Berner 242639 User manual

242639 Mini Booster 600 A
USER MANUAL
Thank you for choosing the E-Power! Always follow basic safety precautions when using electrical
appliances. Read all instructions carefully, Please keep this instruction manual for easy reference.
B. OPERATION GUIDANCE
Indicator
Press the switch to check the storage level of the Booster

The indicator will flash one by one during the period of charging. Different number of solid
indicators show different storage level of the Booster. All indicators light up when the charging is
paused or completed.
the Booster Charging Instruction：
1. Plug the home adaptor into the universal socket.
2. Connect 14V 1A input port of the Booster to the other end of home adaptor.
Or
1. Plug the car adaptor into the socket of cigarette lighter.
2. Connect 14V 1A input port of the Booster to the other end of car adaptor.
Jump start 12V vehicle Instruction:
1.Connect the blue plug fully seated into the SCORPION, and make sure the Cable Indicator is off.
2.Connect Red Clamp to the positive (+) battery terminal, Black Clamp to the negative (-) battery
terminal.
3.Operate following the instruction of the Cable Indicator:
GREEN LIGHT on: Telling the connection is correct and the circuit is working, you can turn on
the engine to jump-start directly.

RED LIGHT on with buzzing: Telling the connection is wrong, and buzzing to alarm to correct the
clamps as step 2 mentioned above, wait until the GREEN LIGHT is on to turn on the engine.
GREEN LIGHT blinking with buzzing: Saying the vehicle battery is low, press the “BOOST” button,
wait GREEN LIGHT becomes solid, then turn on the engine within 30s.
Note : When Boost button is pressed, booster works without any protection
No Lights on, No buzzing: Saying the vehicle's battery maybe damaged, after confirm the clamps
connection is correct, press the “BOOST” button, wait GREEN LIGHT is on, and then turn on the
engine within 30s.
4.Start the vehicle.
5. As soon as the vehicle is started, remove the jumper cable from the vehicle battery. Leave the
vehicle's engine running.
Charging Cell Phone or Tablet Instruction:
1. Plug the switch cable B to USB 5V 2A output port.
2. Select appropriate connector and connect it to your mobile phones or tablet.
3. Press the switch button to charge.
Only for charging/power supply to 19V Notebook
1. Plug the switch cable A to USB 19V 3.5A output port.
2. Select appropriate connector for your Notebook and connect it to the switch cable A and your
Notebook.
3. Press the switch button to charge/power supply.

For power supply to 12V vehicle products or 12V electronics
1. Plug the optional switch cable to 12V 10A output port.
2. Connect the optional switch cable and 12V vehicle product or 12V electronics.
3. Press the switch button to power supply.
LED flash light
Press the switch 3 seconds to start the LED flash light.
There are 4 modes of LED light appear in order (normal. strobe. SOS. off) if you press slightly.
E. FAQ：
Q. How to turn off this appliance?
A. This appliance will power off automatically when no load or charging is complete
Q. Need how long time to full charge the E-Power?
A. Approx. 8 hours through the 14V1A input.
Q. How many times can this appliance charge for my cell phone?
A. Depend on the battery capacity of your cell phone. Take iPhone4 as an example, can full
charging 14 times.
18000mAh high capacity

Q. How long will this appliance take to charge my cell phone full?
A. Approx. 1 hour
Q. How long will this appliance on a full charge take to supply the Notebook?
A. 4-6 hours
Q. How many times can this appliance jump start the vehicle if it is in full battery?
A. Approx. 40 times.
Q. What's the lifetime of E-Power?
A. Usually 3-5years in normal condition.
Q. How long does the battery last after fully charged?
A. 6-12 months, however, we suggest to recharge it every 3 months.
Q. How long does the battery last still can jump start the car after fully charged?
A. 6-12 months
H. Warning:
1. Always make sure the blue plug of jumper cable connect with the jump start socket tight in
E-Power before jumping start the vehicle. Otherwise, it will affect the results, even causing the
melt of the blue plug.
2. Always check if the jumper clamps are well connected, check if the vehicle battery connector is
rusted or dirty, clean it before jumping start the vehicle. DO NOT jump start again after 3
attempts. Otherwise, it will damage the host. And Check your vehicle if it has other trouble.
3. DO NOT connect the two clamps. Otherwise, it may be dangerous!

4. DO NOT disassemble the host. Otherwise, it may be dangerous!
IMPORTANT! Never use the Jump Starter for more than 5 seconds. After 5 seconds of boost wait
until the cables cooled down. The warranty does not cover the jump starter Cables.
I OVER DISCHARGE:
Cause:
a. Product has not been used for long time but did not get charged, which causes over discharge.
Solution: We advise to get product charged every three month.
b. Product is used to force-start cars when battery is in low voltage (less than 3 indicators
power),which causes over discharge.
Solution: We advise to jump start cars at least 3 indicators on.
c. Product is used to start cars many times in short time, which causes over discharge.
Solution: We advise 5 sec. max. in one time car jump start and at least 30 sec. interval of each
car start.
Always take care when using the appliance
This appliance is not intended for use by young or infirm persons without
supervision
Do not use as a toy
Do not allow the appliance to become wet
Do not immerse the appliance in water
Do not operate the appliance in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust
Do not modify or disassemble the Booster. Only a repair technician may
repair this unit
Do not expose the appliance to heat
Do not store in locations where the temperature may exceed 70 °C
Charge only at ambient temperatures between 0 °C and 60 °C
Charge only using the charger provided with the appliance
Under extreme conditions, battery leakage may occur. Carefully wipe the
liquid off using a cloth and avoid skin contact when you notice liquid on
the batteries. In case of skin or eye contact, rinse immediately with clean
water and seek medical attention
At the end of their useful life, discard the appliance with due care for our
Environment
J. WARRANTY INFORMATION:
1.We offer a limited warranty for this product against any defects in material and workmanship
for a period of 12 months from the date of purchase by the end user/consumer. The conditions of
the warranty are as follows:
2.The warranty is only valid upon presentation of the original receipt (from dealer/retailer) by the

original purchaser with the product to be repaired or replaced
3.The warranty is void if the serial number, date of purchase and label has been removed
4.The warranty does not cover damage or product failure resulting from normal wear and tear,
physical abuse, improper installation, misuse, modification or repairs by unauthorized third
parties
5.We do not assume responsibility for any loss or damage incurred during shipment or as a result
of a force majeure
6.We are not liable for any incidental or consequential damages arising from the use or misuse of
this product
7.All warranty claims are limited to repair or replacement of the defective product and at the sole
discretion of us
8.If we repair or replace the product, the product will be covered for the remaining time of the
original warranty period. Repair or replacement may involve the use of reconditioned units which
are equivalent in function. Replaced part or product becomes the property of us
9.Consumable components such as batteries are not covered by the warranty

USER MANUAL - OBDII DATA SAVER CABLE FOR 600A BOOSTER
1) Check that the device is fully charged (5 indicator lights)
2) Plug the cable into the 12V port of the booster. DO NOT plug it into the 19V port.

WARNING
Always take care when using the cable
This cable is not intended for use by young or infirm persons without supervision
Do not use as a toy
Do not allow the cable to become wet
Do not immerse the cable in water
Do not operate the cable in explosive atmospheres, such as in the presence of flammable
liquids, gases or dust
Do not modify or disassemble cable. Only a repair technician may repair this unit
Do not expose the appliance to heat
Do not store in locations where the temperature may exceed 70 °C
At the end of their useful life, discard the appliance with due care for our environment
WARRANTY INFORMATION:
We offer a limited warranty for this product against any defects in material and workmanship for
a period of 12 months from the date of purchase by the end user/consumer.
The conditions of the warranty are as follows:
1. The warranty is only valid upon presentation of the original receipt (from dealer/retailer)
by the original purchaser with the product to be repaired or replaced
2. The warranty is void if the serial number, date of purchase and label has been removed
3. The warranty does not cover damage or product failure resulting from normal wear and
tear, physical abuse, improper installation, misuse, modification or repairs by
unauthorized third parties
4. We do not assume responsibility for any loss or damage incurred during shipment or as a
result of a force majeure
5. We are not liable for any incidental or consequential damages arising from the use or
misuse of this product
6. All warranty claims are limited to repair or replacement of the defective product and at
the sole discretion of us
7. If we repair or replace the product, the product will be covered for the remaining time of
the original warranty period. Repair or replacement may involve the use of
reconditioned units which are equivalent in function. Replaced part or product becomes
the property of us

Produced for Berner Trading Holding GmbH - Bernerstr. 6 D-74653 Künzelsau - T [phone] -
www.berner.eu
