Bematech PDX3000 User manual

i
Serial & USB Interface Customer Displays
2 by 20 character display
USER MANUAL
Oct 2018
PDX3 / LDX9 / LTX9 / LDX1 Series

ii
NOTICE
The manufacturer of the POS pole display makes no representations or warranties,
either expressed or implied, by or with respect to anything in this manual, and shall
not be liable for any implied warranties of fitness for a particular purpose or for any
indirect, special or consequential damages. Information in this document is subject to
change without notice and does not represent a commitment on the part of the
manufacturer.
FCC NOTICE
This equipment generates, uses, and can radiate radio frequency energy and if not
installed and used in accordance with this manual, may cause interference to radio
communications. It has been tested and found to comply with the limits for a Class A
digital device pursuant to Subpart J of Part 15 of FCC Rules, which are designed to
provide reasonable protection against interference when operated in a commercial
environment. Operation of this equipment in a residential area is likely to cause
interference in which case the user at his own expense will be required to take
whatever measures may be required to correct the interference.
LOGIC CONTROLS, INC.
A Bematech Company
999 S. Oyster Bay Road
Building #104
Bethpage, NY11714
TEL: [phone]
FAX: [phone]
www.bematechus.com

iii
Table of Contents
1FEATURES .........................................................................................................1
2CARTON CONTENTS.........................................................................................2
3HARDWARE INSTALLATION.............................................................................3
3.1 STEPS FOR HARDWARE INSTALLATION.......................................................................3
3.1.1 Serial interface displays...........................................................................................................3
3.1.2 USB interface displays.............................................................................................................3
3.2 INTERFACE SPECIFICATION .........................................................................................4
4USB DRIVER INSTALLATION............................................................................6
4.1 WINDOWS XP, WINDOWS 7AND WINDOWS 8 ..................................................6
4.2 MAC OS X10.6.6, 10.6.6 X64, 10.5.8 INTEL, 10.5.8 PPC.......................................9
4.3 LINUX KERNEL 2.6.XX........................................................................................10
5COMMAND SETS AND CONFIGURATION......................................................12
5.1 DOWNLOAD COMMAND SETS..........................................................................12
5.2 SERIAL PORT CONFIGURATION .................................................................................15
5.3 SELECT COMMAND SET.....................................................................................16
6FUNCTIONAL TEST..........................................................................................17
6.1 COM (VIRTUAL)PORT INTERFACE............................................................................17
6.2 DEVICE NAME INTERFACE ........................................................................................17
7OPOS DRIVER INSTALLATION .......................................................................18
8COMMAND SETS DESCRIPTION....................................................................19
8.1 LCI GROUP COMMAND SETS....................................................................................19
8.1.1 Logic Controls (LCI) Command Set ......................................................................................19
8.1.2 Aedex Command Set...............................................................................................................23
8.1.3 Noritake Command Set ..........................................................................................................24
8.1.4 LCI3400 Command Set ..........................................................................................................26
8.1.5 UTC1100(SD) Command Set.................................................................................................28
8.1.6 UTC1100(EN) Command Set.................................................................................................30
8.1.7 UTC220XLT Command Set....................................................................................................32
8.1.8 Epson110-D202 Command Set ..............................................................................................34
8.2 EMAX COMMAND SET...............................................................................................37
8.3 FIRICH COMMAND SET..............................................................................................38
8.4 IEE COMMAND SET ..................................................................................................42
8.5 PTC7220 COMMAND SET.........................................................................................45
9CHARACTER CODE TABLES..........................................................................49
10 GENERAL SPECIFICATIONS...........................................................................58

1
1 FEATURES
The PDX3000/LDX9000/LTX9000/LDX1000 family of universal command customer
displays offers a wide range of high quality features and models to choice from. Listed below
are the features incorporated into each customer display. Not all features are available in all
models. The model identification chart will assist you in selecting the model best suited to the
application needs.
The PDX3000/LDX9000/LTX9000/LDX1000 family line displays of serial port or USB port
interfaces has been pre-assembled to make the installation as simple as possible.
Two line display with twenty 5/9 mm high characters each line
Bright blue-green fluorescent display
Available as pole displays (PDX3000/LDX9000/LDX1000) and table-top displays
(LTX9000)
Pre-downloadable or Pre-selectable command sets for emulating current and future
customer displays
Supports wide variety of languages with multiple fonts, including English, Spanish,
German, French, and Italian, …
Programmable power-up default setting for international symbols and font code
selection
OPOS/JPOS compatible
Better visibility due to optically matched anti-scratch lens and wider character pitch
Long life and trouble free operation
Adjustable viewing angles
Available with 120VAC / 220VAC power adapters
Available in beige or dark gray
Port powered or self-powered USB interface
Direct RS232C, or RS232 pass-thru interface
Programmable RS232C baud rate, supporting high speed up to 19,200 baud rate
User definable character
Automatic standard or smart message scrolling on top or bottom line
Real time clock display
One time message scrolling

2
2 CARTON CONTENTS
PDX3000
LDX9000
LTX9000
LDX1000
1
PDX3 pole display
LDX9 pole display
LTX9 table display
LDX1 pole display
2
USB/DB9 cable with MiniDIN10
interconnector detachable from main cable
USB/DB9 cable,
detachable
USB/DB9 cable
3
Power adapter 7.5VAC/DC
Power adapter 5VDC
4
Metal base plate with mounting hardware
N/A
Metal base plate with
mounting hardware
5
Quick Installation Guide

3
3 HARDWARE INSTALLATION
The PDX3000/LDX9000/LTX9000/LDX1000 family of universal line displays has been pre-
assembled to make the installation as simple as possible. Please follow steps below for
models of different interfaces.
3.1 Steps For Hardware Installation
3.1.1 Serial interface displays
Mount the pole display to the metal base plate using the mounting hardware provided.
The pole display can be used in a freestanding mode or attached to the counter using
the remaining mounting hardware.
Connect the DB9F connector to the computer’s serial port (for example, COM1 or
COM2) if serial interface model is used.
For serial pass-through model, connect the DB25M connector to the peripheral device
and turn on power of the peripheral device.
Connect the female power jack of the power adapter to the male power jack of the
interface cable.
Plug the power adapter into a 120VAC outlet.
A start up text message will be present for a short time to identify the selected
command set and selected baud rate. When this message disappears the cursor will be
displayed at the left-most digit of the top row.
3.1.2 USB interface displays
Mount the pole display to the metal base plate using the mounting hardware provided.
The pole display can be used in a freestanding mode or attached to the counter using
the remaining mounting hardware.
Install USB driver following instructions on "USB DRIVER INSTALLATION"
section.
Plug the USB cable from the pole display into the computer’s USB port.
For double sided USB pole displays, connect the female power jack of the power
adapter to the male power jack of the interface cable and plug the power adapter into a
120VAC outlet.
A start up text message will be present for a short time to identify the selected
command set. The test message will NOT be present until USB driver is installed
correctly. When this message disappears, the cursor will be displayed at the left-most
digit of the top row.

4
3.2 Interface Specification
There are several connection interfaces for the PDX3000/LDX9000/LTX9000/LDX1000
family of universal displays.
USB Interface Connector
All USB pole displays will have standard USB type-A connectors. It is connected to
the USB port of the computer.
1: V+
2: D-
3: D+
4: Ground
Serial Interface Connector
The pin out configuration for the standard serial pole display is a DB9F connector. It
plugs directly into the serial port of the computer.
1: DCD (tied to pins 4&6)
2: NC
3: TXD from PC
4: DTR (tied to pins 1&6)
5: Ground
6: DSR (tied to pins 1&4)
7: RTS (tied to pin 8)
8: CTS (tied to pin 7)
9: +5 VDC
Serial pass-through Interface Connectors (LDX9000 & PDX3000 only)
For pass-through models, the display cable comes with two connectors. The DB9F is to be
connected to the computer while the DB25M is for connection to the peripheral.
To computer:
1: DCD (tied to pins 4&6)
2: TXD to PC
3: RXD from PC
4: DTR (tied to pins 1&6)
5: Ground
6: DSR (tied to pins 1&4)
7: RTS (tied to pin 8)
8: CTS (tied to pin 7)
9: +5 VDC
DB9F (to computer)
DB9F (to computer)

5
To peripheral:
1: NC
2: TXD to peripheral
3: RXD from peripheral
4: RTS
5: CTS (tied to pin 20)
6: NC
7: Ground
8: NC
9-19: NC
20: DTR (tied to pin 5)
21-25: NC
DB25M (to peripheral)

6
4 USB DRIVER INSTALLATION
4.1 WINDOWS 7 and WINDOWS 8 and WINDOWS 10
The USB drivers are available on our web site at www.logiccontrols.com. Please download
and unzip the driver files before installation. There are two types of driver interface available.
If the POS software is only able to access COM port for the pole display, use the virtual
COM port interface. After the driver is installed, the USB interface will be assigned a COM
port name so that the POS software will be able to communicate with the USB display as a
COM port. Note that the operating system will assign the display a different COM port
number if the display is plugged into a different USB port. Another driver interface use a
specific device name (\\.\LCPD3\, \\.\LCLD9\, or \\.\LCLD1\) to access the pole display
directly.
Install this driver if you are using OPOS or the POS software was tailored to use this device
name.
1. DO NOT plug the device in USB port
2. Run “install.bat” batch program in this driver package:
3. Plug the device in USB port and wait for the hardware wizard message box to
display:

7
4. Click <Next> button to continue installation automatically. When finished, click
<Finish> button to end installation (this can delay some seconds):
5. Invoke Device Manager to check COM port number or the device driver's
name. The driver is installed under "Ports (COM & LPT)":
