Victory 4x4 VRKACM Configuration guide

ROOF RACK
ACCESSORY MOUNT
Thank you for purchasing from Victory 4x4! Checkout our website, victory4x4.com for other great o-road
products. Be sure to rate and review our product online. If you have any questions or are missing parts, please
don’t hesitate to call us at 269-459-8447!
INSTALL INSTRUCTIONS
Please read the mounting instructions below carefully before attempting to install.
Be sure to check out the install video on the product page, if available.

INCLUDED HARDWARE
4x
1/4"-20 X 3/8"
Button Head
4x 1/4"-20
T-Nut

INCLUDED PARTS
1x

1Start by sliding 2 t-nuts into each channel in the top of the cross bars that
will be used for the installation. Then, place the accessory mount where
you would like it and move the t-nuts so that they are under the slots in
the panel. Finally, bolt it into place.
INSTALLATION
The accessory mount is made to be able to bolt on in many dierent
positions. Depending on what gear you plan to mount on it, you may need
to rotate the panel or even slide the crossbars forward or backward in their
slots.

TRACTION BOARD
MOUNTING
To mount a traction board, you need a TRACBO-BP and 2 accessory
mounts. Bolt the traction board to the accessory mount through any
of the 3 large slots on each side. Do this using the carriage bolts on the
bottom of the accessory mounts, and the spacers and wing nuts on top of
the traction board. It may be easiest to loosely bolt the traction boards to
the accessory mounts and then line them up with the rack to space them
correctly.

ROTOPAX MOUNTING
To mount a Rotopax, you will need a Rotopax mount that has a detachable
mounting plate, or no mounting plate at all. Then, you simply use the
hardware that comes with the mount to bolt it into 2 of the slots that
make the cross in the middle of the accessory mount.
