BeNext MoLiTe User manual


Version0.320February2012www.2iHome.eu
Quickstart
MoLiTesensorEU
Technicalspecs
Normaloperatingvoltage2xAA1,5Vbatteries
Frequencyrange868.42MHz
WirelessRangeUpto30metersinlineofsight
Temperaturesensoraccuracy+/‐2,5°Cfrom‐55
°
Cto+130
°
C
MotionsensorrangeMax.10metersundera110
°
angle
BasicOperations
‐TheMoLiTecandetectmovement,
‐TheMoLiTecanmeasurelightintensity
‐TheMoLiTecanmeasurethetemperature.
‐TheMoLiTecantriggerasecuritysystem.
Howitoperates
AfterasuccessfulinclusiontheMoLiTecanbemountedonthewalldirectlyorwithabracket.
Whenmovementisdetectedtheindicatorlightwillblinkshortly,thisindicatesthataz‐wavemessagehas
beensendsuccessfully.
Withacontrolleryoucanrequestthetemperatureandbatterylevel.
Mounting
1. Beforemount,theMoLiTeSensorshouldbeincludedintoaZ‐Wavenetworkandassociated.
2. Useaflatscrewdriverattheinletsonthesidestogentlyunlockthebackcover.
3. Usethesuppliedscrewstomountthecoverorbrackettothewall.
Foroptimaluse,mounttheMoLiTebetween1,5mand2,5maboveground
(ArotatingbracketisavailabletoadjustthedirectiontheMoLiTeispointingto).
4. PlacetwoAA1,5Vbatteriesintothedevice.
5. MounttheMoLiTeontothebackcoverandbesuretocloseitonallsides.
6. Mountingiscompletedwhentheledblinksforafull1sec.
7. TheMoLiTesensorhastostartupforca10seconds.
8. Afterca10secondstheMoLiTeisreadyfordetection.
IncludeorexcludeinZ‐Wavenetwork1
1. WhentheMoLiTeismounted,removeitfromthebackcover.
2. PressandholdtheTamperswitchfor2secondsandreleasetostarttheinclusionorexcludeprocess.
3. Whenclassicinclusionfailed,theproductwillstartNetworkWideInclusionautomatically.


1MakesureyourZ‐Wavecontrollerisindecorrectoperationmode(includeorexclude).
Tamperswitch
Indicatorlight
Movementsensor
Lightand
temperature
sensor


Version0.320February2012www.2iHome.eu
TechnicalManual
Caution:
‐Thisdeviceisusingaradiosignalthatpassesthroughwalls,windowsanddoors.Therangeisstrongly
influencedbylocalconditionssuchaslargemetalobjects,housewiring,concrete,furniture,
refrigerators,microwavesandsimilaritems.Onaverage,theindoorrangeisapproximately30meters.
‐Donotexposethisproducttoexcessiveheatormoisture.
‐Preventlongtermexposuretodirectsunlight.
‐Donotattempttorepairthisproduct.Iftheproductisdamagedorifyouareindoubtaboutthe
properoperation,taketheproductbacktotheplaceofpurchase.
‐Donotcleantheproductwithanyliquid.
‐Indooruseonly.
Technicaldetails







Detailedinstruction
WeadvisetheMoLiTetobemountedbetween1,5mand2,5mfromtheground,flaton
thewallandnotfacingdown.Withanoptionalbracket,thedirectiontheMoLiTeis
pointsatcanbechanged(up/downandleft/right).TheMoLiTedetectsmovementupto
10meters.Withoutbracketattached,itisrecommendedtoplacetoMoLiTeinthe
middleofthewall(see‘Goodsensorpositioning’).







Badsensorpositioning(poorareacoverage)Goodsensorpositioning

Normaloperatingvoltage2xAA1,5Vbatteries
From2,3to4,0V
donotuserechargeablebatteries
Frequencyrange868.42MHz
WirelessRangeUpto30metersinlineofsight
Temperaturesensoraccuracy+/‐2,5
°
Cfrom‐55
°
Cto+130
°
C
MotionsensorrangeMax.10metersundera110
°
angle
Storagetemperature‐5
°
Cto+65
°
C
Storagehumidity10%to70%
Operatingtemperature0
°
Cto50
°
C
Operatinghumidity:30%to80%


Version0.320February2012www.2iHome.eu

Indicationmode
Theindicatorlightgivesvariousstatusesofthedeviceasfollows:
1. Readyforlearnmode: indicatorlightblinkseverysecond.
2. Learninprogress(add):indicatorlight2timeseverysecond.
3. Learninprogress(remove):indicatorlight3timeseverysecond.
4. Learnmodesuccess: indicatorlightisonforonesecond.
5. Learnmodefailed: indicatorlightblinks8timesrapidly.
6. Tamperpressed/releasedindicatorlightblinks3timesrapidly.
7. Mountingsuccessful  indicatorlightisonfor1second.
8. RFmessagesendfailed indicatorlightblinks6timesrapidly

SupportingCommandClasses
Basictype:BASIC_TYPE_ROUTING_SLAVE
Generictype:GENERIC_TYPE_SENSOR_BINARY
Specifictype:SPECIFIC_TYPE_NOT_USED
Listening:False,Z‐WaveLib:4.51

class:0x30COMMAND_CLASS_SENSOR_BINARY
class:0x31COMMAND_CLASS_SENSOR_MULTILEVEL
class:0x60COMMAND_CLASS_MULTI_CHANNEL_V2
class:0x70COMMAND_CLASS_CONFIGURATION
class:0x71COMMAND_CLASS_ALARM
class:0x72COMMAND_CLASS_MANUFACTURER_SPECIFIC
class:0x80COMMAND_CLASS_BATTERY
class:0x84COMMAND_CLASS_WAKE_UP
class:0x85COMMAND_CLASS_ASSOCIATION
class:0x86COMMAND_CLASS_VERSION
class:0xEFCOMMAND_CLASS_MARK
class:0x20COMMAND_CLASS_BASIC

NotlisteningRoutingSLAVE
ThisZ‐Waveproductwillbeusedasroutingslave.SlavenodesarenodesinaZ‐Wavenetworkthatreceive
commandsandperformactionsbasedonthecommand.Thisdevicewillalwaysbeinsleepmodebecauseit
worksonbatteries.Insleepmodethedeviceisnotactivelistening,thedevicewillwakeupaccordingtothe
wakeupcommandclass.

IncludeInitiator
TheincludeinitiatorisusedwhenPrimaryandInclusionControllersincludenodesintothenetwork.When
boththeincludeinitiatorhavebeenactivatedsimultaneouslythenewnodewillbeincludedtothenetwork(if
thenodewasnotincludedpreviously).
ExcludeInitiator
TheexcludeinitiatorisusedbyPrimaryControllerstoexcludenodesfromthenetwork.Whentheexclude
initiatorandaslaveinitiatorareactivatedsimultaneously,itwillresultintheslavebeingexcludedfromthe


Version0.320February2012www.2iHome.eu
network(andresettoNodeIDzero).Eveniftheslavewasnotpartofthenetworkitwillstillberesetbythis
action.
Z‐Wavecompatibility
BecausethisisaZ‐Wavedevice,itmeansitcanco‐operatewithotherZ‐Wavedevicesofothermanufacturers.
Itcanco‐existinaZ‐Wavenetworkexistingwithproductfromothermanufacturers.
Hops&Retries
TheZ‐Waverangehasarangeofupto30metersinlineofsight.Thissignalisnotlimitedtothe30meter
rangeduetoroutingtheZ‐Wavemessagetoothernodesinthenetwork.ThiswaytherangeoftheZ‐Wave
networkcanbeexpandedto150metersindoors(limitof4hops).

class0x20COMMAND_CLASS_BASIC
Whenamovementisdetectedabasicsetframewithvalue255issenttotheassociatednodes.Ifthe
configuredtimeisdonewithnomovementisdetectedabasicsetframewithvalue0issenttotheassociated
nodes.Thisisthecontrollingroleofthebasiccommandclass.

Thesupportingroleofthebasiccommandclassismappedtothesensorbinarycommandclass.
class:0x30COMMAND_CLASS_SENSOR_BINARY
TheSensorBinaryCommandClasscanbeusedtocheckifmotionisdetected,value0meansthatthereisno
motiondetectedandthereforeaassociatednodeisoff,value255meansthataassociatednodeison.

Class:0x80COMMAND_CLASS_BATTERY
Thisclassisusedtorequestandreportbatterylevelsforagivendevice.
Whenbatterylevelislowerthen20%theMoLiTewillsendabatterywarning(value255)aftereverywakeup
notification.Abatterygetwillreporttheactualvalueevenifbelow20%

class:0x86COMMAND_CLASS_VERSION
ThisCommandClassisusedtoobtaininformationabouttheMoLiTe.TheZ‐Wavelibrarytype,theZ‐Wave
protocolversionandtheapplicationversionwillbereported.
Becausetheversion2issupportedthiscommandclasscanalsobeusedtorequesttheserialnumberofthe
devicewiththeDEVICE_SPECIFIC_GETcommand.

class:0x72COMMAND_CLASS_MANUFACTURER_SPECIFIC
Thiswillreportinformationaboutthemanufacturer.ThisproductwillcontainthemanufacturerIDofBeNeXt.
ManufacturerIDofBeNeXtis138,theIDofthisproductis4.

class:0x70COMMAND_CLASS_CONFIGURATION
Configureparameters:

0. Notused
1. Settodefault
Description:Setallconfigvaluestodefaultvalues(factorysettings).Readmorein
chapterconfigurationReset.
Size: 1byte*
Param1:  if0xFFthensettodefault
Param2,3,4:notused


Version0.320February2012www.2iHome.eu

2. Modetimeout
Description:Thetimeusedinmode2toturnthesensoroff.This
Timewillstartrunningassoonasdetectionisseen.
Defaultvalue:0x0384=900sec=15min

Size:2bytes(integer)*
Param1:  themostsignificantbyteoftheinteger
Param2:  theleastsignificantbyteoftheinteger
Param3,4:notused 

3. Switchofftime
Description:Theswitchofftimewillstartrunningassoonasmodetimeoutisdone.
Motionsensoristurnedonandwhenmovementis
detectedagainthemodetimeout(cfgparam1)willstartrunningall
overagain.
Whenswitchofftimeisdoneabasicoffmessageissenttothe
associatednode.
Defaultvalue:0x0A8C=2700sec=45min.  

Size:2bytes(integer)*
Param1:  themostsignificantbyteoftheinteger
Param2:  theleastsignificantbyteoftheinteger
Param3,4:notused 

4. Sensitivity
Description:thesensitivityofthemotioncircuit
Default:0x50=80

Size: 1byte*
Param1:Sensitivityvaluebetween0and127(valuesabove127willbereported
asthesetvaluebutwillbehandledinSWas127).
0isleastsensitiveand127ismostsensitive.
Param2,3,4:notused

5. themode
Description:  Themodethatisenteredafterdetection
Default:  0x02

Size:1byte*
Param1:mode1,2or3.
Mode1:nodetectionpossible.Batterysavemode
Mode2:normaloperationmode:sendonafterdetectionandoffafter
giventimenodetection.
Mode3:Z‐Wavechipisalwaysontorequeste.g.versionor
manufacturerid.
Ifmodeis0orhigherthen3,thatvaluewillbereportedafteragetbut
willbehandledinSWasmode2.
Param2,3:  notused.

6. Thetemperatureoffset
Description:  Aoffsetforthetemperature.


Version0.320February2012www.2iHome.eu
Default:  0x00

Size:2bytes*
Param1,2:  Asignedintegertodeterminetheoffsetoffthetemperature.
Param3,4:  notused.

*ifasizeisotherthengivensizetheframeisignoredtotallysoconfigurationvaluesarenotchanged

class:0x31COMMAND_CLASS_SENSOR_MULTILEVEL
Sensor_multilevel_get
TheSensorMultilevelCommandClassisusedtogetareportfromtheMoLiTe.Thereturnedvalueisthe
measuredtemperatueinsidethehousingwith2decimals.

class:0x60COMMAND_CLASS_MULTI_CHANNEL_V2
Requesttemperature
Channel1
Note:Thereturnedvalueisthemeasuredtemperature(+/‐offset)insidethehousingwith2decimals.

Requestlight/lux
Channel2
Note:ThereturnedvalueisthemeasuredLDRresistancein%.

class:0x85COMMAND_CLASS_ASSOCIATION
TheAssociationCommandClassisusedtoassociateotherdeviceswiththeMoLiTe.Thedevicesthatare
associatedcanbecontrolledonapplicationlevel.Everynodeassociatedinthegroupwillbeswitchedonwith
aBASIC_SETverytimemotionisdetected.

Numberofgroupings:1
Maximumsupportednodespergroup:5

Becauseonlyonegroupissupportedgroupingidentifierisignoredinallcases.

class:0x84COMMAND_CLASS_WAKE_UP
TheWakeUpCommandClassisusedatbattery‐operateddevices.ThisclassallowstheMoLiTetowakeup
occasionallytonotifyothersdevices,thattheMoLiTeisreadytoreceivecommands.Afterreceivingthe
commandstheMoLiTewillgointosleepmodeagain.Thewakeupintervalcanbesetusingthe
WAKE_UP_INTERVAL_SETcommand.

Thedefaultvalueis0x1C20=7200sec=2hour
Thedefaultnodeis0xFF=255(broadcast)

Itispossibletosendawakeupnotificationonuserinteraction.Todothispressandholdthetamperswitch
for4seconds(mountthedevice).

Whenthewakeuptimeissetto0awakeupnotificationisneversendperiodically,onlyonuserinteraction.



Version0.320February2012www.2iHome.eu
class:0x71COMMAND_CLASS_ALARM
Thiscommandclassisusedtoidentifythestateofthetamperalarm.Thedevicewillsendanunsolicitedreport
tothecontrollerifthestatusischanged,thevalue0x00willindicatethatthetamperisplacedcorrectlyonthe
wall.Thevalue0xFFwillindicateatamperalarm.
Thereis1alarmtype:
3:Tamperswitch
Everyotheralarmtypethatisrequestedwillbeignoredbyapplication.



Version0.320February2012www.2iHome.eu
ConfigurationReset
TheMoLiTeSupportsaconfigurationresetfunction.Configurationresetmeans
‐Allconfigurationvaluesaredefaulted.
‐Wakeupintervalisdefaulted.

Note:Allconfigurationswillalsobedefaultedafterexclusionthedevice.

Thisfunctioncanbeactivatedbysendingaconfigurationsetframe:

CONFIGURATION_SET
Parameter:0x01
Size: 0x01(can’tbedifferentfrom1)
Value: 0xFF(canbeanyvalueexceptfor0x55or0xAA)

Whenthevalueofconfigurationvalueisrequested2possiblevaluescanbereturned

CONFIGURATION_REPORT
Parameter:0x01
Value0x55:Devicedoesn’thaveallhisdefaultconfigurationsettingsanymore.
Evenwhenaconfigurationparameterischangedbacktothedefaultvalue
Value0xAA:Devicesstillhasallhisfactorysettings.
Thisareonlyconfigurationparameters,wakeupintervalcanbechanged.

Alwaysawakemode
Thealwaysawakemodeisusedtorequestdifferentvaluesfromthedevicee.g.versionandmanufacturer
specific.

Thealwaysawakemodecanbeactivatedby:

CONFIGURATION_SET
Parameter: 0x05
Size:  0x01(can’tbedifferentfrom1)
Value:  0x03(mode3)

Thealwaysawakemodecanbedeactivatedby:

CONFIGURATION_SET
Parameter: 0x05
Size:  0x01(can’tbedifferentfrom1)
Value:  Anyvalueexcept3

Asecondoptiontodeactivatemode3is
1. Removebatteries.
2. Waitca10seconds.
3. Replacebatteries

Note:inalwaysawakemodethebatterieswillbedrainveryfast,wedonotrecommendtousethismode.



Version0.320February2012www.2iHome.eu
Troubleshooting

FrequentlyAskedQuestions

Q:Ican’thavemyMoLiTeincludedintomyZ‐Wavenetwork,whatamIdoingwrong?
A:1.IsthecontrollerreadytoincludeanydeviceintotheZ‐Wavenetwork?Ifthecontrollerisnotin
Includeorexcludemode,theMoLiTecannotbeincludedorexcluded.
2.TheMoLiTeisalreadyincludedinaZ‐Wavenetwork.ExcludetheMoLiTeand
Trytoincludeitagain.

Q:Whydoesn’ttheMoLiTedetectanymovement?
A:1.TheMoLiTeisn’tincludedinaZ‐Wavenetwork.Includeitandtryitagain.
2.Thebatteriesarealmostempty,tryputtingnewonesin.

Q:ThetemperaturereportoftheMoLiTeisincorrect.
A:1.TheMoLiTeisplaceddirectlyinthesun,whichmakesthetemperatureinthehousingoftheMoLiTe
hotterthanelsewhereintheroom.
2.Thecalibrationisnotthesameasyourothertemperaturesensor,itispossibletodoare‐calibration
ofthetemperaturesensorwith2myhomeandthemyGate.

Q:IhaveconfiguredavaluebutwhenIrequestit,itisnotchanged?
A:Itismandatorythatthecorrectsizeisusedwhileconfigureaparameter;gotothedocumentationabout
theconfigurationcommandclasstocheckiftherightsizeisusedduringconfiguration.Ifthewrongsizeisused
theframeisignoredtotally.

Q:IhaveconfiguredanewvalueandwhenIrequestitthecorrectvalueisreturnedbutthebehaviorisstillthe
same?
A:Someconfigurationparametershavelimitsofwhattheycando,gotothedocumentationabout
configurationtocheckifthevalueoftheconfiguredparameterisoutofflimit.

Q:WhenImounttheMoLiTeitperformsitsstandardmountingroutinebutafter4secondstheindicatorlight
doesn’tgoonfor1secondbutblinks6times.
A:blinking6timescanmean:
1. MoLiTeisnotincluded
2. MoLiTeisnotassociated
3. MoLiTecan’treachedhisdestination
Ifallthreeoptionsarecorrected,MoLiTeiswilloperatecorrectlyandcanbemountedagain.

Q:WhenIexcludetheMoLiTetheconfigurationtimes(idleandswitchoff)areresetbacktodefault.
A:ThatiscorrectwhentheMoLiTeisexcludedallconfigurationsincludingwakeuptimingsareresetbackto
default.Youwillneedtoconfigurethedeviceagainafterincludedintothecontroller.
Byforcingthetamperswitchawakeupmessage(broadcast)willbesendtoeasilychangetheconfiguration.

