REFRIGERATOR
INSTRUCTION MANUAL
Model No.: BC88RBFB/BC88RBFR

To ensure proper use of this appliance and your safety, please read the
instruction manual completely before operating this appliance.
CONTENTS
Names of the parts ....................................................................... 1
Safety warnings ...........................................................................2
Installation instructions ................................................................ 3
Operation instructions.................................................................. 3
Packing and moving..................................................................... 4
Maintenance................................................................................ 4
Defrost........................................................................................ 5
Disconnecting the appliance......................................................... 5
User notifications......................................................................... 5
Troubleshooting tips..................................................................... 6
Specifications and parameters...................................................... 7
Packing list.................................................................................. 8
Please read this manual carefully before using. Follow instructions and keep it
for future reference.
Please follow the operating instructions and safety notices in the manual.
If any issues arise, please contact the local authorized service centre.
NAMES OF THE PARTS
1.Freezer room
2.Lamp and temperature control knob
3.Steel shelf
4.Crisper glass cover
5.Vegetable crisper
6.Lamp switch
7.Steel tube
The refrigerator you have purchased may be improved, these change may not be
completely consistent with the manual. However, the functions and operating methods
will not change.
When using the refrigerator for the first time, remove the adhesive tapes from the
drawers, balconies, egg tray, and the drain tube plug.
Do not pull or push the drawers and balconies too hard during use in case of damage.

Don’t open the refrigerator door continually during normal working situation.
Keep the combination of drawers, baskets and shelves in the refrigerator consistent with
its original standard.
1
SAFETY WARNINGS
To ensure your personal safety, please follow the points below:
1. The power plug should have its own socket. A power adapter or multi board must not
be used.
2. The voltage and frequency of this product should be 220-240V;50Hz. Contact your
local retailer if the wire is damaged.
3. Pull the power plug out of the socket directly, not by the wire.
4. Do not damage the refrigerant circuit.
5. This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
6. Children should be supervised to ensure that they do not play with the appliance.
7. Keep ventilation opening, in the appliance enclosure or in the built in structure, clear of
obstruction.
8. Before you throw away your old refrigerator or freezer.
- Take off the doors;
- Leave the shelves in place so that children may not easily climb inside.
9. Do not store explosive substances such as aerosol cans with a flammable propellant in
this appliance. This appliance is intended to be used in household and similar
applications.
10. Do not use electrical appliance inside the food storage compartments of the appliance,
unless they are of the type recommended by the manufacture.
11. This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall not be made by children
without supervision.
NOTICE:
1. If gas leaks from the fridge, don't pull the plug, out or in, as this may ignite the
gas.
2. Do not splash water on the rear of the appliance, for it may cause malfunction
or electric shock.
3. Do not store inflammable materials such as ether, benzene, LP gas and glue
etc. in the refrigerator.
4. Don't place bottled beverage in the freezer, so as to prevent breakage.
5. Do not place objects on the top of appliance which are magnetic, heavy, or filled with
water. Do not store product which is costly or sensitive to temperature fluctuations , e.g.
serum, bacteria and so on.
6. The refrigerant of this product is R600a, which is flammable. Please ensure not to
damage the cooling system during the transportation and installation.
7. DISPOSAL: Do not dispose this product at an unsorted municipal waste. Collection of
such waste separately for special treatment is necessary.
INSTALLATION INSTRUCTIONS
1. The refrigerator should be located on a completely flat surface , Leave 5~10 cm
between each side of the appliance and the wall, and leave 30 cm between the
top of the appliance and the ceiling.
2. Choose a location which is not exposed to sunlight , high
temperature or humidity
3. Pull out the bottom panel before installation.
4. The appliance can be adjusted by rotating the two front
legs. Rotating in clockwise direction will increase the
height.
5. The location should be firm and flat. An un-secured
position may cause noise and vibration: (a) The noise may
be increased if the floor is not firm. (b) Put a sheet under
the appliance for solving the heat emission if you need to
locate it onto a carpet.
6. Make sure the adjustable legs are firm to the floor, and set the appliance slope
backward slightly for keeping the doors closed tightly.
OPERATION INSTRUCTIONS
PLACEMENT OF FOOD
1.There should always be some space between items inside for air circulation.

2.Food should be kept in sealed package to avoid becoming dry or
with odour.
3.Hot food should be cooled down before placing into the
appliance. Otherwise, interior temperature and electronic
consumption will increase.
4.Reduce the frequency of door opening, this can affect efficiency
and electricity consumption.
Warning: Do not use any electronic equipment inside the appliance.
2 3

INSTRUCTION FOR USAGE
The temperature of refrigerator can be controlled manually by the
knob. However, the number shown on the knob does not directly
represent the temperature. Instead, the larger the number is, the lower
the interior temperature will be. 0 stands for off. Turn the knob to state
4 when it is normal used, turn it to the state during 4-7 if a lower
interior temperature is required; contrarily, to the state during 4-1, when
a higher one is needed.
PACKING AND MOVING
1. Unpack , repack and carry
Please memorize the position of each accessory of the appliance when
unpack it, repack the product and check it carefully before transportation.
2. Do not lift or pull the door or the door handle during transportation.
3. When moving, the appliance cannot be sloped over 45 degrees (the angle to the
vertical direction). Please avoid strong vibration and impact.
MAINTENANCE
The appliance should be maintained and cleaned frequently. For your safety, please
pull the plug out of the socket before cleaning.
1. Interior maintenance
Clean the interior of the appliance with clean water or neutral soapy solution then
wipe with a piece of dry cloth.
2. Maintenance of door gasket
Clean the seals with clean water or neutral soapy solution
3. Outer maintenance
Wipe away dust with a piece of dry cloth, and then clean with a neutral soapy
solution if necessary.
4. The displacement of interior light Uninstall the cover and replace the light with a
screwing light (E14 , 220V/10W)，Consult the following pictures：
1) Move the lampshade 3~5mm according 2) Take out the lamp
shade. to arrow point direction.
3) Rotate and take out the bulb in counter
clockwise direction.
DEFROST
A heavy frost will influence the refrigerating of the appliance and increase the energy
consumption. Thus, defrosting is needed is the frost is 5mm or more in thickness.
Processes of manual defrost is as follows: take all the food out of the compartment;
uninstall the drawers and shelves; unplug the electronic power cord; open the doors and
wait for the unit to thaw; wipe up the water with dry cloth.
Do not use any other equipment or method to push the
defrost process. It may destroy the cooling system.
DISCONNECTING THE APPLIANCE
After power failure, even in summer, the refrigerator can store food normally for several
hours.
1. Power failure
After power failure, do not put additional food in the appliance and reduce the
frequency of door opening.
2. Vacation
Please take out the perishable food out of the fridge before a short vacation. For a
long vacation, please take out all food and turn off the power. After defrosting, clean
up the liner of the appliance and wipe it dry, and leave the door open.
3. Stop using
If the refrigerator is to be unused for a long period of time, please unplug from the outlet
and clean the appliance. The door should be kept open in order to prevent unpleasant
smell caused by food leavings.
In a general condition, do not stop the appliance in case of affecting
Attention its life. After unplugging the power, please leave at least 5 minutes before
resumption.

USER NOTIFICATIONS
1. Do not splash water on the refrigerator, as it will cause oxidation and malfunction.
Electronic component such as on/off button should be wiped dryly.
2. Cleaners such as soap powder, abrasive cleaning powder, alkali cleansers, chemical
cloth, thinner, alcohol, acid petroleum product and hot water should not be used to
clean the refrigerator as they may damage the painted cover and plastics.
3. Smears can damage the interior plastic component, so wipe it as soon as possible.
4. Please check the points below after maintenance:
(1) Is there any damage or loss of the power cable?
(2) Can the plug be put in the socket reliably and smoothly?
(3) Is the plug heating unusually?
Please get rid of the gasket of the door before the disposal.
Warning The disposed apparatus should be handled by professional
staff, as it may be harmful to the environment.
TROUBLESHOOTING TIPS
1. The refrigerator does not work
It may not be connected to the power supply (plug, power cut or fuse); Voltage is too
low.
2. The refrigerator does not work efficiently as expected
It may be caused by heavy frost, warm temperature setting, or by frequent door
opening.
3. It makes unusual noise
It may be caused by the unit being un-balance or unstable, or by resonation between
the appliance and other objects.
4. The compressor keeps working for a long period
The environment temperature may be too high. The doors may be opened frequently
or left open. The temperature control knob setting in (4-7) state may increase the
working time of compressor.
5. Unpleasant odours
Food with strong odour should be packed tightly before being put inside the
appliance. Please check whether there is any deteriorated item or whether the liners
are left dirty for a long time.
6. Water leaks from the bottom of the refrigerator. The drain tube is jammed, please
use a proper tool to solve it.
7. Heavy frost occurs on the rear of the appliance
Placing hot food into the appliance may cause this problem. Or it may be caused by
a humid environment.
The follow cases are not malfunctions
1. Moisture may form dew on the outside of the product during the humid season.
2. The flow of refrigerant through the pipeline coil can cause unusual noises.
3. It is normal that the sides of product get warm as a result of the cooling pipeline
working.
6
4. The frame of the appliance will be warm during working by the defrost pipeline inside
it.
Please check the points above first.
If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
SPECIFICATIONS AND PARAMETERS
Model
BC88RBFB/BC88RBFR
Climate class
SN/N/ST/T
Electric shock protection type
I
Capacity (L)
Freezer
26
Refrigerator
60
Voltage (V)
220-240
Frequency (Hz)
50
45

Current (A)
0.57
Voice [dB(A)]
< 42
Energy consumption (kW.h/24h)
0.72
Refrigerant
R600a/30g
Weight (Kg)
28.5
Interior
temperature ( C)o
Freezer
\
Refrigerator
0~8
Dimension (mm)
Width
486
Depth
536
Height
839
7
PACKING LIST
Note: Products are subject to improve from time to time, any
Vegetable crisper
BCD-88V53H
1
pcs
1
pcs
Steel shelf
Owner's manual
1
copy
Model
Number
Parts
Crisper glass cover
1
pcs

changes in parts without further notice.
8
