off your appliance and
allow it to cool down before you clean
any part of it.
6Although every care has been taken to
ensure this appliance has no sharp edges,
we recommend that you wear protective
gloves when installing and moving this
appliance. This will prevent injury.
6This appliance must be fitted to a switch
providing all pole disconnection with a
minimum contact separation of 3mm.
6Connection should be made with a
suitable flexible cable with a minimum
temperature of 70°C.
6Do not use a steam cleaner on any
cooking range, hob or oven appliance.
6If your appliance is fitted with a lid, any
spillage should be removed from the lid
before opening. The hob surface should
be allowed to cool before closing the lid
(if fitted).
6To avoid electric shock, ensure that the
appliance is switched off before replacing
the lamp.
6The appliance is not intended to be
operated by means of an external timer
or separate control system.
6Unattended cooking on a hob with fat or
oil can be dangerous and may result in
fire.
6NEVER try to extinguish a fire with water,
but switch off the appliance and then
cover the flame with a lid or damp cloth.
6Danger of fire: Do not store items on the
cooking surfaces.
6Only use hob guards designed by the
manufacturer of the cooking appliance
or indicated by the manufacturer of the
appliance in the instructions for use as
suitable or hob guards incorporated in
the appliance. The use of inappropriate
hob guards can cause accidents.
6If the cooker is placed on a base,
measures have to be taken to prevent the
appliance slipping from the base.
6The cooking process has to be supervised.
A short term cooking process has to be
supervised continuously.
6This appliance must not be installed
behind a decorative door in order to avoid
overheating.
6Ensure shelving is correctly installed. See
the sections on the shelf runners and
shelf location within this book.
6This appliance is for cooking purposes
only. It must not be used for other
purposes, for example room heating.

6
CAUTION
6The use of a gas cooking appliance
results in the production of heat,
moisture and products of combustion
in the room in which it is installed.
Ensure that the kitchen is well ventilated
especially when the appliance is in use:
keep natural ventilation holes open or
install a mechanical ventilation device
(mechanical extractor hood). Prolonged
intensive use of the appliance may call
for additional ventilation, for example
opening of a window, or more effective
ventilation, for example increasing the
level of mechanical ventilation where
present.
6If the appliance is turned off at the wall,
it needs to be left for 60 seconds before
using the main oven. Failure to do this
will mean the main oven interrupter will
shut off the main oven within 60 seconds
of turning the main oven on. This is a
design feature and not a fault.
FIRE SAFETY ADVICE
6If you do have a fire in the kitchen, don’t
take any risks – get everyone out of your
home and call the Fire Service.
If you have an electrical fire in the
kitchen:
1. Pull the plug out, or switch off the
power at the fuse box – this may be
enough to stop the fire immediately
2. Smother the fire with a fire blanket,
or use a dry powder or carbon dioxide
extinguisher
6Remember: never use water on an
electrical or cooking oil fire.
OTHER SAFETY ADVICE
6Servicing should be carried out only by
authorised personnel.
6Do not operate the appliance without the
glass panel correctly fitted.
6There is a risk of electric shock, so always
make sure you have turned off and
unplugged your appliance. Always allow
the product to cool down before you
change a bulb.
6Do not modify the outer panels of this
appliance in any way.
6This appliance must be earthed.
6The appliance must never be
disconnected from the mains supply
during use, as this will seriously affect
the safety and performance, particularly
in relation to surface temperatures
becoming hot and gas operated parts
not working efficiently. The cooling fan
(if fitted) is designed to run on after the
control knob has been switched off.

7
GETTING TO KNOW YOUR PRODUCT
4Note: Your appliance layout may differ
depending on the model.
HOB
1
2
2
3
4
OVERVIEW
90cm
2
1
3
5
1Fascia
2Grill
3Main Oven
5Fanned Oven
CONTROL PANEL
16 3 14 3
5
810 98
1Cook Zones 6Grill
3Oven 8Hob and Oven controls
4Clock/Programmer 9Light switch
5Thermostat indicator 10 Ignition switch

8
OVEN CONTROLS
Gas oven
OFF
S
1/2
1
2
3
4
5
6
7
8
9
Electric oven
OFF
60
8
0
120
140
1
60
180
20
0
220
240
S
Gas Grill/Hob
OFF
APPLIANCE FUNCTIONS
4Note: Your oven may not have all of the
functions shown here. We recommend
for best cooking results, please preheat
your oven for 15 minutes and 3−5
minutes for grilling.
Intense Baking
Base Heat with Fan
S
Slow Cook
Fanned Grill
Oven Selector Control
Conventional Grill
Top Heat
Lights Only
Defrost
Conventional oven
Fanned Oven
Low Grill
Single Grill
Dual Grill
Base Heat

9
USING YOUR APPLIANCE
OVENS AND GRILL
6The door must be open when the grill is
used for conventional grilling.
4Some appliances are automatic ignition
and do not have an ignition switch fitted.
Choose the required setting and press the ignition
switch (if fitted).
When the Top oven/grill or grill is switched on, the
cooling fans come on to keep the fascia and control
knobs cool during cooking/grilling. The cooling
fans may operate when the main ovens are in use,
depending on the temperature setting. The fans may
continue to operate for a period after the oven/grill
has been switched off. During use the fan may cycle
on and off, this is normal.
6Important: Never put items directly on
top the base of the oven, or cover the
oven base with foil, as this may cause
the element to overheat. Always position
items on the shelf.
6Never operate the grill between the large
flame and the 'OFF' position.
4If you find that over a period of time
the oven becomes hotter when used at
a certain gas mark, the thermostat may
need to be replaced.
TALL FANNED OVEN
Press the control knob to ignite the gas for up to 15
seconds then release.
Choose required setting
GRILL PAN, TRIVET AND
DETACHABLE GRILL PAN HANDLE
The grill trivet (inside the grill pan) can be inverted
to give a high or low position, or it may be removed.
The speed of grilling can be controlled by selecting a
higher or lower shelf position, or adjusting the grill
setting.
4Note: Grill pan handle not included. This
can be purchased as an optional extra
from our spares store.

10
Inverted
6The door must be open when the grill is
used for conventional grilling.
HOB
1. Hold the control knob and press the ignition in for
up to 15 seconds then release. For the wok, please
allow the burner to warm up for a few minutes.
2. Once lit, turn the control knob to the required
setting.
4If the burner fails to ignite within this
time, release the control knob and wait 1
minute before attempting to re-ignite.
FITTING BURNER CAPS AND HEADS
PAN PLACEMENT
Always make sure that your pans are placed centrally
and do not allow the flame to extend over the base of
the pan. Do not place pans directly onto the burners.
PAN SIZES REQUIRED
Hob Cook Zones Minimum Pan
Sizes (mm)
Maximum Pan
Sizes (mm)
Rapid & Wok
100
260
All other cook
zones 250
6Warning: Do not allow cooking vessels to
overlap cooking zones

11
USING THE GRILL
BEFORE YOU START GRILLING. . . .
Before you use the grill, make sure you have placed the
grill shelf in the position you need as once the grill is
on you may injure yourself if you try to move the shelf.
 Do not close the door while the grill is in use.
 Turn the grill control knob to the heat setting you
require.
 To switch off, return the control knob(s) to the ‘off’
position.
 The cooling fan will come on during use, and may
continue to run for some time afterwards.
 To adjust your results, you can turn the grid over,
or remove it altogether.
THE GRILL PAN
This appliance comes with a grill pan and trivet.
SHELF & TRIVET ADJUSTMENTS
Speed of grilling can be adjusted by changing the shelf
position or the turning the trivet.
 High: For thin foods and toasting
 Low: For thicker meat pieces.
ALUMINIUM FOIL
6Never cover the grill pan or grill trivet
with foil, or allow fat to build up in the
grill pan, as this creates a fire hazard.
6Accessible parts may become hot when
the grill is in use. Children should be kept
away
TYPES OF GRILL
6Caution: Accessible parts may be hot
when the grill is used – young children
should be kept away.
6Important: The grill door must be fully
open when the grill is used.
6Important: Never operate the grill
between the large flame and the ‘OFF’
position.
6If cleaning the grill pan when it is hot,
use oven gloves to move it.
4Food for grilling should be positioned
centrally on the trivet.
For best results: Pre-heat the single grill for 5
minutes and the dual grill for 3 minutes.

12
USING THE GRILL
Open the grill door. Push in and turn the control
knob to the ‘FULL ON’ position. Hold the knob in for
15 seconds and press the ignition switch if fitted or
hold a lit match or taper to the burner, until it lights.
If the burner fails to light within this time, release the
knob and wait for 1 minute before attempting further
ignition.
The speed of grilling can be controlled by selecting
a higher or lower shelf position. For toasting, and for
grilling foods such as bacon, sausages or steaks, use a
higher shelf position. For thicker foods such as chops
or chicken joint pieces, use a middle to low shelf
position.
The grill trivet, inside the grill pan, can be inverted to
give a high or low position, or it may be removed.
Variation in grilling can be achieved by setting the
control between the small and large flame symbols.
4The grill power varies by 15% between
the large and small flame symbols and is
visually difficult to see.
To switch off, turn the control knob to the off position.
THE COOLING FAN
During use the fan may cycle on and off, this is
normal.
When the grill is switched on, the cooling fan comes
on to keep the fascia and control knobs cool during
grilling. The fan may continue to operate for a period
after the grill has been switched off.

13
USING THE MAIN OVEN - GAS
6Accessible parts may be hot when the
oven is used. Young children should be
kept away.
OVEN FURNITURE
Oven shelves
The oven shelf must be positioned with the upstand at
the rear of the oven and facing upwards.
4Extra shelves may be ordered from your
local supplier.
Baking tray and roasting tins
For best cooked results and even browning, the
recommended size baking trays and roasting tins that
should be used are as follows;
 Baking tray 350mm x 330mm
This size of baking tray will hold up to 12 small cakes.
 Roasting tin 370mm x 320mm
4Position baking trays and roasting tins on
the middle of the shelves, and leave one
clear shelf-position between shelves, to
allow for circulation of heat.
4We recommend that you use good quality
cookware. Poor quality trays and tins may
warp when heated, leading to uneven
baking results.
Shelf positions
As a general guide, when cooking frozen or chilled
food, use the highest possible shelf position, while
allowing some clearance between the food and the top
element. Follow the instructions given on packaging.
IGNITION
1. Push in and turn the main oven control knob to
the ‘FULL ON’ position. Hold the control knob in. If
after 15 seconds, the burner has not lit, turn off the
oven and leave the compartment door open. Wait
at least one minute before a further attempt to
ignite the burner.
4Do not hold the control knob in for more
than 15 seconds.
2. Turn the control knob to the required setting.
3. To turn off, return the control knob to the “off”
position.
4. Preheat the main oven for 15 minutes. If you are
not preheating the oven, the cooking times in the
baking guides may need to be extended, as they are
based on a preheated oven.
4The oven must be preheated when
reheating frozen or chilled foods, and
we recommend preheating for yeast
mixtures, batters, soufflés and whisked
sponges. Put the oven shelves in the
position required before preheating the
oven.

14
ZONES OF HEAT
The temperature at the centre of the oven corresponds
with the selected gas mark and is slightly higher
towards the top of the oven and slightly lower towards
the oven base. These zones of heat can be useful as
different dishes requiring different temperatures can
be cooked at the same time, when more than one shelf
is used.
4The temperature at the oven base is
suitable for cooking baked vegetables,
baked fruit, milk pudding etc, and for
warming bread rolls, soup, coffee, or
ovenproof plates and dishes.
4If you find that over a period of time,
the oven becomes hotter when used at a
particular gas mark, the thermostat may
need to be replaced.

15
USING THE TALL FANNED OVEN
6Accessible parts may be hot when the
oven is used. Young children should be
kept away.
4The tall fanned oven fitted to your
appliance is electric.
OVEN FURNITURE
Oven shelves
The oven shelf must be positioned with the upstand at
the rear of the oven and facing upwards.
4Extra shelves may be ordered from your
local supplier.
Baking tray and roasting tins
For best cooked results and even browning, the
recommended size baking trays and roasting tins that
should be used are as follows;
 Baking tray 350mm x 250mm
This size of baking tray will hold up to 12 small cakes.
 Roasting tin 370mm x 320mm
4Position baking trays and roasting tins on
the middle of the shelves, and leave one
clear shelf-position between shelves, to
allow for circulation of heat.
4We recommend that you use good quality
cookware. Poor quality trays and tins may
warp when heated, leading to uneven
baking results.
To help the air circulate freely
Position the shelves evenly within the oven and
maintain a clearance from the oven roof and base.
If more than one cooking dish or baking tray is to be
used on a shelf, leave a gap of at least 25mm between
the items themselves and the oven interior.
The cooling fan
The cooling fan may operate when the main oven is
on and may continue to operate for a period after the
oven has been switched off.
Aluminium Foil
6Use foil only to cover food or cooking
dishes, using foil to cover the shelves or
oven base creates a fire hazard.
PREHEATING
When cooking sensitive items such as souffle and
Yorkshire puddings or, when cooking bread, we
recommend that the oven is preheated until the neon
switches off for the first time. For any other types of
cooking, a preheat may not be required.
COOKING WITH A FANNED OVEN
6As this is a high efficiency oven, you may
notice the emission of steam from the
oven when the door is opened. Please
take care when opening the door.

16
If you are used to cooking with a conventional oven
you will find a number of differences to cooking with
a fan oven which will require a different approach:
There are no zones of heat in a fan oven as the
convection fan at the back of the oven ensures an even
temperature throughout the oven.
This makes it ideal for batch baking – eg; when
planning a party as all the items will be cooked within
the same length of time.
4Foods are cooked at a lower temperature
than a conventional oven, so
conventional recipe temperature may
have to be reduced. Please refer to the
conversion chart.
4Preheating is generally not necessary as a
fan oven warms up quickly.
4There is no flavour transference in a fan
oven, which means you can cook strong
smelling foods such as fish at the same
time as mild foods – eg; milk puddings.
4When batch baking foods that will rise
during cooking – eg; bread – always
ensure that enough space has been left
between the shelves to allow for the rise.
Notes:
4When 2 or more shelves are being used, it
may be necessary to increase the cooking
time slightly.
4Because the 2 oven shelves are wider
than in many ovens, it is possible to
cook 2 items per shelf – eg; 2 victoria
sandwiches or 2 casseroles.
4When roasting meats, you will notice that
fat splashing is reduced, which is due in
part to the lower oven temperatures, and
will help keep cleaning of the oven to a
minimum.
4Because a fan oven has an even
temperature throughout the oven, there
is no need to follow the shelf positions
given in the baking guide.
4There is no need to interchange dishes
onto different shelves part way through
cooking, as with a conventional oven.
Defrosting and cooling in the main oven
To defrost frozen foods, turn the oven control to the
defrost position, place the food in the centre of the
oven and close the door.
To cool foods after cooking prior to refrigerating or
freezing, turn the tall oven control to the defrost
position and open the door.
Defrosting times
4Small or thin pieces of frozen fish or
meat – eg; fish filets, prawns & mince
will take approximately 1 – 2 hours.
4Placing the food in a single layer will
reduce the thawing time.
4A medium sized casserole or stew will
take approximately 3 – 4 hours.
4A 1½kg/3lb oven ready chicken will
take approximately 5 hours, remove the
giblets as soon as possible.
Be safe
4Do not defrost stuffed poultry using this
method.
4Do not defrost larger joints of meat and
poultry over 2kg / 4lb using this method.
4Never place uncooked food for defrosting
next to cooked food which is to be cooled,
as this can lead to cross contamination.
4Defrosting meat, poultry, and fish can be
accelerated using this method but make
sure they are completely thawed before
cooking thoroughly. Place meat and
poultry on a trivet in a meat tin.

17
COOKING GUIDE
GRILL
Food Type Time Approx (mins)
Bacon 8 - 15
Sausages 12 - 15
Chops
- Lamb 10 - 15
- Pork 15 - 25
Toast
- 2 rounds 1 - 2 (per side)
- 4 rounds 1 - 2 (per side)
Bread products
- Buns 1 - 2 (per side)
- Tea cakes 1 - 2 (per side)
Cheese on toast
- 2 rounds 4 - 5
- 4 rounds 4 - 5
Fish
- Fillets 10 - 15
Chicken
- Fillets 20 - 30
Beef Steaks
- Rare 7 - 10
- Medium 10 - 15
- Well done 15 - 20
Gammon Steaks 12 - 15
4As with any cooking guide, all times are
approximate and can be adjusted to suit
personal taste.

18
BAKING GUIDE
TOP OVEN
Dish Recommended gas mark Suggested shelf
position
Approximate cooking time
(preheated oven)
Scones 7 top - middle 10 - 15 mins
Meringues “S” slow cook setting bottom 2 - 3 hours
Cakes
Small cakes 5 middle 10 - 15 mins
Whisked sponge 5 middle 20 - 30 mins
Swiss roll 6 middle 10 - 12 mins
Victoria sandwich (2 x
180mm / 7” per shelf) 4middle (side by side) 20 - 35 mins
Genoese Sponge (2 x
180mm / 7” per shelf) 5 middle 25 - 30 mins
Pastry
Rough Pu pastry 7 middle
cooking time depends on
recipe & type of filling
Flaky / Pu 6 middle
Shortcrust 6 middle
Flan 6 middle
Biscuits
Shortbread fingers 5 middle - top
Nut brownies 5 middle
Brandy snaps 4 middle - top
Flapjacks 4 middle - top
Ginger nuts 5 middle - top

19
MAIN OVEN
Dish Recommended gas mark Suggested shelf position Approximate cooking
time (preheated oven)
Scones 7 middle - top 8 - 15 mins
Meringues “S” slow cook setting bottom 2 - 3 hours
Cakes
Small cakes 5 middle - top 15 - 25 mins
Whisked sponge 5 middle - top 20 - 25 mins
Swiss roll 6 middle - top 10 - 12 mins
Victoria sandwich (2 x
180mm / 7”) 4 middle - top 20 - 30 mins
Genoese sponge 4 middle 20 - 30 mins
Madeira (180mm/7”) 3 middle 1 - 1¼hours
Gingerbread 3 middle 1 - 1¼hours
Semi rich fruit cake
(205mm/8”) 2 or 3 middle - top 2½- 3 hours
Christmas cake
(205mm/8”) 1 or 2 bottom depending on recipe
Dundee cake
(205mm/8”) 3 middle - bottom 2 - 2½hours
Pastry
Rough Pu pastry 7 middle - top
cooking time depends
on recipe & type of
filling
Pu / flaky pastry 6 middle - top
Shortcrust pastry 6 middle - top
Flan 6 middle - top
Biscuits
Nut brownies 5 middle - top 25 - 35 mins
Brandy snaps 4 middle - top 10 - 12 mins
Flapjacks 4 middle - top 20 - 25 mins
Ginger nuts 4 middle - top 10 - 20 mins
4Slow cooking times will be about 3 times
as long as conventional cooking times.

20
TALL FANNED OVEN
4Note: This is a high efficiency oven,
therefore some adjustment will have
to be made to conventional cooking
temperatures. The table below shows
conventional cooking temperatures,‘A’
efficiency temperatures and gas marks.
For optimum results, conventional
temperatures need to be converted to ‘A’
efficiency temperatures.
For example, an item which would
normally cook at a conventional
temperature of 180 °C, will now cook at
the ‘A’ efficiency temperature of 160°C.
Conventional temperature (°C) ‘A’ eciency fanned oven (°C) Gas Mark
100
110
130
140
150
160
180 - 190
200
220
230
250
100
110
120
130
140
150
160
170
180
190
200
1/4
1/4
1/2
1
2
3
4 - 5
6
7
8
9
GENERAL BAKING GUIDE
Traditional fruit cakes
It should be remembered that ovens can vary over
time, therefore cooking times can vary, making it
difficult to be precise when baking fruit cakes.
It is necessary therefore, to test the cake before
removal from the oven. Use a fine warmed skewer
inserted into the centre of the cake. If the skewer
comes out clean, then the cake is cooked.
4Follow the temperatures suggested in the
recipe and then adjust accordingly to the
conversion table.
4Do not attempt to make Christmas cakes
larger than the oven can cope with, you
should allow at least 25mm (1”) space
between the oven walls and the tin.
4Always follow the temperatures
recommended in the recipe.
4To protect a very rich fruit cake during
cooking, tie 2 layers of brown paper
around the tin.
4We recommend that the cake tin is not
stood on layers of brown paper, as this
can hinder effective circulation of air.
4Do not use soft tub margarine for rich
fruit cakes, unless specified in the recipe.
4Always use the correct size and shape of
tin for the recipe quantities.
