Sony SRX-R815P User manual

Digital Cinema
Projector Package
Operating Instructions
Before operating the unit, please read this manual and supplied Safety Regulations
thoroughly, and retain them for future reference.
SRX-R815P/SRX-R810P
4-725-921-01(1)
© 2017 Sony Corporation

2
Table of Contents
Please Read This First .............................................. 3
Notations Used in This Guide ................................ 3
Manual Structure ................................................... 3
About License ........................................................ 3
USB HDD and USB Memory Devices That can be
Used on INGEST PORT 1/2 of This Unit ........... 3
Recognized Folder Names ..................................... 3
On Security ............................................................ 3
Water Temperature of a Chiller .............................. 3
Coolant Water ........................................................ 4
Prolonged Storage or Storage in the Winter .......... 4
Chiller Inspection ................................................... 4
Overview
Part Names and Functions ....................................... 5
Digital Cinema Projector SRX-R815/
SRX-R810 ........................................................... 5
Digital Cinema Server XCT-S10 ........................... 7
Touch Panel Monitor LKRA-007 .......................... 9
Main Screen ......................................................... 10
Items to Check
Startup ..................................................................... 12
Turning on the Projector’s Main Power ............... 12
Starting up the Server .......................................... 12
Logging Into the System ...................................... 12
Starting the Projector ........................................... 14
Rebooting the System ............................................. 14
Shutting Down the System ..................................... 15
Operations
Sequence of Operations .......................................... 16
Ingesting DCP .......................................................... 16
Ingesting from HDD via USB Connector ............ 16
Ingesting from HDD via CRU DATAPORT ........ 18
Ingesting via Network .......................................... 18
Ingesting KDM ........................................................ 19
Ingesting from a USB Flash Drive ....................... 19
Ingesting from a Network Folder ......................... 20
Playing Back CPL ................................................... 21
Calling up Screen Adjustment Data .................... 21
Selecting a CPL ................................................... 21
Playing Back CPL ................................................ 22
Creating an SPL ...................................................... 23
Creating an SPL ................................................... 23
Setting an Intermission in the SPL ...................... 25
Triggering SPL Playback Using GPI Signals ...... 26
Playing Back a SPL ................................................. 27
Selecting an SPL .................................................. 27
Playing Back an SPL ........................................... 27
Creating a Schedule ................................................ 27
Creating a Schedule ............................................. 27
Importing/Exporting Schedules ........................... 28
Projecting Images Using an External Playback
Device ....................................................................... 29
Manually Controlling Theater Facilities ............... 30
Others
Attaching and Removing the Lens ........................ 31
Changing the Lens in Lens Replacement
Mode .................................................................. 31
Changing the Lens while the Power is Turned
Off ...................................................................... 31
Removing the Lens .............................................. 32
Attaching the Lens ............................................... 32
Replacing the Lens Using the Lens Change
Table ......................................................................... 34
How to Read the Indicators ................................... 37
Troubleshooting ....................................................... 38
Specifications ........................................................... 40
Digital Cinema Projector SRX-R815 .................. 40
Digital Cinema Projector SRX-R810 .................. 40
Digital Cinema Server XCT-S10 ......................... 41
Touch Panel Monitor LKRA-007 ........................ 41

3
Please Read This First
Notations Used in This Guide
In this guide, SRX-R815/SRX-R810 Digital Cinema
Projector is referred to as the “projector”, XCT-S10 Digital
Cinema Server is referred to as the “server”, and LKRA-
007 Touch Panel Monitor is referred to as the “touch panel
monitor.”
Manual Structure
The following manuals are provided for the SRX-R815P/
SRX-R810P depending on the application.
Safety Regulations
This includes safety instructions and precautions for using
the SRX-R815P/SRX-R810P.
Installation Manual
This includes instructions on how to install the unit,
information on default settings, and instructions on how to
adjust the unit. Be sure to refer to this manual whenever
you need to change settings or readjust the unit after
installation.
Operating Instructions (this guide)
This includes instructions for screening controls in a
theater, how to create a screening schedule, how to change
lenses, projector part names, and product specifications.
Be sure to refer to this guide for instructions on daily
usage.
Maintenance Manual
This includes information such as instructions on periodic
inspection, maintenance, and cleaning.
Service Manual
This is intended for use by service personnel and includes
information on diagnosing malfunctions and instructions
on repair.
About License
Refer to “Software License Agreement.”
USB HDD and USB Memory Devices
That can be Used on INGEST PORT
1/2 of This Unit
USB HDD and USB memory devices that can be used on
INGEST PORT 1/2 of this unit are as follows.
• USB 2.0/3.0 (bus power capacity up to 1 A)
• Do not insert a bus-powered USB HDD and a USB
memory device into the two ports at the same time.
• USB HDD compatible file system
ext2, ext3
(Operation is not guaranteed for all types of USB HDD and
USB memory devices.)
Recognized Folder Names
Regarding the external directories (USB HDD, USB
memory devices, network folders, etc.) that are connected
to the unit, only folder names that consist of alphanumeric
characters will be recognized by the unit.
On Security
• SONY WILL NOT BE LIABLE FOR DAMAGES OF
ANY KIND RESULTING FROM A FAILURE TO
IMPLEMENT PROPER SECURITY MEASURES ON
TRANSMISSION DEVICES, UNAVOIDABLE DATA
LEAKS RESULTING FROM TRANSMISSION
SPECIFICATIONS, OR SECURITY PROBLEMS OF
ANY KIND.
• Depending on the operating environment, unauthorized
third parties on the network may be able to access the
system.
We strongly recommend configuring all of the
passwords for security purposes.
For details on configuring all the passwords, refer to the
Installation Manual.
• Do not browse any other website in the Web browser
while making settings or after making settings. Since the
login status remains in the Web browser, close the Web
browser when you complete the settings to prevent
unauthorized third parties from using the unit or harmful
programs from running.
Water Temperature of a Chiller
Set the water temperature of a chiller according to the
room temperature as follows, and keep the room humidity
below 75%.
• Room temperature below 25°C (77°F): set the water
temperature to 20°C (68°F)
• Room temperature between 25°C and 30°C (77°F and
86°F): set the water temperature to 25°C (77°F)
• Room temperature between 30°C and 35°C (86°F and
95°F): consult qualified Sony service personnel

4
Adjustment of the projector settings is necessary according
to the water temperature.
When the water temperature of the chiller has been
changed, readjust the CSC settings.
For further details, refer to the “Maintenance Manual.”
Caution
Do not set the water temperature to a temperature 5°C
(41°F) or less than that of room temperature. A difference
in temperature causes condensation. It may cause a
malfunction of the projector, or moisten peripheral devices.
If condensation occurs, stop the projector and chiller
immediately, and turn the power off. Do not turn the power
on again before the projector and chiller are completely
dry.
Coolant Water
Use neutral distilled water with a pH range of 6.5 to 7.5.
Caution
Do not use tap water. It may cause pipe corrosion.
Replace the coolant water once every 3 months.
When replacing it, drain the water from the chiller without
disconnecting the projector from the chiller.
Caution
If the coolant water is not replaced, mold occurs in the pipe
due to decomposing (impurity-containing) water. It causes
clogs, corrosion, and rusty pipes.
Prolonged Storage or Storage in the
Winter
Even in temperate regions in winter, water in the pipe may
freeze, and it may result in pipe failure.
If the temperature in the storage area is going to be less
than 5°C (41°F), consult qualified Sony service personnel
for proper preventive measures against freezing.
If water in the pipe freezes, do not use the projector, and
ask for a repair.
Using antifreeze solution generally prevents from freezing.
However, the projector may not achieve its cooling
performance if the antifreeze solution is used.
For further details, contact qualified Sony service
personnel.
Chiller Inspection
To ensure the proper operation of the chiller, check its
water level regularly. If the chiller stops operation, the
projector also stops.
Trademarks
• The terms HDMI and HDMI High-Definition
Multimedia Interface, and the HDMI Logo are
trademarks or registered trademarks of HDMI Licensing
LLC in the United States and other countries.
• Other products or system names appearing in this
document are trademarks or registered trademarks of
their respective owners.
Further, the ® or ™ symbols are not used in the text.
• Reproduction or duplication, in whole or part, of the
operation manual supplied with the system without the
authorization of the right holder is prohibited under
copyright law.
• Sony assumes no responsibility for damages, loss of
income, or any claims from a third party arising out of
use of the system.
• Note that the specifications of the system are subject to
change for improvement without prior notice.

5
Overview
Part Names and
Functions
Digital Cinema Projector SRX-R815/
SRX-R810
Front
aLens fixing lever
Locks/unlocks the lens.
For further details, see “Attaching and Removing the
Lens” (page 31), and “Replacing the Lens Using the
Lens Change Table” (page 34).
bLens attachment part
Used to attach a separately-sold lens.
For further details, see “Attaching and Removing the
Lens” (page 31), and “Replacing the Lens Using the
Lens Change Table” (page 34).
Rear
aStatus lights
Shows the status of the projector.
For further details, see “How to Read the Indicators”
(page 37).
bEMERGENCY switch
Forcibly turns off the projector (equipped with a
cooling function).
cSTATUS MESSAGE window
Displays various messages.
dStatus indicators
Shows the status of the projector.
For further details, see “How to Read the Indicators”
(page 37).
ePower switch
Turns the projector’s main power on (|) or off (a).
When turning the power off
Wait for the projector’s cooling process to complete
before turning the power switch off.
For further details, see “Shutting Down the System”
(page 15).
Touch Panel Monitor (page 9)

6
Right side
aVentilation holes (intake)
bVentilation holes (exhaust)
Left side
aVentilation holes (intake)
bVentilation holes (intake)/air filter
For details on air filter cleaning, refer to the
“Maintenance Manual.”
Connector block
aNETWORK connector (RJ-45 modular jack)
Used to connect to the server’s PRJ connector with the
supplied LAN cable.
bINTER LOCK connector/Remote connector (D-
sub 15 pin, female)
For further details, refer to the “Installation
Manual.”
cRS-232C connector (D-sub 9 pin, female)
For service use.
dAUDIO OUTPUT BAL/UNBAL (audio output
BAL/UNBAL) (AES/EBU) connector (D-sub 25
pin, female)
For connecting to an audio signal processor.
eSTATUS 1/2 (Status 1/2) indicator
Shows the status of the projector.
For further details, see “How to Read the Indicators”
(page 37).
fSERVER connector
Used to connect to the server with the supplied PCI
express cable (2 m).
Connector block
Integrated Media Block (IMB)

7
gHDMI IN 1/2 (HDMI input 1/2) connector
For HDMI signal input.
For details on signal format, see “HDMI signals”
(page 42).
Digital Cinema Server XCT-S10
Front
aPOWER indicator
Shows the status of the server’s power.
For further details, see “How to Read the Indicators”
(page 37).
bSYSTEM SW switch
Starts up the server.
c(HDD) 1/2 indicator
Shows the status of the HDD.
For further details, see “How to Read the Indicators”
(page 37).
dVentilation holes (intake)/air filter
For details on air filter cleaning, refer to the
“Maintenance Manual.”
eINGEST PORT 1/2 connector
For inserting HDD or USB memory to ingest DCP/
KDM.
These can only be used for a USB HDD or USB
memory device.
For further details, see “Ingesting from HDD via
USB Connector” (page 16), and “Ingesting from a
USB Flash Drive” (page 19).
fCRU DATAPORT
For inserting HDD to ingest DCP/KDM.
A CRU DATAPORT carrier is necessary to use the
CRU DATAPORT. For further details, contact
qualified Sony service personnel.

8
Rear
aGPIO 1/2 connector (D-sub 25 pin, female)
For connecting to an external device.
For further details, refer to the “Installation
Manual.”
bGPIO 3/4 connector (D-sub 15 pin, female)
For connecting to an external device.
For further details, refer to the “Installation
Manual.”
cIMB connector
Used to connect to the projector with the supplied PCI
express cable.
dAUDIO CTRL connector (D-sub 9 pin, male)
Used to control audio devices.
eFan Unit
An exhaust fan.
fPower unit (-)
Connects with the power cord.
gPower unit B mount
For use with separately-sold expansion power units.
With both power units A and B attached, each can be
used as a redundant power source.
To connect a power unit, contact qualified Sony
service personnel.
hSPARE connector (RJ-45 modular jack)
For future expansions.
iDATA connector (RJ-45 modular jack)
Used to connect to a theater network (LAN) and allow
linking and data transfer with other systems.
Be sure to use a CAT6 or above for the LAN cable.
jCTRL connector (RJ-45 modular jack)
Used to connect to a theater network (LAN) and allow
linking and data transfer with other systems.
Be sure to use a CAT6 or above for the LAN cable.
kPRJ connector (RJ-45 modular jack)
Used to connect to the projector’s NETWORK
connector with the supplied LAN cable.
lVGA connector (D-sub 15 pin, female)
Used to connect to the touch panel monitor’s VGA
connector with the supplied VGA cable.
For connection instructions, refer to the “Installation
Manual.”
mTPC connector
Used to connect to the touch panel monitor’s TPC
connector with the supplied USB cable.
For connection instructions, refer to the “Installation
Manual.”
nUPS connector
Used to connect to an uninterruptible power supply
(UPS).

9
Touch Panel Monitor LKRA-007
Right side
aMENU switch
Displays the menu.
bv / Vswitches
Used for moving the menu and setting new values.
cSELECT switch
Used for selecting the menu and items.
d1(Power) switch
Press this to turn the power on.
Press this again to turn the power off.
Caution
• When turning the power on, do not touch the touch
panel monitor screen. Doing so may prevent normal
operations after start-up.
• When the power is on, do not remove the touch
panel monitor cable.
eMonitor stand
This is equipped with a tilt mechanism.
The monitor’s position can be adjusted in the up,
down, left, and right directions.
Bottom
aVGA connector (D-sub 15 pin, female)
Used to connect to the server’s VGA connector with
the supplied VGA cable.
For connection instructions, refer to the “Installation
Manual.”
bRS-232C connector (D-sub 9 pin, female)
For service use.
cTPC connector
Used to connect to the server’s TPC connector with
the supplied USB cable.
For connection instructions, refer to the “Installation
Manual.”
dPower input connector
For connecting the supplied AC adapter.

10
Main Screen
aAuditorium number
If a computer is being used to control multiple
auditoriums via a network, the auditorium numbers
will be displayed. Touch the number to display the
auditorium selection dialog box, and then select the
auditorium to operate.
Caution
Multiple auditoriums can only be controlled via a
network when a Web browser is used on a computer
to operate this unit. Do not control multiple
auditoriums using the touch panel monitor.
bDate display
Displays the current date (server date).
cNext SPL title for screening
dSPL playback status
Displays the SPL playback status using the same
icons used for the playback control buttons.
For details on the buttons, see “Playing Back CPL”
(page 22).
eCurrent SPL title
fProgress bar
Displays the progress of the title currently being
screened by CPL or SPL frames.
gElapsed showing time
Displays an approximate time. Although there may be
a slight discrepancy in the units depending on system
conditions, this will not affect the actual screening.
hTime remaining until start of next SPL for
screening
iProjector status indicator / control button
Indicates the operation status of the projector.
When you tap the button, the “Projector Light
Control” screen appears allowing you to operate the
projector.
jJob display button
Tap the button to switch to the “Job Status” screen in
the [Library] tab.
kError display button
Displays the status of the device being controlled by
the server.
When you tap the button, the “Error History” screen
appears.

11
For details on the “Error History” screen, refer to the
“Maintenance Manual.”
Error: An error has occurred. (screening stops)
Warning: A non-fatal problem or error has occurred.
(screening continues)
Normal: The status is normal.
lLogin user name
Displays the login user name.
m(Power) button
This enables shutdown, or logout from the projection
system. (page 15)
nMain menu
This menu provides access to all the functions on this
unit. The following menus are also available.
[Status]: Monitors the title being screened.
For details on how to read the status, see “To
check installation/connections” (page 38).
[Schedule]: Creates a schedule. Manual playback can
also be performed here.
See “Creating a Schedule” (page 27).
[SPL]: Creates an SPL (Show Playlist).
See “Creating an SPL” (page 23).
[Library]: Manage DCP (Digital Cinema Package)
or KDM (Key Delivery Message).
See “Ingesting DCP” (page 16), and “Ingesting
KDM” (page 19).
[Configuration]: Adjusts various settings.
For details on indicators, refer to the
“Installation Manual.”
oPlayback mode display button
Displays the playback mode.
Tap the button to switch the playback mode.
Manual: Playback is performed manually.
Scheduled: Playback is performed using a schedule.
You can select the [Play Manually] checkbox to
perform playback manually even in schedule
mode.
pVersion information
Displays the version information of the projector.
qProjector information display
Displays information about the projector.
See “Calling up Screen Adjustment Data” (page 21),
“Manually Controlling Theater Facilities”
(page 30), “Attaching and Removing the Lens”
(page 31).
rShortcut button
Often-used functions are registered to this button.
Tap the button to activate a function.
Tip
The following operations can be carried out in
[Prepare].
• Turn on the light source
• Open the douser
• Cancel mute
• Cancel test pattern display
To register a function to the shortcut button, refer to
the “Installation Manual.”
sError information display
Displays the location and time an error occurred, an
explanation of the error and a solution.
When an error occurs, refer to [Solution] on the lower
left to deal with the problem.
When multiple errors or warnings have occurred, you
can check the next or previous warning by tapping [i]
or [I].
tPlayback control button
In manual playback mode, you can control playback.
For details, see “Playing Back CPL” (page 22).
The solution will be displayed here. Follow the
instructions to deal with the problem.

12
Items to Check
Startup
When starting up the projection system, turn on the
projector’s main power first, and then start up the server
and log in to the system.
Turning on the Projector’s Main
Power
Move the projector’s power switch on the rear to on ( |) to
turn on the power.
The power will turn on and the MAIN indicator and
LIGHT indicator will turn solid red when the projector
enters standby mode.
Starting up the Server
Press the SYSTEM SW switch on the server’s front to turn
it on.
The POWER indicator will blink green, and after start-up
is complete, it will turn solid green.
Once the server is on, the “Login” screen will be displayed
on the monitor.
Caution
• Do not start up the server with a USB devise inserted in
INGEST PORT1/2 connector on the front of the server.
The USB device may not be recognized.
• When starting-up the server, do not touch the touch panel
monitor screen. Doing so may prevent normal operations
of the touch panel monitor after start-up.
Logging Into the System
Caution
It is necessary to pre-register as a user to log in to the
projection system.
For further details, refer to the “Installation Manual.”
1 Tap your own user name in the user list, and then tap
the [Password] column.
A virtual keyboard for entering your password will be
displayed.
2 Enter your password, and then tap [Enter].
If you make a mistake when entering your password,
tap [BS] to delete the last character.
When the password is entered, it will be displayed
masked above the keyboard.
Tips
• Startup of the projection system will take some
time. Startup processes for the server continue even
after the user list appears. Lists, such as those for
ingested CPLs, will not appear until the startup
processing is complete.
• You can change your password.
See “To change your login password” (page 13).
The virtual keyboard will disappear, and asterisks (*)
will be entered in the [Password] column.

13
3 Tap [Login].
Once you log in to the system, the “Status” screen will
be displayed.
Proceed to “Starting the Projector” (page 14).
To change your login password
As a user, you can change your own password.
1 Tap the area where the user name is displayed at the
top right of the screen to display the “Login” screen,
and tap [Change Password].
A screen for changing your password will be
displayed.
2 Enter a new password, and then tap [OK].
Tap each field to display a virtual keyboard, and enter
the necessary information.
3 Tap [OK] when the confirmation screen appears.
Your password will be changed.
Changing the login user
1 Tap on the upper right of the screen.
2 Select [Logout], and then tap [OK].
3 Tap [OK] when the confirmation screen appears.
The “Login” screen will be displayed.
4 Change the user and log in.

14
Starting the Projector
Caution
The projector is not lit if a chiller is not working in a
prescribed condition. Start a chiller in advance.
When using a Sony-recommended chiller that is
communicating with the projector, set the chiller to
standby.
1 In the [Status] tab, tap [Auditorium], and then tap
[Projector] in the [Control] pane.
The “Projector Control” screen will be displayed.
2 Tap [Power On] in [Power/Light].
The MAIN indicator on the rear of the projector will
turn solid green, and the LIGHT indicator will blink
green.
When the projector turns on, its MAIN, LIGHT, and
IMB indicators will be solid green.
3 Tap [CLOSE] at the bottom of the screen to close the
“Projector Control” screen.
The above procedures complete preparations and
confirmation for using the projection system.
Rebooting the System
1 Tap on the upper right of the screen.
2 Select [Reboot], and then tap [OK].
3 Tap [OK] when the confirmation screen appears.
The server (including the IMB) reboots.
Tips
• The projector itself will not reboot.
• If the projector is lit, it will be turned off, and
entered the cooling state.

15
Shutting Down the
System
1 Tap on the upper right of the screen.
2 Select [Shutdown], and then tap [OK].
3 Tap [OK] when the confirmation screen appears.
The projection system will shut down.
The MAIN indicator and LIGHT indicator on the rear
of the projector will turn to blinking green while
cooling. Once cooling is complete, the LIGHT
indicator will turn to solid red. Leave the system as it
is at this point.
4 Once the MAIN and LIGHT indicators turn solid red,
and the IMB indicator begins blinking red, move the
power switch to off (a) to turn off the power.
Caution
If, after shutdown, the power switch on the rear of the
projector is not turned off and only the server is turned on,
the IMB on the projector will not power on. If this happens,
the IMB indicator will blink red. Turn the power switch
off, and then turn the power on again.

16
Operations
Sequence of Operations
The sequence of operations from receiving distributed
DCP to screening operations are shown below.
r
r
r
r
r
When screening via manual operations
When using a screening schedule
Ingesting DCP
This procedure ingests DCP, such as the main feature to be
screened, or previews, to the server.
Tips
• When DCP is encrypted, the KDM encryption key file is
necessary.
• Depending on the USB HDD type being used, the
following messages may be displayed on the center of
the screen. These do not indicate problems.
“Unable to mount Audio Disc”
“Unable to mount Utility_**USB HDD model
number**”
For details on ingesting KDM, see “Ingesting KDM”
(page 19).
Tip
When ingesting DCP/KDM, be sure to do so with the
power switches on the server and projector set to on. In
such cases, be sure to verify that the IMB indicator on the
projector is lit green.
DCP can be ingested in the following ways.
• Ingesting from HDD via USB Connector (page 16))
• Ingesting from HDD via CRU DATAPORT (page 18)
• Ingesting via Network (page 18)
Ingesting from HDD via USB
Connector
Caution
Do not start up the server with a USB devise inserted in
INGEST PORT1/2 connector on the front of the server.
The USB device may not be recognized.
1 Connect the HDD containing the DCP to the server’s
INGEST PORT 1/2 connector.
2 Tap the [Library] tab, and then tap [Library].
The “Library” screen will be displayed.
3 In the [External Folder] pane, select the following
terminals connected to the HDD, and then tap [Open].
• When connected to INGEST PORT 1 terminal,
select [Ingest_USB_1].
• When connected to INGEST PORT 2 terminal,
select [Ingest_USB_2].
Starting up (page 12)
Starting up the projection system.
Ingesting DCP (page 16)
Ingest distributed DCP to the server.
Ingesting KDM (page 19)
When DCP is encrypted, ingest the KDM (encryption key
file) necessary for playback.
Playing Back CPL (page 21)
Call up screen adjustment data and play back CPL to
confirm.
Creating an SPL (page 23)
Create an SPL to screen DCP in an auditorium.
Playing Back a SPL (page 27)
Select an SPL to screen.
Creating a Schedule (page 27)
Create a schedule to automatically
screen titles.

17
The content inside the HDD connected to INGEST
PORT 1/2 will be displayed.
However, folders with the following character strings
(regardless of case) will not appear.
bin, boot, dev, etc, home, initrd, lib, misc, opt, proc,
root, sbin, selinux, srv, tmp, sys, usr, var
4 Select the DCP ( ) to ingest, and then tap [Ingest].
Tips
• Select the CPL ( ) within DCP and tap [Ingest]
to ingest the selected CPL only as new DCP.
• To refresh the displayed content, tap .
The selected DCP will be ingested into the server.
Tap [OK] to close the message.
5 To continue ingesting multiple DCPs, repeat step 4.
The DCP ingest request will be registered as the
following job.
6 After DCP has been ingested, select the following
terminals connected to the HDD, and then tap
[Unmount].
• When connected to INGEST PORT 1 terminal,
select [Ingest_USB_1].
• When connected to INGEST PORT 2 terminal,
select [Ingest_USB_2].
You can now safely remove HDDs.
How to export ingested DCP
1 In the [External Folder] pane, select the export
destination.
2 In the [Local Folder] list, select a DCP to export, and
then tap [Export].
How to confirm progress of ingesting/
exporting DCP
You can tap [Job Status] in the [Library] tab to display the
“Job List” screen and check the progress and status of
ingestion.
The following operations are available for each button in
the [Job List] pane.
[Pause]: Suspends jobs
[Resume]: Reopens jobs
[Cancel]: Cancels jobs in progress.
[Remove]: Deletes jobs
Tip
If you pause a job and then remove it, the next job will
enter a paused state. Tap [Resume] to resume that job.

18
To check ingested DCP
Ingested DCP can be checked in the “Library” screen’s
[Local Folder] list.
Select [DCP] to display DCP ingested to the server in a list
in the [Current Auditorium] pane.
The following operations are available for each button in
the [Local Folder] list.
[Edit]: The name of the selected DCP can be changed.
[Details]: Detailed information on the selected DCP will
be displayed.
[Delete]: The selected DCP can be deleted.
Tip
To refresh the displayed content, tap .
Ingesting from HDD via CRU
DATAPORT
A CRU DATAPORT carrier is necessary to use the CRU
DATAPORT. For further details, contact qualified Sony
service personnel.
1 Insert the HDD containing DCP to the server’s CRU
DATAPORT.
2 For further instructions, follow steps 2to 6in
“Ingesting from HDD via USB Connector” (page 16)
to ingest DCP.
In step 3and 6, select [Ingest_SATA] in the [External
Folder] pane.
To remove the HDD
Perform the following to remove the HDD.
1Press the power button.
The LED blinks for a moment and then turns off.
2Verify that the LED is off, push the left side of the
handle, and remove the HDD.
Ingesting via Network
DCP stored on another server can be ingested via network.
Caution
To ingest DCP via network, it is necessary to register the
source device ahead of time.
For further details, refer to the “Installation Manual.”
To ingest DCP, follow steps 2to 5in “Ingesting from HDD
via USB Connector” (page 16).
In step 3, select the source device in the [External Folder]
pane.
1
2

19
Ingesting KDM
When DCP is encrypted, it is necessary to also ingest the
KDM encryption key file to the server.
When DCP is encrypted, a key icon will be displayed on
any CPL containing DCP.
DCP can be opened in the “Library” screen.
KDM can be ingested in the following ways.
• Ingesting from a USB Flash Drive (page 19)
• Ingesting from a Network Folder (page 20)
Ingesting from a USB Flash Drive
Caution
Do not start up the server with a USB devise inserted in
INGEST PORT1/2 connector on the front of the server.
The USB device may not be recognized.
1 Connect the USB flash drive containing the KDM to
the server’s INGEST PORT 1/2 connector.
2 Tap the [Library] tab, and then tap [Library].
The “Library” screen will be displayed.
3 In the [External Folder] pane, select the following
terminals connected to the USB memory device, and
then tap [Open].
• When connected to INGEST PORT 1 terminal,
select [Ingest_USB_1].
• When connected to INGEST PORT 2 terminal,
select [Ingest_USB_2].
The content on the USB memory device connected to
INGEST PORT 1/2 will be displayed.
4 Select the KDM ( ) to import, and then tap
[Ingest].
Tip
To refresh the displayed content, tap .
The selected KDM is ingested to the server.
Tap [OK] to close the message.
5 Confirm that the ingested KDM has been applied to
the DCP.
For further details, see “To confirm that KDM has
been applied” (page 20).
Tip
You can ingest KDM from the CRU DATAPORT. For
instructions, see steps 1to 2in “Ingesting from HDD via
CRU DATAPORT” (page 18), and steps 1to 4in
“Ingesting from a USB Flash Drive” (page 19). For steps
Key icon

20
on how to remove an HDD, see “To remove the HDD”
(page 18).
Ingesting from a Network Folder
If a KDM is copied to a preset network folder, it will be
automatically ingested.
For details on network folder settings, see the
“Installation Manual.”
Execute the following steps to ingest to a network folder
that has not been set.
1 Tap the [Library] tab, and then tap [Library].
The “Library” screen will be displayed.
2 Select a network folder, select the KDM you want to
ingest, and then tap [Ingest].
The selected KDM is ingested to the server.
Tap [OK] to close the message.
3 Check that the ingested KDM has been applied to the
DCP.
For details on operations, see “To confirm that KDM
has been applied” (page 20).
To confirm that KDM has been applied
1 In the [Library] tab’s “Library” screen, tap under
[Local Folder].
The displayed content will be refreshed.
2 Tap the desired DCP to open it and confirm that the
ingested KDM is displayed underneath the applicable
CPL.
When KDM has not been ingested, “No Key” will be
displayed.
To confirm the KDM time limit
After selecting the KDM radio button in the “Library”
screen, select a KDM in the [Local Folder] pane, select a
KDM to check, and then tap [Details] to check the period
of validity.
Deleting unnecessary KDM files
Tap [KDM Cleanup] to delete KDM that are not related to
DCP.
