Product Service Manual –Level II
Service Manual for BenQ:
XL2411T
P/N: 9H.L9SLB.xxx
Applicable for All Regions
Version: 001
Date:2012/09/06
Notice:
- For RO to input specific “Legal Requirement” in specific NS regarding to responsibility and liability
statements.
- Please check BenQ’s eSupport web site, http://esupport.benq.com, to ensure that you have the most
recent version of this manual.
First Edition (Sep, 2012)
© Copyright BenQ Corporation 2012. All Right Reserved.

- 2 -
Content Index
Abbreviations & Acronyms.............................................................................3
1About This Manual.......................................................................................3
1.1. Trademark............................................................................................................ 3
2Introduction..................................................................................................4
2.1. RoHS (2002/95/EC) Requirements...................................................................... 4
2.2. Safety Notice........................................................................................................ 4
2.3. Compliance Statement......................................................................................... 4
2.4. General Descriptions ........................................................................................... 4
2.5. Related Service Information................................................................................. 4
3Product Overview ........................................................................................5
3.1. Specification......................................................................................................... 5
3.2. Customer Acceptance........................................................................................ 20
4. Level 1 Cosmetic / Appearance / Alignment Service ..............................27
4.1. Software / Firmware Upgrade Process .............................................................. 27
4.2. Alignment procedure (for function adjustment)................................................... 37
5. Level 2 Disassembly /Assembly Circuit Board and Standard Parts
Replacement..................................................................................................40
5.1. Exploded View ................................................................................................... 40
5.2. Disassembly /Assembly..................................................................................... 41
5.3. Packing.............................................................................................................. 44
5.4. Block diagram .................................................................................................... 45
5.5. Trouble Shooting Guide ..................................................................................... 46
5.6. Circuit Operation Theory.................................................................................... 49
Appendix 1 –Screw List / Torque.................................................................51
Appendix 2-Physical Dimension Front View and Side view.......................54

- 3 -
Abbreviations & Acronyms
1 About This Manual
This manual contains information about maintenance and service of BenQ products. Use this
manual to perform diagnostics tests, troubleshoot problems, and align the BenQ product.
1.1. Trademark
The following terms are trademarks of BenQ Corporation:
BenQ
Importance
Only trained service personnel who are familiar with this BenQ Product shall perform
service or maintenance to it. Before performing any maintenance or service, the
engineer MUST read the “Safety Note”.

- 4 -
2 Introduction
This section contains general service information, please read through carefully. It should be
stored for easy access place for quick reference.
2.1. RoHS (2002/95/EC) Requirements
–Applied to all countries require RoHS.
The RoHS (Restriction of Hazardous Substance in Electrical and Electronic Equipment Directive)
is a legal requirement by EU (European Union) for the global electronics industry which sold in EU
and some counties also require this requirement. Any electrical and electronics products
launched in the market after June 2006 should meet this RoHS requirements. Products launched
in the market before June 2006 are not required to compliant with RoHS parts. If the original
parts are not RoHS complaints, the replacement parts can be non ROHS complaints, but if the
original parts are RoHS compliant, the replacement parts MUST be RoHS complaints.
If the product service or maintenance require replacing any parts, please confirming the RoHS
requirement before replace them.
2.2. Safety Notice
1. Make sure your working environment is dry and clean, and meets all government safety
requirements.
2. Ensure that other persons are safe while you are servicing the product. DO NOT perform any
action that may cause a hazard to the customer or make the product unsafe.
3. Use proper safety devices to ensure your personal safety.
4. Always use approved tools and test equipment for servicing.
5. Never assume the product’s power is disconnected from the mains power supply. Check that
it is disconnected before opening the product’s cabinet.
6. Modules containing electrical components are sensitive to electrostatic discharge (ESD).
Follow ESD safety procedures while handling these parts.
7. Some products contain more than one battery. Do not disassemble any battery, or expose it to
high temperatures such as throwing into fire, or it may explode.
8. Refer to government requirements for battery recycling or disposal.
2.3. Compliance Statement
Caution: This Optical Storage Product contains a Laser device. Refer to the product specifications
and your local Laser Safety Compliance Requirements.
2.4. General Descriptions
This Service Manual contains general information. There are 3 levels of service:
Level 1: Cosmetic / Appearance / Alignment Service
Level 2: Circuit Board or Standard Parts Replacement
Level 3: Component Repair to Circuit Boards
2.5. Related Service Information
BenQ Global Service Website: http://www.benq.com/support/
eSupport Website: http://esupport.benq.com/v2

- 5 -
3 Product Overview
3.1. Specification
3.1.1 Introduction
XL2411T is defined 24’W LCD Monitor supports WXGA (1920x1080) resolution with DPMS
(Display Power Management System) and Senseye function. There are five different input
types, D-sub, DVI-D Dual-Link, and HDMI ports of models. XL2411T adopts AUO panel,
M240HW01-V8.
The features summary is shown as below,
* All spec. of monitor need to warm up at least 1hr.
* To test the “Contrast Ratio” and “Luminance” functions, the color status must be “User
preset” mode.
* 1. “Contrast Ratio”: Set “brightness” at 100, and “contrast” at 50.
* 2. “Luminance”: Set “brightness” at 100, and “contrast” at 100.
Feature items Specifications Remark
Panel supplier & module name AUO M240HW01 V8 TN
Screen diagonal 24” 531.36(H)x298.89(V)
Display Format 1920 (H) x 1080 (V) Panel Display information
Pixel Pitch 0.27675 mm x 0.27675 mm per one triad
Viewing Angle (@ Contrast Ratio >= 10) R/L:170 degrees (typ)
U/D: 160 degrees (typ)
Analog interface with Scaling supported Yes With 15-pin D-sub connector
DVI interface with Scaling supported Yes DVI-D Dual-Link
DP interface with Scaling supported NO Display port 1.2
HDMI interface with Scaling supported Yes HDMI 1.4(1 port)
Video interface with Scaling supported No
Max resolution mode supported 1920x1080@60Hz
Number of Display Colors supported 16.7 millions RGB 6-bit + Hi_FRC
Luminance 350 cd/m2(typ.)
Test Condition:
Contrast=100,
Brightness=100,
Color=User mode
Contrast Ratio 1000(typ.)
Test Condition:
Contrast=50,
Brightness=100,
Color=User mode
Color Temperature
(1) Bluish mode:
(x,y)=
(0.283, 0.297)+/-(0.02, 0.02)
(2) Reddish mode:
(x,y)=
(0.326, 0.342)+/-(0.02, 0.02)

- 6 -
(3) 6500K mode :
(x,y)=
(0.313, 0.329)+/-(0.02, 0.02)
(4) sRGB:
(x,y)=
(0.313, 0.329)+/-(0.015, 0.015)
AC power input Yes 90-264 Volts, 47-63 Hz.
DC power input (with AC power adapter) No
DPMS supported(Power Saving) Yes <0.5W
LED indicator for power status showed Yes White/Amber
OSD for control & information supported Yes ADC Key
Multi-language supported for OSD Yes 17 languages
Buttons control supported Yes
6 buttons including 1
monitor power on/off
control button.
(Touch sensor)
Flywheel control supported No
Scaling function supported Yes
Auto adjustment function supported Yes “OSD” function
DDC function supported (EDID ver. 1.3) Yes DDC2B
DDC-CI support version 1.1 or later Yes DDC-CI
Audio speakers supported No
Audio Jack (input connector) supported NO
Earphone Jack (input connector)
supported Yes For HDMI port
Microphone function supported No
Mechanical Tilt base design Yes From -5 to +20 degree
VESA wall mounting design Yes
Mechanical Rotate design No
Mechanical Lift base design No
Kensington compatible lock design Yes
3.1.2 Operational Specification
3.1.2.1 Power supply
Item Condition Spec OK N.A Remark
Input Voltage range Universal input full
range 90~264VAC /47~63Hz 
Input Current range 90 ~ 264VAC < 1.5 Arms 
Power Consumption
Normal “On”
operation < 36W LED: Green
DPMS “Sleep” state < 0.5 W LED: Amber
DPMS “Off” state < 0.5 W LED: Off
Inrush Current 110 VAC
220 VAC <40 A (peak) <80 A (peak) Cold-start
Earth Leakage Current 264 VAC/50Hz < 3.5 mA 

- 7 -
Hi-Pot 1. 1500VAC, 1 sec 2. Ground test: 30A,
1sec
Without damage
< 0.1 ohm (on-line test) (in-lab test)
Power Line Transient IEC1000-4-4 1KV 
IEC1000-4-5 (Surge) Common: 2KV,
Differential: 1KV 
LED Operation Current (2D) 90V ~ 264VAC 110mA Panel Spec
LED Operation Current (3D) 90V ~ 264VAC 200mA
215mA Panel spec (duty
33%, 24%)
CCFL operation range 90V ~ 264VAC 7.5mA (Typ.) 
Depends on panel
source (Operation
with fixed driving
current)
CCFL Frequency 90V ~ 264VAC 40KHz ~ 80KHz Depends on panel
source
Power cord Color: Black Length: 1800 +/- 50
mm 
3.1.2.2 Signal interface
Item Condition Spec OK N.A Remark
Signal Cable 15-pin D-Sub Color: Black
Length: 1800 +/- 30 mm 
24-pin DVI-D
Dual-Link Color: White
Length: 1800 +/- 50 mm Dual-Link Cable
Pin assignment
15-pin D-sub
connector See Note-1 For 15-pin D-sub
24-pin DVI-D
connector See Note-2  For 24-pin DVI-D Dual-Link
19-pin HDMI
connector See Note-3 For 19-pin HDMI
Video input Signal type Separate analog R/G/B For 15-pin D-sub Level 700 mV (peak to peak) 
Impedance 75 Ohms +/- 1.5 Ohms 
Sync input
Signal type Separate H/V-sync Composite H/V-sync
(Positive/Negative) For 15-pin D-sub
Level Logic High: 2.4V ~ 5.5V Logic Low: 0V ~ 0.5V
(TTL level) Refer to VESA
VSIS Standard
V1R1
Impedance Minimum 2.2KΩ(pull down) 10KΩ for
application
Sync Pulse Width
(SPW) 0.7μs < H-SPW 1H < V-SPW 

- 8 -
Note-1: The pin assignment of 15-pin D-sub connector is as below,
Pin Signal Assignment Pin Signal Assignment
1 Red video 9 PC5V (+5 volt power)
2 Green video 10 Sync Ground
3 Blue video 11 Ground
4 Ground 12 SDA
5 Cable Detected 13 H-Sync (or H+V)
6 Red Ground 14 V-sync
7 Green Ground 15 SCL
8 Blue Ground
Note-2: The pin assignment of 24-pin DVI-D connector is as below,
Pin Signal Assignment Pin Signal Assignment
1 TMDS RX2- 13 TMDS RX3+
2 TMDS RX2+ 14 +5V Power
3 TMDS Ground 15 GROUND
4 TMDS RX4- 16 Hot Plug Detect
5 TMDS RX4+ 17 TMDS RX0-
6 DDC CLOCK 18 TMDS RX0+
7 DDC DATA 19 TMDS Ground
8 Floating 20 TMDS RX5-
9 TMDS RX1- 21 TMDS RX5+
10 TMDS RX1+ 22 TMDS Ground
11 TMDS Ground 23 TMDS CLOCK+
12 TMDS RX3- 24 TMDS CLOCK-

- 9 -
Note-3: The pin assignment of 19-pin HDMI connector is as below
3.1.2.3 Video performance
Item Condition Spec OK N.A Remark
Max. support Pixel rate
170 MHz Both for analog and
HDMI
330 MHz DVI-D Dual-link
And DP
Max. Resolution 1920 x 1080 
Rise time + Fall time 5 ms(Typ.) 1920 x 1080 @ 60Hz
(max. support timing)
Settling Time after
overshoot /undershoot < 5% final full-scale value Refer to VESA VSIS Standard V1R1
Overshoot/Undershoot < 12% of step function voltage level over the full
voltage range Refer to VESA VSIS
Standard V1R1
3.1.2.4 Scan range
Item Condition Spec OK N.A Remark
Horizontal H-Freq VGA/HDMI:15K-135K
H-Freq DVI:30K-140K 
Vertical V-Freq VGA:24-120HZ
V-Freq HDMI:56-120HZ 

- 10 -
3.1.2.5 Plug & Play DDC2B DDC-CI Support
Item Condition Spec OK N.A Remark
DDC channel type DDC2B 
EDID
Version 1.3

Refer to S/W spec.
document to see the
detailed EDID data
definition.
DDC-CI Version 1.1 or Later Refer to S/W spec
3.1.2.6 Support Timings
Resolution Pixel
clock H-sync V-sync
(unit:MHz) (unit:KHz) (unit:Hz)
P 640x350 25.18 31.47 70.09
P 640x480 25.17 31.47 59.94
P 640x480 31.50 37.50 75.00
P 720x400 28.32 31.47 70.08
P 832x624 57.27 49.71 74.53
P 800x600 40.00 37.88 60.32
P 800x600 49.50 46.88 75.00
P 1024x576 46.966 35.82 60
P 1024x600 48.964 37.32 60
P 1024x768 65.00 48.36 60.00
P 1024x768 80.00 60.24 74.93
P 1024x768 78.75 60.02 75.03
P 1152x720 66.75 44.86 60
P 1152x864 108.00 67.50 75.00
P 1152x870 100.00 68.68 75.06
P 1152x900 92.94 61.80 65.95
P 1280x720 74.25 45.00 59.94
P 1280x720 74.50 44.77 59.86
P 1280x720 95.75 56.46 74.78
P 1280x768-R 68.25 47.40 60.00
P 1280x800 83.50 49.702 59.81
P 1280x800 106.6 62.795 74.934
P 1280x960 108.00 60.00 60.00
P 1280x1024 108.00 63.98 60.02
P 1280x1024 135.00 79.98 75.02
P 1360x768 85.50 47.71 60.01
P 1366x768 85.50 47.71 59.79
P 1440x900-R 88.75 55.496 59.901
P 1440x900 106.5 55.935 59.887
P 1440x900 136.75 70.6 75
P 1600X900-R 108 60 60
P 1600x1000- R 108.5 61.648 59.910
P 1600x1200 162.00 75.00 60.00
P 1680x1050 146.25 65.29 59.95
P 1680x1050 187 82.306 75
P 1920x1080- R 138.5 66.587 59.934
P 1920x1080 173 67.158 59.963
P 1920x1080 148.5 67.5 60

- 11 -
3.1.3 Operational & Functional Specification
3.1.3.1 Video performance
*All spec. of monitor need to warm up at least 1hr.
Item Condition Spec OK N.A Remark
Resolution Any input resolution modes which are
under 1920x1080 1920 x 1080 
Contrast ratio 1000 (typ.) 
Test Condition:
Set Contrast at
50, Brightness
at 100, and
Color at User
preset.
Brightness At R/G/B saturated
condition 350 cd/m2(Typ.) 
Test Condition:
Set contrast at
100, brightness
at 100, and color
at User preset.
Response time Gray to Gray 1ms (typ.) 
Test Equipment:
Westar TRD 100
or equal level
equipment ;
Viewing angle At Contrast ratio = 10 R/L: 170 degrees (typ.) 
At Contrast ratio = 10 U/D: 160 degrees (typ.) 
CIE coordinate of
White
(1) Bluish mode:
(x,y)=
(0.283, 0.297)+/-(0.02, 0.02)
(2) Reddish mode:
(x,y)=
(0.326, 0.342)+/-(0.02, 0.02)
(3) 6500K mode :
(x,y)=
(0.313, 0.329)+/-(0.02, 0.02)
(4) sRGB:
(x,y)=
(0.313, 0.329)+/-(0.015, 0.015)

Display colors 16.7 Millions colors RGB 6-bit +
Hi_FRC
Color temperature specification:
Color mode Color temperature x Y
Normal 6500k 0.313±0.020 0.329±0.020 Min 250m2
Bluish 9300k 0.283±0.020 0.297±0.020 Min 200/m2
Reddish 5800k 0.326±0.020 0.342±0.020 Min 250/m2
User Mode Panel default color temp. Min 250/m2
sRGB 6500k (Gamma=2.2±0.2) 0.313±0.015 0.329±0.015 200+/-20 cd/m2

- 12 -
3.1.3.2 Brightness Adjustable Range
Item Condition Spec OK N.A Remark
Brightness adjustable
range
At default contrast level
(saturate point) & Full-
white color pattern
(Max. brightness value –
Min. brightness value)
≧100 cd/㎡
3.1.3.3 Acoustical Noise
Item Condition Spec OK N.A Remark
Acoustical Noise At 4 cm distance & “Audio” function
disabled ≦28 dB/A 
3.1.3.4 Environment
Item Condition Spec OK N.A Remark
Temperature Operating 0 ~ +40 ℃
Non-operating -20 ~ +60 ℃
Humidity Operating 10 ~ 90% Non-
condensing
Non-operating 10 ~ 70% Non-
condensing
Altitude Operating 0~3048m (10,000ft) Without
packing
Non-operating 0~12,192m (40,000ft) With packing
3.1.3.5 Transportation
Item Condition Spec OK N.A Remark
(1) Vibration
Package,
Non-
Operating
(1)

* Acceleration: 1.15G;
(1)The product should be
packaged and non-operating.
(2) The duration of endurance is 30
minutes per axis (X, Y and Z)
(3) Procedure:
Confirmed sample with
appearance and function ready
before testing then compare with
after test record as brightness,
uniformity and contrast ratio.
Perform random vibration after
sine-wave vibration test.
(2) Unpackaged Vibration Unpackaged,
Non-
Operating
Test Spectrum:
20 Hz 0.0185(g2/Hz)
200Hz 0.0185(g2/Hz)
Duration : 5 Minutes
Axis : 3 axis ( Horizontal and
Vertical axis ,Z axis)


- 13 -
(3) Drop Package, Non-
Operating
91 cm Height (MP stage)
(1 corner, 3 edges, 6 faces)

(4) Shock Wooden package, Non-
Operating
Waveform: half sine
Faces: 6 sides/ per orientation
3 shocks.
Duration: <3ms
Velocity accelerate: 75g

3.1.3.6 Electrostatic Discharge Requirements
Item Condition Spec OK N.A Remark
Electrostatic Discharge IEC801-2 standard Contact: 8KV
Air: 15KV 
3.1.3.7 EMC
Item Condition Spec OK N.A Remark
TCO03 Electric Band 1 < 10 V/m
Band 2 < 1 V/m 
Magnetic Band 1 < 200nT
Band 2 < 25nT 
EMI
FCC part 15J class B After Mass production
under 1dBuv for constant
measure. Besides DNSF
and VCCI class-2 are
optional.

EN55022 class B
3.1.3.8 Reliability
Item Condition Spec OK N.A Remark
MTBF Prediction Refer to Telcordia
(Bellcore) > 60,000 Hours Excluding
backlight
Backlight Life time At 25±2℃30,000 Hours (min) See Note-A
Note-A: Backlight life time is defined as the time when brightness of backlight become 50% or less than
its original value at the condition of typical backlight operation current (for CCFL backlight, it’s CCFL
operation current; for LED backlight, it’s LED forward (/operation) current).

- 14 -
3.1.3.9 Audio performance
3.1.4 LCD Characteristics
3.1.4.1 The Physical definition & Technology summary of LCD panel
Item Condition Spec OK N.A Remark
LCD Panel Supplier AUO 
Panel type of Supplier M240HW01V8 
Screen Diagonal 609.7(24”) 
Display area Unit=mm 531.36(H) x 298.89(V) 
Physical Size Unit=mm 556(W) x323.2(H) x 14.4(D) 
Weight Unit=gram 2200 (Typ.) 
Technology TN type 
Pixel pitch Unit=mm 0.27675(H) x 0.27675(W) Per one triad
Pixel arrangement R/G/B vertical stripe 
Display mode Normally White 
Support color 16.7 Millions colors RGB 6-bit +
Hi_FRC
3.1.4.2 Optical characteristics of LCD panel
Item Unit Conditions Min. Typ. Max. Remark
Viewing Angle
[degree]
[degree] Horizontal (Right) CR = 10 (Left) 150 170 -
-
[degree]
[degree] Vertical (Up) CR = 10 (Down) 140 160 -
-
Contrast ratio Normal Direction 600 1000
Response Time [msec] Rising Time - 3.5 7.4 [msec] Falling Time - 1.5 2.6
[msec] Rising + Falling - 5 10
Color / Chromaticity
Coordinates (CIE)
Red x Typ.-
0.03 0.65 Typ.+0.03
Red y Typ.-
0.03 0.329 Typ.+0.03
Green x Typ.-
0.03 0.331 Typ.+0.03
Item Condition Spec OK N.A Remark
Speaker
(1)Nominal impedance @ 1KHz 4 ± 15% ohm
(2)Rated input power 3W/CH
(3)Frequency response SPL-10dB 450~20KHz SPL-10dB
(4)Output sound pressure level 1W 0.5M >75 ± 3 dB
Earphone out
Signal Level
when 1Vrms sin
wave input, tested
under 32 ohm
dummy load 1
<= 150 mVrms
Line out
Signal Level when 1Vrms sin
wave input >=1.0 Vrms

- 15 -
Green y Typ.-
0.03 0.622 Typ.+0.03
Blue x Typ.-
0.03 0.151 Typ.+0.03
Blue y Typ.-
0.03 0.053 Typ.+0.03
Color Coordinates (CIE)
White
White x Typ.-
0.03 0.313 Typ.+0.03
White y Typ.-
0.03 0.329 Typ.+0.03
Luminance Uniformity [%] 9 points
measurement 75 80
White Luminance @ CCFL
6.0mA (center) [cd/m2] 300 350 -
Crosstalk (in 60Hz) [%] 1.5
3.1.5 User Controls
3.1.5.1 User’s hardware control definition
Item Condition Spec OK N.A Remark
Power button 
Enter button 
Right/Inc. button 
Left/Dec. button 
Menu button 
Mode button 
Input Select button 
iKey button 
Mute button 
3.1.5.2 OSD control function definition
Item Condition Spec OK N.A Remark
Auto Adjust Auto-Geometry 
Brightness 
Contrast 
Horizontal Position 
Vertical Position 
Pixel Clock 
Phase 
Color
Bluish
Reddish
Normal
sRGB
Senseye
User: Separate R/G/B
adjustment
Reset Color

OSD Position OSD Horizontal position
OSD Vertical position 
OSD Time From 5 sec to 30 sec 
OSD Lock 

- 16 -
Language 17 languages 
Recall Recall All 
Mode
Standard
Movie
sRGB
ECO
FPS1
FPS2
RTS
Gamer1
Gamer2
Gamer3

Input Select 
Sharpness 
Display Information For input timing 
Volume Selection by Custom
key 
Mute Selection by Custom
key 
Hot key for Brightness Selection by Custom
key 
Hot key for Contrast Selection by Custom
key 
Hot key for Volume Selection by Custom
key 
Hot key for Input Select Selection by Custom
key 
Hot key for Mode Selection by Custom
key 
3.1.6 Mechanical Characteristics
3.1.6.1 Dimension
Item Condition Spec OK N.A Remark
Bezel opening 533.2*300.7 
Monitor without Stand W x H x D mm 570*347*63 
Monitor with Stand W x H x D mm 570*431*222.6 
Carton Box (outside) L x W x H mm 652*420*251 
Tilt and Swivel range Tilt: -5°~20°
Swivel: ±45° 
3.1.6.2 Weight
Item Condition Spec OK N.A Remark
Monitor (Net) 6.0Kg 
Monitor with packing
(Gross) 8.5Kg 

- 17 -
3.1.6.3 Plastic
Item Condition Spec OK N.A Remark
Flammability >ABS<,94-HB 
Heat deflection To ABS 65 ℃
UV stability ABS Delta E < 8.0 
Resin MPRII: ABS (SD0150/PA756/GP-
35/HF
-380/D-150) 
Texture RC&CVR: MT-11020
Others: MT-11010 
Color 7015A(Black) 
3.1.6.4 Carton
Item Condition Spec OK N.A Remark
Color color 
Material BE Flute 
Compression strength 250 Kgf 
Burst Strength 19.3 KGF/cm2(general) 
Stacked quantity WW 20’:360 / 40’:810 JP 20’:320 / 40’:720
EU 20’:270 / 40’:567 
3.1.7 Pallet & Shipment
3.1.7.1 Container Specification
Stowing Type Container Quantity of products (sets)
(Every container)
Quantity of Products
(sets)
(Every Pallet)
Quantity of pallet
(sets)
(Every Container)
With pallet
20'
380(WW)
344(JP）
270(EU)
Pallet A:36
Pallet B: 54
Pallet A:32
Pallet B: 48
Pallet A:27
Pallet A: 4
Pallet B: 4
Pallet A: 4
Pallet B: 4
Pallet A: 10
40'
810(WW)
720(JP)
567(EU)
Pallet A:36
Pallet B: 54
Pallet A:32
Pallet B: 48
Pallet A:27
Pallet A: 9
Pallet B: 9
Pallet A: 9
Pallet B: 9
Pallet A:21
Without pallet
20' X X X
X X
40' X X X
X X

- 18 -
3.1.7.2 Carton Specification
Product:
Net Weight (Kg) Gross Weight (Kg) Dimension w/o Base
W*H*D (mm)
6.0Kg 8.5Kg 570*348.4*63
Package:
Carton Interior Dimension (mm)
L*W*H Carton External Dimension (mm) L*W*H
640*408*231 652*420*251

- 19 -
3.1.8 Certification

- 20 -
3.2. Customer Acceptance
3.2.1. SCOPE
This document establishes the general workmanship standards and functional
Acceptance criteria for LCD color monitor model XL2411T Produced by BenQ.
3.2.2. PURPOSE
The purpose of this publication is to define a procedure for inspection of the LCD monitor
by means of a customer acceptance test, the method of evaluation of defects and rules
for specifying acceptance levels.
3.2.3. APPLICATION
The "Customer Acceptance Criteria" is applicable to the inspection of the LCD monitor,
completely packed and ready for dispatch to customers. Unless otherwise specified, the
customer acceptance inspection should be conducted at manufacturer's site.
3.2.4. DEFINITION
The "Customer Acceptance Criteria" is the document defining the process of examining,
testing or otherwise comparing the product with a given set of specified technical,
esthetic and workmanship requirements leading to an evaluation of the "degree of fitness
for use", including possible personal injury or property damage for the user of the product.
3.2.5. CLASSIFICATION OF DEFECTS
The defects are grouped into the following classes:
Critical defect
A critical defect is a defect that judgment and experience indicate is likely to result in
hazardous or unsafe conditions for individuals using, maintaining or depending upon the
product.
Major defect
A major defect is a defect, other than critical, that is likely to result in failure, or to reduce
materially the usability of the product for its intended purpose.
