Beltronics 928i Vector User manual

Beltronics
5442 West Chester Road
West Chester OH 45069 -2950
U.S. Customer Service:
1.800.341.2288
www.beltronics.com
©2012 Beltronics.
Manufactured and Printed in Canada.
Beltronics Vector 928i
U LT I M AT E R A D A R / L A S E R / S A F E T Y D E T E C T O R
Owner’s Manual

The Beltronics Vector 928i is the most
advanced radar, laser and safety detector
ever designed by Beltronics.
The Bel V928i includes full X, K,
SuperWide Ka, and Safety Warning System
radar capability, front and rear laser
detection, varactor-tuned (VTO) microwave
receiver, digital signal processing (DSP)
for superior range and reduced false
alarms, our patented Mute and AutoMute,
audible and visual band alerts, and all the
performance you’d expect from Beltronics.
In addition, the Bel V928i introduces
the following revolutionary features:
• Varactor-tuned receiver provides
long-range protection against all
radar threats
• New easy-to-use Programming lets
you customize up to 6 features
• Ultra-bright text-display provides
easy to read information from any
angle
• Detects and decodes Safety Warning
System messages
If you’ve used a radar detector before,
a review of the Quick Reference Guide on
pages 4 and 5, and the Programming
information on pages 12 and 13 will briefly
explain the new features.
If this is your first detector, please read
the manual in detail to get the most out of
your V928i’s outstanding performance and
innovative features.
Please drive safely.
Congratulations Quick Reference
1Programming Details 
Factory Default Settings
To reset your V928i to its original factory settings,
press and hold the “CITY” and “BRT” buttons while
turning the power on. The V928i’s display will
provide a Reset message, accompanied by an
audible alert, acknowledging the reset.
An example
Here is how you would turn the V928i’s AutoMute
feature off.
1 Enter the Program Mode by holding both the CITY
and BRT buttons down for 2 seconds. The V928i will
beep twice and display Program.
2 Then hold the RVW button down. V928i will scroll
through the categories, starting with Display (Pilot),
then Voice (Voice), then Power-On sequence (PwrOn),
and then AutoMute (aMute).
3 Release the RVW button when the V928i shows the
AutoMute item. Since the factory setting is for
AutoMute to be on, the V928i will display aMute ON.
If you accidentally don’t release the Review button
in time, and the V928i goes to the next category, hold
the RVW button down again, and after the V928i
scrolls through all categories, it will begin again at
the top of the list.
4 Press the CHG button to change from aMute ON to
aMute OFF.
5 To complete the Programming, simply wait 8
seconds without pressing any button. The V928i will
display Complete, beep 4 times, and return to
normal operation.
FCC Note:
Modifications not expressly approved
by the manufacturer could void the
user’s FCC granted authority to operate
the equipment.
There are 6 user-selectable options so you can
customize your V928i for your own preferences.
The buttons labeled CITY and BRT are also used to
enter the Program Mode, REVIEW your current
program settings, and to CHANGE any settings as
desired. The words PGM, RVW and CHG are located on
the top of the detector, and are highlighted in graphics.
How to use Programming
1 To enter Program Mode, press and hold both
CITY and BRT buttons down for 2 seconds. The
unit will beep twice, and will display the word
Program.
2 Then press the RVW button to review the
current settings. You can either tap the button to
change from item to item, or hold the button to scroll
through the items.
3 Press the CHG button to change any setting.
You can either tap the button to change from setting to
setting, or hold the button to scroll through all the
options.
4 To leave Program Mode, simply wait 8 seconds
without pressing any button. The unit will display
Complete, beep, and return to normal operation.
Register
online:
@
www.beltronics.com

Table of Contents
Quick Reference Guide 4-5
Installation 6-7
• Power Connection 6
• Mounting Location 6
• Windshield Mount 7
Controls and Features 8-10
• Power and Volume Control 8
• Power-on indication 8
• Voice 8
• AutoMute 8
• Mute 8
• Highway / City Button 9
• Brightness and Dark Mode 9
• Audible Alerts 10
• SmartCord Power Connector 10
• Signal Strength Meter 10
Programming 11-14
• How to use Programming 11
• Example of Programming 11
• Overview of Programming 12
• Details of Programming 13-14
Technical Details 15-21
• Specifications 15
• Interpreting Alerts 16-17
• How Radar Works 18
• How “POP” Works 18
• How Laser Works 19
• How Safety Radar Works 20-21
Service 22-28
• Troubleshooting 22-23
• Service 24
• Warranty and Accessories 25
• Registration 27-28
32
Quick Reference
* Factory Default Settings
Press the RVW button
to go from one category
to the next
PILOT
(Power-on indication)
VOICE
POWER-ON SEQUENCE
AUTOMUTE
CITY MODE SENSITIVITY
BANDS
Pilot HWY
Pilot H
Voice ON
Voice OFF
PwrOn STD
PwrOn FST
aMute ON
aMute OFF
City STD
City LoX
Bands DFT
Bands MOD
X ON or OFF (default is OFF)
K K STD (default)
K Puls (STD + ISKRA)
K Hyper (STD + K Pulse + K Low)
Ka ON or OFF (default is ON)
POP ON or OFF (default is OFF)
Laser ON or OFF (default is ON)
SWS ON or OFF (default is OFF)
Press the CHG button
to change your setting
within a category
* Full word: Highway or City
Letter: H or C
* Voice alerts on
Voice alerts off
* Standard power-on sequence
Fast power-on sequence
* AutoMute on
AutoMute off
* Standard City mode sensitivity
Low X band sensitivity in City Mode
* Factory default settings
Factory default settings modified
Turn bands “ON” or “OFF” by
pressing the VOLUME/MUTE button

Radar Antenna and Laser Lens
The rear panel of your V928i should have
a clear view of the road ahead. For best
performance, do not mount the V928i
directly behind windshield wipers
or tinted areas. Page 6
Alphanumeric Matrix Display
Your V928i’s display will show Highway
or City as its power-on indication. If you
prefer, you can choose other power-on
indications. Page 12-14
During an alert, the display will indicate
radar band, and a precise bar graph of signal
strength. Page 10
NOTE: In the Dark Mode the display
will not light during an alert. Page 9
Quick Reference Guide
To begin using your V928i,
just follow these simple steps
1 Plug the small end of the power cord
into the side jack of the detector, and
plug the large end of the power cord
into your car’s lighter socket.
2 Mount your V928i on the windshield
using the supplied windshield mount.
3 Press the PWR button, located top left,
to turn the V928i on.
4 Press and hold the Volume/Mute
button to adjust the volume.
Please read the manual to fully understand
your V928i’s operation and features.
QuickMount Slot
Insert the V928i’s adjustable Windshield
mount into this slot. Page 7
QuickMount Button
Press the button, and slide the Windshield
mount into one of its four locking positions.
Page 7
City Button
Switches between City and Highway,
settings. In general, we recommend
Highway. Page 9
Power
Press the PWR button to turn the V928i on
or off.
AutoMute
Your V928i’s patented AutoMute
automatically reduces the volume level of
the audio alert after a brief period. If you
prefer, you can turn AutoMute off. Page 8
Programming
Your V928i is ready to go, just plug it in and
turn it on. But you can also easily change 6
features for your preferences. Page 12-14
45
Rear Laser Port
Receives laser signals from behind the
vehicle.
Earphone Jack
Accepts standard mono 3.5mm earphone.
Brightness Button
Press to adjust display brightness. There are
three brightness settings, plus Dark Mode.
In the Dark Mode, the power-on
indication will be changed to a “HD” or “CD”
(indicating Highway Dark or City Dark). In
the Dark Mode, the V928i’s meter will not
display during an alert, only the audio will
alert you. Page 9
Power Jack
Plug the power cord into this connector.
Page 6
Volume and Mute Button
Press and hold the Volume/Mute button to
adjust the alert volume level. Page 8
Briefly press this button to silence the
audio for a specific alert. (The audio will
alert you to the next encounter.) Page 8

Power Connection
To power your V928i, plug the small
end of the power cord, (telephone-type
connector) into the modular jack on the
V928i’s right side, and plug the SmartCord
into your vehicle’s lighter or accessory
socket.
Your V928i operates on 12 volts DC
negative ground only. The lighter plug
provided is a standard size and will work
in most vehicles. However, some vehicles
may require the optional European sleeve
to ensure a snug fit. If so, simply call our
service department to order one. This
sleeve slides over the lighter plug. Of
course, your lighter socket must be clean
and properly connected for proper
operation.
NOTE: Depending on your vehicle, the
lighter socket power may either be
continuously on, or it may be switched on
and off with your ignition switch.
Mounting Location
WARNING: BELTRONICS cannot anticipate
the many ways the V928i can be mounted.
It is important that you mount your V928i
where it will not impair your view nor
present a hazard in case of an accident.
Where to mount your V928i
For optimum detection performance, we
recommend the following:
• Using the QuickMount bracket, mount
your V928i level, and high enough on your
front windshield to provide a clear view of
the road from the front and rear.
• Mount the V928i away from windshield
wipers, other solid objects, and heavily
tinted areas that might obstruct the radar
antenna or laser lens.
6
Installation
7
Caution!
A few vehicles (including some Porsches)
have windshields with a soft anti-lacerative
coating on the inside surface. Use of
suction cups will permanently mar this
coating. Consult your dealership or the
vehicle owner’s manual to determine if
your windshield has this coating.
User’s Tip
You can leave the QuickMount bracket in
place on your windshield, and easily remove
the V928i by pressing the adjustment
button and sliding the V928i off the mount.
Again, be sure to position the bracket
where it won’t present a hazard in the
event of an accident. Additional mounts are
available.
Windshield QuickMount
The V928i’s QuickMount bracket is
designed for unobtrusive and hassle-free
mounting.
1 Depress the QuickMount button
on the top of the V928i (by the word
BELTRONICS) and slide the QuickMount
bracket into the slot until it is locked into
the position which best fits the angle of
your windshield (there are four settings
available). For extremely horizontal or
extremely sloped windshields,
the QuickMount bracket can
be bent.
To ensure that the suction cups
adhere to the windshield firmly, be sure to
keep both your windshield and the suction
cups clean.
2 To adjust the V928i on your
windshield, use the QuickMount
adjustment button located on the top of
the V928i, and slide the V928i forward
or backward to obtain a level horizontal
position.
When installed and adjusted properly, the
back top edge of the V928i should rest
solidly against your windshield.

Controls and Features
Power
To turn your V928i on or off, press the PWR
button located on the top. When you turn
your V928i on, it goes through a sequence
of alerts.
If you prefer, you may program your
V928i for a shorter power-on sequence. See
the Programming section for details.
Volume
Press and hold the Volume/Mute button
located on the top case to adjust the
V928i’s alert volume level. The audio will
ramp up and down, accompanied by a bar-
graph on the display. Once you’ve reached
your preferred audio level, simply release
the button.
Power-on indication
After the V928i’s start-up sequence is
complete, the alphanumeric display will
show Highway or City to indicate which
sensitivity mode is selected.
If you prefer, you can select alternate
power-on displays. See the Programming
section for details.
Voice Alerts
The V928i provides digital voice
announcements of radar and laser bands
detected. If Safety Radar (SWS) is turned
on, a safety radar message will also be
announced. See the Programming section
for details.
If you prefer, you can turn Voice Alerts
off. See Programming section for details.
AutoMute
Your V928i has our patented AutoMute
feature. After the V928i alerts you to a radar
encounter at the volume you have selected,
the AutoMute feature will automatically
reduce the volume to a lower level. This
keeps you informed without the annoyance
of a continuous full-volume alert.
If you prefer, you can turn the
AutoMute feature off. See the Programming
section for details.
Mute
The Mute button, located on the V928i’s
top case, allows you to silence the audio
alert during a radar encounter.
To mute the audio for a single specific
signal, briefly press the Mute button. After
that radar encounter has passed, the mute
will automatically reset and the audio will
alert you to the next encounter.
8
Highway / City Button
The City button selects the V928i’s
sensitivity mode. We recommend the
Highway mode for most driving.
When driving in urban areas where
annoying X-band intrusion alarms and door
openers are common, City mode can be
engaged to lower X-band sensitivity and
reduce X-band alerts. Full sensitivity is
maintained on all other bands. See the
Programming section for details.
Brightness
The V928i’s BRT button selects the
brightness of your V928i’s display. There are
four settings: Maximum, Medium, Minimum,
and Dark. Press the BRT button to select
your preferred brightness.
9
Dark Mode
When you select the Dark mode with the
BRT switch, your V928i changes to a very
inconspicuous power-on indication: a
very Dim HD or CD. (In this display, the H
or C indicates Highway or City, and the D
indicates Dark.)
When the V928i is in the Dark mode,
the display will not show visual alerts when
V928i detects signals. Only the audible alert
will tell you of detected signals.

Controls and Features
10
SmartCord™ Power Connector
The V928i’s power jack uses a telephone-
type connector. This 4-conductor
connector only works with the included
SmartCord or optional direct-wire.
For more information or to order, call
us toll-free at 1-800-341-2288.
Signal Strength Meter
Your V928i’s alphanumeric display consists
of 280 individual LEDs, to provide an
intuitive ultra-bright display of signal
strength and text messages.
The V928i’s standard bar-graph signal
strength meter only displays information
on a single radar signal. If there are multiple
signals present, the V928i’s internal
computer determines which is the most
important threat to show on the bar-graph
meter.
When your V928i detects radar, it
displays the band (X, K, or Ka), and a
precise bar-graph of the signal strength.
When your V928i detects a laser signal, the
display will show LASER.
NOTE: If you are operating the V928i
in the Dark mode, the display will not light
when a signal is detected, only the audio
will be heard.
11
Audible Alerts
For Radar signals:
Your V928i uses a Geiger-counter-like
sound to indicate the signal strength and
type of radar signal being encountered.
When you encounter radar, a distinct
audible alert will sound and occur faster as
the signal gets stronger. This allows you to
judge the distance from the signal source
without taking your eyes from the road.
Each band has a distinct tone for easy
identification.
X-band = chirping
K-band = buzzing
Ka-band = double-chirp
POP = full double-chirp
For Laser and POP signals:
Since laser and POP signals (if turned
on) are a possible threat no matter how
weak, the V928i alerts you to these bands at
full strength.
For Safety signals:
Your V928i will alert you to these
signals with a double-beep tone, and a
corresponding text message. A complete
listing of the text messages is on page 21.
Programming
There are 6 user-selectable options so you
can customize your V928i for your own
preferences. The buttons labeled CITY and
BRT are also used to enter the Program
Mode, REVIEW your current program
settings, and to CHANGE any settings as
desired. The words PGM, RVW, and CHG are
located on the top of the detector, and are
highlighted in colored graphics. Pages 13-
14 explain each option in more detail.
How to use Programming
1 To enter Program Mode, press and
hold both the CITY and BRT buttons
down for 2 seconds. The unit will beep
twice, and will display the word Program.
2 Then press the RVW button to
review the current settings. You can
either tap the button to change from item
to item, or hold the button to scroll through
the items.
3 Press the CHG button to change
any setting. You can either tap the button
to change from setting to setting, or hold
the button to scroll through all the options.
4 To leave the Program Mode,
simply wait 8 seconds without
pressing any button, or press the PWR
button. The unit will display Complete,
beep 4 times, and return to normal
operation.
An example
Here is how you would turn your V928i’s
AutoMute feature off.
1 Enter the Program Mode by holding
both the CITY and BRT buttons down for
2 seconds. The V928i will beep twice and
display Program.
2 Then hold the RVW button down. The
V928i will scroll through the categories,
starting with Pilot (Pilot), Voice
(Voice), Power-on sequence (PwrOn),
and then AutoMute (aMute).
3 Release the RVW button when the
V928i shows the AutoMute item. Since the
factory setting is for AutoMute to be on,
the V928i will display aMute ON.
If you accidentally don’t release the
RVW button in time, and the V928i goes
to the next category, hold the RVW button
down again, and after your V928i scrolls
through all categories, it will begin again
at the top of the list.
4 Press the CHG button to change from
aMute ON to aMute OFF.
5 To complete the Programming, simply
wait 8 seconds without pressing any
button, or press the PWR button. The V928i
will display Complete, beep 4 times, and
return to normal operation.

12
Overview of Programming
13
* Factory Default Settings
To reset your V928i to its original
factory settings, press and hold the
“CITY” and “BRT” buttons while
turning the power on. The V928i’s
display will provide a Reset
message, accompanied by an audible
alert, acknowledging the reset.
Details of Programming
Pilot (Power-on indication)
NOTE: When you are using the Dark
mode, the display will only show HD or CD
(Highway-Dark or City-Dark).
Pilot HWY (Full description)
In this setting, your V928i will display
“Highway” or “City” as its power-on
indication. (factory default)
Pilot H (Letter)
In this setting, your V928i will display “H”
for Highway and “C” for City.
Voice
Voice On (Voice announcements on)
In this setting, all radar, laser, and SWS
messages (if programmed) will be
announced using a digital voice.
Voice Off (Voice announcements off)
In this setting, only the distinct audio tone
will be heard when a radar, Laser, or SWS
message is detected.
Power-on Sequence
PwrOnSTD (Standard)
In this setting, each time you turn on your
V928i, it will display “BEL V928i,” “Laser,” “Ka-
band,” “K-band,” “X-band,” “Safety,” followed
by a brief X-band alert. (factory default)
If any bands have been changed from
the factory default settings, a double X-band
tone and corresponding message
(i.e. “SWS ON”), will alert you that one or
more bands have been changed.
PwrOnFST (Fast power-on)
In this setting, your V928i will provide a
single X-band tone. If any bands have been
changed from the factory default settings,
a double X-band tone and corresponding
message (i.e. “SWS ON”), will alert you that
one or more bands have been changed.
AutoMute
aMute ON (AutoMute on)
In this setting, your V928i’s audio alerts will
initially be at the volume you set, but after
a few seconds, the V928i will automatically
reduce the volume level, to keep you
informed, but not annoyed. (factory default)
aMuteOFF (AutoMute off)
With AutoMute off, your V928i’s audio alerts
will remain at the volume you set for the
duration of the radar encounter.
Press the RVW button
to go from one category
to the next
PILOT
(Power-on indication)
VOICE
POWER-ON SEQUENCE
AUTOMUTE
CITY MODE SENSITIVITY
BANDS
Pilot HWY
Pilot H
Voice ON
Voice OFF
PwrOn STD
PwrOn FST
aMute ON
aMute OFF
City STD
City LoX
Bands DFT
Bands MOD
X ON or OFF (default is OFF)
K K STD (default)
K Puls (STD + ISKRA)
K Hyper (STD + K Pulse + K Low)
Ka ON or OFF (default is ON)
POP ON or OFF (default is OFF)
Laser ON or OFF (default is ON)
SWS ON or OFF (default is OFF)
Press the CHG button
to change your setting
within a category
* Full word: Highway or City
Letter: H or C
* Voice alerts on
Voice alerts off
* Standard power-on sequence
Fast power-on sequence
* AutoMute on
AutoMute off
* Standard City mode sensitivity
Low X band sensitivity in City Mode
* Factory default settings
Factory default settings modified
Turn bands “ON” or “OFF” by
pressing the VOLUME/MUTE button

14 15
City Mode Sensitivity
City STD (Standard)
In this setting, when you put your V928i in
the City mode, X-band sensitivity is
significantly reduced, to reduce annoyance
from X-band intrusion alarms and motion
sensors. (factory default)
City LoX (Low X band sensitivity)
In this setting, when you put your V928i in
the City mode, X-band sensitivity is reduced
more than the standard setting. This will
reduce X-band alarms from other sources
even further, but also significantly reduces
range to X-band traffic radar.
Bands
BandsDFT
In this setting, all North American radar and
laser frequencies are monitored. This is the
factory setting and it is recommended that
you use your V928i in this mode.
BandsMOD
In this setting, your V928i will warn you
with an audible alert, and associated text
message stating which band has changed
from the original factory setting (i.e. “SWS
ON”). This warning is displayed during the
start up sequence (standard or fast).
Details of Programming
Features and Specifications
Operating Bands
• X-band 10.475-10.575 GHz ±25 MHz
• K STD, or K PULS, or K HYPR, or K OFF
K Standard: 23.950-24.250 GHz ±100 MHz
K Pulse: Detects K STD with Rapid K
Pulse (ISKRA)
K Hyper: Detects K STD, K Pulse, and
Low Power K source
• Ka-band 33.400-36.110 GHz ±1300 MHz
• POP 33.725-33.875 GHz ±1300 MHz
• Laser 904nm with 5 KHz Pulse,
33 MHz bandwidth
Radar Receiver / Detector Type
• Superheterodyne, VTO
• Scanning Frequency Discriminator
• Digital Signal Processing (DSP)
Laser Detection
• Quantum Limited Video Receiver
• Multiple Laser Sensor Diodes
Display Type
• 280 LED Alphanumeric
• Bar Graph
• 3 Levels of Brightness, plus Dark Mode
Power Requirement
• 12VDC, Negative Ground
• Power cord (included)
Programmable Features
• Power-On Indication
• Voice Alerts
• Power-On Sequence
• AutoMute
• City Mode Sensitivity
• Bands
Sensitivity Control
• Highway and City
Auto Calibration Circuitry
VG2 Immunity
Dimensions (Inches)
• 1.25 H x 2.75 W x 4.75 L
Technical Details

16 17
Technical Details
Interpreting Alerts
Although the V928i has a comprehensive
warning system and this handbook is as
complete as we can make it, only
experience will teach you what to expect
from your V928i and how to interpret what
it tells you. The specific type of radar being
used, the type of transmission (continuous
or instant-on) and the location of the radar
source affect the radar alerts you receive.
The following examples will give you
an introduction to understanding the your
V928i’s warning system for radar, laser and
safety alerts.
Explanation
You are approaching a continuous radar
source aimed in your direction.
An instant-on radar source is being used
ahead of you and out of your view.
An instant-on radar source or laser source is
being used nearby. This kind of alert requires
immediate attention!
Laser is being used in the area. Because laser
is inherently difficult to detect, any laser alert
may indicate a source very close by.
A moving patrol car with continuous radar is
overtaking you from behind. Because these
signals are reflected (reflections are increased
by large objects), they may or may not
eventually melt into a solid point even when
the patrol car is directly behind you.
Alert
The V928i begins to sound slowly, then the
rate of alert increases. The Signal Meter ramps
accordingly.
The V928i emits short alerts for a few seconds
and then falls silent only to briefly alert and
fall silent again.
The V928i suddenly sounds a continuous
tone for the appropriate band received. All
segments in the Signal Strength Meter are lit.
A brief laser alert.
The V928i receives weak signals. These
signals may be a little stronger as you pass
large, roadside objects. The signals increase in
frequency.
Explanation
You are approaching a radar unit concealed
by a hill or an obstructed curve.
A patrol car is traveling in front of you with a
radar source aimed forward. Because signals
are sometimes reflected off of large objects
and sometimes not, the alerts may seem
inconsistent.
A patrol car is approaching from the other
direction, sampling traffic with instant-on
radar. Such alerts should be taken seriously.
You are driving through an area populated
with radar motion sensors (door openers,
burglar alarms, etc.). Since these transmitters
are usually contained inside buildings or
aimed toward OR away from you, they are
typically not as strong or lasting as a real radar
encounter.
Alert
The V928i alerts slowly for a while and then
abruptly jumps to a strong alert.
The V928i alerts intermittently. Rate and
strength of alerts may be inconsistent or vary
wildly.
The V928i alerts intermittently. Rate and
strength of signal increases with each alert.
The V928i gives an X-band, or K-band alert
intermittently.
CAUTION: Since the characteristics of
these alerts may be similar to some of
the preceding examples, overconfidence
in an unfamiliar area can be dangerous.
Likewise, if an alert in a commonly
traveled area is suddenly stronger or on a
different band than usual, speed radar may
be set up nearby.

18 19
Technical Details
How Radar Works
Traffic radar, which consists of microwaves,
travels in straight lines and is easily
reflected by objects such as cars, trucks,
even guardrails and overpasses. Radar
works by directing its microwave beam
down the road. As your vehicle travels into
range, the microwave beam bounces off
your car, and the radar antenna looks for
the reflections. Using the Doppler Principle,
the radar equipment then calculates your
speed by comparing the frequency of
the reflection of your car to the original
frequency of the beam sent out.
Traffic radar has limitations, the most
significant of these being that it typically
can monitor only one target at a time. If
there is more than one vehicle within
range, it is up to the radar operator to
decide which target is producing the
strongest reflection. Since the strength of
the reflection is affected by both the size of
the vehicle and its
proximity to the antenna, it is difficult for
the radar operator to determine if the signal
is from a sports car nearby or a semi-truck
several hundred feet away.
Radar range also depends on the
power of the radar equipment itself.
The strength of the radar unit’s beam
diminishes with distance. The farther the
radar has to travel, the less energy it has for
speed detection.
Because intrusion alarms and motion
sensors often operate on the same
frequency as radar, your V928i will
occasionally receive non-police radar
signals. Since these transmitters are usually
contained inside of a building, or aimed
toward the ground, they will generally
produce much weaker readings than will
a true radar encounter. As you become
familiar with the sources of these pseudo
alarms in your daily driving, they will serve
as confirmation that your V928i’s radar
detection abilities are fully operational.
How “POP” Works
“POP” mode is a relatively new feature for
radar gun manufacturers. It works by
transmitting an extremely short burst,
within the allocated band, to identify
speeding vehicles in traffic. Once the target
is identified, or “POPPED,” the gun is then
turned to its normal operating mode to
provide a vehicle tracking history, (required
by law).
How Laser (Lidar) Works
Laser speed detection is actually LIDAR
(Light Detection and Ranging). LIDAR
guns project a beam of invisible infrared
light. The signal is a series of very short
infrared light energy pulses, which move,
in a straight line, reflecting off your car and
returning to the gun. LIDAR uses these light
pulses to measure the distance to a vehicle.
Speed is then calculated by measuring how
quickly these pulses are reflected given the
known speed of light.
LIDAR (or laser) is a newer technology
and is not as widespread as conventional
radar, therefore, you may not encounter
laser on a daily basis. And unlike radar
detection, laser detection is not prone
to false alarms. Because LIDAR transmits
a much narrower beam than does radar,
it is much more accurate in its ability to
distinguish between targets and is also
more difficult to detect. AS A RESULT,
EVEN THE BRIEFEST LASER ALERT
SHOULD BE TAKEN SERIOUSLY.
There are limitations to LIDAR
equipment. LIDAR is much more sensitive
to weather conditions than RADAR, and a
LIDAR gun’s range will be decreased by
anything affecting visibility such as rain,
fog, or smoke. A LIDAR gun cannot operate
through glass and it must be stationary in
order to get an accurate reading. Because
LIDAR must have a clear line of sight and
is subject to cosine error (an inaccuracy,
which increases as the angle between the
gun and the vehicle, increases) police
typically use LIDAR equipment parallel to
the road or from an overpass. LIDAR can be
used day or night.

20 21
Technical Details
How Safety Radar Works
Safety Warning System, or SWS, uses a
modified K-band radar signal. The SWS safety
radar system has 64 possible messages (60
currently allocated). The SWS messages
your V928i can display are listed on the
facing page.
From the factory, your V928i is
programmed with SWS decoding OFF. If
SWS is used in your area, your V928i will
display the safety messages associated with
the signal. If you wish to detect this system,
use the Programming feature to turn the
V928i’s SWS decoding ON.
NOTE: Some of the safety messages
have been condensed, so that each message
can be displayed on one or two screens on
the V928i’s eight-character display.
Since Safety radar technology is
relatively new, and the number of
transmitters in operation is not yet
widespread, you will not receive Safety
signals on a daily basis. Do not be surprised
if you encounter emergency vehicles, road
hazards and railroad crossings that are
unequipped with these transmitters. As
Safety transmitters become more prevalent
(the number of operating transmitters
is growing every day), these Safety radar
signals will become more common.
SWS Text Messages
Highway Construction or Maintenance
1 Work Zone Ahead
2 Road Closed Ahead/Follow Detour
3 Bridge Closed Ahead/Follow Detour
4 Highway Work Crews Ahead
5 Utility Work Crews Ahead
6 All Traffic Follow Detour Ahead
7 All Trucks Follow Detour Ahead
8 All Traffic Exit Ahead
9 Right Lane Closed Ahead
10 Center Lane Closed Ahead
11 Left Lane Closed Ahead
12 For future use
Highway Hazard Zone Advisory
13 Stationary Police Vehicle Ahead
14 Train Approaching/At Crossing
15 Low Overpass Ahead
16 Drawbridge Up
17 Observe Drawbridge Weight Limit
18 Rock Slide Area Ahead
19 School Zone Ahead
20 Road Narrows Ahead
21 Sharp Curve Ahead
22 Pedestrian Crossing Ahead
23 Deer/Moose Crossing
24 Blind/Deaf Child Area
25 Steep Grade Ahead/Truck Use Low Gear
26 Accident Ahead
27 Poor Road Surface Ahead
28 School Bus Loading/Unloading
29 No Passing Zone
30 Dangerous Intersection Ahead
31 Stationary Emergency Vehicle Ahead
32 For future use
Weather Related Hazards
33 High Wind Ahead
34 Severe Weather Ahead
35 Heavy Fog Ahead
36 High Water/Flooding Ahead
37 Ice On Bridge Ahead
38 Ice On Road Ahead
39 Blowing Dust Ahead
40 Blowing Sand Ahead
41 Blinding Snow Whiteout Ahead
42 For future use
Travel Information/Convenience
43 Rest Area Ahead
44 Rest Area With Service Ahead
45 24 Hour Fuel Service Ahead
46 Inspection Station Open
47 Inspection Station Closed
48 Reduced Speed Area Ahead
49 Speed Limit Enforced
50 Hazardous Materials Exit Ahead
51 Congestion Ahead/Expect Delay
52 Expect 10 Minute Delay
53 Expect 20 Minute Delay
54 Expect 30 Minute Delay
55 Expect 1 Hour Delay
56 Traffic Alert/Tune AM Radio
57 Pay Toll Ahead
58 Trucks Exit Right
59 Trucks Exit Left
60 For future use
Fast/Slow Moving Vehicles
61 Emergency Vehicle In Transit
62 Police In Pursuit
63 Oversize Vehicle In Transit
64 Slow Moving Vehicle

22 23
Troubleshooting
Problem
The V928i beeps briefly at the same
location every day, but no radar
source is in sight.
The V928i does not seem sensitive
to radar or laser.
The V928i did not alert when a
police car was in view.
The V928i did not provide a Safety
signal while within range of an
emergency vehicle.
The V928i’s display is not working.
The V928i’s audible alerts are less
loud after the first few alerts.
The V928i bounces or sags on
windshield.
The V928i’s power-on sequence
reoccurs while you are driving.
Solution
• An X or K-band motion sensor or intrusion alarm is
located within range of your route. With time, you will learn
predictable patterns of these signals.
• Make sure that windshield wipers do not block your V928i’s
radar antenna and that the laser lens is not behind tinted
areas.
• Determine if your vehicle has an Instaclear®, ElectriClear®
or solar reflective windshield which may deflect radar or laser
signals.
• Your V928i may be in City Mode.
• VASCAR (Visual Average Speed Computer and Recorder) a
stopwatch method of speed detection, may be in use.
• Officer may not have radar or laser unit turned on.
• Safety transmitters may not be commonly used in your area.
• Press the BRT button to deactivate Dark Mode.
• The V928i is in AutoMute Mode. See page 8 for details.
• The V928i is not making contact with the windshield
to provide stability. While holding down the V928i’s
QuickMount button, slide the V928i toward the windshield so
that the back top edge makes firm contact.
• A loose power connection or dirty lighter socket can cause
the V928i to be briefly disconnected.
Problem
Your 14-year old son has changed
all 6 of the Programming options.
The V928i will not turn on.
The V928i feels very warm.
Solution
• You can return all of the programming options to the
factory defaults by holding down the CITY and BRT buttons
while you turn the V928i on.
• Check that the power is ON.
• Check that vehicle ignition is ON.
• Check that vehicle lighter socket is functional.
• Try the V928i in another vehicle.
• It is normal for the V928i to feel warm.
Explanation of Displays
HD Sensitivity control is in Highway mode, display is in Dark mode (page 9)
CD Sensitivity control is in City mode, display is in Dark mode (page 9)
No display The V928i is in the Dark mode (page 9)
PilotHWY One of the many programming messages (pages 11-14)
WorkZone One of the many Safety Radar messages (pages 20-21)
Caution The V928i has detected a Safety Radar Signal, but the signal isn’t yet strong
enough to decode the specific safety message (page 20-21)
Self Cal The V928i is running a self-calibration test
Service The V928i has failed the calibration test. Contact Beltronics for repair
Required

24 25
Service
Service Procedure
If your V928i ever needs service, please
follow these simple steps:
1 Check the troubleshooting section of
this manual. It may have a solution to your
problem.
2 Call us at 1-800-341-2288. We may be
able to solve your problem over the phone.
If the problem requires that you send your
V928i to the factory for repair, we will
provide you with a Service Order Number,
which must be included on the outside of
your shipping box.
Enclose the following information with
your V928i:
• Your Service Order Number
• Your name and return address
• Your daytime telephone number
• A description of the problem you are
experiencing
• Copy of original purchase receipt
Beltronics Extended Service Plan
Beltronics offers an optional extended
service plan. Call Beltronics for details at
1-800-341-2288
Out Of Warranty Repairs
For out of warranty repairs, include
prepayment in the amount you were
quoted by the Beltronics Customer Service
Representative. If the detector has been
damaged, abused or modified, the repair
cost will be calculated on a parts and labor
basis. If it exceeds the basic repair charge,
you will be contacted with a quotation.
If the additional payment is not received
within 30 days (or if you notify us that you
choose not to have your V928i repaired
at the price quoted), your V928i will be
returned, without repair. Payment can be
made by check, money order, or credit card.
Ship your V928i and power cord to:
BELTRONICS
Customer Service Department
Service Order Number ______________
5442 West Chester Road
West Chester OH 45069
For your own protection, we recommend
that you ship your V928i postpaid and
insured. Insist on a proof of delivery, and
keep the receipt until the return of your
V928i.
Warranty and Accessories
BELTRONICS One Year Limited Warranty
What this warranty covers:
BELTRONICS warrants your Product
against all defects in materials and
workmanship.
For how long: One (1) year from the date
of the original purchase.
What we will do: BELTRONICS, at our
discretion, will either repair or replace your
Product free of charge.
What we will not do: BELTRONICS will
not pay shipping charges that you incur for
sending your product to us.
What you must do to maintain this
warranty: Show original proof of purchase
from an authorized BELTRONICS dealer.
Warranty Exclusions: Warranty does not
apply to your product under any of the
following conditions: 1. The serial number
has been removed or modified. 2. Your
product has been subjected to misuse or
damage (including water damage, physical
abuse, and/or improper installation). 3. Your
product has been modified in any way. 4.
Your receipt or proof-of-purchase is from a
non-authorized dealer or internet auction
site including E-bay, U-bid, or other non-
authorized resellers.
To obtain service: 1. Contact
BELTRONICS (1-800-341-2288) to obtain a
Return Authorization number. 2. Properly
pack your product and include: your
name, complete return address, written
description of the problem with your
product, daytime telephone number, and
a copy of the original purchase receipt. 3.
Label the outside of the package clearly
with your Return Authorization number.
Ship the product pre-paid (insured, for your
protection) to: Beltronics Inc, 5442 West
Chester Rd., West Chester, OH 45069.
LIMITATION OF WARRANTY: EXCEPT AS
EXPRESSLY PROVIDED HEREIN, YOU ARE
ACQUIRING THE PRODUCT “AS
IS” AND “WHERE IS,” WITHOUT
REPRESENTATION OR WARRANTY.
BELTRONICS SPECIFICALLY DISCLAIMS
ANY REPRESENTATION OR WARRANTY
INCLUDING, BUT NOT LIMITED TO
THOSE CONCERNING THE MERCHANT-
ABILITY AND SUITABILITY OF THE
PRODUCT FOR A PARTICULAR PURPOSE.
BELTRONICS SHALL NOT BE LIABLE
FOR CONSEQUENTIAL, SPECIAL OR
INCIDENTAL DAMAGES INCLUDING,
WITHOUT LIMITATION, DAMAGES
ARISING OUT OF THE USE, MISUSE OR
MOUNTING OF THE PRODUCT.
The above limitations or exclusions shall be
limited to the extent they violate the laws
of any particular state. BELTRONICS is not
responsible for products lost in shipment
between the owner and our service center.
Other legal rights: This Warranty gives
you specific rights. You may have other
legal rights, which vary, from state to state.
Features, specifications and prices are
subject to change without notice.
U LT I M AT E R A D A R / L A S E R / S A F E T Y D E T E C T O R
