Fujitsu fi-5220C Configuration guide

Open the document cover clean:
Consumables Part Number
Pad PA03289-0111
Pick Roller PA03289-0001
Cleaning Materials SC-CLE-KIT1
2
3
4
1Pad Assy
Wipe downwards. When cleaning take care to prevent the cleaning paper from catching on the
metal parts.
ADF Glass Surfaces x 2
Located on the ADF cover and opposite side. Clean lightly.
Clean lightly taking care not to scratch the surface.
Pick Roller
Clean lightly while rotating with your finger. Take care not to roughen the surface.
Plastic Rollers x 4
Turn the Scanner OFF while cleaning the following locations
Cleaning the Flatbed It is recommended that these items be
cleaned EVERY 1,000 SCANS
Using cleaning paper moistened with F1 Cleaner
Cleaning Instructions for
fi-5220C Flatbed Scanner
2
3
4
1
5
Pad Assy
Plastic
Rollers
Pick Roller
Feed Rollers
Glass
P.T.O.
Using cleaning paper
moistened with F1 Cleaner
1
2Document Holding Pad
Document Bed
BEFORE CLEANING
Open the ADF while pulling
the cover open lever
ADF Button

Turn the Scanner ON while cleaning the following locations
Using cleaning paper moistened with F1 Cleaner
January 2007
Cleaning Instructions for fi-5220C Flatbed ScannerFujitsu Europe LImited
For further information please refer to the
fi-5220C Image Scanner Operators Guide
which can be found on our Website:
www.fel.fujitsu.com/scanner
2
3
4
1
5
Pad Assy
Plastic
Rollers
Pick Roller
Feed Rollers
Glass
5Clean lightly taking care not to roughen the surface.
Feed Rollers x 2
12
“Send to” Button “Scan” Button
Open the ADF only if the Function Number Display is showing “1”
through “9”.
Simultaneously hold down the “Send to” and “Scan”
buttons on the operator panel. The Feed Rollers will
rotate slowly each time buttons are pressed
Hold a soft dry, moistened cleaning paper against the
surface of the rotating rollers, lightly cleaning the
surface.
As a guideline, 7 presses of the “Send to” and
“Scan” buttons make the rollers rotate one full turn.
