Bernard Q150X-1 Application guide

Centerfire™ contact tips, nozzles and diffusers
are easy-to-use and high performing - they
provide better arc starts, less spatter and more
consistent welds - and also last up to three times
longer than competitive brands.
Necks available in fixed, rotatable and multiple
length options for optimal weld accessibility and
improved operator comfort. Rotatable necks
changeover without tools.
Patented Jump Liner allows quick neck change
and replacement of only most commonly worn or
clogged liner area, which reduces the amount of
time a gun is offline and minimizes inventory.
Liners coiled in-house with proprietary process
that improves wire feed performance and 100
percent tested to ensure smoothest wire feed in
the industry.
OXO® style handle option allows configuration
of Bernard Q-Gun with feel similar to former OXO
APX gun.
Power cable equipped with Stay-Tite™
Technology and internal gas hose that resists
kinking, improves gas flow and feedability.
Back end with durable rigid strain relief and
easily interchangeable direct plugs and trigger
leads connect to wire feeders and machines
from major manufacturers and allow simple
maintenance.
Q150 MIG Q-Gun™ shown with
OXO® style small curved handle,
medium 45˚ rotating neck.
All Guns are Not Created Equal.
A MIG gun should be durable, easy to
use and customized to your specific
application. Our MIG guns put you in
control: you choose the options you need
and we'll build a gun to last. We even
ship most of our guns within 24 hours.
Issued Jan. 2007 • Index No. SPEC Q150X-1.1
Q-Gun™ Series with OXO® style small handle
150 Amp MIG Guns
USA
Made with
Pride and without
Compromise in the
Lightweight, comfortable and
easy-to-use. Our Q150 MIG gun
is a perfect fit for low amperage
industrial applications.
Phone: [phone] (US Only) 708-946-2281 (Outside US)
Fax: [phone]
For more information, visit us at BernardWelds.com
Q150 Amperage Ratings
Duty Cycle Description
100% NEMA 100%CE 60% CE 35%CE
160 150 180 225 CO2 Gas
n/a 140 150 180 80%AR20%CO2
Bernard®
An Illinois Tool Works Company
449 West Corning Road, Box 667
Beecher, Illinois 60401 USA
Stay-Tite™ Technology
Long-lasting power cable
compression fittings
and necks with large
tapered gun connections
combine to form the
foundation of Bernard®
Stay-TiteTM technology.
This technology ensures
optimal conductivity to
increase weld consistency
and lessen heat output
while improving product
durability.

©2007 Bernard Printed in U.S.A.
Replacement Parts List
9
9
10
12
11
15
8
13
1
2
4
5
6
3
7
AMP
17
18
19
16
19
20
20
21 21
22
23
10
12
14
ITEM # PART # DESCRIPTION
1 See Centerfire Spec Sheet Nozzle Assy
2 See Centerfire Spec Sheet Contact Tip
3 See Centerfire Spec Sheet Gas Diffuser
4 See Centerfire Spec Sheet Cap
5 See Neck Spec Sheet Neck
6See Jump Liner Spec Sheet Jump Liner
7 4E213B Stay-Tite™ End Fitting
8 4305 Stay-Tite™ Cone Nut
9 1880219 *Handle Kit, Standard and Locking
Trigger
10 203296-005 Handle Screw (4 Req'd)
11 2280044 Handle Screw, Small
12 177272 Handle Nut (4 Req'd)
13 2030029 Handle Nut, Small
14 177488 Trigger, Standard
MS2110 Trigger, Locking
177379 Trigger, Standard w/Extension
15 177271 Trigger Pin (2 Req'd)
16 4932 Butt Connector (2 Req'd)
17 2520007 Cap, Rigid Strain Relief
18 2520048 Spring, Strain Relief
19 Rigid Strain Relief
2520073 Strain Relief with Installed Gas Pin
(Bernard Direct Plug)
2520047 Strain Relief (Euro Direct Plug)
2520047E Strain Relief with Trigger Cable
Adapter (OXO, Tweco 4 w/Twist Lock)
2520047H Strain Relief with Trigger Cable
Adapter (L-Tec, Hobart Direct Plug)
2520047L Strain Relief with Trigger Cable
Adapter (Lincoln Direct Plug)
2520047T Strain Relief with Trigger Cable
Adapter (National, Tweco Direct Plug)
2520047M Strain Relief with Trigger Cable
Adapter (All Other Direct Plugs)
20 See Direct Plug Spec Sheet Direct Plug Components
21 See Liner Spec Sheet Liner
22 1010027 Adapter Block (Not Req'd on Bernard
or Euro Direct Plug)
23 W11127-002 Screw, Strain Relief (Not Req'd on
Bernard Direct Plug)
*1880219 Handle Kit includes halves, screws and nuts.
