Titan Lifts ROT-4500 Instruction manual
INSTALLATION, OPERATION
& MAINTENANCE MANUAL
FOLLOW THIS MANUAL CAREFULLY TO ENSURE THE EQUIPMENT WILL
FUNCTION CORRECTLY AND PROVIDE MANY YEARS OF DEPENDABLE SERVICE.
FAILURE TO FOLLOW THESE INSTRUCTIONS AND SAFETY WARNINGS MAY
RESULT IN PERSONAL INJURY OR PROPERTY DAMAGE. KEEP THIS MANUAL IN A
SAFE DRY PLACE FOR FUTURE REFERENCE.
MODEL:
ROT-4500
4,500 LB CAPACITY AUTOMOTIVE ROTISSERIE
®
PO Box 7069 Greenwood, IN 46142
1.888.908-4826 FAX (317) 215.2770
www.titanlifts.com
TITAN MARKETING, LLC
®
To Our Valued Customers:
Thank you for purchasing a Titan Lifts®product. We hope this high quality equipment provides you with years of
dependable service.
It is unfortunate that rare situations may occur with the products you purchase from Titan Lifts®. We value your
business as well as the trust you have and need to maintain your relationship with us. Titan Lifts®carries liability
coverage that may protect our customers if a situation does occur. However, as in all accidents there must be
proof of liability for a claim to be made. Our insurance company requires the following procedures be observed in
order to consider a claim:
A. The claimant must contact the Titan Lifts®distributor immediately with the facts of the situation.
B. If any equipment is damaged, including vehicles or shop equipment, Titan Lifts®must be given the
opportunity to send an impartial representative to the site for proper assessment of the situation.
C. The Vehicle cannot be moved until either an impartial representative has reviewed the accident or clear
and precise pictures are taken that reect all the pertinent information for an impartial representative to be able
to access the information from a distance. Titan Lifts®or its representatives must approve the pictures before
anything can be moved.
D. If any potential liability is determined on behalf of Titan Lifts®, two estimates must be submitted for
damages to be reimbursed.
It is imperative that the claimant complies with these procedures, because without proper assessment of the
situation a claim will be denied.
ARBITRATION NOTICE
The installation or use of this equipment shall constitute an acknowledgement that the user agrees to resolve any
and all disputes or claims of any kind whatsoever, which relate in any way to the equipment, by way of binding
arbitration, not litigation. No suit or legal action may be led in any state or federal court. Any arbitration shall be
governed by the Federal Arbitration Act, and administered by the American Mediation Association, Indianapolis
Indiana. The maximum amount that an arbitrator may award and all damages shall not exceed the retail value of
this equipment.
WARRANTY NOTICE
This equipment must be assembled and used in the manner according to the documentation provided to be
covered by warranty.
Damaged or missing components must be reported within 72 hours of receipt to your freight carrier and to the
distributor. Claims must be led to cover cost.
If you have any questions or if we can be of any further assistance, please don’t hesitate to contact a Titan Lifts®
representative at 1-888-908-4826. Thank you for the opportunity to continue to serve your lift equipment needs.
1
DESCRIPTION
This product should be used for repairing and maintaining automobiles. The vehicle can be
lifted 49” and rotated 360°.
SPECIFICATIONS
Max Height: 49”
Min Height: 21”
Max Length: 260”
Min Length: 121”
Width: 81”
Max Length Between Support Arms: 238”
Min Length Between Support Arms: 99”
1. DO NOT exceed the rated capacity of 4,500 lb
2. Stay clear of the equipment when lifting or lowering
3. Keep the area around the equipment clear of obstacles
4. ALWAYS use the safety lock on the equipment
SAFETY PRECAUTIONS
WARNING: BEFORE OPERATING THE EQUIPMENT, MAKE SURE THAT ALL THE
HARDWARE IS SECURE AND THAT EACH UNIT HAS BEEN TESTED PROPERLY.
CAUTION: IF YOU ATTEMPT TO ROTATE AN UNBALANCED VEHICLE YOU RISK
INJURY, AN UNSAFE SITUATION, AND POSSIBLE DAMAGE TO YOUR VEHICLE.
WARNING: READ ENTIRE MANUAL AND COMPLY WITH ALL SAFETY AND
SERVICE PRECAUTIONS. DEATH, PERSONAL INJURY AND / OR PROPERTY DAMAGE MAY
OCCUR IF INSTRUCTIONS ARE NOT FOLLOWED CAREFULLY.
Prior to working with Titan ROT-4500 rotisserie, always check for any obstructions that may
interfere with the operation of the rotisserie such as: tools, air hoses, shop equipment, etc.
These are generic instructions, please keep in mind there are different ways to hook up the
same vehicle. Make sure to properly secure and balance vehicles center of gravity before
using the rotisserie unit.
NOTE: There are no set rules when hooking up a vehicle. Make sure to utilize the structural
mounting points on the vehicle.
2
INSTALLATION
TOOLS
ASSEMBLY (REFER TO PARTS LIST)
THE FOLLOWING TOOLS ARE NEEDED FOR PROPER ASSEMBLY
1. Unpack all components
2. Attach one #41 Main Connecting Rod to each #34 Main Stand using hardware #30-33 –
PLACE BOLTS THROUGH SUPPORT PLATE #49 PRIOR TO PUSHING THROUGH #34
3. Attach two #37 8” Casters to each #34 Main Stand using hardware #38-40
4. Attach one #42 3” Caster to each #41 Main Connecting Rod using hardware #43-45
5. Insert one #47 Connecting Rod into each #41 Main Connecting Rod
6. Insert one #46 Extending Rod into each #47 Connecting Rod
7. Insert the other end of each #46 Extending rod into #48 intermediate Connecting Rod
8. Attach one #25 Hydraulic Cylinder to each #34 Main Stand using hardware #7, 21-23
9. Insert one #24 Lifting Stand into each #34 Main Stand
10. Insert one #14 Rotating Stand into each #24 Lifting Stand
11. Slide one #19 Locking plate onto each #14 Rotating Stand and attach using hardware
#18, 20
12. Remove hardware #4, 7, 8 from each #1 Adjust Screw Rod
13. Insert one #16 Stand into each #14 Rotating Stand
14. Place one set of hardware #7, 4, 7 onto #1 Adjust Screw Rod before pushing #1 through
hole in #16 Stand
15. Place second set of hardware #7, 4, 7 onto #1 Adjust Screw Rod and secure using
hardware #8 – DO NOT OVERTIGHTEN
16. Attach #3 Screw Rod Stand to #16 Stand using hardware #2
17. Slide two #6 Movable Stand onto each #16 Stand
18. Loosely attach twenty two #5 Screw into each respective set screw welded nut for use
as needed
19. Re-check all hardware and test each #25 Hydraulic Cylinder prior to each use
1. Knife
2. Ratchet
3. 13mm socket/wrench
4. 17mm socket/wrench
5. 21mm socket/wrench
6. 24mm socket/wrench
7. 6mm allen wrench
8. 8mm allen wrench
9. 3” extension if using socket set
3
PARTS DIAGRAM
OPTIONAL
OPTIONAL
49
49
4
NO. DESCRIPTION QTY NO. DESCRIPTION QTY
1 Adjust Screw Rod 2 25 Hydraulic Cylinder 2
2 Screw M8*12 4 26 Circlip 4
3 Screw Rod Stand 2 27 Guide Sleeve 2
4 Bearing 4 28 Guide Spindle 2
5 Screw M10*25 22 29 Operation Handle 2
6 Movable Stand 4 30 Bolt M14*100 4
7Flat Washer Φ16 6 31 Flat Washer Φ14 4
8 Lock Nut M16 2 32 Lock Washer Φ14 4
9 Lock Nut M10 2 33 Lock Nut M14 4
10 Wedge Handle Seat 2 34 Main Stand 2
11 Handle 2 35 Set Screw 4
12 Spring 2 36 Steel Feet 4
13 Locking Pin 2 37 8” Caster 4
14 Rotating Stand 2 38 Bolt M10*20 16
15 Chain Pin 4 39 Lock Washer Φ10 16
16 Stand 2 40 Flat Washer Φ10 16
17 17 Turning Handle 2 41 Main Connecting Rod 2
18 Connecting Pin 2 42 3” Caster 2
19 Locking Plate 2 43 Bolt M8*16 8
20 R-pin 2 44 Lock Washer Φ8 8
21 Bolt M16*70 4 45 Flat Washer Φ8 8
22 Lock Washer Φ16 4 46 Extending Rod 2
23 Nut M16 4 47 Connecting Rod 2
24 Lifting Stand 2 48 Intermediate Connecting Rod 1
49 Plate 2
PARTS LIST
EQUIPMENT MODEL:
TYPE OF POWER UNIT:
DATE OF PURCHASE:
PLACE PURCHASED:
NAME:
STREET:
CITY, STATE, ZIP:
PHONE:
EMAIL:
SERIAL NUMBER:
SERIAL NUMBER:
WARRANTY REGISTRATION
OPT OUT OF PROMOTIONS
In order to utilize the warranty on this Titan Lifts product, you must register your product with us. The
simplest way to do this is to visit TITANLIFTS.COM/WARRANTIES and submit your information online. If you
prefer to send your information through the mail, please ll out the form below and send this page to us at :
Titan Lifts
PO Box 7069
Greenwood, IN 46142
In order to receive your warranty, return this card
or visit TITANLIFTS.COM/WARRANTIES within 30 days.
Products May Be
Upgraded Without Notice
Please Visit
WWW.TITANLIFTS.COM
For The Latest Version Of
This Manual
P.O. Box 7069 • Greenwood, IN 46142 • Ph. 888-908-4826 • Fx. 317-215-2770 • www.titanlifts.com
P.O. Box 7069 • Greenwood, IN 46142 • Ph. 888-908-4826 • Fx. 317-215-2770 • www.titanlifts.com
LIMITED WARRANTY
The Titan 2 Post lifts, 4 Post lifts and Bridge Jacks are backed by a standard 1-year replacement parts warranty and a 5-year
structural warranty from the date of purchase, to the original purchaser only. The 1-year replacement parts warranty covers power
units, hydraulic cylinders, and all other assembly components such as, but not limited to: turn plates, slip plates, cables, chains,
valves, switches etc. This does not cover normal wear items such as, but not limited to: rubber lifting pads and nylon slide blocks.
Titan Elite model lifts have been discontinued but still qualify under the same terms as shown above.
Titan SL-6600 Scissor Lifts and PREMIER Series 2 Post Lifts are backed by a 2-year replacement parts warranty and a 5-year
structural warranty from the date of purchase, to the original purchaser only. The 2-year replacement parts warranty covers power
units, hydraulic cylinders, and all other assembly components such as, but not limited to: valves, switches, capacitors etc. This does
not cover normal wear items such as, but not limited to: rubber lifting pads, nylon slide blocks and rubber arm pads.
Titan MRL-6000 Scissor lifts are backed by a standard 1-year replacement parts warranty and a 5-year structural warranty from the
date of purchase, to the original purchaser only. The 1-year replacement parts warranty covers power units, hydraulic cylinders, and
all other assembly components such as, but not limited to: valves, switches, capacitors etc. This does not cover normal wear items
such as but not limited to rubber lifting pads.
Titan ROT-4500 Rotisseries are backed by a standard 1-year replacement parts warranty from the date of purchase, to the original
purchaser only. The 1-year replacement parts warranty covers components such as, but not limited to: hydraulic cylinders, caster
assemblies, bearings etc. This does not cover normal wear items such as, but not limited to, mounting adapters.
Titan Standard Duty and Heavy Duty motorcycle lifts are backed by a standard 1-year replacement parts warranty from the date of
purchase, to the original purchaser only. The 1-year replacement parts warranty covers power units, hydraulic cylinders, pneumatic
cylinders, and all other assembly components such as, but not limited to: cables, caster wheels, valves, switches, wheel vises etc.
This does not cover normal wear items such as, but not limited to: rubber wheel vise pads.
Titan Light Duty motorcycle lifts are warrantied for replacement parts only to the original purchaser for a period of 90 days from the
date of purchase. This 90 day replacement parts warranty covers items such as, but not limited to: hydraulic cylinder, casters, pedal
assemblies, wheel vises etc. This does not cover normal wear items such as, but not limited to: rubber wheel vise pads.
Titan Bulldog Moto Cradle Wheel Chock is warrantied for replacement parts, only to the original purchaser, for a period of 2-years
from the date of purchase.
XL Tool by Titan Wheel Service Machines and Helper Arm Assemblies are backed by a standard 1-year replacement parts warranty
from the date of purchase, to the original purchaser only. The 1-year replacement parts warranty covers internal boards, motors,
pneumatic cylinders, and all other assembly components such as, but not limited to: cabinet, switches, valves, ttings etc. This does
not cover normal wear items such as but not limited to: rubber pads, jaw protectors, air hoses, quick nut assemblies.
Titan shop equipment products and accessories are warrantied for replacement parts only to the original purchaser for a period of
90 days from the date of purchase. This 90 day replacement parts warranty covers products such as but not limited to: EZ -Mover
Jacks, Mini Jacks, tie down products, wheel service accessories, Bulldog Moto Cradle Wheel Chock accessories, dollies, stands,
Multi-purpose Jacks, etc.
Titan TJ1T, FJ2T, and FJ3T are warrantied for replacement parts only to the original purchaser for a period of 1 year from the date of
purchase.
All non-serialized items
will require proof of purchase in the form of a sales receipt from an authorized Titan Lifts dealer showing the
date of purchase for any warranty consideration.
For all warranty considerations, Titan Marketing, LLC will supply replacement parts only during the warranty period. The original
purchaser is responsible for all shipping, handling, and any labor charges incurred. Hydraulic/Pneumatic cylinders may qualify for
exchange under warranty if reported within the rst 30 days from date of sale. After the rst 30 days from date of sale, a seal kit and
installation instructions will be sent for cylinder repairs. All defective parts must be returned to Titan for inspection and examination.
Any parts that are found to be defective will be replaced or repaired to proper working order. Other items not listed above may be
considered general wear parts and therefore, will not be covered under warranty. These warranties do not extend to defects caused
by ordinary wear, abuse, misuse, shipping damage, improper installation, voltage or lack of required maintenance. Titan Marketing,
LLC is not to be held responsible for any failure
that results from an accident, purchaser/operator abuse, neglect, or failure to operate
products in accordance with instructions provided in the owner’s manual(s) supplied. Damage caused by rain, excessive humidity,
corrosive environments or other contaminants are not covered under warranty. THESE WARRANTIES DO NOT EXTEND TO ANY
COSMETIC DEFECT NOT INTERFERING WITH EQUIPMENT FUNCTIONALITY OR ANY INCIDENTAL, INDIRECT, OR CONSEQUENTIAL
LOSS, DAMAGE, OR EXPENSE THAT MAY RESULT FROM ANY DEFECT, FAILURE OR MALFUNCTION OF A TITAN MARKETING LLC
PRODUCT OR THE BREACH OR DELAY IN PERFORMANCE OF THE WARRANTY.
WARNING
The warnings, precautions and instructions in this manual cannot
cover all possible conditions and situations that may occur. The
operator must understand that the operator must supply common
sense and examine caution factors when using this product to
determine safety in all circumstances being used.
®
PO Box 7069 Greenwood, IN 46142
1.888.908-4826 FAX (317) 215.2770
www.titanlifts.com
TITAN MARKETING, LLC
Copyright © 2019 by Titan Marketing, LLC. All rights reserved. No portion of this manual or any artwork contained herein may be
reproduced in any shape or form without the express consent of Titan Marketing, LLC. Diagrams within this manual may not be
drawn proportionally. Due to continuing improvements, actual product may dier slightly from the product described herein. Tools
required for assembly and service may not be included.
Patent No.: US 8,104,588 B2
CA 2,729,670
12/20/19
Table of contents
