Tahoe (Dwg # 13867-00 Rev G) October, 2005 1205941 1
Tahoe
Installation and Operating Manual
INTRODUCTION
The Tahoe is a single pump for industrial and warewash
applications. Setup is handled via potentiometers located on the
front of the unit under the cover. The Tahoe can dose based on
time, speed, time and speed, or pushing the rocker switch. It doses
recharge upon receipt of a signal and initial charge after the signal
has been present for 20 seconds. It runs continuously at the set
speed for rinse applications. It has a modular design so units can fit
together for multiple product applications, and also has side
knockouts for conduit connections. For manually activated dosing
applications such as pot & pan, the Tahoe Remote is available with
a remote push button dose trigger. For encapsulated product, the
Tahoe is available with a solenoid.
PREFACE
Material in this manual is subject to change without notice. Special
circumstances involving important design, operation, or
application information will be released via Equipment Technical
Bulletins. Every effort has been made to ensure this information is
accurate, but no guarantee is made as to the accuracy or
completeness of this document.
© Beta Technology, Inc., 2002
SPECIFICATIONS
D250MF01
Figure 1. Tahoe Dimensions
Enclosure
Molded ABS plastic, water-resistant, flame retardant
Pump
Peristaltic, self priming, self checking, 24 VDC
Maximum Vacuum: 8in/200mm of Mercury [Hg]
Maximum Pressure: 10psi/0.7 bar/69 kPa detergent,
30psi/2.1 bar/200kPa rinse
Detergent Flow Rate: 110ml/min nominal, not to run more
than 15 out of 30 minutes
Rinse Flow Rate: 16ml/min nominal, unlimited
continuous run with rinse tube
Ambient Temperature
104ºF (40ºC) maximum
Potentiometers Rocker Switch
Speed: 1-100% Up: Init. Charge/Prime
Recharge: 0-20sec/continuous Middle: Enable pump
Initial Charge: 0-190 seconds Down: Disable pump
Electrical
Input voltage 100-120 VAC 50/60 Hz 0.2 amp
Input voltage 200-240 VAC 50/60 Hz 0.1 amp
Alternate initial charge option voltage 24 VAC (+/-10%)
50/60 Hz 0.5 amp (use transformer 066135)
Please note that 230 VAC Tahoes do not have
100-120 VAC input wires. Tahoe Remotes and Tahoe
pot-and-pan units only accept 100-120 VAC inputs.
Please note that the Tahoe still has high
voltage inside when disabled, and must
only be serviced by qualified personnel.
To comply with the European Union
EN61010-1, the input power source must
go through an on/off switch or circuit
breaker, such as that on the dishwasher.
This must be marked as the disconnecting
device for the equipment.
Regulatory
CE, NSF, CSA, NRTL/C
INSTALLATION AND SETUP
The Tahoe installation chart shows potentiometer settings and
power sources for typical warewash applications. Most
applications utilize a single power input for initial charge and
recharge, but exceptions with a separate power input for
initial charge are noted on the chart.
Alternate Initial Charge (Europe)
This wiring configuration uses the Tahoe power input cable to
trigger recharge from the rinse arm, and a fill valve signal to
trigger initial charge. The fill valve signal needs to go through
a transformer so it is 24 VAC. This procedure must only be
performed by qualified personnel.
•Ensure no wires are live. Remove top cover by inserting
screwdriver under right side of cover and gently prying
off. Be careful not to damage unit. Remove screws.
•Bring the 24 VAC fill valve input from the transformer
through the knockout on the bottom of the Tahoe.

2 1205941 Tahoe (Dwg # 13867-00 Rev G) October, 2005
•Connect to the two quick disconnects in the Tahoe enclosure.
•Route wires per the diagram in the back of this manual.
•When replacing screws, insert into holes and turn
counterclockwise until they click/seat into the threads prior to
screwing in clockwise.
115- 230 VAC MAIN POWER
WIRE COLORS CIRCUIT VOLTAGE
BLK/WHT...................
BLK/RED...................
115 VAC 50/60 HZ
230 VAC 50/60 HZ
UNUSED WIRE IS LIVE AND MUST BE INSULATED
CAUTION
TAHOEM01
Figure 2. Input Voltage Cable label
Dual supply voltage Tahoe’s have a three
wire cable which accepts the label shown in
Figure 2 on either 115 or 230 VAC voltage
inputs. The unused wire must be insulated.
Single supply voltage units have a brown
and a blue wire for 230 VAC input.
For installations where the local law requires,
the power supply cable must be housed in an
impact-proof conduit to prevent severing of
the cable. Please refer to your local
authorities for details.
Prime/Push-Button Initial Charge
•Pushing the rocker switch up will activate initial charge if
power is present. A second push will stop the dose.
•If initial charge = 0, the pump will operate as long as the
switch is held up.
Remote Push Button Initial Charge
The Tahoe Remote is for pot and pan and other manually activated
dosing applications. It comes with a plug to accept a normal power
supply from the wall.
To use Remote for Initial Charge:
•Put all settings to "0" before connecting to power.
•Set recharge to "0", speed to 100%, and initial charge to
desired dose size.
•Tahoe will dose initial charge amount whenever you
push the Remote button.
•Note that it does not wait 20 seconds to dose when the
button is pushed, but begins the dose immediately.
TAHOEMF02
Figure 3. Rear view of two Tahoe units,
interlocked with #6 x ½” (12mm) self-tapping screws
Pot-and-Pan Sink Applications
The Tahoe solenoid has only low voltage in the dispenser, so
it can be safely installed over a sink. It is intended for use
with an encapsulated product and bowl unit such as W-6000.
1. Mount Tahoe unit near the sink, plug it in and attach
tubing.
2. Set the speed to 100%. The solenoid will turn on and off,
making a clicking noise, if the speed is not set to 100%.
3. Set the recharge to 0.
4. Set initial charge for the desired dose size.
The Tahoe is now ready for operation. It will dose the initial
charge amount whenever the switch on the front panel is
pressed upward.

Tahoe (Dwg # 13867-00 Rev G) October, 2005 1205941 3
TAHOE INSTALLATION CHART
SpeedApplication Chemical Injection
Point Power Alternate Initial Charge
Recharge
Initial Charge
Figure
Door Liquid
Detergent Wash Tank Rinse Solenoid N/A 100% 0-20 sec 0-190 sec 4 & 5
Door Liquid
Detergent Wash Tank Rinse Solenoid Fill Valve 100% 0-20 sec 0-190 sec
Door Liquid
Rinse Booster Wash Pump N/A 100% 0-20 sec 0 sec 4
Door Liquid
Rinse Rinse Line Rinse Solenoid N/A 1%-100% Continuous 0 sec 5
Conveyer Liquid
Detergent Wash Tank Rinse Solenoid Fill Valve 100% 0-20 sec 0-190 sec 6
Conveyer Liquid
Rinse Rinse Line Rinse Solenoid N/A 1%-100% Continuous 0 sec 6
Manual Dose Various
Liquids Various Plug N/A 1%-100% 0 0-190 sec
Sink/Solenoid Dry/Solid
Chemical Wall-mount 115VAC
Transformer
N/A 100% 0 0-190 sec
80%
90%
100%
70%
60%
50%
40%
30%
20%
10%
0%
100sec
80sec
60sec
15sec
20sec
RUN
CONTINUOUSLY
10sec
5sec
0sec 0sec
40sec
20sec
140sec
160sec
180sec
190sec
120sec
SPEED RECHARGE PRIME / INITIAL CHARGE
TAHOEM03
Turn potentiometers gently; they are fragile.

4 1205941 Tahoe (Dwg # 13867-00 Rev G) October, 2005
BULKHEAD
FITTING
RINSE
SOLENOID
RINSE
WATER
TAHOE
CABLE
TAHOEMF03
DETERGENT RINSE
WASH MOTOR
RINSE SOLENOID
POWER
TO TAHOE CABLE
CALORIFIER
(BOOSTER HEATER)
RINSE
INJECTOR
TAHOE
CABLE
0
1
RINSE
0
1
DETERGENT
WASHER MOTOR
POWER
TO TAHOE CABLE
Figure 4. Tahoe with Door machine
BULKHEAD
FITTING
RINSE
SOLENOID
RINSE
WATER
TAHOEMF04
DETERGENT RINSE
BOOSTER
HEATER
RINSE
INJECTOR
RINSE SOLENOID
POWER
TO TAHOE
CABLE
0
1
RINSE
0
1
DETERGENT
WASHER MOTOR
POWER
TO TAHOE CABLE
WASH MOTOR
TAHOE
CABLE
TAHOE CABLE
Figure 5. Tahoe with door machine-Rinse injection into pressurized rinse line

Tahoe (Dwg # 13867-00 Rev G) October, 2005 1205941 5
RINSE
INJECTOR
RINSE
WATER
CONVEYOR MACHINE
TAHOEMF05
BULKHEAD
FITTING
RINSE
SOLENOID
RINSE SOLENOID
POWER
TO TAHOE
CABLE
0
1
DETERGENT
FILL VALVE
POWER
TO ALTERNATE
INITIAL CHARGE
0
1
RINSE
ALTERNATE
INITIAL CHARGE
INPUT
FILL VALVE
TAHOE CABLE
TAHOE CABLE
Figure 6. Conveyer machine with alternate initial charge
MAINTENANCE
REPLACING PUMP CARTRIDGES
To Remove
1. Disable pump (power remains on).
2. Remove the cartridge from the motor housing by twisting the
snap pins.
To Install
1. Align and engage the pump drive spline with the motor gear
by rotating the roller assembly.
2. Turn the snap pins so that the arrow is pointed up. Then push
in until you hear a distinct click.
Replacing Pump Squeeze Tubing
To protect against pressurized spray, wrap
a rag around the connections when
replacing tubes.
1. Remove the cartridge as described above.
2. Remove the small screw at the bottom of the rear cover and
lift the cover from the cartridge.
3. Pull the adapter fittings back until they clear the cartridge.
4. Pull the roller assembly back to release the pump squeeze
tubing.
5. Cut the tie wraps holding the pump squeeze tubing to the
adapter fitting and pull the tubing from the fittings.
6. Replace the pump squeeze tubing, making certain to use
the proper size tube.
7. Push the adapters to the ends of the tubing and secure
with tie wraps. Make certain that the "buckles" of the tie
wraps are both facing the same direction. This will keep
the tube from twisting in the cartridge.
8. When using Flex, coat the inside of the cartridge with a
liberal amount of Silicon 111 lubricant.
9. Press the two adapter fittings into the cartridge so that
the tie wrap "buckles" face toward the center of the
pump. Remember, the tube must not be twisted during
the assembly.
Power remains on when pump is
disabled.
Pump interior should only be serviced by
qualified personnel.
Servicing Interior Parts
To access interior, slide top cover up and insert screwdriver
under right side of cover. Gently pry off, taking care not to
damage unit.

6 1205941 Tahoe (Dwg # 13867-00 Rev G) October, 2005
ORDERING INFORMATION
Complete Systems with Basic Installation Kits
Item#Part
099638 Tahoe, Detergent (Norprene standard),
115/230 VAC input
087298 Tahoe, Rinse (Bi-wall standard),
115/230 VAC input
087299 Tahoe, Sanitizer (Norprene standard),
115/230 VAC input
068020 Tahoe, Detergent (Norprene standard),
230 VAC input
068021 Tahoe, Rinse (Flex standard), 230 VAC input
087702 Tahoe Remote, (Norprene standard),
115 VAC input
1201016 Tahoe Solenoid, (115 VAC wall-mount transformer
input)
Spare Parts
Item#Part
087176 Tahoe PCB
099662 Tahoe internal transformer
051351 Motor/gearbox
039550 Roller assembly
043469 Wall-mount transformer
099986 Tahoe enclosure gasket
099705 Tahoe pump gasket
099709 Tahoe cover label
039553 Norprene detergent tube kit 1/4T-1/4T
058209 Silicone detergent tube kit 1/4T-1/4T
039552 Norprene rinse tube kit 1/8T-1/8T
058550 EPDM (Nordel) detergent tube kit 1/4T -1/4T
058552 Viton detergent tube kit 1/4T-1/4T
098158 Biwall rinse tube kit 1/8T-1/8T
092962 Flex rinse tube kit 1/8T-1/8T
097683 Flex rinse tube kit 4mmT-4mmT
058207 Silicone rinse tube kit 1/8T-1/8T
058549 EPDM (Nordel) rinse tube kit 1/8T-1/8T
058551 Viton rinse tube kit 1/8T-1/8T
092850 Flex sanitizer tube 1/4T-1/4T
057203 Norprene sanitizer tube 1/4T-1/4T
058778 Norprene food grade sanitizer tube kit 1/4T 1/4T
094678 Microbore PharMed .030”-0.76mm ID tube kit 1/8T-
1/8T

Tahoe (Dwg # 13867-00 Rev G) October, 2005 1205941 7
APPENDIX-SPARE PARTS
TAHOEMA01
MOTOR/GEARBOX
PUMP CARTRIDGE
ASSEMBLY
25
20
06
07
01
24 11
Seq# Item# Description
01 099150 Tahoe enclosure door
04 099986 Tahoe enclosure gasket
05 099662 Internal transformer
06 099153 Tahoe rocker switch
07 099154 Tahoe rocker switch cover
08 087048 Tahoe cover label
Seq# Item# Description
09 087176 Tahoe PCB
11 032121 Strain relief
19 099705 Tahoe pump gasket
20 099693 Tahoe rocker switch gasket
24 SCR,T-B,PH PNH,#4X1/2,SST
25 SCR,T-B,PH PNH,#4X5/8,SST,BLK

8 1205941 Tahoe (Dwg # 13867-00 Rev G) October, 2005
APPENDIX-WIRING
TAHOEMA02
ALTERNATE INITIAL CHARGE
24VAC INPUT

Tahoe (Dwg # 13867-00 Rev G) October, 2005 1205941 9
APPENDIX-LABEL TRANSLATIONS
TAHOEM02
ENGLISH
Prime/Initial charge
On
Off
Timed dosing (recharge)
Speed dosing
NEDERLANDS
Voor dosering/handmatige dosering
Aan
Uit
Tijds dosering
Snelheids dosering
ESPAÑOL
Carga Inicial/Cebado
Prender
Apagar
Dosif. Temporizada
Reg. Velocidad
DEUTSCH
Antriebsmaschine/ Erstfüllung
An
Aus
Zeitlieh kontrollierte Dosierung
Geschwindigkeitsdosierung
PORTUGUESE
Primeiro/Carga inicial
Ligado
Desligado
Temporização
Velocidade
SWEDISH
Tvångskörning/Grunddosering
Till
Från
Grund och tillsatsdosering
Varvtalsreglerad dosering
This Manual is available in Microsoft
Word. If you want to make a local
translation, contact your Beta
Technology, Inc. customer service
representative.
Beta Technology http://www.beta-technology.com
913 William Leigh Drive
Tullytown. PA. 19007
Phone [phone]
Fax [phone]
Cannon Water Technology Inc.
233 Technology Way Suite 9 Rocklin, CA 95765
Call us - 916-315-2691 FAX: [phone]
https://cannonwater.com [email protected]
