Miele H 6460 BP User manual

Operating and installation instructions
Oven
To avoid the risk of accidents or damage to the appliance it is essential
to read these instructions before it is installed and used for the first time.
M.-Nr. 09 610 230en-GB

Warning and Safety instructions .....................................6
Caring for the environment.........................................18
Oven overview ...................................................19
Oven controls....................................................20
On/Off sensor K..................................................21
Function selector ..................................................21
Rotary selector....................................................21
Sensor controls ...................................................21
Display ..........................................................24
Features ........................................................26
Model numbers ...................................................26
Data plate .......................................................26
Items supplied ....................................................26
Accessories supplied and available to order ............................26
Side runners ...................................................27
Baking tray, universal tray and rack with non-tip notches ................27
FlexiClip telescopic runners HFC72 .................................28
Fitting and removing FlexiClip telescopic runners .....................28
Oven controls.....................................................32
Safety features ....................................................32
System lock 0for the oven........................................32
Safety switch-off ................................................32
Cooling fan ....................................................32
Vented oven door ...............................................32
Door lock - Pyrolytic cleaning ......................................32
PerfectClean treated surfaces ........................................33
Pyrolytic accessories ...............................................33
Using for the first time.............................................34
Basic settings ....................................................34
Heating up the oven for the first time and rinsing the steam injection system ...36
Settings.........................................................38
Settings overview..................................................38
Calling up the Settings menu.........................................40
To change and save settings ......................................40
Language J......................................................40
Time of day ......................................................41
Display .......................................................41
Clock format ...................................................41
Contents
2

Set...........................................................41
Date ............................................................41
Lighting .........................................................42
Display brightness .................................................42
Volume ..........................................................42
Buzzer tones ...................................................42
Keypad tone ...................................................42
Units............................................................43
Weight........................................................43
Temperature ...................................................43
Cooling fan run-on .................................................43
Pyrolytic cleaning..................................................44
Recommended temperatures ........................................44
System lock 0....................................................44
Showroom programme .............................................45
Demo mode ...................................................45
Factory default ....................................................45
Minute minder N.................................................46
Using the minute minder N..........................................46
To set the minute minder .........................................46
To change the time set for the minute minder .........................47
To cancel the time set for the minute minder ..........................47
Overview of functions .............................................48
Using the oven - Getting started ....................................50
Tips on saving energy ..............................................50
Using residual heat .............................................50
Simple operation ..................................................51
Cooling fan.......................................................51
Using the oven - further functions ...................................52
Changing the function ..............................................52
Changing the temperature...........................................53
Rapid heat-up ....................................................54
Pre-heating the oven.............................................54
Setting the duration ................................................55
Switching off automatically ........................................55
Switching on and off automatically ..................................56
Sequence of a programme that switches on and off automatically .........56
Changing an entered cooking time .................................57
Contents
3

Cancelling cooking ..............................................57
Moisture plus d.................................................58
Moisture plus function d...........................................60
Setting the temperature ..........................................60
Setting the number of bursts of steam ...............................60
When to add the steam...........................................61
Preparing and starting the water intake process .......................61
Changing the type of heating ......................................62
Automatic steam ................................................63
1, 2 or 3 bursts of steam ..........................................63
Residual water evaporation ..........................................64
To start residual water evaporation immediately .......................64
To skip residual moisture evaporation ...............................65
Automatic programmes............................................66
Overview ........................................................66
To use an Automatic programme .....................................66
Notes on using these programmes .................................67
User programmes ................................................68
To create a User programme ........................................68
To start a User programme ..........................................70
To change User programmes ........................................71
Change cooking stages ..........................................71
Change name ..................................................72
To delete User programmes .........................................73
Baking ..........................................................74
Notes on the baking chart ...........................................75
Baking chart......................................................76
Roasting ........................................................80
Notes on the roasting chart ..........................................80
Roasting chart ....................................................82
Low temperature cooking ..........................................84
Grilling .........................................................86
Notes on the grilling chart ...........................................87
Grilling chart .....................................................89
Further applications ..............................................90
Further programmes ............................................90
Gentle bake ...................................................90
Contents
4

Defrosting .....................................................91
Drying food ....................................................92
Reheat........................................................93
Proving dough .................................................93
Pizza .........................................................94
Heat crockery ..................................................94
Frozen food / Ready meals ..........................................95
Note for test institutes.............................................96
Test food acc. to EN 60350 .......................................96
Energy efficiency class...........................................96
Cleaning and care ................................................97
Useful tips .......................................................98
Normal soiling ....................................................98
Stubborn soiling (does not apply to the FlexiClip runners) ..................99
Pyrolytic cleaning ^of the oven interior ..............................100
Preparation for using the Pyrolytic cleaning programme ................100
Starting the Pyrolytic cleaning programme ..........................101
At the end of the Pyrolytic cleaning programme ......................102
If the Pyrolytic cleaning programme is cancelled .....................103
Removing the door ...............................................104
Dismantling the door............................................105
Refitting the door .................................................109
Removing the side runners .........................................110
Lowering the top heat/grill element ...................................111
Cleaning and care ...............................................112
Descaling the steam injection system F...............................112
Sequence of a descaling cycle ...................................112
Preparation ...................................................113
Starting the descaling process....................................113
Problem solving guide ...........................................117
After Sales / Guarantee ...........................................122
Electrical connection.............................................123
Building-in diagrams .............................................125
Appliance and niche dimensions ....................................125
Front dimensions .................................................127
Installing the oven ...............................................128
Addresses......................................................131
Contents
5

This appliance complies with statutory safety requirements.
Inappropriate use can, however, lead to personal injury and
damage to property.
To avoid the risk of accidents and damage to the appliance,
please read these instructions carefully before using it for the first
time. They contain important notes on installation, safety, use and
maintenance.
Miele cannot be held liable for non-compliance with these
instructions.
Keep these instructions in a safe place and ensure that new users
are familiar with the contents. Pass them on to any future owner.
Warning and Safety instructions
6

Correct application
~This oven is intended for use in domestic households and similar
working and residential environments.
~The oven is not intended for outdoor use.
~It is intended for domestic use only to cook food, and in particular
to bake, roast, grill, cook, defrost and dry food. Any other use is not
supported by the manufacturer and could be dangerous.
~People with reduced physical, sensory or mental capabilities, or
lack of experience or knowledge who are not able to use the
appliance safely on their own must be supervised whilst using it.
They may only use it unsupervised if they have been shown how to
use it safely and recognise and understand the consequences of
incorrect operation.
Warning and Safety instructions
7

Safety with children
~Children under 8 years of age must be kept away from the
appliance unless they are constantly supervised.
~Children 8 years and older may only use the oven unsupervised if
they have been shown how to use it safely and recognise and
understand the consequences of incorrect operation.
~Children must not be allowed to clean or maintain the appliance
unsupervised.
~Please supervise children in the vicinity of the oven and do not let
them play with it.
~Danger of suffocation. Packaging, e.g. plastic wrappings, must
be kept out of the reach of babies and children. Whilst playing,
children could become entangled in packaging or pull it over their
head and suffocate.
Warning and Safety instructions
8

~Danger of burning.
Children's skin is far more sensitive to high temperatures than that of
adults. External parts of the oven such as the door glass, control
panel and the vents become quite hot during use. Do not let
children touch the oven whilst it is in use.
~Danger of injury.
The oven door can support a maximum weight of 15 kg. Do not let
children sit on the door, lean against it or swing on it.
~Danger of burning.
Children's skin is far more sensitive to high temperatures than that of
adults. The oven gets hotter during pyrolytic cleaning than it does in
normal use. Do not let children touch the oven whilst the pyrolytic
cleaning programme is running.
Warning and Safety instructions
9

Technical safety
~Unauthorised installation, maintenance and repairs can cause
considerable danger for the user. Installation, maintenance and
repairs must only be carried out by a Miele authorised technician.
~Never use a damaged oven. It could be dangerous. Check it for
visible signs of damage before using it.
~The electrical safety of this appliance can only be guaranteed
when correctly earthed. It is essential that this standard safety
requirement is met. If in any doubt please have the electrical
installation tested by a qualified electrician.
~To avoid the risk of damage to the oven, make sure that the
connection data on the data plate (voltage and frequency) match
the mains electricity supply before connecting the oven to the
mains. Consult a qualified electrician if in doubt.
~Do not connect the appliance to the mains electricity supply by a
multi-socket unit or an extension lead. These do not guarantee the
required safety of the appliance (fire hazard).
~For safety reasons, this appliance may only be used after it has
been built in.
~The oven must not be used in a non-stationary location (e.g. on a
ship).
Warning and Safety instructions
10

~Tampering with electrical connections or components and
mechanical parts is highly dangerous to the user and can cause
operational faults.
Never open the casing of the appliance.
~While the appliance is under guarantee, repairs should only be
undertaken by a Miele authorised service technician. Otherwise the
guarantee is invalidated.
~Miele can only guarantee the safety of the appliance when
genuine original Miele replacement parts are used. Faulty
components must only be replaced by Miele spare parts.
~If the connection cable is damaged or if the oven is supplied
without a cable, it must be replaced or fitted with a suitable
connection cable by a Miele authorised technician (see "Electrical
connection").
~During installation, maintenance and repair work, the appliance
must be disconnected from the mains electricity supply, e.g. if the
oven lighting is faulty (see "Problem solving guide" and "Electrical
connection").
Warning and Safety instructions
11

~In order to function correctly, the oven requires an adequate
supply of cool air. Ensure that the supply of cool air is not impaired
(e.g. by heat insulation strips in the housing unit). Please also ensure
that the cool air supply is not unduly heated by other heat sources
such as a wood burning stove.
~If the oven is installed behind a furniture panel (e.g. a door),
ensure that the door is never closed whilst the oven is in use. Heat
and moisture can build up behind a closed furniture panel and
cause subsequent damage to the oven, the housing unit and the
floor. Do not close the door until the oven has cooled down
completely.
Warning and Safety instructions
12

Correct use
,Danger of burning.
The oven becomes hot when in use.
You could burn yourself on the heating elements, oven interior,
cooked food or oven accessories.
Wear oven gloves when placing food in the oven, turning or
removing it and when adjusting oven shelves etc. in a hot oven.
~Due to the high temperatures radiated, objects left near the oven
when it is in use could catch fire.
Do not use the oven to heat up the room.
~Oil and fat can ignite if overheated. Never leave the oven
unattended when cooking with oil and fat.
If it does ignite do not put the flames out with water. Switch the oven
off immediately and then suffocate the flames by keeping the oven
door closed.
~Grilling food for an excessively long time can cause it to dry out
with the risk of it catching fire.
Do not exceed recommended grilling times.
Warning and Safety instructions
13

~Some types of food dry out quickly and can self-ignite if high grill
temperatures are used. Never use the grill to finish baking
part-cooked rolls or bread or to dry flowers or herbs. Use Fan
plus Uor Conventional heat Vfor this type of procedure.
~If using alcohol in your recipes, please be aware that high
temperatures can cause the alcohol to vaporise. The vapour can
catch fire on hot heating elements.
~When using residual heat to keep food in the oven warm, the high
moisture content and amount of condensation in the oven can cause
corrosion damage. The control panel, the worktop or the housing
unit can also suffer damage.
When using residual heat do not switch the oven off. Instead set the
temperature to the lowest setting and leave the oven on the selected
function. The fan will then remain on automatically and dissipate the
moisture.
~Food which is stored in the oven or left in it to be kept hot can dry
out and the moisture released can lead to corrosion damage in the
oven. Always cover food that is left in the oven to keep warm.
~A build-up of heat can cause the enamel on the floor of the oven
to crack or shatter.
Do not line the floor of the oven with anything, e.g. aluminium foil. Do
not place roasting pans, pots or baking trays directly on the oven
floor.
~The enamelling on the oven floor can become damaged by items
being pushed around on it. If using the oven to store pots and pans,
ensure that you avoid pushing them around on the oven floor.
Warning and Safety instructions
14

~If cold liquid is poured onto a hot surface steam will occur, which
can cause scalding. The sudden change in temperature can also
damage enamel surfaces.
Do not pour cold liquid directly onto hot enamelled surfaces.
~During cooking processes using moisture and during the residual
moisture evaporation process, steam is produced which can cause
serious injury by scalding.
Do not open the door whilst a burst of steam is being released or
during the evaporation process.
~It is important that the temperature in the food being cooked is
evenly distributed and sufficiently high. Stir and / or turn it to ensure
even heat distribution.
~Plastic containers which are not suitable for use in an oven can
melt at high temperatures and can even damage the oven or catch
fire.
Only use plastic containers which are declared by the manufacturer
as being suitable for use in an oven. Follow the manufacturer's
instructions on use.
~Do not heat up food in closed containers e.g. tins or sealed jars in
the oven, as pressure can build up in the container, causing it to
explode.
~You could injure yourself on the open oven door or trip over it.
Avoid leaving the door open unnecessarily.
~The door can support a maximum weight of 15 kg.
Do not sit on or lean against an open door, and do not place heavy
objects on it. Also make sure that nothing can get trapped between
the door and the oven cavity. The oven could get damaged.
Warning and Safety instructions
15

Cleaning and care
~Do not use a steam cleaning appliance to clean this appliance.
The steam could reach electrical components and cause a short
circuit.
~Scratches on the door glass can result in the glass breaking. Do
not use abrasive cleaners, hard sponges, brushes or sharp metal
tools to clean the door glass.
~The side runners can be removed for cleaning purposes (see
"Cleaning and care"). Ensure that they are replaced correctly and do
not use the oven without them fitted.
~Coarse soiling should be removed before running the Pyrolytic
cleaning programme. If not removed, coarse soiling can smoke and
cause the Pyrolytic cleaning programme to switch itself off.
Warning and Safety instructions
16

Accessories
~Only use genuine original Miele accessories. Using accessories
from other manufacturers will invalidate the guarantee, and Miele
cannot accept liability.
~If you have a Miele HUB 5000-M, HUB 5001-M or a HUB 5000-XL
oven dish, do not place it on Shelf level 1.
This would damage the floor of the oven. The very small gap
between the bottom of the dish and the oven floor would cause a
build-up of heat and could cause the enamel to crack or chip.
Never place a Miele oven dish on the top rail of Shelf level 1 as it will
not be held securely in this position by the anti-tip notches on the
runners.
In general it is best to use Shelf level 2.
~The high temperatures used during pyrolytic cleaning will
damage accessories that are not designed for cleaning in the
Pyrolytic programme.
Please remove these accessories from the oven interior before
starting the Pyrolytic cleaning programme.
Warning and Safety instructions
17

Disposal of the packing
material
The packaging is designed to protect
the appliance from damage during
transportation. The packaging materials
used are selected from materials which
are environmentally friendly for disposal
and should be recycled.
Recycling the packaging reduces the
use of raw materials in the
manufacturing process and also
reduces the amount of waste in landfill
sites.
Disposing of your old
appliance
Electrical and electronic appliances
often contain valuable materials. They
also contain materials which, if handled
or disposed of incorrectly, could be
potentially hazardous to human health
and to the environment. They are,
however, essential for the correct
functioning of your appliance. Please
do not therefore dispose of it with your
household waste.
Please dispose of it at your local
community waste collection / recycling
centre.
Ensure that it presents no danger to
children while being stored for
disposal.
Caring for the environment
18

aOven controls
bDoor lock - Pyrolytic cleaning
cTop heat/grill element
dSteam inlet openings
eWater intake pipe for the steam injection system
fAir inlet for the fan with ring heating element behind it
gSide runners with 5 shelf levels
hOven floor with bottom heat element underneath it
iFront frame with data plate
jDoor
Oven overview
19
