TASCHENRADIO
POCKET RADIO
Operating instructions
ŽEPNI RADIO
Navodila za uporabo
KH 224
CV_KH224_AR2513_LB4C.qxd 18.01.2008 13:34 Uhr Seite 2

CV_KH224_AR2513_LB4C.qxd 18.01.2008 13:34 Uhr Seite 3

KH 224
q
w
e
t
r
i
u
y
o
a
s
A B C
DE
CV_KH224_AR2513_LB4C.qxd 18.01.2008 13:34 Uhr Seite 4

- 1 -
INDEX PAGE
1. Intended purpose 2
2. Technical data 2
3. Package contents 3
4. Safety instructions 3
5. Operating elements 5
6. Initial operation 6
7. Operation 7
8. Cleaning and maintenance 9
9. Disposal 9
10. Importer 10
11. Important warranty notice 10
Read these operating instructions carefully before using the device for the
first time and preserve this manual for later reference. Pass this booklet on to
whoever might acquire the device at a future date.
IB_KH224_AR2513_LB4C 18.01.2008 13:21 Uhr Seite 1

POCKET RADIO KH 224
1. Intended use
The pocket radio is designed to receive FM/AM radio transmissions
and for listening to radio programmes.
The radio is not intended for use in commercial or industrial areas.
No warranty claims will be granted for damage resulting from improper
use!
2. Technical data
This device has been tested and approved in accordance with the
basic requirements and other relevent regulations of the EMV direc-
tive 2004/108/EC.
Battery operation: 2 x 1,5 V, Type AA/LR6/Mignon
(not supplied)
Frequency ranges:
AM (MW) : 540– 1600 KHz
FM (VHF) : 88 – 108 MHz
Headphones output: 3,5 mm Mono jackplug socket
Operating temperature range: +5° -+40°C
Humidity: 5 -90% (no condensation)
Dimensions (L x W x H): 118 x 70 x 30 mm
Weight: 130 g approx.
- 2 -
IB_KH224_AR2513_LB4C 18.01.2008 13:21 Uhr Seite 2

3. Items supplied
Pocket radio
Headphones
This operating manual
4. Safety Instructions
• This device is not intended for use by persons (including children)
with restricted physical, sensorial or mental abilities or those who
have a lack of experience and/or knowledge unless, of course, for
their own safety they are supervised by a responsible person or
they receive instructions from that person on how to use the device.
• Children should be supervised in order to make sure that they do
not play with the device.
TTooaavvooiiddlliiffee--tthhrreeaatteenniinnggeelleeccttrriiccsshhoocckkss::
• Devices that do not function properly or that are damaged should
be returned to customer service for repair or exchange as soon as
possible.
• Only use the device in dry rooms.
NEVER submerse the device in water. Wipe it only with
a slightly damp cloth.
• Make sure that liquids and/or objects are never able to enter into
the device.
- 3 -
IB_KH224_AR2513_LB4C 18.01.2008 13:21 Uhr Seite 3

• Do not place water-filled receptacles (e.g. flower vases) on the device.
• You may not open the casing or repair the device yourself. Should
you do so, the safety of the device may be compromised and the
warranty becomes void. Repairs are to be carried out exclusively in
a specialist firm or in a service centre.
RRiisskkooffeexxpplloossiioonn!!
Do not throw batteries into a fire. Do not recharge the batteries.
TTooaavvooiiddtthheerriisskkssooffffiirreeoorriinnjjuurryy::
• Do not place candles or other open fire sources on the device.
• Do not use the device in the vicinity of hot surfaces.
• Do not keep the device in places that are exposed to direct sunlight.
If you do, it may overheat and become irreparably damaged.
• Place the device in a location with adequate ventilation to prevent
heat build up.
• Never cover the ventilation openings!
• Avoid any additional heat build up, e.g. direct sunlight, heaters,
other devices, etc.
• Keep children away from the connecting cable and the device. Children
frequently underestimate the danger from electrical appliances.
• Make sure to find a safe place for the device.
• Do not operate the device if it has sustained a fall or is damaged.
Arrange for the device to be checked and/or repaired by qualified
technicians.
• Keep batteries away from children. Children can put batteries into
their mouths and swallow them.
- 4 -
IB_KH224_AR2513_LB4C 18.01.2008 13:21 Uhr Seite 4

5. Operating elements
Left side
qTelescopic antenna
wOn/Off switch with volume control
eHeadphone output
Top side
rFrequency dial
tOn/Off indicator
yTUNING indicator
uCarrying strap
iLoudspeaker
Right side
oFrequency adjustment wheel
aBand selection switch
Rear side
sBattery compartment
Headphones
E
D
C
B
A
- 5 -
IB_KH224_AR2513_LB4C 18.01.2008 13:21 Uhr Seite 5

6. Activation
Preparing for use
• Remove the radio and accessories from the packaging.
• Remove all transport restraints and adhesive tape/films.
Important!
Do not permit small children to play with plastic packaging. There
is a risk of suffocation!
Inserting the batteries
For operation you need two 1,5 V batteries type Mignon AA/LR6
(not supplied).
1. Open the battery compartment son the rear side of the radio.
2.Place the batteries into the battery compartment smaking sure
that you observe the correct polarity according to the illustration.
3.Carefully close the battery compartment lid until it clicks into place.
Interaction with batteries
Leaking batteries can cause damage to the device.
• If you do not intend to use the device for an extended period,
remove the batteries.
• Always change all batteries at the same time and always use
batteries of the same type.
• Should the batteries leak, wear protective gloves and clean the
battery compartment with a dry cloth.
• Do not expose the batteries to excessive heat such as sunlight,
fire or similar.
- 6 -
IB_KH224_AR2513_LB4C 18.01.2008 13:21 Uhr Seite 6

Connecting Headphones
You can connect stereo heaphones to the pocket radio with a 3.5 mm
jack plug. The headphones socket is located on the left side of the radio.
When you have connected the headphones, the loudspeaker is dis-
connected and you will only hear sound through the headphones.
• Insert the headphones jackplug into the headphones output e.
Warning:
Listening to music with headphones for long periods and at
high volume levels can lead to hearing damage!
7. Operation
Switching On and Off
• To switch the radio on turn the On/Off switch with volume control
wupwards until you feel that a slight resistance has been overcome.
A green bar will become visible in the On/Off indicator t.
• To switch the radio off turn the On/Off switch with volume control
wdownwards until you feel a slight resistance has been overcome.
The green bar in the On/Off indicator tis no longer visible.
Note:
In order to switch the device off completely the batteries have to be
removed from the device.
- 7 -
IB_KH224_AR2513_LB4C 18.01.2008 13:21 Uhr Seite 7

To control the Volume
• Turn the On/Off switch with volume control wupwards to increase
the volume.
• Turn the On/Off switch with volume control wdownwards to
reduce the volume.
Selecting a waveband
• Place the band selection switch ain the AM position for medium
wave reception (MW) and/or FM for very high frequency reception
(VHF).
• Lift the telescopic antenna qup and pull it out.
Important!
The telescopic antenna qdoes not rotate!
Adjusting the frequency
• By using the frequency setting wheel oyou can set the desired
frequency to the AM (kHz) and/or FM (MHz) scale r.
• Adjust the pocket radio for optimal reception.
• When a transmission with full signal strength is received the
TUNING yindicator lights up.
Notice:
To improve the reception of radio stations in the FM frequency range
turn the radio and the telescopic antenna qslowly in various
directions. When you have found a good reception position for
the set radio station leave the radio and telescopic antenna in this
position. For the reception of AM transmissions, an antenna is built
into the device. For improved reception, alter the position of the de-
vice in radio mode.
- 8 -
IB_KH224_AR2513_LB4C 18.01.2008 13:21 Uhr Seite 8

8. Cleaning and maintenance
Important!
Make sure that no liquids get into the device.
• Only clean the device with a lightly moistened cloth.
• Do not use detergents or solvents. They can damage the plastic
surfaces.
9. Disposal
Disposing of the appliance
Do not dispose of the appliance in your normal domestic waste.
This product is subject to the European directive 2002/96/EC.
Dispose of the device through an approved disposal centre or at
your community waste facility. Observe the currently applica-
ble regulations. In case of doubt, please contact your waste
disposal centre.
Disposing of batteries!
Do not dispose of the batteries with household waste. Every consumer
is legally obliged to dispose of batteries at a collection site of his com-
munity/city district or at a retail store. The purpose of this obligation is
to ensure that batteries are disposed of in a non-polluting manner. Only
dispose of batteries when they are fully discharged.
Disposal of packaging
Dispose of the packaging materials in an environmentally
responsible manner.
- 9 -
IB_KH224_AR2513_LB4C 18.01.2008 13:21 Uhr Seite 9

10. Importer
KOMPERNASS GMBH
BURGSTRASSE 21
D-44867 BOCHUM
www.kompernass.com
11. Important warranty notice
The warranty for this appliance is for 3 years from the date of purcha-
se. The appliance has been manu-factured with care and meticulously
examined before delivery. Please retain your receipt as proof of pur-
chase. In the case of a warranty claim, please make contact by tele-
phone with our service department. Only in this way can a post-free
despatch for your goods be assured.
The warranty covers only claims for material and maufacturing defects,
not for wearing parts or for damage to fragile components. This pro-
duct is for private use only and is not intended for commercial use.
The warranty is void in the case of abusive and improper handling, use
of force and internal tampering not carried out by our authorized servi-
ce branch. Your statutory rights are not restricted in any way by this
warranty.
- 10 -
IB_KH224_AR2513_LB4C 18.01.2008 13:21 Uhr Seite 10

DES Ltd
Units 14-15
Bilston Industrial Estate
Oxford Street
Bilston
WV14 7EG
Tel.: [phone]
Fax: [phone]
e-mail: [e-mail]
Irish Connection
Harbour view
Howth
Co. Dublin
Tel: 00353 (0) 87 99 62 077
Fax: [phone]
e-mail: [e-mail]
- 11 -
IB_KH224_AR2513_LB4C 18.01.2008 13:21 Uhr Seite 11

- 12 -
IB_KH224_AR2513_LB4C 18.01.2008 13:21 Uhr Seite 12

KAZALO STRAN
1. Namen uporabe 14
2. Tehnični podatki 14
3. Vsebina kompleta 15
4. Navodila za varno uporabo izdelka 15
5. Upravljalni elementi 17
6. Začetek uporabe 18
7. Uporaba 19
8. Čiščenje in vzdrževanje 21
9. Odstranitev neuporabnega izdelka 22
10. Uvoznik 22
11. Pomembna obvestila glede garancije 23
- 13 -
Pred prvo uporabo ta navodila skrbno preberite in jih shranite za poznejšo
uporabo. Ob predaji naprave tretji osebi zraven priložite tudi navodila za
uporabo.
IB_KH224_AR2513_LB4C 18.01.2008 13:21 Uhr Seite 13

ŽEPNI RADIJSKI SPREJEMNIK
KH 224
1. Namen uporabe
Žepni radijski sprejemnik je namenjen za poslušanje ultrakratkovalovnih
(UKV oz. FM) in srednjevalovnih (SV oz. AM) radijskih postaj ter za
poslušanje radijskih programov.
Žepni radijski sprejemnik ni predviden za uporabo v poslovnih oz.
industrijskih območjih.
Za škodo, ki nastane zaradi nepredvidene uporabe naprave, ne prev-
zamemo nobene odgovornosti/jamstva!
2. Tehnični podatki
Ta izdelek je bil preizkušen in ima potrdilo o izpolnjevanju temeljnih
zahtev in drugih ustreznih predpisov direktive o elektromagnetni
združljivosti 2004/108/ES.
Baterijsko napajanje: 2 x 1,5 V, vrste AA/LR6/Mignon
(eivät kuulu toimitukseen)
Frekvenčna območja:
SV (AM) : 540–1600 kHz
UKV (FM): 88–108 MHz
Izhod za slušalke: 3,5 mm mono vtičnica (klinken)
Delovna temperatura: +5°- +40 °C
Vlaga: 5 - 90% (brez kondenzacije)
Mere (D x Š x V): 118 x 70 x 30 mm
Teža: pribl. 130 g
- 14 -
IB_KH224_AR2513_LB4C 18.01.2008 13:21 Uhr Seite 14

3. Vsebina kompleta
Žepni radijski sprejemnik
Slušalke
Ta navodila za uporabo
4. Varnostni napotki
• Ta izdelek ni namenjen za to, da bi ga uporabljale osebe (tudi otroci
ne) z zmanjšanimi fizičnimi, zaznavnimi ali duševnimi sposobnostmi
ali s pomanjkljivimi izkušnjami in/ali s pomanjkljivim znanjem, razen
v primeru, da jih nadzoruje oseba, ki odgovarja za njihovo varnost
oz. jih pouči, kako se izdelek uporablja.
• Otroke je potrebno nadzorovati, da se z napravo ne bi igrali.
DDaasseeiizzooggnneetteessmmrrttnniinneevvaarrnnoossttiizzaarraaddiieelleekkttrriiččnneeggaauuddaarraa::
• Aparate, ki ne delujejo brezhibno ali se poškodujejo, dajte takoj
popraviti na servisu ali jih zamenjajte z novimi.
• Napravo uporabljajte samo v suhih prostorih.
Naprave ne potapljajte v vodo. Obrišite jo le z rahlo vlažno
krpo.
• Poskrbite, da v notranjost aparata nikoli ne bodo stekle tekočine ali
zašli predmeti.
- 15 -
IB_KH224_AR2513_LB4C 18.01.2008 13:21 Uhr Seite 15

• Na napravo ne postavljajte posod napolnjenih z vodo (npr. vaz).
• Ohišja naprave ne smete odpirati ali popravljati. V tem primeru var-
nost ni več zagotovljena in jamstvo preneha veljati. Popravila sme
izvajati izključno strokovno podjetje oz. servisna služba.
NNeevvaarrnnoosstteekksspplloozziijjee!!
Baterij ne mečite v ogenj. Baterij ne polnite.
DDaasseeiizzooggnneetteeppoožžaarruuiinnppoošškkooddbbaamm::
• Na napravo ne postavljajte sveč ali drugih virov odprtega ognja.
• Naprave ne uporabljajte v bližini vročih površin.
• Aparata ne postavljajte na mesta, kamor neposredno sije sonce.
Drugače se lahko pregreje ter nepopravljivo poškoduje.
• Napravo postavite tako, da ne more priti do kopičenja toplote, to-
rej prosto in z dobrim zračenjem.
• Prezračevalnih odprtin nikoli ne pokrivajte!
• Preprečujte dodatno dovajanje toplote, npr. zaradi direktnega so-
nčnega sevanja, radiatorjev in drugih naprav!
• Otroci naj se ne približujejo priključni napeljavi ali napravi. Otroci
pogosto podcenjujejo nevarnost električnih naprav.
• Poskrbite, da bo izdelek postavljen stabilno.
• Če bi naprava padla dol ali je poškodovana, je ne smete več upo-
rabljati. Napravo naj preveri strokovno osebje in jo po potrebi po-
pravi.
• Baterije ne smejo zaiti v otroške roke. Otroci bi baterije lahko dali
v usta in jih požrli.
- 16 -
IB_KH224_AR2513_LB4C 18.01.2008 13:21 Uhr Seite 16
