BellSouth MH9110 User manual

PAGE
900 MHz CORDLESS CALLER ID
TELEPHONE WITH CALL WAITING
40CHANNELAUTOSCAN
Model MH9110
PLEASE READ THIS
MANUAL CAREFULLY
BEFORE USE.
KEEP FOR YOUR
REFERENCE.
OWNER'S MANUAL
INSTALLATION AND
OPERATING
INSTRUCTIONS
5
© 1995, 2002 BellSouth Corporation
TA LK
DIR
SAVE
R E
D I A L

ongratulations on your selection of a quality BellSouth Product. With proper
care, and by following the setup and user instructions in this manual, this unit
will provide you with years of trouble free service.
BellSouthiscommittedtoprovidingqualityproductsthatfityourneeds.Wewouldliketo
have any comments or suggestions you might have on this product. You may mail your
comments to: U.S. Electronics
105 Madison Avenue
New York, NY 10016
When examining your new BellSouth cordless telephone, you will find an array of
special features including:
Filtered Sound™ System -Receivesconsiderablylessnoise thanconventionalcordless
telephones because of a special circuit which delivers the clearest possible
reception.
40 Channel Autoscan - Press the DEL/CHAN button on theHANDSET tofind and lock
on to the clearest channel for any call.
Desk or Wall Mount - Use this equipment as a desk phone or as a wall phone.
TONE or PULSE Dialing - Use this phone for either TONE (rotary) or PULSE (push-
button) dialing.
Automated Functions - Redial the last number called and automatic STANDBY mode.
Security - Ensures greater privacy because a built-in security code with 65,536
combinations prevents use of your telephone line by another nearby cordless
telephone.
Dependable Battery - Recharge your BATTERY PACK many times with the built-in
charger. The battery low warning tone tells you when the BATTERY PACK needs
recharging (See page 27).
Special Services -Use the EDIT/FLASH button to access special services such as
Call Waiting supplied by your telephone company or company switchboard.
STANDBY Mode -When in STANDBY mode (ON-HOOK), the telephone is capable of
receiving a call. When theHANDSET is on the BASE UNIT, it is automatically in the
STANDBY mode (ON-HOOK). When the HANDSET is taken off the BASE UNIT, it
remains in the STANDBY mode until you activate the button.
Battery Power Saver -Once fully charged, in STANDBY mode, the HANDSET can
receive/send calls for a maximum of five days without the need for recharging.
Length of charge depends on frequency of use.
Luminous LCD Screen - The LCD Screen emits light for 10 seconds every time you
press any of the TELEPHONE KEYPAD buttons.
HANDSET Ringer Level - Select the ringer sound level (HI, LOW, OFF).
HANDSET Volume Control Switch - Select the receiver volume level (HI, MID, LOW).
C
Special Features

HEADSET JACK - Your telephone can utilize a headset for hands-free communication.
BELT CLIP - Use the BELT CLIP to hang your HANDSET on your belt.
CALLER ID SYSTEM
Multi-Function Large LCD Screen - Shows the number you are dialing and, with Caller
ID service (available through subscription from your local telephone company),
displays information about the caller before you answer the call.
NameandNumber Directory-Storesupto40namesandnumbers sothatyoucancall
them with a single key stroke.
Caller List - Available with Caller ID service. Stores up to 80 calls to keep track of
everyone who called. The name, phone number, time and date of the call are
recorded. Allows you to return their calls with a single key stroke.
Preferred Calls - You can mark the name and number of a welcome caller in the
DIRECTORY. When that number calls in, the caller’s name will appear on the
DISPLAY and a special ring sound will be heard.
Blocked Calls - You can mark the name and number of an unwelcome caller in
the DIRECTORY. When that number calls in, the caller’s name will appear on
the DISPLAY and the ringer will be disabled.
Repeat Call Indicator - Shows if a new incoming call has called more than once.
Unavailable Call Indicator -Advises you that the origin of the incoming call does not
support the Caller ID system.
Call Waiting Service -Displays the name and number of the second caller, if you
have subscribed for Call Waiting service from your local telephone company
(see page 13).
Voice Mail -IndicatesmessagewaitingsignalifyousubscribedtoVoiceMailmessage
service and requested Visual Message Indication from your local telephone
company (see page 13). This telephone also detects a Stutter Dial Tone signal
every time there is a Voice Mail message for you from your Voice Mail message
provider if you have subscribed to Voice Mail message service.
Special Features

TALK DIR
SAVE
R
E D I A L
1. LARGE LCD SCREEN
11. DIR (DIRECTORY)
BUTTON
Pg. 14, 15, 16, 18, 19
15. DEL (DELETE)/CHAN
(CHANNEL) BUTTON
Pg. 9, 15, 16, 18, 19,
12. REDIAL/SAVE
BUTTON Pg. 10, 15,
16, 18, 20~25
9. MESSAGE
WAITING LED
INDICATOR Pg. 13
NEW CALL/
13. VOLUME CONTROL
(HI, MID, LOW)
SWITCH
10. BATT LOW
INDICATOR Pg. 27
5. HEADSET JACK
Pg. 11
4. MENU/VOICEMAIL
BUTTON
Pg. 13, 20~25
6. TELEPHONE KEYPAD
Pg. 16~18, 20, 21, 24, 25
8. FLASH BUTTON
Pg. 13, 14, 16, 18, 20~25
EDIT/
16. CHARGECONTACTS
HANDSET Controls
HANDSET Controls
1. items.
2. SCROLL UP-DOWN/SHIFT
LEFT-RIGHT BUTTON
Pg. 12, 14~16, 18~24
3. TALK BUTTON
Pg. 6, 7, 9, 10, 13,
14, 18, 29
2. SCROLL UP -DOWN , SHIFT LEFT -RIGHT Button:
3. Button:
Press to move around
Press to answer an incoming call or to place a call. Press to end a call
the large LCD Screen.
Pg. 14,19
7
14. OPTION BUTTON
Pg. 9, 12
TALK

HANDSET Controls
4. /VOICE MAIL Button: (MENU) Press to access the special functions
operation inSTANDBYmode.(Forspecialfunctionsseepage20~21.)(VOICEMAIL)
Press to automatically dial the Voice Mail Post Code in your area to access your
Voice Mail message.
5. HEADSET JACK: For connecting your headset plug to enjoy hands-free
communication. (See page 11 for detail.)
6. TELEPHONE KEYPAD Buttons: Allows you to make a call depending on pressed
button. (For TELEPHONE KEYPAD characters, see page 17.)
7. TEMPORARYTONE Button:Presstotemporarilychangethedialingmodefrom
PULSEto TONEforRotaryServiceUsers.(Pressoncebeforeenteringnumbers to
access the Answering System or electronic banking services, etc.)
8. EDIT/FLASH Button:(EDIT) Press to edit listed items. (FLASH) Press to answer a
call if you have Call Waiting.
9. NEWCALL/MSGWTG (MESSAGE WAITING) LEDIndicator: (NEW CALL) Blinks to
indicate that you have a new Caller ID call stored in memory. (MESSAGEWAITING)
Blinks at a slow rate when receiving a Message Waiting signal, if you have
subscribed to a Voice Mail message service from your local telephone company.
(Seepage 13.)
10.BATT LOW INDICATOR: AppearsontheLCDScreenwhenthebatterychargeislow.
(See page 27 for detail.)
11. (DIRECTORY) Button: Press to access names and numbers stored in the
DIRECTORY. (See pages 16 to 19 for details.)
12. /REDIAL Button: (SAVE)Pressandholddownto save the changeson thelisted
items. (REDIAL) Press to redial the last number you dialed. (PAUSE) Press to
insert a pause while dialing. (You will need the /REDIAL button to dial
numbers which use an alternative Long Distance Access Code.)
13. HANDSET Volume Control (hi, mid, low) Switch:Select the receiver volume level
(HI, MID, LOW).
14. /OPTION Buttton: Press to change the displayed number to form 7, 10 or 11
digits during Caller ID callback.
15. DEL(DELETE)/CHAN (CHANNEL) Button: (DELETE) - Press and hold down to
delete itemsor individual characters. (CHANNEL) Press to change the operating
channel when you hear interference.
16. CHARGE CONTACTS: For charging the BATTERY PACK inside the HANDSET. We
recommend cleaning the CHARGE CONTACTS periodically with a damp cloth.
*
#

BASE UNIT Controls
1. TELEPHONE LINE
CONNECTION JACK
Pg. 5, 6, 8, 29
3. TONE/PULSE
SELECT SWITCH
Pg. 6, 29
2. POWER-IN
CONNECTION JACK
Pg. 5, 6
6. CHARGE TERMINALS
5.BASE UNITANTENNA
Pg. 5, 6, 9, 29, 30
8. IN USE/CHARGE
LED INDICATOR
7. PAGE BUTTON
PAGE
4.HANDSET RETAINER
TAB

BASE UNIT Controls
1. TELEPHONE LINE CONNECTION JACK
2. POWER-IN CONNECTION JACK
3. TONE/PULSE Select Switch
4. HANDSETRetainerTab: For holding theHANDSET to rest securely in theBASEUNIT
CRADLE during wall mounting.
5. BASE UNIT ANTENNA
6. CHARGE TERMINALS: For charging the HANDSET BATTERY PACK. For best
performance, clean the CHARGE TERMINALS periodically with a damp cloth.
7. Button:Press to page theHANDSET.
8. INUSE/CHARGELED Indicator:(IN USE) Lights up to indicate that theHANDSET isin
TALKmodeandblinkswhenanextensiontelephone isinuse.(CHARGE)Lightsup
when theHANDSET is placed on theBASE UNIT for charging.
IMPORTANT
Placing your BASE UNIT near appliances
such as televisions, refrigerators, radios, or
microwave ovens may cause interference.

Safety Instructions.....................................................................................................................3
Getting Started...........................................................................................................................5
Desk Mounting............................................................................................................................8
Wall Mounting.............................................................................................................................8
Cordless Telephone Operation...................................................................................................9
Preparing for Use................................................................................................................ 9
Receiving Calls.................................................................................................................... 9
Placing Calls.........................................................................................................................10
Redialing.............................................................................................................................. 10
Extension Phones................................................................................................................11
Using the Headset Feature..................................................................................................11
Caller ID System Operation........................................................................................................ 12
Caller ID System...................................................................................................................12
Viewing Caller Information During Incoming Calls......................................................... 12
Caller ID with Call Waiting..............................................................................................13
Message Waiting...........................................................................................................13
One-Touch Voice Mail Dialing........................................................................................ 13
Caller List.............................................................................................................................14
Viewing the Caller List.................................................................................................. 14
Placing a Call from the Caller List.................................................................................. 14
Storing Caller ID Records into the DIRECTORY.................................................................15
To Delete a Single Record in the Caller List...................................................................15
To Delete all Records in the Caller List.......................................................................... 15
Name and Telephone Number DIRECTORY..........................................................................16
Viewing the DIRECTORY (Phonebook)........................................................................ 16
Storing Phone Numbers.................................................................................................16
Telephone Keypad Characters......................................................................................17
Placing Calls from the DIRECTORY................................................................................18
Editing a Stored Number in the DIRECTORY.................................................................. 18
Deleting a Stored Number in the DIRECTORY ...............................................................19
Preferred Calls.............................................................................................................. 19
Blocked Calls.................................................................................................................19
Contents
1

Function Settings................................................................................................................20
A. Setting the Ringer Level.........................................................................................21
B. Changing the Language.........................................................................................21
C. Turning the First Ring ON or OFF...........................................................................22
D. Setting the Time and Date......................................................................................22
E. Adjusting the Contrast...........................................................................................23
F. Setting the PBX Number.........................................................................................23
G. Changing the Flash Time........................................................................................23
H. Changing the Pause Time.......................................................................................24
I. Programming One-Touch Voice Mail Dialinbg.........................................................24
J. Deleting Message Waiting Indication......................................................................25
K. Setting the Area Code............................................................................................25
Security................................................................................................................................26
Recharging the BATTERY PACK............................................................................................27
Changing the BATTERY PACK...............................................................................................28
Problem Solving.....................................................................................................................29
Technical Information.....................................................................................................................30
FCC Requirements...........................................................................................................................31
Warranty Information.......................................................................................................................33
Wall Mount Template........................................................................................................................37
Contents
2

Safety Instructions
3
IMPORTANTSAFETYINSTRUCTIONS
To reduce the risk of fire, electric shock and/or injury, always follow these
basic safety precautions when using your cordless telephone equipment.
1. Readandunderstandallinstructions.
2. Followall warningsandinstructionsmarkedonthetelephone.
3. Do not use this telephone near a bathtub, wash bowl, kitchen sink, or laundry tub,
ina wetbasement, near aswimming pool,or anywhere elsewhere thereis water.
4. Avoid using a telephone (other than a cordless type) during an electrical storm.
There may be a remote risk of electric shock from lightning.
5. Do not use the telephone to report a gas leak in the vicinity of the leak.
6. Useonly thepower cordand BATTERYPACK indicatedin theOwner’s Manual. Do
not dispose of the BATTERY PACK in a fire. The BATTERY PACK may explode.
Checkwith localcodesforpossiblespecialdisposalinstructions.
7. Operate this telephone using the electrical voltage as stated on theBASE UNITor
in the Owner’s Manual. If you are not sure of the voltage in your home, consult your
dealeror localpower company.
8. Unplug this telephone from the wall outlet before cleaning or replacing the
BATTERY PACK. Do not use liquid cleaners or aerosol cleaners on the telephone.
Use a damp cloth for cleaning.
9. Placethis telephoneonastablesurface.Seriousdamageand/orinjurymay result
if the telephone falls.
10. Donotcovertheslotsandopeningsonthistelephone.Thistelephoneshouldnever
be placed near or over a radiator or heat register. This telephone should not be
placedin a built-ininstallationunless properventilationis provided.
11. Do not place anything on the power cord. Install the telephone where no one will
step or trip on the cord.
12. Do not overload wall outlets or extension cords as this can increase the risk of fire
orelectric shock.
13. Never push any objects through the slots in the telephone. They could touch
dangerous voltage points or short out parts that could result in a risk of fire or
electric shock. Never spill liquid of any kind on the telephone.
14. To reduce the risk of electric shock, do not take this telephone apart. If service or
repair work is required on this telephone, take it to a qualified service
representative.Openingorremovingcoversmayexposeyoutodangerousvoltage
orotherrisks.Incorrectreassemblycancauseelectricshockwhentheapplianceis
subsequentlyused.
15. Unplug this telephone from the wall outlet and consult a qualified service
representative in any of the following situations.
A. When the power supply cord is frayed or damaged.
B. Ifliquid has beenspilledinto the telephone.
C. If the telephone has been exposed to rain or water.
D. If the telephone does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the operating
instructions. Improper adjustment may require extensive work by a qualified
technicianto restore thetelephoneto normal operation.

E. Ifthetelephone has been dropped or thecasehasbeendamaged.
F. If the telephone exhibits a distinct change in performance.
16. Neverinstall telephone wiringduringa lightning storm.
17. Never install telephone jacks in wet locations unless the jack is specifically
designedforwetlocations.
18. Nevertouchuninsulatedtelephonewiresorterminalsunlessthetelephonelinehas
beendisconnectedat thenetwork interface.
19. Usecautionwheninstallingormodifyingtelephonelines.
Battery Safety
CAUTION:
Danger of explosion if BATTERY PACK is incorrectly replaced. Replace only
with the same or equivalent type. To reduce the risk of fire or personal
injury, read and follow these instructions:
1. Use only the following type and size of BATTERY PACK:
CordlessTelephoneBATTERYPACK
3.6V, 600mAh
U.S. Electronics Inc.
Ni-Cd BATTERY PACK: model B650
(See page 27 for ordering information.)
2. Do not dispose of the BATTERY PACK in a fire. It may explode. Check with local
codesforpossiblespecialdisposalinstructions.
3. Do not open or mutilate the BATTERY PACK. Released electrolyte from a BATTERY
PACK is corrosive and may cause damage to the eyes or skin. Electrolyte may be
toxic if swallowed.
4. Exercise care in handling the BATTERY PACK to prevent shorting the BATTERY
PACK with conductive materials such as rings, bracelets and keys. The BATTERY
PACK or conductor may overheat and cause burns.
5. Charge the BATTERY PACK provided with (or identified for use with) this telephone
only in accordance with the instructions and limitations specified in this manual.
6. Observe proper polarity orientation between the BATTERY PACK and BATTERY
CHARGER.
SAVETHESEINSTRUCTIONS
ATTENTION:
The product that you have purchased contains a rechargeable BATTERY PACK. The
BATTERY PACK is recyclable. At the end of its useful life, under various state and local
laws, it may be illegal to dispose of thisBATTERY PACKinto the municipalwaste stream.
Check with your local solid waste officials for details in your area for recycling options or
proper disposal.
Safety Instructions
4

Getting Started
Connecting Your Phone
Thissectionisa reference guideto the basicfunctions and operationsof yourcordless
telephone. For more detailed descriptions of the operations and features of this
telephone, refer to the Contents on page 1.
1.Carefully remove your cordless telephone from its shipping carton. If there is any
visible damage, do not attempt to operate this equipment. Return it to the place
ofpurchase.
2.Checkto be sureyouhave all itemsthatcome withthis cordlesstelephonesystem.
You should have a HANDSET, BASE UNIT, AC ADAPTOR, BATTERY PACK,
MOUNTINGBRACKET,TELEPHONELINECORD,SHORTTELEPHONELINECORD,
BELT CLIP and Owner’s Manual.
5
3. Insert the small plug on the end of the AC ADAPTOR into the POWER-IN
CONNECTION JACK at the back of theBASEUNIT.
4. Plug the AC ADAPTOR into a 120V AC wall outlet.
USE ONLY WITH CLASS 2 POWER SOURCE 9V DC, 300mA.
5. Insert one plug of the TELEPHONE LINE CORD into the house TELEPHONE JACK
andtheotherendintotheTELEPHONELINECONNECTIONJACKatthebackofthe
BASE UNIT. (If you have an older 4-prong TELEPHONE JACK, you will need an
RJ-11C TELEPHONE JACK ADAPTOR. This adaptor is available at the same place
you purchased your telephone.)
6. We recommend not placing this unit next to appliances. Doing so may cause
interference.
HANDSET BELT CLIP
TELEPHONE LINE CORD
ACADAPTOR
SHORT TELEPHONE LINE CORD
BASE UNIT MOUNTINGBRACKET
BATTERY PACK
TALK
PAGE

Getting Started
7. Place the HANDSET BATTERY PACK into the BATTERY COMPARTMENT with the
TERMINAL PLATES facing the CONTACT SPRINGS in the BATTERY
COMPARTMENT.
8. Slide the HANDSET BATTERY
COMPARTMENT COVER firmly into
place in its closed position.
9. IMPORTANT: Before initial use, charge
the HANDSET for 12 hours.
10. TONE/PULSE Select Switch:
A.Ifyour home isequippedwith a tone
dialingsystem,settheTONE/PULSE
Select Switch to the TONE position.
B.If you have a rotary dialing system,
set the TONE/PULSE Select Switch
to the PULSE position.
C.Ifyou are notsurewhich system you
have, set the TONE/PULSE Select
Switch to the TONE position. Press
the button on the HANDSET
to get a dial tone, and press any
buttonon theTELEPHONEKEYPAD
except the zero. If the dial tone
continues, it means that you do not
have TONE dialing service. Press
the button on the HANDSET
to hang up. Set the TONE/PULSE
Select Switch to the PULSE mode
and then try again.
11. Set the date and time on theHANDSET. (See page 22 for details.)
6
ACADAPTER
TELEPHONELINE CORD
TELEPHONE
JACK
120V WALL
OUTLET
TONE/PULSE
SELECT SWITCH
TELEPHONELINE
CONNECTION JACK
POWER-IN
CONNECTION
JACK
BATTERY PACK
BATTERY
COMPARTMENT
COVER

Getting Started
Press the button to confirm that you
haveadial tone. If you do notgetadialtone,
review steps 3 through 11. If you still do not
have a dial tone, refer to the Problem
Solving section on page 29.
You are now ready to use your new
BellSouthCordlessTelephone.
Belt Clip Installation
With the back of the HANDSET facing up,
insertone sideoftheBELTCLIPHOOKinto
the matching slot at the top side of the
HANDSET.Pressdownontheoppositeside
of the BELT CLIP until the other hook locks
into the slot on the side of theHANDSET.
7
.42GHz
TALK
BELT CLIP HOOK

Desk Mounting
One of the special features of your telephone is the unique design of the MOUNTING BRACKET
which can hold your phone at an angle of 30° and 60° when desk mounting. There are three
positions to choose from:
1. NORMAL POSITION (MOUNTING BRACKET not required):
For normal position, as shown in Figure 1, place
the BASE UNIT on any desired but suitable
location.
2. 30° POSITION (See Figure 2):
With the back of the BASE UNIT facing up, insert
the hooks of the MOUNTING BRACKET (with the
position as shown in Figure 3) into the upper four
slots of the BASE UNIT. Then slide the MOUNTING
BRACKET upward until it locks into place.
3. 60° POSITION (See Figure 4):
With the back of the BASE UNIT facing up, insert
the hooks of the MOUNTING BRACKET (with the
position as shown in Figure 5) into the lower four
slots of the BASE UNIT. Then slide the MOUNTING
BRACKET upward until it locks into place.
Wall Mounting
You may choose to put the BASE UNIT of your cordless telephone on a wall.
1. With the back of theBASEUNIT facingup,connect
the SHORT TELEPHONE LINE CORD to the
TELEPHONE LINE CONNECTION JACK.
2. Insert the free end of the SHORT TELEPHONE LINE
CORDthroughtheholeoftheMOUNTINGBRACKET.
3. Insert the hooks of the MOUNTING BRACKET into
the matching slots on the back of the BASE UNIT
(following the arrow direction for the WALL
MOUNT). Then slide the MOUNTING BRACKET until
it locks into place. Plug the free end of the SHORT
TELEPHONE LINE CORD into the MODULAR WALL
JACK.
4. Alignthe upperkeyholeof theMOUNTINGBRACKET
with the upper stud of the wall plate, so that the
opening end of the MOUNTING BRACKET matches
the lower stud, then pull the BASE UNITdownuntil
it is securely seated.
Desk Mounting
8
FIGURE 2
FIGURE 3
FIGURE 1
FIGURE 5
FIGURE 4
MOUNTING
BRACKET MODULAR
WALL JACK
WALL
PLATE
WALL PLATE STUD
SHORT TELEPHONE
LINECORD

Cordless Telephone Operation
9
Receiving Calls
1. When the phone rings, the display will
show “RING.” If you have Caller ID, the
display will show the Caller ID
information after the first ring.
2. With theHANDSET off the base, press
the button.The Call Timer starts to
count.
3. To end your conversation, either press the button or place theHANDSETon
the BASE UNIT. If you place theHANDSET on theBASEUNIT CHARGECRADLE,
you activate the AUTOMATIC STANDBY feature.
NOTE: The Call Timer will start to count once you press the button.
Minutes
Seconds or Channel (Press
the DEL/CHAN button to
display the channel.)
Call Timer Display
02 08
Preparing for Use
Before you can use your cordless telephone, you must charge the HANDSET for 12
hours. Failure to do so will require recharging of the BATTERY PACK more often.
1. Place theHANDSET on the BASE UNIT for 12 hours.
2. After 12 hours, remove theHANDSET from the BASEUNIT.
Before you can use your cordless telephone, you must charge the HANDSET
for 12 hours. Failure to do so will require more frequent charging of the
BATTERY PACK. See page 27 for more information on the BATTERY PACK.
NOTE:
Depending on the frequency of use, once the HANDSET is fully charged, it remains
functional for approximately 4 hours of continuous use and approximately 5 days when
the HANDSET is off theBASE UNIT in STANDBY mode.
TALK
IMPORTANT
In order to utilize the Caller ID feature, you
must subscribe to Caller ID service from
your local telephone company.
TALK

Cordless Telephone Operation
Placing Calls
1. Press the button, the Call Timer
starts to count.
2. Wait until you hear a dial tone and then
dial the phone number.
3. When you have finished your call,
press the button again or place the
HANDSET on theBASEUNIT.
OR
1. Dial the phone number.
2. Press the button. The number
displayed will be dialed.
3. When you have finished with your call,
press the button again or place
the HANDSET on the BASE UNIT.
Redialing
1. If you get a busy tone, press the
button or place theHANDSETon theBASE
UNIT to hang up.
2. Later, press the button again.
3. Listen for a dial tone.
4. Press the /REDIAL button. This
willautomaticallyredialthelasttelephone
number you called.
5. When you have finished with your call,
press the button again or place
the HANDSET on theBASEUNIT.
NOTE:
If you are too far away from the BASE UNIT, the HANDSET emits “beep” sounds to
warnyouthatthebackgroundnoiselevelis toohighforpropercommunicationbetween
the HANDSET and theBASEUNIT.Whenyouhearthissound,you shouldmovecloser
to theBASE UNIT toreduce thenoise level.Otherwise, the callwill automaticallycutoff.
10
SAVE
1, 3 TALK
1, 2, 5 4
TALK

Extension Phones
Extension telephones can be connected. When
an extension phone is being used, the display
will show “EXT IN USE” and the Private Call
indicator will blink on the LCD screen. You will
have to wait until the line is free to make a
call.
If, during a telephone conversation, the BASE
UNIT IN USE LED indicator begins to blink, an
extension phone has gone off-hook.
NOTE:
If the telephone line cord is not connected to the
wall jack and the TELEPHONE LINE
CONNECTION JACK, the display will also show
“EXT IN-USE.”
Using the Headset Feature
Your telephone can utilize a headset (not
included) to be connected to your HANDSET for
you to enjoy hands-free communication.
Insert the small plug on the end of the headset
into the HEADSET JACK at the right side of the
HANDSET. Follow the procedures discussed in
“Receiving Calls” and “Placing Calls” to receive
and place a call.
NOTE:
When you plug the headset plug into the
HEADSET JACK it automatically mutes the
MICROPHONEandSPEAKERoftheHANDSET.
Unplug the headset to return the HANDSET to
normal use.
Headsets are available at most retail outlets that sell telephone equipment. The
HEADSET JACK is compatible with 2.5 mm headset plugs only.
Cordless Telephone Operation
11
PRIVATE CALL
Indicator
TALK
MICROPHONE
HEADSET
SPEAKER
HEADSETJACK
HEADSET
PLUG (2.5mm)

Caller ID System Operation
Caller ID System
This telephone automatically displays an incoming caller’s name and telephone
number together with the date and time of the call. It records up to 80 calls and stores
the data in Memory.
IMPORTANT: You must subscribe to the Caller ID service from your local telephone
company to utilize this feature.
Viewing Caller Information During Incoming Calls
1. Whenthereisanincomingcall,thenameandthetelephonenumberofthecaller
will automatically appear after the first ring. Press the SHIFT RIGHT
button to view a name of more than 11 digits.
ORCaller’stelephonenumberwillappearifthecaller’sname
is not available.
OR“UNAVAILABLE” will appear when Caller ID information
is not available. The origin of the call does not support
the Caller ID system (including international calls).
OR“DATA ERROR” will appear when the Caller ID
information was received incorrectly or only part of the
data was received.
NOTE: When an error is received, none of the data from
this call is saved in memory.
OR“PRIVATE” will appear if the caller’s name and/or
telephone number is blocked.
OR“MSG WAITING” will appear when a Voice Mail Message
has been received and is stored by Message Waiting
service provided by the telephone company.
12

Caller ID with Call Waiting
Whenyou subscribetoCallWaitingservicefromyourlocaltelephonecompany, this
telephone will display the name and number of the second caller while you are
having a conversation with the first caller.
When a new call comes in while you are
talking, you will hear a notification beep from
the HANDSET andthevolumeismomentarily
muted. The new caller’s name and phone
number, if available, appears on the display.
An “L2” in the lower right corner icon
indicates the call waiting caller ID caller so
you can keep track of who you are talking to.
1. When you receive a “Call Waiting” call and you want to connect the call,
press the EDIT/FLASH button. The active call will be placed on hold.
2. Press the EDIT/FLASH button to alternate between calls.
3. Press the button to end the call or place the HANDSET on the BASE
UNIT.
“MSG WAITING” (Message Waiting)
TheMessageWaitingLEDindicatorwillblinkwhenthereisamessageforyoufrom
your telephone company if you have subscribed to Voice Mail message service and
if you have requested Visual Message Indication from your local telephone
company. “MSG WAITING” will appear on the LCD Screen in STANDBY mode. (To
remove the MSG WAITING indicator, see page 25 for detail.)
Note: This function requires voice mail subscription from the local telephone
company.Furthermore, thelocalphonecompanymustprovideatypeofvoice mail
signaling called “FSK” (Frequency Shift Key). Not all telephone companies have
the visual message waiting feature available. Please contact your local telephone
company to check if this is available in your area.
One-Touch Voice Mail Dialing
When the setting is programmed in the Functions menu (see “Programming
One-TouchVoiceMailDialing”onpage24)you candialoutaprogrammednumber
at the touch of a button. This feature is specifically designed to easily check voice
mail when you have that service through your telephone company.
1. Press the button to access the telephone line.
2. Press the /VOICE MAIL button.
3. The phone will automatically dial the number.
Caller ID System Operation
MIN SEC
13
