BEP TS1 User manual
INST-TS1-V13
18/11/10
Page 1
TS1
Ultrasonic Tank Sender
Installation and Operating Instructions
For TS1 Firmware v3.8
INST-TS1-V13
18/11/10
Page 2
Table of Contents
1.FEATURES.......................................................................................................3
2.SPECIFICATIONS............................................................................................3
3.DIMENSIONS....................................................................................................4
4.MOUNTING AND INSTALLATION...................................................................5
5.WIRING.............................................................................................................9
6.PROGRAMMING AND SETUP.......................................................................10
7.PROBLEM SOLVING .....................................................................................10
8.FREQUENTLY ASKED QUESTIONS ............................................................11
Important TS1 Installation Issues
1. The sender must not be mounted closer than 150mm from the
centre of the sender to sides of the tank, baffles or other intrusions.
2. Only use on tanks greater than 200mm in depth.
3. Sender must be mounted parallel to the surface of the liquid.
4. Do not install on flexible tanks that may bulge/distort as fluid levels
change.
5. Check unit is calibrated to suit tank shape, depth and fluid type.
6. Make sure that sender protrusion is NOT in contact with any
object including sealants when mounted.
7. Use gasket and fittings as provided.
8. Mount above deepest point of the tank.
INST-TS1-V13
18/11/10
Page 3
1. Features
12V and 24V operation
Extremely low profile only 20mm high once mounted
Operating distance of 0mm to 2000mm maximum
Programmable tank dimensions via windows application
Linear and non linear tank calibration at 5 levels
Supports metal and plastic tanks
Supports tanks wall thickness up to 6mm (or larger if spacer is used and top limit
adjusted)
Industry standard SAE-5 stud mounting pattern with gasket seal and washers.
Supports analogue gauge types 10-180, 300-10, 240-33
Supports Digital meter that require 0-5 volt inputs
Operating temperature range of 4°c to 65°c
2. Specifications
Electrical
10VMIN to 32VMAX DC.
Ignition protected to ISO 8846
Fire Resistance tested to ABYC, US Coast guard and ISO10088
Output types: Analogue 10-180, 300-10, 240-33 ohm gauges and 0-5volt
Environmental
Resistant to Petrol, Diesel, Water, and Chemical Toilet.
Maximum Tank depths
Operating distance of 0mm to 1100mm for Petrol tanks
Operating distance of 0mm to 2000mm for Water tanks
Operating distance of 0mm to 2000mm for Diesel tanks
Operating distance of 0mm to 1500mm at 55°c
Note: Liquids that may have a sound absorbing surface will limit tank depth or in the worst
case provide no return signal eg. foam bubbles or porous sludge.
Permanent liquid surfaces that are more than 3 degree’s off level will have a tank depth de-
rating effect.
Liquids that have higher viscosities than water (e.g. oil) may not propagate liquid ripples that
create a strong return signal. This will also have a tank depth de-rating effect.
Don’t use on tanks shallower than 200mm in depth as angular reflections will reduce
accuracy.
INST-TS1-V13
18/11/10
Page 4
3. Dimensions
95.35 [3 3/4"]
19.64 [3/4"]
95.35 [3 3/4"]
84.88 [3 5/16"]
ACOUSTIC
PROTRUSION
8.9 [3/8"]
INST-TS1-V13
18/11/10
Page 5
4. Mounting and Installation
INDICATES CUTOUT
68°
80°
68°
72°
72°
R27[R11/16"]
VERY IMPORTANT:
DIAMETER MUST NOT BE
LESS THAN Ø42mm
Ø42[Ø15/8"]
Ø5[Ø3/16"]
42mm
4.5mm 4.5mm
ACOUSTIC
PROTRUSION
TANK
LID TANK
LID
IMPORTANT
SIDE WALLS OF ACOUSTIC PROTRUSION MUST BE NO
CLOSER THAN 4.5mm TO THE TANK SIDES OF THE
CUTOUT HOLE
GASKET
GLUE
BARRIER
RING
The acoustic protrusion should be positioned in the tank aperture in the centre of the
hole. The protrusion should ideally be protruding into the tank and not be recessed in the
hole. See drawing above.
For tightening screws ensure base and washers are sitting flat. Tighten screw until screw
head makes contact with the washer, and then tighten another 2 full turns.
Maximum torque for the mounting screws is 0.5 Newton meter.
Note: Drawing is not to scale. Please use the tank gasket as a template and make sure
the tank hole is 42mm.
INST-TS1-V13
18/11/10
Page 6
Case 1
TS1 must be mounted at the deepest tank point!
It is recommended the sender is mounted in the middle of the tank, this is particularly
important on low or no baffled tanks that are mounted in moving vehicles or vessels. This
allows the TS1 to average waves of fluid to the correct level when the depth is varying due to
wave slop.
Case 2
TS1 must be mounted at least 150mm from a vertical tank baffle, tank walls and piping.
INST-TS1-V13
18/11/10
Page 7
Case 3
Correct BEP Gasket must be used!
Use 5 washers provided, washers must be placed under screw heads to prevent rubber lid
damage.
Case 4
Acoustic protrusion must not touch the tank frame!
Case 5
TS1 must be mounted so it can see the bottom of the tank if the liquid is to be measured to
the bottom.
INST-TS1-V13
18/11/10
Page 8
Case 6
Inlet and Outlet piping must go in at least ⅔rds of the way in to the tank on grey and black
water tanks to stop water turbulence when filling.
Case 7
Do not fit the TS1 with a tube.
Case 8
Ensure bolts and mounting holes are aligned properly to keep plastic body isolated
acoustically from tank. Do not over tighten the screws.
INST-TS1-V13
18/11/10
Page 9
5. Wiring
Power must be removed before TS1 is connected to the system. Ensure wiring is
correct or else damage may occur rendering the device inoperable.
+-
NEG
BAR
POS
BAR
OUTPUT (GREEN)
POS (RED)
NEG (BLACK)
+-
NEG
BAR
POS
BAR
OUTPUT (GREEN)
POS (RED)
NEG (BLACK)
G
12V
12V
USE 24V RATED GAUGES FOR 24V SYSTEMS
(GAUGE SHOULD HAVE DROPPING RESISTOR)
(S)
INST-TS1-V13
18/11/10
Page 10
6. Programming and Setup
Please visit the BEP website for the programming software.
7. Problem Solving
Water Tanks
After long periods of no use, condensation will build up on the roof of the water tank and the
sender face. If the water droplets are large, the sender will not be able to read the contents
of the tank accurately. This will clear with normal boat or RV use.
Waste Tanks
Large amounts of foam bubble on the surface of the liquid caused by detergents or washing
powders will result in the sender not receiving reflected sound pulses back from the liquid
surface, instead these will be absorbed by the bubbles until they disperse. Then normal
operation will resume.
Interface Box + USB-to-Serial Converter Cable
(BEP P/N TS1-PK) Computer with USB Port
TS1 Tank Sender
(BEP P/N TS1)
INST-TS1-V13
18/11/10
Page 11
8. Frequently Asked Questions
Q: What is the signal update period?
A: Signal is updated in real time.
Q: Why is the tank level stuck on one value?
A: When the sender cannot measure a valid tank level, the sender will recover the last good
reading of the tank level from its own memory. This will be sent to the monitor until a new
valid level is found.
Q: Is the TS1 ignition protected?
A: The TS1 is ignition protected and approved. It is fully potted.
Q: On power up, the analogue gauge goes full scale then back to empty. After 5 seconds it
shows the correct level.
A: This is normal for a 10 – 180ohm analogue gauge.
Q: On power up, the analogue gauge goes full scale and then back to the correct level.
A: This is normal for a 240 – 33ohm analogue gauge.
Q: The gauge is reading full all the time.
A: 1. The most common problem is that the acoustic protrusion is touching the tank.
2. The incorrect gasket has been used specified gasket is a Cork/viton mix.
3. The sender is to close to the side of the tank.
4. There is an obstruction in the tank.
5. The mounting screws are not isolated acoustically from body (see. Case 8)
Q: Is the sender sensitive to electrical interference. Should we use shielded cable?
A: There is no need to use shielded cable, unless you are running a long distance and near
appliance cables that radiate noise.
Q: What is the maximum distance between sender and meter?
A: 50 metres.
Q: What support is there for the product?
A: Updates will be placed on BEP website.
Q: Why is the meter reading incorrect when tank is empty?
A: There must be some fluid covering the bottom of the tank for sender to receive a valid
return signal.
Q: What is the beam angle of the sender?
A: 300mm at 2M depth
Q: Can I use a sealant with the TS1 and gasket
A: Yes, but ensure sealant does not get on to protrusion. Also, do not over tighten screws
for purpose of providing a tighter seal. The screws should be tightened until there is
contact between screw head and washer, then another 2 full turns.
INST-TS1-V13
18/11/10
Page 12
BEP MARINE
55 Paul Matthews Road,
Albany, Auckland 0632
New Zealand
PO Box 101739 NSMC
Phone (+649)4157261
Fax. (+649)4159327
www.bepmarine.com
Please visit our website for the latest International Distributor List
