The above numbers are approximate and may be slightly different from the actual measurements. Only the recommended
screen sizes are listed. If your screen size is not in the table above, please contact your dealer for assistance.
Projection dimensions
The screen aspect ratio is 16:10 and the projected picture is 16:10
SU931
Screen dimensions Projection distance <D> [cm]Lowest/
Highest lens
position <E>
[cm]
Diagonal
<A>
[inch (mm)]
Height
<B>
[cm]
Width
<C>
[cm]
Min distance Average Max distance
<A> <B>
<C> <E>
<D>
<F>
<G>
<B>
<A>
<C>
<F>
<G>
<D>
<E>
<F>: Screen <G>: Center of lens
60 (1524) 81 129 139180221 4.0
70 (1778) 94 151 162210258 4.7
80 (2032) 108 172 185240295 5.4
90 (2286) 121 194 208270332 6.1
100 (2540) 135 215 231300369 6.7
110 (2794) 148 237 254330406 7.4
120 (3048) 161 259 277360442 8.1
130 (3302) 175 280 300390479 8.8
140 (3556) 189 302 323420516 9.4
150 (3810) 202 323 34645055310.1
160 (4064) 215 345 36947959010.8
170 (4318) 229 366 39250962711.4
180 (4572) 242 388 41553966312.1
190 (4826) 256 409 43856970012.8
200 (5080) 269 431 46159973713.5
240 (6096) 323 517 55471988416.2

2
1
1
2

X2

Ceiling mount screws: M4
(Max. L = 25 mm;
Min. L = 20 mm)
Unit: mm
144.02
444.99
227.02
538.11
577.70
402.70
322.90
273.70
23.52
109.57 30.24
29.48
7.15
336 152
446
78.5
74

<MEMO>

Table of contents
English ........................................................................................... 11
Français ......................................................................................... 12
Deutsch ......................................................................................... 13
Italiano ........................................................................................... 14
Español .......................................................................................... 15
Português ...................................................................................... 16
Svenska .......................................................................................... 17
Русский ........................................................................................ 18
Nederlands ................................................................................... 19
Polski .............................................................................................. 20
Türkçe ........................................................................................... 21
Čeština .......................................................................................... 22
繁體中文 ...................................................................................... 24
................................................................................................... 23
...................................................................................... 25
............................................................................................ 26
............................................................................................ 27
.............................................................................................. 28

11
All specifications are subject to change without notice.
Optical
Projection system Single-chip DLP™ system
Native resolution SX930: 0.7" DLP (1024 x768);
SU931: 0.67" DLP (1920 x1200)
Lens SX930: F = 2.1 to 2.63, f = 21.7 to 34.64 mm
SU931: F = 2.45 to 3.07, f = 15.78 to 25.12 mm
Projection screen size SX930: 60" to 300" ; SU931: 60" to 240"
Lamp 465 W
Electrical
Compatibility PC: 640 x 480 to 1600 x1200
Video: NTSC, PAL, SECAM, YPbPr (480i/480p/576i/576p/
720p/1080i/1080p), HDTV (720p/1080i/1080p)
Color Space Ty p. = 6 0 % N T S C
Te r m i n a l s
Input Analog RGB: D-Sub 15-pin (female) x1
HDMI (V. 1.4a) x2
MHL (V 2.1) x1 (shared with HDMI input)
S-Video: Mini DIN 4pin x1
Component Video (Y/CB/CR, Y/PB/PR) x1
(shared with RGB input)
Composite Video x1
RCA Audio x1 ; PC Audio x1
Microphone x1
RJ45 LAN x1 (Control only)
Output Analog RGB: D-Sub 15-pin (female) x1
Audio out x1
Ty p e - A U S B x1
Speaker: 10W x2
Control Serial Connector: RS232 9 pin (male)
Mini B type USB x1
IR receiver x2
LAN x1 (RJ45)
12V DC Trigger x1 (Max. 0.5 A)
General characteristics
Projector weight <8.5 kg (18.74 lbs)
Power VAC 100-240V, 7.1 A, 50-60Hz
Power consumption Max. 694 W; Standby < 0.5 W; Network Standby < 3 W
Operating temperature 0 °C to 40 °C (without condensation)
Operating humidity 10% - 90% (without condensation)
Specifications
(EN)
SX930_QSG.fm Page 11 Friday, July 17, 2015 8:20 AM

12
Toutes les caractéristiques peuvent être modifiées sans notification préalable.
Caractéristiques optiques
Système de projection Système à une puce DLP™
Puce DMD SX930 : DLP 0,7" (1024 x768) ;
SU931 : DLP 0,67" (1920 x1200)
Objectif SX930 : F = 2,1 à 2,63, f = 21,7 à 34,64 mm ;
SU931 : F = 2,45 à 3,07, f = 15,78 à 25,12 mm
Taille de l’écran de projection SX930 : 60" à 300" (152 cm à 762 cm) ;
SU931 : 60" à 240" (152 cm à 610 cm)
Lampe 465 W
Caractéristiques électriques
Compatibilité PC : 640 x 480 à 1600 x1200
Vidéo : NTSC, PAL, SECAM, YPbPr (480i/480p/576i/
576p/720p/1080i/1080p), HDTV (720p/1080i/1080p)
Espace couleur Typ. = 60% NTSC
Prises
Entrée RVB analogique : D-Sub 15 broches (femelle) x1
HDMI (V. 1,4a) x2
MHL (V. 2,1) x1 (partagé avec l’entrée HDMI)
S-Video : mini DIN à 4 broches x1
Vidéo composantes (Y/CB/CR, Y/PB/PR) x1
(partagé avec entrée RVB)
Vidéo composite x1
Entrée audio RCA x1 ; Entrée audio PC x1
Microphone x1
Réseau RJ45 x1 (Contrôle seulement)
Sortie RVB analogique : D-Sub 15 broches (femelle) x1
Prise sortie audio x1
USB type A x1
Haut-parleur : 10 W x2
Commande Connecteur série : RS232 à 9 broches (mâle)
USB type mini B x1
Récepteur IR x2
Réseau x1 (RJ45)
Déclencheur 12 V CC x1 (max. 0,5 A)
Caractéristiques générales
Poids du projecteur <8,5 kg (18,74 lb)
Alim. 100 à 240 V AC, 7,1 A, 50/60 Hz
Consommation Max. 694 W ; veille < 0,5 W ; veille réseau < 3 W
Température de
fonctionnement
0°C à 40°C (sans condensation)
Humidité en fonctionnement 10% à 90% (sans condensation)
(FR)
Caractéristiques
SX930_QSG.fm Page 12 Friday, July 17, 2015 8:20 AM

13
Alle Daten können ohne Bekanntmachung geändert werden.
Optische Daten
Projektionssystem Einzel-Chip DLP™-System
DMD-Chip SX930: 0,7" DLP (1024 x768);
SU931: 0,67" DLP (1920 x1200)
Objektivlinse SX930: F = 2,1 bis 2,63; f = 21,7 bis 34,64 mm;
SU931: F = 2,45 bis 3,07; f = 15,78 bis 25,12 mm
Größe des Projektionsbilds SX930: 60" bis 300" ; SU931: 60" bis 240"
Lampe 465 W
Elektrische Daten
Kompatibilität PC: 640 x 480 bis 1600 x1200
Video: NTSC, PAL, SECAM, YPbPr (480i/480p/576i/
576p/720p/1080i/1080p), HDTV (720p/1080i/1080p)
Farbraum Ty p. = 6 0 % N T S C
Anschlüsse
Eingang Analog RGB: Eine 15-polige D-Sub-Buchse x1
HDMI (V. 1,4a) x2
MHL (V. 2,1) x1 (geteilt mit HDMI Eingang)
S-Video: Mini DIN 4-polige x1
Component-Video (Y/CB/CR, Y/PB/PR) x1
(gemeinsam benutzt mit RGB-Eingang)
Composite-Video x1
Cinch Audioeingang x1
PC Audioeingang x1
Mikrofon x1
RJ45 LAN x1 (nur Steuerung)
Ausgang Analog RGB: D-Sub 15-Pin (weiblich) x1
Audioausgang x1
USB (Typ-A) x1
Lautsprecher: 10W x2
Steuerung Serieller Anschluss: 9-poliger RS232 (Stecker)
USB (Mini B Typ) x1
IR-Empfänger x2
LAN x1 (RJ45)
12V DC Auslöser x1 (Max. 0,5 A)
Allgemeine Eigenschaften
Gewicht des Projektors <8,5 kg (18,74 lbs)
Stromversorgung VAC 100-240V, 7,1 A, 50-60Hz
Stromverbrauch Max. 694 W; Standby < 0,5 W; Netzwerk Standby < 3 W
Betriebstemperatur 0°C bis 40°C (nicht kondensierend)
Betriebsluftfeuchtigkeit 10% bis -90% (nicht kondensierend)
Technische Daten
(DE)
SX930_QSG.fm Page 13 Friday, July 17, 2015 8:20 AM

14
Tutte le specifiche sono soggette a modifiche senza preavviso.
Parte ottica
Sistema di proiezione Sistema DLP™ a chip singolo
Chip DMD SX930: DLP da 0,7" (1024 x768);
SU931: DLP da 0,67" (1920 x1200)
Obiettivo SX930: F = da 2,1 a 2,63, f = da 21,7 a 34,64 mm
SU931: F = da 2,45 a 3,07, f = da 15,78 a 25,12 mm
Dimensioni schermo di
proiezione
SX930: Da 60" a 300" ; SU931: Da 60" a 240"
Lampada 465 W
Parte elettrica
Compatibilità PC: 640 x 480 a 1600 x1200
Video: NTSC, PAL, SECAM, YPbPr (480i/480p/576i/576p/
720p/1080i/1080p), HDTV (720p/1080i/1080p)
Spazio di colore Ty p . = 6 0 % N T S C
Te r m i n a l i
Input RGB analogico: D-Sub da 15-pin (femmina) x1
HDMI (V. 1,4a) x2
MHL (V. 2,1) x1 (condiviso con l’ingresso HDMI)
S-Video: Mini DIN 4pin x1
Component Video (Y/CB/CR, Y/PB/PR) x1
(in condivisione con input RGB)
Composite Video x1
Ingresso audio RCA x1 ; Ingresso audio PC x1
Microfono x1
RJ45 LAN x1 (Solo controllo)
Uscita RGB analogico: D-Sub da 15-pin (femmina) x1
Audio out x1
USB (tipo A) x1
Altoparlante 10W x2
Controllo Connettore seriale: RS232 a 9 pin (maschio)
USB (Mini tipo B) x1
Ricevitore infrarossi x2
LAN x1 (RJ45)
Interruttore 12 V CC x1 (massimo 0,5 A)
Caratteristiche generali
Peso del proiettore <8,5 kg (18,74 lbs)
Power VAC 100-240V, 7,1 A, 50-60Hz
Consumo energetico Max. 694 W; Standby < 0,5 W; Standby rete < 3 W
Temperatura operativa da 0°C a 40°C (senza condensa)
Umidità operativa da 10% a 90% (senza condensa)
(IT)
Specifiche tecniche
SX930_QSG.fm Page 14 Friday, July 17, 2015 8:20 AM

15
Todas las especificaciones están sujetas a cambio sin previo aviso.
Óptico
Sistema de proyección Sistema DLP™ de un solo chip
Chip DMD SX930: DLP 0,7 pulg. (1024 x768);
SU931: DLP 0,67 pulg. (1920 x1200)
Lente SX930: F = 2,1 a 2,63; f = 21,7 a 34,64 mm;
SU931: F = 2,45 a 3,07; f = 15,78 a 25,12 mm
Tamaño de la pantalla de
proyección
SX930: 60 pulg. a 300 pulg.;
SU931: 60 pulg. a 240 pulg.
Lámpara 465 W
Especificaciones eléctricas
Compatibilidad PC: 640 x 480 a 1600 x1200
Vídeo: NTSC, PAL, SECAM, YPbPr (480i/480p/
576i/576p/720p/1080i/1080p), HDTV (720p/1080i/
1080p)
Espacio de color Tip. = 60% NTSC
Te r m i n a l e s
Entrada RGB analógico: D-Sub de 15 patillas (hembra) x1
HDMI (V. 1,4a) x2
MHL (V. 2,1) x1 (compartido con entrada HDMI)
S-Vídeo: Mini DIN de 4 patillas x1
Componente de vídeo (Y/CB/CR, Y/PB/PR) x1
(compartido con entrada RGB)
Vídeo compuesto x1
Entrada de audio RCA x1;
Entrada de audio de PC x1; Micrófono x1
RJ45 LAN x1 (Solo mando)
Salida RGB analógico: D-Sub de 15 patillas (hembra) x1
Salida de audio x1
USB (Tipo-A) x1
Altavoz: 10W x2
Control Conector en serie: RS232 de 9 patillas (macho)
USB (Tipo mini B) x1
Receptor IR x2
LAN x1 (RJ45)
Disparador de 12 V CC x1 (máx. 0,5 A)
Características generales
Peso del proyector <8,5 kg (18,74 lbs)
Alimentación 100-240 V de CA; 7,1 A, 50-60 Hz
Consumo de energía Máx. 694 W; en espera < 0,5 W; Espera red < 3 W
Temperatura de funcionamiento 0°C a 40°C (sin condensación)
Humedad de funcionamiento 10% - 90% (sin condensación)
Especificaciones
(ES)
SX930_QSG.fm Page 15 Friday, July 17, 2015 8:20 AM

16
Todas as especificações estão sujeitas a alteração sem aviso prévio.
Ópticas
Sistema de projecção Sistema Single-chip DLP™
Chip DMD SX930: 0,7" DLP (1024 x768);
SU931: 0,67" DLP (1920 x1200)
Lente SX930: F = 2,1 a 2,63, f = 21,7 a 34,64 mm;
SU931: F = 2,45 a 3,07, f = 15,78 a 25,12 mm
Tamanho de ecrã de projecção SX930: 60" a 300" ; SU931: 60" a 240"
Lâmpada 465 W
Eléctricas
Compatibilidade Computador: 640 x 480 a 1600 x1200
Video: NTSC, PAL, SECAM, YPbPr (480i/480p/576i/
576p/720p/1080i/1080p), HDTV (720p/1080i/1080p)
Espaço de Cor Tip. = 60% NTSC
Te r m i n a i s
Entrada RGB Analógico: D-sub 15 pinos (fêmea) x1
HDMI (V. 1,4a) x2
MHL (V. 2,1) x1 (partilhado com entrada HDMI)
S-Video: Mini DIN 4 pinos x1
Vídeo Componente (Y/CB/CR, Y/PB/PR) x1
(partilhado com entrada RGB)
Vídeo Composto x1
Entrada áudio RCA x1; Entrada áudio PC x1
Microfone x1
RJ45 LAN x1 (Controlo apenas)
Saída RGB Analógico: D-sub 15 pinos (fêmea) x1
Saída Áudio x1
USB (Tipo A) x1
Altifalante: 10 W x2
Controlo Conector de Série: RS232 9 pinos (macho)
USB (Tipo Mini B) x1
Receptor IR x2
LAN x1 (RJ45)
Interruptor 12 V DC x1 (Máx. 0,5 A)
Características gerais
Peso do projector <8,5 kg (18,74 lbs)
Energia VAC 100-240V, 7,1 A, 50-60Hz
Consumo de energia Máx. 694 W; Em espera < 0,5 W;
Suspensão em rede < 3 W
Temperatura de funcionamento 0°C a 40°C (sem condensação)
Humidade de funcionamento 10% - 90% (sem condensação)
(PT)
Especificações
SX930_QSG.fm Page 16 Friday, July 17, 2015 8:20 AM

17
Alla specifikationer kan ändras utan föregående meddelande.
Optik
Projektorsystem DLP™-system med enkel krets
DMD-krets SX930: 0,7" DLP (1024 x468);
SU931: 0,67" DLP (1920 x1200)
Lins SX930: F=2,1 till 2,63, f= 21,7 till 34,64 mm;
SU931: F=2,45 till 3,07, f= 15,78 till 25,12 mm
Skärmstorlek SX930: 60" till 300" ; SU931: 60" till 240"
Lampa 465 W
El
Kompabilitet PC: 640 x 480 till 1600 x1200
Video: NTSC, PAL, SECAM, YPbPr (480i/480p/576i/576p/
720p/1080i/1080p), HDTV (720p/1080i/1080p)
Färgområde Ty p. = 6 0 % N T S C
Kontakter
Ingångar Analog RGB: D-Sub (hona) med 15 stift x1
HDMI (V. 1,4a) x2
MHL (V. 2,1) x1 (delar ingång med HDMI)
S-Video: Mini DIN 4-stift x1
Komponentvideo (Y/CB/CR, Y/PB/PR) x1 (delad med RGB)
Kompositvideo x1
RCA-ljudingång x1
PC-ljudingång x1
Mikrofon x1
RJ45 LAN x1 (Endast kontroll)
Uttag Analog RGB: D-Sub (hona) med 15 stift x1
Ljudutgång x1
USB (Typ A) x1
Högtalare: 10W x2
Kontroll Serieanslutning: RS232 9-stifts (hane)
USB (Typ Mini B) x1
IR-mottagare x2
LAN x1 (RJ45)
12 V DC-utlösare x1 (Max. 0,5 A)
Allmänna egenskaper
Projektorns vikt <8,5 kg (18,74 lbs)
Av/på VAC 100-240V, 7,1 A, 50-60Hz
Strömförbrukning Max. 694 W; Viloläge < 0,5 W; Nätverksviloläge < 3 W
Driftstemperatur 0°C till 40°C (icke-kondenserande)
Driftsfuktighet 10 - 90 % (icke-kondenserande)
Specifikationer
(SV)
SX930_QSG.fm Page 17 Friday, July 17, 2015 8:20 AM

18
Все характеристики могут быть изменены без предварительного уведомления.
Оптические характеристики
Система проектирования Система Single-chip DLP™
DMD чип SX930: 0.7" DLP (1024 x 768);
SU931: 0.67" DLP (1920 x 1200)
Объектив SX930: F = 2.1 - 2.63, f = 21.7 - 34.64 мм;
SU931: F = 2.45 - 3.07, f = 15.78 - 25.12 мм
Размер экрана проецирования SX930: 60" - 300" ; SU931: 60" - 240"
Лампа 465 Вт
Электрические характеристики
Совместимость ПК: 640 x 480 - 1600 x 1200
Видео: NTSC, PAL, SECAM, YPbPr (480i/480p/576i/
576p/720p/1080i/1080p), HDTV (720p/1080i/1080p)
Цветовое пространство Тип. = 60% NTSC
Терминалы
Вход Аналоговый RGB 15-контактный D-sub (гнездо) x 1
HDMI (V. 1.4a) x 2
MHL (V. 2.1) x 1 (совместно со входом HDMI)
S-Video: 4-контактный разъем Mini DIN x 1
Компонентное видео (Y/CB/CR, Y/PB/PR) x 1
(вместе сRGB входом)
Композитное видеосигнал x 1
Аудиовход RCA x 1
Аудиовход ПК x 1
Микрофон x 1
RJ45 LAN x 1 (только управление)
Выход Аналоговый RGB 15-контактный D-sub (гнездо) x 1
Аудиовыход x 1
USB (тип A) x 1
Динамик: 10 Вт x 2
Управление Последовательный разъем: RS232 9 контактный
(штырьковый)
USB (тип Mini B) x 1
ИК-приемник x 2
LAN x 1 (RJ45)
Переключатель 12 Вx 1 (макс. 0,5 A)
Общие характеристики
Вес проектора <8,5 кг (18,74 фунта)
Питание Вперем. тока 100-240В, 7,1 A, 50-60Гц
Энергопотребление Макс. 694 Вт; Режим ожидания < 0,5 Вт;
режим ожидания сети < 3 Вт
Рабочая температура 0 °C ~ 40 °C (без конденсации)
Рабочая влажность 10% ~ 90% (без конденсации)
(RU)
Технические характеристики
SX930_QSG.fm Page 18 Friday, July 17, 2015 8:20 AM

19
Alle specificaties kunnen zonder voorafgaande kennisgeving worden gewijzigd.
Optisch
Projectiesysteem Single-chip DLP™-systeem
DMD chip SX930: 0,7" DLP (1024 x768);
SU931: 0,67" DLP (1920 x1200)
Lens SX930: F = 2,1 tot 2,63, f = 21,7 tot 34,64 mm;
SU931: F = 2,45 tot 3,07, f = 15,78 tot 25,12 mm
Geprojecteerde schermgrootte SX930: 60" tot 300" ; SU931: 60" tot 240"
Lamp 465 W
Electrisch
Compatibiliteit PC: 640 x 480 tot 1600 x1200
Video: NTSC, PAL, SECAM, YPbPr (480i/480p/576i/
576p/720p/1080i/1080p), HDTV (720p/1080i/1080p)
Kleurruimte Ty p . = 6 0 % N T S C
Aansluitingen
Ingangen Analoog RGB: D-sub 15-pin (contrastekker) x1
HDMI (V. 1,4a) x2
MHL (V. 2,1) x1 (gedeeld met HDMI-ingang)
S-Video: Mini DIN 4-pin x1
Component video (Y/CB/CR, Y/PB/PR) x1
(gedeeld met RGB-ingang)
Composite video x1
RCA Audio-in x1; PC Audio-in x1
Microfoon x1
RJ45 LAN x1 (alleen besturing)
Uitgang Analoog RGB: D-sub 15-pin (contrastekker) x1
Audio uit x1
Usb (Type-A) x1
Luidspreker: 10W x2
Bediening Seriële aansluiting: RS232 9-pin (male)
Usb (mini B-type) x1
IR-ontvanger x2
LAN x1 (RJ45)
12 V gelijkspanningtrigger x1 (max. 0,5 A)
Algemene kenmerken
Projectorgewicht <8,5 kg (18,74 lbs)
Energie VAC 100-240V, 7,1 A, 50-60Hz
Stroomverbruik Max. 694 W; stand-by < 0,5 W; netwerkstand-by < 3 W
Bedrijfstemperatuur 0°C tot 40°C (zonder condens)
Omgevingsvochtigheid 10% - 90% (zonder condens)
Specificaties
(NL)
SX930_QSG.fm Page 19 Friday, July 17, 2015 8:20 AM
