BHO Gemini 90 User manual

1
User Manual
Gemini 90
Extraction System

2
Introduction
How To Use
Precautions
User Manual
Contents
Page 3
Page 3-7
Introduction Page 4
How To Assemble Page 7
Pulling A Vacuum Page 8
Cooling The Column Page 9
Troubleshooting
Contact
Page 7-11
Page 12
Page 13
Product Breakdown Page 4
Specification Page 5
Online Resources Page 7
Administering Butane Page 10
Removing Your Final Product Page 10
Packing The Column Page 7
Removing Your Solvent Page 11

3
Introduction
Precautions
- Never put butane filled tubes in the freezer.
- Always use in extremely well-ventilated OUTDOOR Areas.
- Never operate near/around Open flames or other ignition sources
or risk fiery, explosive death.
- When using large amounts of dry ice, oxygen deprivation can
occur.

4
User Manual
Introduction
Introducing BHO Hardware’s exclusive open column material system,
the Gemini 90. Part of our Gemini series, the 90 is capable of holding
and processing between 53-91g of material.
The user Can develop solvent pressure by closing the valve at the bottom
of the Gemini 90 and packing it with material.
A vacuum can be pulled by attaching a hose to the extractor before
administering the solvent and leaving it to soak, the solvent and oil mix-
ture can then be released via the bottom valve.
Manufactured from 304 grade stainless steel, the Gemini 90 ideal for
extracting a range of essential oils. Each tube goes through rigorous
testing procedures before leaving our facility, combined with a two-year
warranty as standard. This ensures our customers receive both high
quality equipment and aftercare when using purchasing any of our
systems.
Gemini Open Blast
Features
All units are made of 304 grade stainless steel
Welded ball valves to reduce leaks (PTFE is needed)
An MB Valve on all lids to (providing safe and controlled gas flow)
A Quadpod (4 Prong Stand) to provide stability and eliminating the
need to hold the freezing cold tube during solvent administration
A Hose tail connector to allow the tube to be put under vacuum
pressure

5
Introduction
Product Breakdown
Mb Non-Return Valve1
End Cap
2
Gasket3
Tri Clamp4
Column
5
Gasket6
Filter
7
Quadpod / 4 Prong Stand8
Gas Outlet Ball Valve
10 Male Hose Tail Connector
9
1
2
3
4
5
6
7
8
10
9

6
User Manual
Specifications
Name, Index, Type Gemini 45
Different Accessories Can be added to the equipment to suit
your needs.
Gemini 90 Gemini 130

7
How To Use
Online Resources
1. For more information including a full walkthrough of the
Gemini 45 Extraction System, please visit:
www.bhohardware.com and search ‘Guides and How To’

8
How To Use
How to Assemble
1.For instructions on assembly please see the complete video walkthrough
How To Use
Packing The Column
1.Firstly, remove the clamp at the top of the column. Then begin to pour
in your material. (Tip: use a packing rod to compress the material, this
will result in better absorption and a cleaner, higher yield).
Once you have filled your tube, re attach the gasket and endcap using
the included clamp.

9
How To Use
Pulling a Vacuum
1.Once the column is full you can pressurize the column to remove
excess oxygen and moisture.
To do this, ensure that the bottom valve is in the “closed” position. Then
attach a hose to the bottom of the column and open the valve. Next,
ensuring the hose is connected to a pump, turn on the pump and begin
to remove the oxygen and moisture from within the column.
(This allows the butane to be administered and pass through the material
at a much faster rate) you can tell when a vacuum has been reached by
closing and opening the bottom valve.
If tone of the pump remains the same, a full vacuum has been reached.
How To Use
Cooling The Column
1. Freezing the column after pulling a vacuum is highly beneficial when
improving quality, clarity, and yield.
This can be done by placing the vacuumed tube into a freezer or dry ice
and letting the tube freeze for a minimum of two hours.

10
How To Use
Administering Butane
1. Once the tube has been frozen, simply insert the butane into the port
on the top and fill it to the necessary capacity
2. Once you have administered the necessary amount, let the tube sit for
between 10-30 minutes.
(Note: the longer it is let to sit, the higher the yield will be, however the
clarity and quality will also lower.)
How To Use
Removing the final product
1. After the tube has been let to sit, you can begin to collect your
product. Place a container under the quadpod (Such as a pyrex dish).
Next, slowly open the bottom valve to allow oil/butane solution to
fill the container.
The endcap at the top of the tube can be removed at his point.
(See The included specifications If your unsure)

11
How To Use
Removing Your Solvent
1.Now you have your oil/solvent soulution, the solvent can be removed.
Place the container into a warm water (Aprox 40-60°C). This will cause
the majority of the solvent to evaporate out of you oil.
Once the solution begins to stop bubbling, enough butane has been
removed to go on to the final process.
2.Now the last remnants of solvent can be extracted. Place your oil into
either a Vacuum Oven/Chamber.
(If your using a chamber it will need to be used with a heat mat,
available from the website).
The combination of heat and pressure from a vacuum will result in all the
solvant left being pulled out of the oil.
(This process should take a minimum of 48 hours, including flipping the
product half way through)
After this process is complete, your final product is now ready.

12
User Manual
TroubleShooting
Problem Possible Reason Solution

13
Thank you for buying with BHO Hardware.
We hope your newly-assembled hardware suits your
requirements. If any problems arise with our equipment,
contact our team via the following:
[e-mail]
www.bhohardware.com
0114 229 1807

14
Thank you.
[e-mail]
www.bhohardware.com
0114 229 1807
