Bernard Shortstub 40B User manual

Electrodes can be used to within one inch of
the high heat, high impact head compared with
the normal three inches of the electrode that is
leftover when using a typical tong-type holder.
Bernard Shortstub greatly improves
productivity because it is designed for quick,
easy installation of electrodes and it is built
to last with a proven high impact, high heat
replaceable head.
Bernard Shortstub models provide long life
because the replaceable head can be ordered
separately and installed quickly, eliminating total
replacement.
Over 2,000 pounds of gripping pressure
enables the electrode to be bent to a desired
shape for access to difficult welds.
40B Shortstub®
Time Tested Performance.
Our Manual Welding Products provide
high quality with a wide range of
styles, sizes and capacities to enhance
your welding applications.
Issued July 2007 • SPEC SS-1.2
Shortstub®
Stick Electrode Holder
USA
Made with
Pride and without
Compromise in the
Bernard's Shortstub® has
maintained its time-tested
design for decades.
Phone: [phone] (US Only) 708-946-2281 (Outside US)
Fax: [phone]
For more information, visit us at BernardWelds.com
Bernard®
An Illinois Tool Works Company
449 West Corning Road, Box 667
Beecher, Illinois 60401 USA
Specifications
Capacity Electrode
Size
Weight Length Cable
Connection
Cable
Socket
400 Amps
at 60%
duty cycle
1/16" - 1/4"
(1.6 mm - 6.4 mm)
17oz
(481 g)
8 3/4
(22 cm)
Model “B” large
ball point screw
connection
19/32"
(1.5 cm)

©2007 Bernard Printed in U.S.A.
Replacement Parts List
1. Head Assembly K40
2. Coil Spring S5
3. Handle (molded) MH4
4. Connector Body B37
5. Ball Point Set Screw B33
6. Head Insulator (Pair) EL
7. Boot BB4
8. Snap Ring SR4
9. V Jaw Spring V4
10. Jaw J4
11. Jaw Pin JP4
12. Head H4
13. Pressure Pin PP4
40B Shortstub®
1
2345
6
7
89
10
11 12 13
