Benchmark USA THE ZEPHYR User manual

OWNERS MANUAL
MODEL:
T
TT
T
T
TT
TH
HH
H
H
HH
HE
EE
E
E
EE
E Z
ZZ
Z
Z
ZZ
ZE
EE
E
E
EE
EP
PP
P
P
PP
PH
HH
H
H
HH
HY
YY
Y
Y
YY
YR
RR
R
R
RR
R
Professional Cotton Candy Machine
PART NUMBER:
8
88
8
8
88
81
11
1
1
11
10
00
0
0
00
01
11
1
1
11
11
11
1
1
11
1
115 volts, 60 hz
WARNING: Handling the cord on this product may expose you to lead, a chemical known to the State Of California to
cause cancer and birth defects or other reproductive harm. WASH HANDS AFTER HANDLING.
Electrical ground is required on this appliance.
1. Do not modify the power supply cord plug. If it does not fit the outlet, have a proper outlet installed by a
qualified electrician.
2. Do not use an extension cord with this appliance.
3. Check with a qualified electrician if you are in doubt as to whether the appliance is properly grounded.
SAFETY INSTRUCTIONS
1. Plug electrical cord into a certified electrical outlet with a corresponding voltage rating as listed on the
machine model labels.
2. Always unplug the electric cord when appliance is not in use and before cleaning, adjusting or maintaining
this steamer. Do not operate with a damaged cord or plug or after the machine malfunctions, has been
dropped or damaged. Use authorized service for examination, electrical or mechanical adjustment or repair.
3 This equipment will be HOT during use and for a short time after it is turned off, BE CAREFUL. To avoid
burns, do not let bare skin touch hot surfaces. If provided, use handles when moving this appliance. Keep
combustible materials away from appliance.
4. Extreme caution is necessary when any appliance is used by or near children and whenever the appliance is
left operating and unattended.
5. This appliance is not intended for use in wet locations. Never locate appliance where it may fall into a water
container.
6. Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this may cause an
electrical shock, fire or damage to the appliance.
B
Be en nc ch hm ma ar rk k U US SA A I In nc c. . ● ● 2 25 5- -J J B Br ro oo ok kf fi ie el ld d O Oa ak ks s D Dr r. . ● ● G Gr re ee en nv vi il ll le e, , S SC C 2 29 96 60 07 7 ● ● T T: : 8 86 64 4- -3 31 12 2- -5 55 50 00 0 ● ● F F: : 8 86 64 4- -3 31 12 2- -5 55 50 05 5
WARNING ELECTRICAL SHOCK HAZARD.
FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR DEATH.

Assembly Instructions
1. Remove two bolts located on either side of extractor head. These bolts are used only for shipping and storage
purpose.
2. Locate three spring loaded mounting bolts and align with mounting brackets on bottom of bowl. Twist bowl to lock
into place on the body of the machine.
3. Attach dome to bowl with three screws provided.
Wiring Diagram
Operating Instructions
1. Plug unit into a properly grounded 120 volt power supply.
2. Be sure to keep hands and loose clothing away from the spinning head.
3. Fill spinning head with desired amount of sugar floss (1/8 cup = an average cone)
4. Turn on MOTOR switch.
5. Turn on HEAT switch.
6. Once the head heats up floss will begin to melt and create cotton candy.
7. Using a paper cone collect the cotton candy from the edges of the bowl in a circular motion.
8. Repeat steps 3-7 until the desired amount of cotton candy has been produced.
9. Turn OFF motor and heat switches when finished making cotton candy.
Cleaning
1. Make sure unit is unplugged and has had time to cool down before cleaning. The ZEPHYR COTTON CANDY
MACHINE breaks down to – body, bowl, dome, and extractor head for easy cleaning.
2. After excessive build up of sugar in the extractor head, unplug the unit. Remove the extractor head by
disconnecting it from the unit. Allow the extractor head to soak in hot water for at least 15 minutes. Let dry and
replace on the unit.
3. Remove bowl and dome and wash with soap and water. Use wash cloth to wipe clean and let dry.
4. Use a slightly damp, non-abrasive sponge or non-abrasive towel to wipe clean the outside of the unit, wipe with a
non-abrasive towel to dry. Do not use excessive water when cleaning this unit.
Page 2

Parts List
P
Pa ar rt t # # D De es sc cr ri ip pt ti io on n P Pa ar rt t # # D De es sc cr ri ip pt ti io on n
8
80 00 01 1 H He ea at ti in ng g e el le em me en nt t 8 80 01 10 0 M Mo ot to or r s sp pr ri in ng gs s a an nd d h ha ar rd dw wa ar re e
8
80 00 02 2 R Re el la ay y 8 80 01 11 1 M Mo ot to or r c ch ha as ss si is s
8
80 00 03 3 E El le ec ct tr ri ic ca al l b br ru us sh h 8 80 01 12 2 F Fu us se e 1 10 0A A / / 1 12 25 5V V
8
80 00 04 4 M Mo ot to or r 8 80 01 13 3 F Fu us se e 6 6A A / / 2 25 50 0v v
8
80 00 05 5 O On n/ /O Of ff f s sw wi it tc ch h 8 80 01 14 4 F Fu us se e s so oc ck ke et t
8
80 00 06 6 B Bo ow wl l 8 80 01 15 5 C Ch ha as ss si is s
8
80 00 07 7 D Do om me e 8 80 01 16 6 E Ex xt tr ra ac ct to or r h he ea ad d
8
80 00 08 8 B Bo ow wl l M Mo ou un nt ts s 8 80 01 17 7 E Ex xt tr ra ac ct to or r h he ea ad d l li id d
8
80 00 09 9 B Bo ow wl l M Mo ou un nt t s sp pr ri in ng gs s
T
To o O Or rd de er r P Pa ar rt ts s C Co on nt ta ac ct t: :
B
Be en nc ch hm ma ar rk k U US SA A I In nc c. . ● ● 2 25 5- -J J B Br ro oo ok kf fi ie el ld d O Oa ak ks s D Dr r. . ● ● G Gr re ee en nv vi il ll le e, , S SC C 2 29 96 60 07 7
T
T: : 8 86 64 4- -3 31 12 2- -5 55 50 00 0 ● ● F F: : 8 86 64 4- -3 31 12 2- -5 55 50 05 5 E Em ma ai il l: : p pa ar rt ts s@ @b be en nc ch hm ma ar rk ku us sa ai in nc c. .c co om m
Page 3

T
Th hr re ee e Y Ye ea ar r W Wa ar rr ra an nt ty y
THE WARRANTY:
Benchmark USA warrants the original purchaser of new food equipment manufactured by
Benchmark USA to be free from defects in material or workmanship from the date of the
original purchase for a period of three years.
WHO IS COVERED BY THIS WARRANTY:
The original purchaser who has provided proper proof of the original retail purchase and all
other requested information.
WHAT IS WARRANTIED:
The obligation of Benchmark USA under this warranty is limited to the replacement of any
parts or components that in the opinion of Benchmark USA are defective, F.O.B. the factory, or
at any other location that Benchmark USA may designate.
WHAT VOIDS THE WARRANTY:
1. Any piece of equipment that has been installed, operated or maintained inconsistently
with Benchmark USA operating instructions.
2. Any part or component that has been modified, changed or altered from its original
configuration.
3. Any electrical component that has been damaged due to submergence in any
liquid.
4. Any part or component that has been subject to abuse, misuse, neglect or
accidents.
EXTENT OF WARRANTY:
Any defective component, part or assembly returned to Benchmark USA will be replaced by
Benchmark USA. Benchmark USA will not be responsible for any expenses incurred by the
customer under the terms of this warranty, nor shall it be responsible for any damages either
consequential, special, contingent, or otherwise; or expenses or injury arising directly or
indirectly from the use of a Benchmark USA product. Any component, part or assembly
returned to Benchmark USA must be returned at the customers expense along with proof of
purchase. Benchmark USA reserves the right to determine whether the terms of this warranty
have been properly complied with. In the event that the terms are not complied with,
Benchmark USA shall be under no obligation to honor this warranty.
B
Be en nc ch hm ma ar rk k U US SA A I In nc c. . ● ● 2 25 5- -J J B Br ro oo ok kf fi ie el ld d O Oa ak ks s D Dr r. . ● ● G Gr re ee en nv vi il ll le e, , S SC C 2 29 96 60 07 7 ● ● T T: : 8 86 64 4- -3 31 12 2- -5 55 50 00 0 ● ● F F: : 8 86 64 4- -3 31 12 2- -5 55 50 05 5
