Specifications
Projection System
Epson 3LCD, 3-chip technology
Projection Method
Front/rear/ceiling mount
Driving Method
Epson Poly-silicon TFT Active Matrix
Pixel Number
786,432 (1024 x 768) x 3
White Light Output1
4000 lumens (ISO 21118 Standard)
Color Light Output1
4000 lumens
Aspect Ratio
16:10
Native Resolution
1024 x 768 (XGA)
Resize Support
640 x 480 (VGA), 800 x 600 (SVGA),
1024 x 768 (XGA) ,1152 x 864 (SXGA),
1440 x 900 (WSXGA), 1680 x 1050 (WSXGA+),
1400 x 1050 (SXGA+), 1600 x 1200 (UXGA)
Lamp Type
E-TORL 230 W UHE
Lamp Life2
Up to 3500 hours (ECO Mode)
Up to 2500 hours (Normal Mode)
Throw Ratio Range
1.62 – 2.61
Size (projected distance)
30" – 300" 16:10 aspect (0.76 – 7.62 m)
Keystone Correction Manual
Vertical: ± 30 degrees, (± 45 manual)
Horizontal ± 20 degrees, (± 30 manual)
USB Plug ’n Play
USB Plug ’n Play for Windows®2000 or later
Other Connectivity
Mac®compatible via DVI to VGA adapter
(not included)
Contrast Ratio
Up to 2000:1
Color Reproduction
16.77 million colors
Projection Lens
Type
Powered focus
Manual (optical) zoom
F-number Focal Length
1.75 – 2.42 (24 mm – 38.2 mm)
Zoom Ratio
Optical zoom 1.0 – 1.6
Other
Display Performance
NTSC: 480 lines
PAL: 560 lines
(Depends on observation of the multi-burst
pattern)
Input Signal
NTSC/NTSC4.43/PAL/M-PAL/N-PAL/
PAL60/SECAM
Interfaces
Computer/component video: D-sub 15 pin x 1
S-video: Mini DIN x 1
Composite video: RCA x 1
USB connector: Type-B x 1 (USB display and
mouse/keyboard control)
Serial: RS-232c x 1
Operating Temperature
41 ˚ to 95 ˚F (5 ˚ to 35 ˚C)
Power Supply Voltage
100 – 240 V ±10%, 50/60 Hz
Power Consumption
317 W (Normal Mode)
7.2 W Standby (Communication On)
0.2 W Standby (Communication Off)
Fan Noise
29 dB (ECO Mode)
37 dB (Normal Mode)
Security
Kensington®- style lock provision, security
anchor bar
Dimensions (W x D x H)
Including feet: 14.1" x 10.12" x 3.74"
Excluding feet: 14.1" x 10.12" x 3.4"
Weight: 7.82 lb
Remote Control
Features
Search, comp, video, USB, LAN, power, aspect,
color mode, volume, e-zoom, A/V mute, freeze,
menu, page up and down, help, auto, mouse
functions, user, ID num, pointer, esc, enter
Operating Angle
Right/left: ± 30 degrees
Upper/lower: ± 30 degrees
Operating Distance
26' (8 m)
Support
The Epson ConnectionSM
Pre-sales support (U.S. and Canada):
800-463-7766
Internet website: www.epson.com
Service Programs
Two-year projector limited warranty, Epson
Road Service program, Epson PrivateLine®
dedicated toll-free support and 90-day lamp
limited warranty
What’s In The Box
Power cord, computer cable (VGA), USB cable,
projector remote control, batteries, user manual
CD, projector software CD, Quick Setup Sheet,
PrivateLine support card, and password
protection sticker
Accessory Part Numbers
Universal projector ceiling mount ELPMBPJF
Advanced projector ceiling mount ELPMBPRG
High-security projector ceiling mount ELPMBATA
Adjustable suspended ceiling
channel kit ELPMBP01
False ceiling plate kit ELPMBP02
Structural round ceiling plate ELPMBP03
Adjustable extension column
(pipe) 8" – 11" ELPMBC01
Component to VGA video cable ELPKC19
50" portable screen ELPSC06
80" portable pop-up screen ELPSC08
Duet™ screen ELPSC80
Epson DC-06 document camera V12H321001
Kensington security lock ELPSL01
Distribution amplifier ELPDA01
Genuine Epson lamp V13H010L53
Replacement air filter V13H134A24
Packaging Specifications
Epson VS400
Dimensions 20.6" x 15.4" x 9.1" (W x D x H)
Weight 14.8 lb
Genuine Epson Lamp
Dimensions 6.1" x 5.4" x 5.5" (W x D x H)
Weight 0.8 lb
Master Carton
Dimensions 28.2" x 12.9" x 6.4" (W x D x H)
Weight 9.1 lb
Units Per Master Carton 10
Air Filter Set
Dimensions 4.7" x 3.3" x 1.8" (W x D x H)
Weight 0.1 lb
Master Carton
Dimensions 9.9" x 7.1" x 5.3" (W x D x H)
Weight 1.0 lb
Units Per Master Carton 10
Epson VS400
Multimedia Projector
Product Name Product Code UPC
Epson VS400 V11H326020 0 10343 88005 4
Genuine Epson Lamp V13H010L53 0 10343 87483 1
Replacement Air Filter V13H134A24 0 10343 87484 8
Specifications and terms are subject to change without notice. Epson, E-TORL and Instant Off are registered trademarks, Epson Exceed Your Vision is a registered logomark and Better Products for a
Better Future is a trademark of Seiko Epson Corporation. PrivateLine is a registered trademark, Duet is a trademark and Epson Connection is a service mark of Epson America, Inc. All other product and
brand names are trademarks and/or registered trademarks of their respective companies. Epson disclaims any and all rights in these marks. Copyright 2010 Epson America, Inc. CPD-32769 7/10
Epson America, Inc.
3840 Kilroy Airport Way, Long Beach, CA 90806
Epson Canada, Ltd.
3771 Victoria Park Avenue, Toronto, Ontario M1W 3Z5
www.epson.com
www.epson.ca
1 Light output varies depending on modes (color and white light output). White light output measured using ISO 21118 standard.
2 Lamp life will vary depending upon mode selected, environmental conditions and usage. Lamp brightness decreases over time.
3 Data source: ProjectorCentral.com, Jan. 2010. Average of 910 shipping models, for which manufacturers provided lumens and total power data, all resolutions and brightness levels.
4 See our website for convenient and reasonable recycling options at www.epson.com/recycle
5 SmartWay is an innovative partnership of the U.S. Environmental Protection Agency that reduces greenhouse gases and other air pollutants and improves fuel efficiency.
FPO
Video S-video
Computer 1
USB (Type B) Rear IR Port
Power

T
h
e
b
e
s
t
s
e
l
l
i
n
g
p
r
o
j
e
c
t
o
r
s
i
n
t
h
e
w
o
r
l
d
Epson Projectors
Epson VS400
MULTIMEDIA PROJECTOR
The Epson VS400 is an unbeatable value in multimedia projectors — one with outstanding image quality. Ideal
for conference room tables or AV carts, it offers sharp, ultra-bright performance in virtually any setting with
4000 lumens color light output, 4000 lumens white light output1and XGA resolution. Whatever you choose
to project, this brilliant performer delivers colorful, detailed images thanks to Epson’s innovative 3LCD, 3-chip
technology. With USB Plug ‘n Play connectivity, just plug in a standard USB cable and instantly view your
images on both the screen and your PC, simultaneously. The VS400 is also equipped with a long-life E-TORL®
lamp that lasts up to 3500 hours.2The Epson VS400 delivers both cost efficiency and brilliant light output —
all from one cost-effective performer.
Brilliant image quality — native XGA (1024 x 768) resolution
Ultra-bright — 4000 lumens color light output and 4000 lumens white light output1
Ultra-bright performance at an unbeatable value.

T
h
e
b
e
s
t
s
e
l
l
i
n
g
p
r
o
j
e
c
t
o
r
s
i
n
t
h
e
w
o
r
l
d
Epson Projectors
14.1"
3.74"
10.12"
The best-selling projectors in the world.
Epson offers a wide range of high-quality projectors to meet almost any need. Built with image
quality and reliability in mind, Epson projectors enhance communication and inspire collaboration,
while offering a low total cost of ownership. From ultraportable projectors designed for educational
settings to boardroom-ready business projectors, Epson has the model made for you.
Epson VS400 MULTIMEDIA PROJECTOR
3LCD technology — for quality and color
that’s beyond amazing
Innovative technology with proven reliability
• 3chipsfortrue-to-life,vibrantcolor
• 25%lesselectricityrequiredperlumenofbrightness
when compared to 1-chip DLP projectors3
• Road-testedreliabilityfromacompanywithover20 
years of experience
Red
Green
Blue
Screen
Lens
Prism
Mirror LCD chips
Mirror
Dichroic mirror
Dichroic mirror
Lamp
Mirror
Energy-efficient E-TORL lamp, exclusively
from Epson
• Deliversmorelumensperwattandlastsupto3500hours2
• E-TORLtechnologyprolongslamplifebyminimizingpower
 consumptionandmaximizinglightefciency
• E-TORLlampsmaximizeyour   
presentation time, while
 minimizingyourcosts
For more information on Epson’s environmental
programs, go to eco.epson.com
Eco Features
• Energy-efcient3LCDlightengine3
• Energy-efcientE-TORLlamp
• Designedtoberecycled4
• RoHScompliant
• EpsonAmerica,Inc.isaSmartWaySM Transport Partner5
Compact and portable design
3LCD technology
E-TORL lamp

Precision control
USB Plug ‘n Play instant setup
• NomorecomputerfunctionkeysorbulkyVGAcables
• JustpluginastandardUSBcableandinstantlyproject
video with audio from your PC!
• USBPlug‘nPlayalsoenablesyoutomaintaincontrol
over your presentation with the page up/page down
function on the remote control
Fast, easy setup and control
• Instant Off®— no cool-down time required, so it’s ready
to shut down when you are
• A/V Mute Slide — control your presentation; it’s right at
your fingertips
• Sleep Mode — set from 1 to 30 minutes to save energy
when the A/V Mute Slide is closed or no signal is detected
• 1.6x optical zoom — offers great positioning flexibility
• Direct Power Off/On — power the projector on and off
with the flip of a wall switch
Amazing light output
• 4000lumenscolorlightoutputand
4000 lumens white light output1
• Highcolorlightoutputforbright, 
balanced, colorful images
• Whitelightoutputthat’smeasuredusing  
ISO 21118 (a more rigid standard than the
 outdatedANSIlumensratingusedby  
competitive products)
T
h
e
b
e
s
t
s
e
l
l
i
n
g
p
r
o
j
e
c
t
o
r
s
i
n
t
h
e
w
o
r
l
d
Epson Projectors
Epson VS400 Features
• Brilliantdetail — XGA (1024 x 768) resolution and
up to 2000:1 contrast ratio
• Easypictureadjustmentsandgreaterpositioning
 exibility — 1.6x optical zoom with powered focus,
controllable via the remote or RS-232
• Addedsecurityinanyenvironment — convenient
metal anchor bar, control panel lockout
• Easymaintenance—easy,side-loadinglampand 
one-touch filter replacement
• Outstandingsupport—two-yearlimitedwarranty
Brilliant image quality and detail
Resolutiondenesthelevelofdetailanddepthyou’ll
seeinaprojectedimage.It’smeasuredasthenumber
ofpixelswidebythenumberofpixelshigh.Themore
pixels,thebettertheimagequality.
Built-in closed captioning
• Helpssavemoney—noneedtopayforanadditional 
decoder and its installation
• Effectiveandeasytouse—easilyenabledor  
disabled through the projector remote or menu
800 x 600
Meets basic
projection
needs
1024 x 768
Ensures
sharper detail
1280 x 800
Offers the highest
quality and is ideal
for widescreen
(16:10) display
Highcolorlightoutput Lowcolorlightoutput
Actual photographs of images taken from two competing projectors run in default mode.
Price, resolution and brightness (white light output) are the same for both projectors.
