Bellini BOT608BK User manual

USER MANUAL
60cm Built In Electric Oven
Model No. B
OT608BK
BOT608BK-F
GSM Retail Australia Pty Ltd ABN: 53 007 682 475
For Warranty and technical queries: Australia 1300 373 199
For Warranty and technical queries: New Zealand0800 764 912
www.belliniappliances.com.au
V2 May 2023

Thank you.
Thank you for choosing Bellini Appliances.
This Bellini appliance carries a 3 year in home warranty, be
sure to retain your user manual and receipt.
For all warranty and technical queries please phone:
Australia 1300 373 199
New Zealand 0800 764 912
GSM Retail Australia Pty Ltd ABN: 53 007 682 475
For Warranty and technical queries: Australia 1300 373 199
For Warranty and technical queries: New Zealand 0800 764 912
www.belliniappliances.com.au
GSM Retail Australia Pty Ltd ABN: 53 007 582 475

Contents
Safety Instructions-----------------------------
Product Description----------------------------
Installation----------------------------------------
Oven Setting--------------------------------------
Maintenance and Cleaning -------------------
Warranty------------------------------------------
4
1
6
8
10
14

1
This manual explains the proper installation and use of your oven, please read it carefully before
using, even if you are familiar with the product. The manual should be kept in a safe place for
future reference. In case of failure, only the Authorised Technical Service Agent may repair this
oven.
Otherwise the guarantee will be null and void. All Bellini Appliances are for domestic use only.
Important Safety Instruction
s

General Warning
◆If the supply cord is damaged, the cord must be
replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a
hazard.
◆This product has not been designed for any uses
other than those specified in this booklet
◆This appliance must not be used as a space heater.
◆In order to avoid fire, the appliance must be kept
clean and vents kept unobstructed.
◆Do not spray aerosols within the vicinity of the
appliance during operation.
◆Do not store flammable materials in or under the
appliance, e.g. aerosols.
◆Do not line the bottom of the oven with
foil/cookware.
◆Always use gloves when handling hot items inside
the oven.
◆Always turn the grill off immediately after use as fat
left behind may catch fire.
◆Do not leave the appliance unattended when
cooking. Oils and fats may catch fire due to
overheating or boiling over.
◆Do not put pans weighing over 15Kgs on the
opened door of the oven.
◆Do not use the appliance in the event of a technical
fault. Any faults must be fixed by an appropriately
qualified and authorised person.
◆In the event of any incident caused by a technical
fault, disconnect the power and report the fault to
the service centre to be repaired.
◆The rules and provisions contained in the
instruction manual should be strictly observed.
◆Do not allow anybody who is not familiar with the
contents of this instruction manual to operate the
appliance.
Child Safety
◆This appliance is not intended for use by persons
sensory or mental capabilities, or lack of experience,
unless they've been give supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
◆Children should be supervised to ensure that they do not
play with the appliance.
◆During use this appliance becomes hot. Care should be
taken to avoid touching hot surfaces, e.g. oven door,
heating elements.
◆Accessible parts will also become hot when in use. To
avoid burns and scalds children should be kept away.
Installation, Cleaning & Servicing
◆The appliance must be installed only by an authorised
person in compliance with the instructions provided.
Incorrect installation may cause harm to persons,
animals or may damage property,
◆Before using the appliance, ensure that all packaging
materials are removed from the appliance.
◆In order to avoid any potential hazards, the enclosed
installation instructions must be followed,
◆Ensure that all specified vent's openings and air spaces
are not blocked.
◆The panels adjacent to the oven must be made of heat
resistant material.
◆Cabinets with a vaneer exterior must be assembled with
glues which can withstand temperature of up to 120°C.
◆To reduce the risk of fire, do not place or install this unit
in areas where the ventilation or circulation ducts may
become blocked. Make sure there are at least 70mm of
space between the back of your oven and the wall. Keep
some distance on each side of your oven that you can
use that distance flowing installation instructions.
◆The units power cord must be connected to a properly
grounded and protected, 220-240V electrical outlet.
Always use ground fault protection where required by the
electrical code.
2

◆When transporting or storing the unit, keep it in a
dry location, free from dust, excessive vibration or
other factors, which may damage the unit.
◆Do not operate oven with a damaged cord, plug or
if the oven has malfunctioned or has been
dropped or damaged in any manner. Return oven
to authorised service facility for repair.
◆Only authorised personnel should carry out
servicing. (Certificate of Compliance to be
retained)
◆Always ensure the appliance is switched off
before cleaning or replacing parts.
◆Do not use steam cleaners, as this may cause
moisture build-up.
◆Always clean the appliance immediately after any
food spills.
◆THIS APPLIANCE MUST BE EARTHED.
◆To maintain safe operation, it is recommended
that the product be inspected every five years by
an authorised service person.
Oven
◆During use the appliance becomes hot. Care
should be taken to avoid touching the hot surfaces
inside the oven.
◆Switch the appliance off before removing the oven
light glass for globe replacement.
◆To avoid an accident, ensure that oven shelves
and fittings are always inserted into the appliance
in accordance with the instructions.
◆Do not use the door as a shelf.
◆Do not push down when the oven door is open.
Grill
◆Do not cover the grill insert with foil, as fat built up
may catch on fire.
◆Always keep the grill dish clean as any build up may
catch on fire.
◆Do not leave the grill on unattended.
◆To avoid fire, ensure that grill trays and fittings are
always inserted into the appliance in accordance
with the instructions.
◆Do not place thick portions of food under the grill. Foods
may curl, catch and ignite.
◆Accessible parts may become hot when grill is in use.
Children should be kept away.
Environmental Hints
◆Use the oven efficiently, by cooking many trays of food at
the same time.
◆Cook 2 trays of scones, small cakes or sausage rolls at the
same time.
◆Select the correct shelf location for food being cooked.
◆Do not open the oven door more than necessary.
◆After the oven is turned off it retains heat for some time.
This product must not be disposed together
with domestic waste. This product has to
be disposed at an authorised place for
recycling of electrical and electronic
appliances.
By collecting and recycling waste, you help save
natural resources, and make sure the product is
disposed in an environmental
friendly and healthy way.
3

Accessory Name
Quantity
Mounting Screws(ST4x20)
2 pcs
Baking Pan & Rack
1 Pair
Rack
2 pcs
Product Description
A
D
E
F
B
C
A. Minute Timer Knob
B. Function Select Knob
C. Temperature Select Knob
D. Heating Indicator Light
E. Handle
F. 3 Layer Glass Door
Accessories
4

Tray handle
1 pc
Technical data
model
product dimensions
(L x W x D) mm
electrical
connection
min. fuse
rating
max. power
rating
max. current
rating
All 2 models
595x596x575
220-240V/50Hz
15A
2.7 –3.22Kw
13.4A
Heating elements
Motor
Oven lower heating el.: 1200Watt
Oven inside heating el. 1900 Watt
Oven upper heating el.: 1000Watt
Total grill heating el. 1000+1900 Watt
Shaded motor (back) 33 Watt
Oven light: 25 Watt
Circle heating el. 2100Watt
Shaded motor (top) 25 Watt
5

WARNING!
Please follow the points below when installing the
appliance
Use an Authorised Person
◆Installation should be carried out according to the
instructions by a professionally qualified person.
The manufactcrer declines all responsibility for any
damage to persons, animals or things due to a
wrong installation.
◆Wiring connections must be in accordance with
AS/NZS 3000 Wiring Rules and any particular
conditions of the local authority.
◆Refer to data plate or rating information. The date
plate is positioned behind the bottom of the oven
door. The circuit diagram is positioned on the top
panel of the appliance.
◆A functions switch should be provided near the
appliance in an accessible position. Refer to
AS/NZS
3000 clause 4.7.1
◆Wiring should be protected against mechanical
failure. Refer to AS/NZS 3000 clause 1.5
◆A means of disconnection with a contract
separation of at least 3mm must be supplied in the
fixed wiring. Always turn the grill off immediately
after use as fat left behind may catch fire.
◆Unplug the power plug appliance from socket
before installation or any adjustment or
maintenance
This Appliance Must Be Properly Earthed
◆Do not lift the appliance by the door handles.
◆Prepare the cupboard opening to match your
appliance measurements (See Diagrams)
◆Slide appliance into the cupboard, ensuring the
supply cable (where fitted) does not king.
◆To prevent tipping, secure your oven into the
cupboard by fastening with 2 screws supplied.
◆Where the appliance is built into a cabinet, the cabinet
must be capable of withstanding 120°C. Installation
into low temperature tolerant cabinetry
(eg Vinyl Coated) may result in deterioration of the low
temperature coating by discoloring or bubbling.
◆The unit panels next to the appliance must be heat
resistant. In the case of veneered wood units, glue
must be resistant to a temperature of 120°C.
◆If the appliance is to be installed adjacent to vinyl
wrapped surfaces, use an installation kit available
from the vinyl-wrap supplier.
◆GSM cannot accept responsibility for damage caused
by installation into low temperature tolerant cabinets.
◆After installation, test and ensure that the appliance
operates correctly before handing it over to the
customer.
◆Once the appliance is installed, there must be no
possible contact with electrical parts. Any protective
parts must can only be removed with the use of tools
◆If a power point is fitted, it must be accessible with the
appliance installed, as the plug must be accessible
after installation
◆Always slide shelves into the layer with stopper
◆Be cautious when using the oven, gloves may need to
be used
To avoid any potential hazard, you must follow our
instructions when you install your appliance. Failure
to install the appliance correctly could invalidate any
warranty or liability claims and lead to prosecution.
Install the Shelf
Installation
6

The unit panels next to the appliance must be heat resistant.
In the case of veneered wood units, glues must be resistant
to a temperature of 120°C.
Fitting Your Appliance
Fit the appliance into its surround (beneath a work-top or
above another appliance) by inserting screws into the 2
holes that can be seen in the frame of the oven when the
door is open.
Mounting Screws
Note:
Your appliance must be mounted on a flat surface for the full
width and depth of the product
Connect Power Supply Cord
◆Pull open terminal board cover at rear panel of appliance.
◆Fit wires through on terminal board and make connections
to terminals.
◆Engage wires into plastic clip. Secure plastic clip with
supplied screws.
◆Close the terminal board cover.
Hard Wired
Appliances :
When making the mains supply conductor connections to the terminal
block within the terminal box , please ensure that minimum clearances
are being maintained between individual conductors and conductors/
connectors to the adjacent metal surfaces of the terminal box itself ,
where possible add heat shrink sleeves to any bare conductor end/
connectors prior to securing.
Cabinet Construction For Your Appliance
The sizes of the unit for installing the ap
pliance under
a worktop or i
n a column unit are shown in figure.
To provide adequate ventilation, there must be
appropriate ventilation opening, the panel to which
the oven is fitted should have a gap of at least 70 mm
at the rear.
Plastic clip
Plastic clip
Securing
7

Preparing Your Oven
1. Please remove all stickers, leaflets and boxes from the door and from the floor of the oven before operation.
2. Please wipe out the oven interior prior to operation with warm soapy water and polish dry with a soft cleancloth.
Do not close the oven door until the oven is completely dry.
Select the Functions
Turn the function selector in any direction to the desired function. The oven cavity light will turn on.
Function Selector
function
description
Oven Light
When the selector knob is in any position other than the “0”position, the oven light
comes on.
Defrost
Select this function, the air at ambient temperature is distributed inside the oven for
defrosting food more quickly and without proteins adulteration.
Conventional Mode
Both the lower and upper heating elements operate together.
This is for traditional cooking. Very good for roasting joints, ideal for biscuits, baked
apples and crisping food. You obtain very good results when cooking on a shelf
adjusting the temperature between 50°C and MAX°C.
8
Oven Settings

Fan Forced
Boththe fan and the circular heating element operate together. The hot air adjustable
between 50°C and MAX°C is evenly distributed inside the oven. This is ideal for
cooking several types of food (meat, fish) at the same time without affecting taste
and smell. It is ideal for delicate pastries.
Half Grill
It is indicated for grilling small quantities of food.
Full Grill
This feature activated all upper heating elements and give rapid cooking to food.
Full Grill + Fan Force
The air which is heated by the grill heating element is circulated by the fan and so
helps to distribute the heat between 50°C and 200°C. This function can be used for
sterilizing glass jars.
Bottom Element with
Fan Force
The air which is heated by the lower heating element is circulated by the fan and so
helps to distribute the heat between 50°C and 200°C. This function can be used for
sterilizing glass jars.
Select the Temperature
◆Toset the temperature, turnthetemperature selector in aclockwise direction to the desiredsetting. Anindicator
light above the temperature selector will come on.
◆A thermostat controls the temperature in your appliance. When the temperature is reached, the heating source
switches itself off and the indicator light goes out. When the oven temperature falls below the desired setting,
the heating source switches on and the indicator light comes on again.
◆Once the food is cooked, turn the temperature selector back in an anti-clockwise direction. Do not force it right
round in a clockwise direction as this will result in damage to the thermostat.
9

Important
The desired cooking function must be selected before the oven will operate.
Minute Timer
Turn the knob clockwise to set the desired duration. The minute minder can be adjusted from 1 to 120 minutes.
An audible signal will sound at the expiry of the set time ,this will NOT switch the oven OFF. Switching the oven OFF has to
be manually conducted by turning Function Selection Knob to O
WARNING!
◆Before cleaning your oven, or performing maintenance, disconnect it from the power supply.
◆Do not use steam cleaners.
◆Do not line the oven bottom with aluminium foil, as the consequent accumulation of heat could compromise the cooking
and damage the enamel.
◆To protect against the risk of electrical shock, do not immerse the unit, cord or plug in water or other liquid or sprinkle
water to clean the appliance!
◆Do not clean the appliance when it is still hot! The inside and external surface of the oven should preferably be cleaned
by damp cloth when it is cooled down.
◆Wash all accessories in hot soapy water or in a dishwasher and wipe dry with a paper or cloth towel.
◆If you use your oven for an extended period of time, condensation may form. Dry it using a soft cloth.
Stainless Steel
◆All grades of stainless steel can stain, discolour or become greasy. You must clean these areas regularly by following
the procedures below, if you want your appliance to look its best, perform well and have a long life.
◆Care must be taken when wiping exposed stainless steel edges, they can be sharp!
◆The front frame around the oven can be cleaned with stainless steel cleaners if it becomes soiled or discoloured.
◆The stainless steel should only be cleaned with warm water and a mild detergent.
◆Do not use stainless steel cleaners, abrasive cleaners or harsh solvents.
◆Make sure you follow the polish or brushing lines in the steel.
Maintenance & Cleaning
10

Glass
◆Glass surfaces on doors and control panels are best cleaned immediately after soiling.
◆A damp cloth may help remove baked on food deposits.
◆Oven cleaners can be used to remove stubborn marks and stains.
◆Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door since they can scratch the surface,
which may result in shattering of the glass ◆ Treat glass door gently.
Oven
◆Always keep your appliance clean. Ensure fats and oils do not accumulate around elements, burners or fans.
◆Always keep the oven dish, baking trays and grill dish inserts clean, as any fat deposits may catch fire.
◆Always wrap your meats in foil or an oven roasting bag to minimise cleaning. Any polyunsaturated fats can leave a
varnish-like residue which is very difficult to remove.
◆Always keep the grill dish and grill insert clean, as any fat deposits may catch fire.
Replacement of the Oven Light Bulb
WARNING!
Ensure that the appliance is switched off before replacing the lamp to avoid the possibility
of electric shock.
◆Cut off the supply of power to the oven by turning off the omni-polar switch connecting it to the mains, or by
removing the plug if it is accessible; Avoids appearing the
electric shock;
◆Unscrew the glass cover attached to the lamp holder;
◆Pull out the lamp and replace it with another
hightemperature lamp (300℃) with the following
characteristics:
- Voltage: AC230V
- Wattage: 25W
- Socket: G9
◆Remount the glass cover and reconnect the appliance to the power supply.
11

The oven door is made up of 3 panes of glass and has vents at the top and bottom. When the oven is operating, air
is circulated through the door to keep the outer pane cool. If condensation has worked its way in between the glass
panes, the door can be dismantled in order to clean in between the panes.
Remove the door as per above instruction and place it on a protective surface (e.g. on a table cloth) to prevent it
getting scratched. The door handle should line up with the edge of the table. Make sure the glass lies flat to avoid
breakage of glass during cleaning.
1. Undo the 2 screws on upper bracket.
2. Take out upper bracket and first pane of glass.
3. Loosen the 4 clips.
4. Slide out middle pane of glass carefully. Clean the glass panes and other parts with a damp microfiber cloth or a clean
sponge and a solution of hot water with a little washing-up liquid. Wipe dry using a soft cloth.
Door Removal
In order to obtain easier access to the oven chamber for
cleaning, it is possible to remove the door.
To do this, tilt
the safety catch part of the hinge upwards. Close the
door lightly, lift and pull it out towards you. In order to fit
the door back on to the a, do the reverse. When fitting,
ensure that the notch of the hinge is correctly placed on
the protrusion of the hinge holder. After the door is fitted
to the oven, the safety catch should be carefully lowered
down again.
If the safety catch is not set it may cause
damage to the hinge when closing the door.
Middle Layer Glass Removal
12

Troubleshooting
Faults Causes Remedies
The upper crust is dark and
the lower part too pale Not enough heat from the bottom -Use the natural convection position.
-Use deeper cake tins.
-Lower the temperature.
-Put the cake on a lower shelf.
The lower part is dark and the
upper crust too pale Excessive heat from the bottom -Use the natural convection position.
-Use lower side tins.
-Lower the temperature.
-Put the cake on a higher shelf.
The outside is too cooked
and the inside not cooked
enough
Too high temperature -Lower the temperature and increase the cooking
time.
The outside is too dry even
though of the right color Too low temperature -Increase the temperature and reduce the cooking time.
The appliance does not work Break in power supply -Check the household fuse box, if there is a
blown fuse replace it with a new one.
The oven lighting does not
work Bulb is loose or damaged -Tighten up or replace the blown bulb. (See chapter Cleaning & Maintenance).
Step 1
Step 2
Step 3
Step 4
* New Appliances could have a smell during first use. It is recommended to 'run in' the oven before you cook for the
first time. Operate the oven empty, at temperature of 180°C for approximately 2 - 4 hours. Please ensure the room
is well ventilated during this process.
13

WARRANTY
1.1 In this warranty:
1.1.1 Australian Consumer Law means the law as set out in Schedule 2 of the Competition and
Consumer Act 2010;
1.1.2 Company means GSM Retail Australia Pty Ltd ABN 53 007 682 475 of 142-144 Fullarton Road, Rose
Park SA 5067. Telephone [phone]. Email [e-mail]
1.1.3 Consumer means a “consumer” as that term is defined in Section 3 of the Australian Consumer
Law as the original purchaser of a Bellini product;
1.1.4 Consumer Guarantees means the guarantees under the Australian Consumer Law;
1.1.5 You means the Consumer.
1.2 Nothing in this warranty affects any person’s rights under the Australian Consumer Law. The benefits to
any Consumer under this warranty are in addition to the rights and remedies available under any
Consumer Guarantees.
1.3 Subject to the other clauses of this warranty, the Company warrants to the Consumer that the Bellini
product will be free of manufacturing defects and will perform to the Company’s specifications.
1.4 The benefit of this warranty extends only to the Consumer as original purchaser of a Bellini product which
is installed in a domestic household area.
*The in Home warranty does not apply to Commercial and or industrial usage. *Please See 1.7.7 for additional
information
1.5 This warranty commences on the date of purchase of the Bellini product by the Consumer and
continues for the benefit only of the Consumer until the expiry of three (3) year (Warranty Period).
1.6 If within the Warranty Period a manufacturing defect is discovered in the Bellini product or it fails to perform
to the Company’s specifications as a result of some defect in materials, components or workmanship
(Defect) then the Company will, at its option, repair the Bellini product or supply a replacement Bellini
product free of charge. A replacement Bellini product may differ from the original product purchased by the
Consumer.
1.7 This warranty will not apply to any Bellini product:
1.7.1 Installed by any person other than a qualified tradesperson; or
1.7.2 Subjected to misuse, neglect, negligence or accidental damage; or
1.7.3 Operated in any way contrary to any operating or maintenance instructions; or
1.7.4 Improperly handled, installed or maintained; or
1.7.5 Altered or modified prior to or after installation; or
1.7.6 Damaged directly or indirectly by power surges, electrical storm damage or connection to incorrect
power supply
1.7.7 Industrial and or Commercial usage is inclusive of staff areas in office/ shop environments, hotel/
motel or other similar accommodation or rental type properties including Bed and Breakfast
establishments.
The Australian Consumer Law requires the inclusion of the following
statement with this warranty:
Our goods come with guaranteed that cannot be excluded under the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage.
You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure.

1.8 You must provide proof of your purchase of the Bellini product and the date of purchase in order to obtain
the benefit of this warranty.
1.9 If you live outside the service area of the Company or one of its service agents, this warranty does not
cover the cost of transport of the Bellini product for service nor the service agent’s traveling costs to and
from your home.
1.10 If you are required to transport the Bellini product to the Company or its service agent, you must ensure it is
safely disconnected by a qualified tradesman and securely packed and insured. The Company does not
accept any responsibility for loss or damage of the Bellini product prior to it being received by the Company or
its service agent.
1.11 You will be responsible for all costs of returning a Bellini product to the Company and for redelivery of the
Bellini product by the Company (whether it is the original or a repaired and/or a replacement Bellini product)
and for any other expenses you incur in claiming under this warranty.
1.12 The Company or its service agent will examine any Bellini product and if the Company determines that it is
defective through no fault of the Owner and is otherwise undamaged, the Company will repair or replace the
Bellini product in accordance with this warranty.
DO NOTSEND IN THIS WARRANTY
Fill out the following details and file with your purchase invoice for safe keeping.
RETAIN & FILE WITH YOUR RECEIPT
Your Purchase Receipt/Invoice is proof of date of purchase. If you are unable to establish the date of purchase, or if
the fault is not covered by this warranty, or if the product is found to be in working order, you will be required to bear
all service call charges.
GSM Retail Australia Pty Ltd reserves the right to discontinue items, modify designs and change specifications
without incurring obligation.
Whilst every effort is made to ensure that descriptions, specifications and other information in this publication is
correct, no warranty is given in respect thereof and the company shall not be liable for any errors therein.
Purchased from:
Co. Name:
Address:
Date of Purchase:
Serial number:
NOTE: Consistent with our continuing product development policy, improvements may have been made which
render the contents of this packaging slightly different to that shown.
For Warranty and technical queries: Australia 1300 373 199
: New Zealand 0800 764 912
