Thermal Arc 400GTS CC/TIG User manual

INVERTER
ARC
WELDER
MODEL 400GTS CC/TIG
• STICK
• TIG - HIGH FREQUENCY
- LIFT START
OPERATING MANUAL
July 1, 1997 Manual No. 0-2512
TM
R

TABLE OF CONTENTS
1.0 GENERAL INFORMATION ........................................................2
1.01 Notes, Cautions and Warnings .................................................2
1.02 Important Safety Precautions....................................................3
1.03 Publications .................................................................................6
1.04 Note, Attention et Avertissement .............................................7
1.05 Precautions De Securite Importantes.......................................8
1.06 Documents De Reference......................................................... 11
1.07 Declaration of Conformity ......................................................12
1.08 Statement of Warranty .............................................................13
2.0 INTRODUCTION AND DESCRIPTION................................15
2.01 Description ................................................................................15
2.02 Functional Block Diagram.......................................................16
2.03 Transporting Methods..............................................................17
2.04 Electrical Input Connections ...................................................17
2.05 Specifications.............................................................................20
2.06 Duty Cycle .................................................................................21
3.0 OPERATOR CONTROLS ...........................................................22
3.01 Front and Rear operator controls ...........................................22
3.02 Setup for Operation ..................................................................24
Shielded Metal Arc Welding (SMAW) .........................................25
Gas Tungsten Arc Welding (GTAW)
High Frequency/Lift Start.............................................................26
Gas Tungsten Arc Welding-Pulsed (GTAW-P)
-Sloped (GTAW-S) -TIG Spot .........................................................28
4.0 BASIC TROUBLESHOOTING..................................................31
4.01 Common Welding Operation Faults......................................31
4.02 Specific Problems......................................................................31
4.03 Remote 8-Pin Connections ......................................................35
APPENDIX A – ACCESORIES.........................................................36
APPENDIX B – INTERCONNECTION DIAGRAMS.................39

1GENERALMANUAL 0-2512
WARNING Read and understand this entire Operating Manual and your
employer’s safety practices before installing, operating, or servicing
the equipment.
WARNING While the information contained in this Operating Manual represents
our best judgement, Thermal Dynamics Corporation assumes no
liability for its use.
Thermal Arc Models 400GTS CC/TIG Welder
Operating Manual Number 0-2512
Published by:
Thermal Dynamics Corporation
Industrial Park No. 2
West Lebanon, New Hampshire, USA 03784
[phone]
Copyright 1997 by
Thermal Dynamics Corporation
All rights reserved.
Reproduction of this work, in whole or in part, without written
permission of the publisher is prohibited.
The publisher does not assume and hereby disclaims any liability to any
party for any loss or damage caused by any error or omission in this
Operating Manual, whether such error results from negligence,
accident, or any other cause.
Printed in the United States of America
July 1, 1997

2
GENERAL MANUAL 0-2512
1.0 GENERAL INFORMATION
1.01 NOTES, CAUTIONS AND WARNINGS
Throughout this manual, notes, cautions, and warnings are used to
highlight important information. These highlights are categorized as
follows:
NOTE An operation, procedure, or background information which requires
additional emphasis or is helpful in efficient operation of the system.
CAUTION A procedure which, if not properly followed, may cause damage to the
equipment.
WARNING A procedure which, if not properly followed, may cause injury to the
operator or others in the operating area.

3GENERALMANUAL 0-2512
WARNING
1.02 IMPORTANT SAFETY PRECAUTIONS
OPERATION AND MAINTENANCE OF PLASMA ARC EQUIPMENT
CAN BE DANGEROUS AND HAZARDOUS TO YOUR HEALTH.
To prevent possible injury, read, understand and follow all warnings, safety precautions and
instructions before using the equipment. Call 1-603-298-5711 or your local distributor if you have any
questions.
GASES AND FUMES Gases and fumes produced during the plasma cutting process can be
dangerous and hazardous to your health.
• Keep all fumes and gases from the breathing area. Keep your head out
of the welding fume plume.
• Use an air-supplied respirator if ventilation is not adequate to remove
all fumes and gases.
• The kinds of fumes and gases from the plasma arc depend on the kind
of metal being used, coatings on the metal, and the different
processes. You must be very careful when cutting or welding any
metals which may contain one or more of the following:
Antimony Chromium Mercury
Arsenic Cobalt Nickel
Barium Copper Selenium
Beryllium Lead Silver
Cadmium Manganese Vanadium
• Always read the Material Safety Data Sheets (MSDS) that should be
supplied with the material you are using. These MSDSs will give you
the information regarding the kind and amount of fumes and gases
that may be dangerous to your health.
• For information on how to test for fumes and gases in your
workplace, refer to item 1 in the Publications Section in this manual.
• Use special equipment, such as water or down draft cutting tables, to
capture fumes and gases.
• Do not use the plasma torch in an area where combustible or
explosive gases or materials are located.
• Phosgene, a toxic gas, is generated from the vapors of chlorinated
solvents and cleansers. Remove all sources of these vapors.

4
GENERAL MANUAL 0-2512
IMPORTANT SAFETY PRECAUTIONS (CONTINUED)
ELECTRIC SHOCK Electric Shock can injure or kill. The plasma arc process uses and
produces high voltage electrical energy. This electric energy can cause
severe or fatal shock to the operator or others in the workplace.
• Never touch any parts that are electrically “live” or “hot.”
• Wear dry gloves and clothing. Insulate yourself from the work piece
or other parts of the welding circuit.
• Repair or replace all worn or damaged parts.
• Extra care must be taken when the workplace is moist or damp.
• Install and maintain equipment according to NEC code, refer to item 4
in the Publications section of this manual.
• Disconnect power source before performing any service or repairs.
• Read and follow all the instructions in the Operating Manual.
FIRE AND EXPLOSION Fire and explosion can be caused by hot slag, sparks, or the plasma arc.
• Be sure there is no combustible or flammable material in the
workplace. Any material that cannot be removed must be protected.
• Ventilate all flammable or explosive vapors from the workplace.
• Do not cut or weld on containers that may have held combustibles.
• Provide a fire watch when working in an area where fire hazards may
exist.
• Hydrogen gas may be formed and trapped under aluminum
workpieces when they are cut underwater or while using a water
table. DO NOT cut aluminum alloys underwater or on a water table
unless the hydrogen gas can be eliminated or dissipated. Trapped
hydrogen gas that is ignited will cause an explosion.
NOISE Noise can cause permanent hearing loss. Plasma arc processes can cause
noise levels to exceed safe limits. You must protect your ears from loud
noise to prevent permanent loss of hearing.
• To protect your hearing from loud noise, wear protective ear plugs
and/or ear muffs. Protect others in the workplace.
• Noise levels should be measured to be sure the decibels (sound) do
not exceed safe levels.
• For information on how to test for noise, see item 1 in the Publications
section of this manual.

5GENERALMANUAL 0-2512
IMPORTANT SAFETY PRECAUTIONS (CONTINUED)
PLASMAARC RAYS Plasma Arc Rays can injure your eyes and burn your skin. The plasma
arc process produces very bright ultra violet and infra red light. These
arc rays will damage your eyes and burn your skin if you are not
properly protected.
• To protect your eyes, always wear a welding helmet or shield. Also
always wear safety glasses with side shields, goggles or other
protective eye wear.
• Wear welding gloves and suitable clothing to protect your skin from
the arc rays and sparks.
• Keep helmet and safety glasses in good condition. Replace lenses
when cracked, chipped or dirty.
• Protect others in the work area from the arc rays. Use protective
booths, screens or shields.
• Use the shade of lens as recommended in the Operating Manual.

6GENERAL MANUAL 0-2512
1.03 PUBLICATIONS
Refer to the following standards or their latest revisions for more information:
1. OSHA, SAFETY AND HEALTH STANDARDS, 29CFR 1910, obtainable from the Superintendent
of Documents, U.S. Government Printing Office, Washington, D.C. 20402
2. ANSI Standard Z49.1, SAFETY IN WELDINGAND CUTTING, obtainable from the American
Welding Society, 550 N.W. LeJeune Rd, Miami, FL 33126
3. NIOSH, SAFETY AND HEALTH IN ARC WELDING AND GAS WELDINGAND CUTTING,
obtainable from the Superintendent of Documents, U.S. Government Printing Office,
Washington, D.C. 20402
4. ANSI Standard Z87.1, SAFE PRACTICES FOR OCCUPATION AND EDUCATIONAL EYE AND
FACE PROTECTION, obtainable from American National Standards Institute, 1430 Broadway,
New York, NY 10018
5. ANSI Standard Z41.1, STANDARD FOR MEN’S SAFETY-TOE FOOTWEAR, obtainable from the
American National Standards Institute, 1430 Broadway, New York, NY 10018
6. ANSI Standard Z49.2, FIRE PREVENTION IN THE USE OF CUTTING AND WELDING
PROCESSES, obtainable from American National Standards Institute, 1430 Broadway, New York,
NY 10018
7. AWS StandardA6.0, WELDING AND CUTTING CONTAINERS WHICH HAVE HELD
COMBUSTIBLES, obtainable from American Welding Society, 550 N.W. LeJeune Rd, Miami, FL
33126
8. NFPAStandard 51, OXYGEN-FUEL GAS SYSTEMS FOR WELDING, CUTTING AND ALLIED
PROCESSES, obtainable from the National Fire Protection Association, Batterymarch Park,
Quincy, MA 02269
9. NFPAStandard 70, NATIONAL ELECTRICAL CODE, obtainable from the National Fire
Protection Association, Batterymarch Park, Quincy, MA 02269
10. NFPAStandard 51B, CUTTING AND WELDING PROCESSES, obtainable from the National Fire
Protection Association, Batterymarch Park, Quincy, MA 02269
11. CGA Pamphlet P-1, SAFE HANDLING OF COMPRESSED GASES IN CYLINDERS, obtainable
from the Compressed Gas Association, 1235 Jefferson Davis Highway, Suite 501, Arlington, VA
22202
12. CSA Standard W117.2, CODE FOR SAFETY IN WELDING AND CUTTING, obtainable from the
Canadian Standards Association, Standards Sales, 178 Rexdale Boulevard, Rexdale, Ontario,
Canada M9W 1R3
13. NWSA booklet, WELDING SAFETY BIBLIOGRAPHY obtainable from the National Welding
Supply Association, 1900 Arch Street, Philadelphia, PA 19103
14. American Welding Society StandardAWSF4.1, RECOMMENDED SAFE PRACTICES FOR THE
PREPARATION FOR WELDING AND CUTTING OF CONTAINERS AND PIPING THAT HAVE
HELD HAZARDOUS SUBSTANCES, obtainable from the American Welding Society, 550 N.W.
LeJeune Rd, Miami, FL 33126
15. ANSI Standard Z88.2, PRACTICE FOR RESPIRATORY PROTECTION, obtainable from
American National Standards Institute, 1430 Broadway, New York, NY 10018

7GENERALMANUAL 0-2512
1.04 NOTE, ATTENTION ET AVERTISSEMENT
Dans ce manuel, les mots “note,” “attention,” et “avertissement” sont
utilisés pour mettre en relief des informations à caractère important. Ces
mises en relief sont classifiées comme suit :
NOTET oute opération, procédure ou renseignement général sur lequel il
importe d’insister davantage ou qui contribue à l’efficacité de
fonctionnement du système.
ATTENTION Toute procédure pouvant résulter l’endommagement du matériel en cas
de non-respect de la procédure en question.
AVERTISSEMENT Toute procédure pouvant provoquer des blessures de l’opérateur
ou des autres personnes se trouvant dans la zone de travail en cas de
non-respect de la procédure en question.

8
GENERAL MANUAL 0-2512
AVERTISSEMENT
1.05 PRECAUTIONS DE SECURITE IMPORTANTES
L’OPÉRATION ET LA MAINTENANCE DU MATÉRIEL DE SOUDAGE
À L’ARC AU JET DE PLASMA PEUVENT PRÉSENTER
DES RISQUES ET DES DANGERS DE SANTÉ.
Il faut communiquer aux opérateurs et au personnel TOUS les dangers possibles. Afin d’éviter les
blessures possibles, lisez, comprenez et suivez tous les avertissements, toutes les précautions de
sécurité et toutes les consignes avant d’utiliser le matériel. Composez le + 603-298-5711 ou votre
distributeur local si vous avez des questions.
FUMÉE et GAZ La fumée et les gaz produits par le procédé de jet de plasma peuvent
présenter des risques et des dangers de santé.
• Eloignez toute fumée et gaz de votre zone de respiration. Gardez votre
tête hors de la plume de fumée provenant du chalumeau.
• Utilisez un appareil respiratoire à alimentation en air si l’aération
fournie ne permet pas d’éliminer la fumée et les gaz.
• Les sortes de gaz et de fumée provenant de l’arc de plasma dépendent
du genre de métal utilisé, des revêtements se trouvant sur le métal et
des différents procédés. Vous devez prendre soin lorsque vous coupez
ou soudez tout métal pouvant contenir un ou plusieurs des éléments
suivants:
antimoine cadmium mercure
argent chrome nickel
arsenic cobalt plomb
baryum cuivre sélénium
béryllium manganèse vanadium
• Lisez toujours les fiches de données sur la sécurité des matières (sigle
américain “MSDS”); celles-ci devraient être fournies avec le matériel
que vous utilisez. Les MSDS contiennent des renseignements quant à
la quantité et la nature de la fumée et des gaz pouvant poser des
dangers de santé.
• Pour des informations sur la manière de tester la fumée et les gaz de
votre lieu de travail, consultez l’article 1 et les documents cités à la
page 11.
• Utilisez un équipement spécial tel que des tables de coupe à débit
d’eau ou à courant descendant pour capter la fumée et les gaz.
• N’utilisez pas le chalumeau au jet de plasma dans une zone où se
trouvent des matières ou des gaz combustibles ou explosifs.
• Le phosgène, un gaz toxique, est généré par la fumée provenant des
solvants et des produits de nettoyage chlorés. Eliminez toute source
de telle fumée.

9GENERALMANUAL 0-2512
PRECAUTIONS DE SECURITE IMPORTANTES
CHOC ELECTRIQUE Les chocs électriques peuvent blesser ou même tuer. Le procédé au jet
de plasma requiert et produit de l’énergie électrique haute tension. Cette
énergie électrique peut produire des chocs graves, voire mortels, pour
l’opérateur et les autres personnes sur le lieu de travail.
• Ne touchez jamais une pièce “sous tension” ou “vive”; portez des
gants et des vêtements secs. Isolez-vous de la pièce de travail ou des
autres parties du circuit de soudage.
• Réparez ou remplacez toute pièce usée ou endommagée.
• Prenez des soins particuliers lorsque la zone de travail est humide ou
moite.
• Montez et maintenez le matériel conformément au Code électrique
national des Etats-Unis. (Voir la page 6, article 9.)
• Débranchez l’alimentation électrique avant tout travail d’entretien ou
de réparation.
• Lisez et respectez toutes les consignes du Manuel de consignes.
INCENDIE ET
EXPLOSION Les incendies et les explosions peuvent résulter des scories chaudes, des
étincelles ou de l’arc de plasma. Le procédé à l’arc de plasma produit du
métal, des étincelles, des scories chaudes pouvant mettre le feu aux
matières combustibles ou provoquer l’explosion de fumées
inflammables.
• Soyez certain qu’aucune matière combustible ou inflammable ne se
trouve sur le lieu de travail. Protégez toute telle matière qu’il est
impossible de retirer de la zone de travail.
• Procurez une bonne aération de toutes les fumées inflammables ou
explosives.
• Ne coupez pas et ne soudez pas les conteneurs ayant pu renfermer des
matières combustibles.
• Prévoyez une veille d’incendie lors de tout travail dans une zone
présentant des dangers d’incendie.
• Le gas hydrogène peut se former ou s’accumuler sous les pièces de
travail en aluminium lors’quelles sont coupeés sous l’eau ou sur une
table d’eau. NE PAS couper les alliages en aluminium sous l’eau ou
sur une table d’eau à mains que le gas hydrogène peut s’échapper ou
se dissiper. Le gas hydrogène accumulé explosera si enflammé.

10
GENERAL MANUAL 0-2512
PRECAUTIONS DE SECURITE IMPORTANTES
RAYONS D’ARC
DE PLASMA Les rayons provenant de l’arc de plasma peuvent blesser vos yeux et
brûler votre peau. Le procédé à l’arc de plasma produit une lumière
infra-rouge et des rayons ultra-violets très forts. Ces rayons d’arc
nuiront à vos yeux et brûleront votre peau si vous ne vous protégez pas
correctement.
• Pour protéger vos yeux, portez toujours un casque ou un écran de
soudeur. Portez toujours des lunettes de sécurité munies de parois
latérales ou des lunettes de protection ou une autre sorte de protection
oculaire.
• Portez des gants de soudeur et un vêtement protecteur approprié
pour protéger votre peau contre les étincelles et les rayons de l’arc.
• Maintenez votre casque et vos lunettes de protection en bon état.
Remplacez toute lentille sale ou comportant fissure ou rognure.
• Protégez les autres personnes se trouvant sur la zone de travail contre
les rayons de l’arc en fournissant des cabines ou des écrans de
protection.
• Respectez le teint de lentille recommandé dans le manuel de
consignes.
BRUIT Le bruit peut provoquer une perte permanente de l’ouïe. Les procédés
de soudage à l’arc de plasma peuvent provoquer des niveaux sonores
supérieurs aux limites normalement acceptables. Vous dúvez vous
protéger les oreilles contre les bruits forts afin d’éviter une perte
permanente de l’ouïe.
• Pour protéger votre ouïe contre les bruits forts, portez des tampons
protecteurs et/ou des protections auriculaires. Protégez également les
autres personnes se trouvant sur le lieu de travail.
• Il faut mesurer les niveaux sonores afin d’assurer que les décibels (le
bruit) ne dépassent pas les niveaux sûrs.
• Pour des renseignements sur la manière de tester le bruit, consultez
l’article 1, page 11.

11 GENERAL
MANUAL 0-2512
1.06 DOCUMENTS DE REFERENCE
Consultez les normes suivantes ou les révisions les plus récentes ayant été faites à celles-ci pour de plus
amples renseignements :
1. OSHA, NORMES DE SÉCURITÉ DU TRAVAIL ET DE PROTECTION DE LA SANTÉ, 29CFR
1910, disponible auprès du Superintendent of Documents, U.S. Government Printing Office,
Washington, D.C. 20402
2. Norme ANSI Z49.1, LA SÉCURITÉ DES OPÉRATIONS DE COUPE ET DE SOUDAGE,
disponible auprès de la Société Américaine de Soudage (American Welding Society), 550 N.W.
LeJeune Rd., Miami, FL 33126
3. NIOSH, LASÉCURITÉ ET LA SANTÉ LORS DES OPÉRATIONS DE COUPE ET DE SOUDAGE
À L’ARC ET AU GAZ, disponible auprès du Superintendent of Documents, U.S. Government
Printing Office, Washington, D.C. 20402
4. Norme ANSI Z87.1, PRATIQUES SURES POUR LA PROTECTION DES YEUX ET DU VISAGE
AU TRAVAIL ET DANS LES ECOLES, disponible de l’Institut Américain des Normes Nationales
(American National Standards Institute), 1430 Broadway, New York, NY 10018
5. Norme ANSI Z41.1, NORMES POUR LES CHAUSSURES PROTECTRICES, disponible auprès de
l’American National Standards Institute, 1430 Broadway, New York, NY 10018
6. Norme ANSI Z49.2, PRÉVENTION DES INCENDIES LORS DE L’EMPLOI DE PROCÉDÉS DE
COUPE ET DE SOUDAGE, disponible auprès de l’American National Standards Institute, 1430
Broadway, New York, NY 10018
7. Norme A6.0 de l’Association Américaine du Soudage (AWS), LE SOUDAGE ET LA COUPE DE
CONTENEURS AYANT RENFERMÉ DES PRODUITS COMBUSTIBLES, disponible auprès de la
American Welding Society, 550 N.W. LeJeune Rd., Miami, FL 33126
8. Norme 51 de l’AssociationAméricaine pour la Protection contre les Incendies (NFPA), LES
SYSTEMES À GAZAVEC ALIMENTATION EN OXYGENE POUR LE SOUDAGE, LA COUPE
ET LES PROCÉDÉS ASSOCIÉS, disponible auprès de la National Fire Protection Association,
Batterymarch Park, Quincy, MA 02269
9. Norme 70 de la NFPA, CODE ELECTRIQUE NATIONAL, disponible auprès de la National Fire
Protection Association, Batterymarch Park, Quincy, MA 02269
10. Norme 51B de la NFPA, LES PROCÉDÉS DE COUPE ET DE SOUDAGE, disponible auprès de la
National Fire Protection Association, Batterymarch Park, Quincy, MA 02269
11. Brochure GCA P-1, LA MANIPULATION SANS RISQUE DES GAZ COMPRIMÉS EN
CYLINDRES, disponible auprès de l’Association des Gaz Comprimés (Compressed Gas
Association), 1235 Jefferson Davis Highway, Suite 501, Arlington, VA 22202
12. Norme CSAW117.2, CODE DE SÉCURITÉ POUR LE SOUDAGE ET LA COUPE, disponible
auprès de l’Association des Normes Canadiennes, Standards Sales, 178 Rexdale Boulevard,
Rexdale, Ontario, Canada, M9W 1R3
13. ivret NWSA, BIBLIOGRAPHIE SUR LASÉCURITÉ DU SOUDAGE, disponible auprès de
l’Association Nationale de Fournitures de Soudage (National Welding Supply Association), 1900
Arch Street, Philadelphia, PA 19103
14. NormeAWSF4.1 de l’Association Américaine de Soudage, RECOMMANDATIONS DE
PRATIQUES SURES POUR LA PRÉPARATION À LA COUPE ET AU SOUDAGE DE
CONTENEURS ET TUYAUX AYANT RENFERMÉ DES PRODUITS DANGEREUX , disponible
auprès de la American Welding Society, 550 N.W. LeJeune Rd., Miami, FL 33126
15. NormeANSI Z88.2, PRATIQUES DE PROTECTION RESPIRATOIRE, disponible auprès de
l’American National Standards Institute, 1430 Broadway, New York, NY 10018

12GENERAL MANUAL 0-2512
1.07 DECLARATION OF CONFORMITY
Manufacturer: Thermal Dynamics Corporation
Address: Industrial Park #2
West Lebanon, New Hampshire 03784
USA
The equipment described in this manual conforms to all applicable aspects and regulations of the ‘Low
Voltage Directive’ (European Council Directive 73/23/EU, as recently changed in Directive 93/63/EU)
and to the National legislation for the enforcement of this Directive.
The equipment described in this manual conforms to all applicable aspects and regulations of the “EMC
Directive” (European Council Directive 89/336/EEC) and to the National legislation for the enforcement
of this Directive.
Serial numbers are unique with each individual piece of equipment and details description, parts used to
manufacture a unit and date of manufacture.
National Standard and Technical Specifications
The product is designed and manufactured to a number of standards and technical requirements among
them are:
* CSA(Canadian Standards Association) standard C22.2 number 60-M1990 for Arc welding equipment.
* UL (Underwriters Laboratory) rating 94VO flammability testing for all printed-circuit boards used.
* CENELEC EN50199 EMC Product Standard forArc Welding Equipment March 1995.
* IEC 974-1 (BS 638-PT10) (EN 60 974-1) applicable to welding equipment and associated accessories.
* Extensive product design verification is conducted at the manufacturing facility as part of the routine
design and manufacturing process, to ensure the product is safe and performs as specified. Rigorous
testing is incorporated into the manufacturing process to ensure the manufactured product meets or
exceeds all design specifications.
Thermal Dynamics has been manufacturing products that perform in a safe manner for more than 30
years and will continue to achieve excellence in our area of manufacture.
Manufacturers responsible representative: David Ashworth
Vice President & Managing Director
Thermadyne Europe
Chorley England.

13 GENERAL
MANUAL 0-2512
1.08 STATEMENT OF WARRANTY
LIMITED WARRANTY: Thermal Dynamics Corporation (hereinafter “Thermal”) warrants that its
products will be free of defects in workmanship or material. Should any failure to conform to this
warranty appear within the time period applicable to the Thermal products as stated below, Thermal
shall, upon notification thereof and substantiation that the product has been stored, installed, operated,
and maintained in accordance with Thermal’s specifications, instructions, recommen dations and
recognized standard industry practice, and not subject to misuse, repair, neglect, alteration, or accident,
correct such defects by suitable repair or replacement, at Thermal’s sole option, of any components or
parts of the product determined by Thermal to be defective.
THIS WARRANTYIS EXCLUSIVE AND IS IN LIEU OFANY WARRANTY OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE.
LIMITATION OF LIABILITY:Thermal shall not under any circumstances be liable for special or
consequential damages, such as, but not limited to, damage or loss of purchased or replacement goods,
or claims of customers of distributor (hereinafter “Purchaser”) for service interruption. The remedies of
the Purchaser set forth herein are exclusive and the liability of Thermal with respect to any contract, or
anything done in connection therewith such as the performance or breach thereof, or from the
manufacture, sale, delivery, resale, or use of any goods covered by or furnished by Thermal whether
arising out of contract, negligence, strict tort, or under any warranty, or otherwise, shall not, except as
expressly provided herein, exceed the price of the goods upon which such liability is based.
THIS WARRANTYBECOMES INVALID IF REPLACEMENT PARTS OR ACCESSORIES ARE USED
WHICH MAY IMPAIR THE SAFETY OR PERFORMANCE OFANY THERMAL PRODUCT.
THIS WARRANTYIS INVALID IF THE PRODUCT IS SOLD BY NON-AUTHORIZED PERSONS.
The limited warranty periods for Thermal products shall be as follows: A maximum of three (3) years
from date of sale to an authorized distributor and a maximum of two (2) years from date of sale by such
distributor to the Purchaser, and with the following further limitations on such two (2) year period:
PAK UNITS, POWER SUPPLIES PARTS LABOR
MAIN POWER MAGNETICS........................................ 2 YEARS...................1 YEAR
ORIGINAL MAIN POWER RECTIFIER ....................... 2 YEARS...................1 YEAR
CONTROL PC BOARD .................................................. 2 YEARS...................1 YEAR
ALLOTHER CIRCUITS AND COMPONENTS ........... 1 YEAR....................1 YEAR
INCLUDING, BUT NOT LIMITED TO, STARTING
CIRCUIT, CONTACTORS, RELAYS, SOLENOIDS,
PUMPS, POWER SWITCHING SEMI-CONDUCTORS
CONSOLES, CONTROL EQUIPMENT, HEAT ...................... 1 YEAR....................1 YEAR
EXCHANGES, ANDACCESSORY EQUIPMENT
TORCH AND LEADS ............................................................ 180 DAYS ................ 180 DAYS
REPAIR/REPLACEMENT PARTS ......................................... 90 DAYS.................. 90 DAYS
Warranty repairs or replacement claims under this limited warranty must be submitted by an authorized
Thermal Arc®repair facility within thirty (30) days of the repair. Authorized ThermalArc®repair facilities
are authorized distributors and authorized Thermal Arc®Service Centers. No transportation costs of any
kind will be paid under this warranty. Transportation charges to send products to an authorized
warranty repair facility shall be the responsibility of the customer. All returned goods shall be at the
customer’s risk and expense. This warranty supersedes all previous Thermal warranties.
Thermal Arc®is a Registered Trademark of Thermal Dynamics.
Effective January 18, 1991

14 MANUAL 0-2512

15MANUAL 0-2512
2.0 INTRODUCTION AND DESCRIPTION
2.01 Description
The Thermal Arc™Model 400GTS are single or three-phase DC arc welding
power sources with Constant Current (CC) output characteristics. They are
available with an optional digitalAMPERAGE/VOLTAGE panel meter
(standard in European models).
The 400GTS unit is equipped with a built-in Sloper, Pulser, gas control
solenoid, lift arc starter, and a high-frequency arc starter for use with Gas
Tungsten Arc Welding (GTAW), Gas Tungsten Arc Welding-Pulsed
(GTAW-P), Gas Tungsten Arc Welding-Sloped (GTAW-S), Gas Tungsten Arc
Welding-TIG Spot (GTAW-TIG), and Shielded Metal Arc Welding (SMAW)
processes.
19V
4005 AMPS
VOLTS Arc Characteristics
"CURRENT" Control
410145
OCV Less than 70V C.C.
Figure 1. 400GTS model Volt-Ampere curve
NOTE Volt-Ampere curves show the maximum Voltage and Amperage output
capabilities of the welding power source. Curves of other settings will fall
between the curves shown.
INTRODUCTION

16 MANUAL 0-2512
2.02 Functional Block Diagram
Figure 2 illustrates the functional block diagram of the 400GTS power supplies.
Main
Circuit
Breaker
DC Power
Supply for
Control Circuit
Voltage Sensor
Drive Circuit Primary
Current
Sensor
Lift Tig Mode
Output Short
Sensing Circuit
Input
Diode Output
Diodes
Output
Inductor
Input

Power Inrush Current 
Suppresor IGBT Inverter Module
Thermal
Sensor
Output
Transformers
High
Frequency
Unit
Current
Transformer
(CT-1)
Capacitor
Thermal
Sensor
Circuit
Current
Adjustment
Circuit
Reference
Adjustments &
Control Switches
Torch Control
Connection
(CON1)
Control
Transformer
(-c Config.)
Gas
Control
Circuit
+
+–
–
+
Trouble
Sensing
Circuit Sequence
Control
To each control circuit
+12VDC +20VDC
+24VDC +5VDC
Coupling
Coil
Figure 2. GTS Model functional block diagram
INTRODUCTION

17MANUAL 0-2512
2.03 Transporting Methods
These units are equipped with a handle for carrying purposes.
WARNING ELECTRIC SHOCK can kill.
• DO NOT TOUCH live electrical parts.
• Disconnect input power conductors from de-energized supply line
before moving welding power source.
WARNING FALLING EQUIPMENT can cause serious personal injury and equipment
damage.
• Lift unit with handle on top of case.
• Use hand cart or similar device of adequate capacity.
• If using a fork lift vehicle, place and secure unit on a proper skid
before transporting.
2.04 Electrical Input Connections
WARNING ELECTRIC SHOCK can kill; SIGNIFICANT DC VOLTAGE is present after
removal of input power.
• DO NOT TOUCH live electrical parts.
• SHUT DOWN welding power source, disconnect input power
employing lockout/tag out procedures. Lockout/tag out procedures
consist of padlocking line disconnect switch in open position,
removing fuses from fuse box, or shutting off and red-tagging circuit
breaker or other disconnecting device.
Electrical Input
Requirements Operate the welding power source from a single or three-phase 50/60 Hz,
AC power supply. The input voltage must match one of the electrical input
voltages shown on the input data label on the unit nameplate. Contact the
local electric utility for information about the type of electrical service
available, how proper connections should be made, and inspection
required.
The line disconnect switch provides a safe and convenient means to
completely remove all electrical power from the welding power supply
whenever necessary to inspect or service the unit.
NOTE These units are equipped with a four-conductor with earth power cable
that is connected at the welding power source end for single or three-phase
electrical input power.
INTRODUCTION

18 MANUAL 0-2512
• To operate single-phase, do not connect the RED input conductor.
• Do not connect an input (WHITE, BLACK or RED) conductor to the
ground terminal.
• Do not connect the ground (GREEN) conductor to an input line
terminal.
Refer to Figure 3 and:
1. Connect end of ground (GREEN) conductor to a suitable ground. Use a
grounding method that complies with all applicable electrical codes.
2. Connect ends of line 1 (BLACK), line 2 (WHITE) and line 3 (RED)
input conductors to a de-energized line disconnect switch.
3. Use Table 1 below as a guide to select line fuses for the disconnect
switch.
Table 1. Fuse Size Selection Input Power/Input Voltage Fuse Size (Amperes)
Three-Phase Single-Phase
208-230VAC 70 80
380-415 VAC 40 N/A
460 VAC 30 40
NOTE Fuse size is based on not more than 200 percent of the rated input
amperage of the welding power source (Based onArticle 630, National
Electrical Code).
THERMADYNE
OFF ON
208-230V 460V
INPUT SELECT
SWITCH
PRIMARY POWER
PRIMARY CABLE
TURN OFF YOUR MAIN POWER SOURCE AND
CIRCUIT BREAKER OF THIS WELDER BEFORE
MAINTENANCE OR INSPECTION
5A/10V - 400A/36V
400/ 300/ 230/
60%
25% 100%
280A 210A 160A
U
S
UV
UV
X
I
31V
36/ 32/ 28/
28V 26V
64
208V
3/1
3/1
230V
460V
60/80 Hz
61/78A 40/63A
66/70A 37/48A
27/36A 18/24A
28/37A
26/34A
13/17A
21.9/
16.2kVA 14.6/ 10.9kVA 10/ 8.0kVA
IP 23S
f1f2
IEC974
2
2
1
0
1
400S
Thermal Dynamics
WESTLEBANON, NEW HAMPSHIRE USA 03784
MADEIN JAPAN
Primary Power Cable
Line Fuse
Line Fuse
Line
Disconnect
Switch
Welding Power Supply
Ground
Conductor
Ground
Terminal
Figure 3. Electrical input connections
INTRODUCTION
