USER MANUAL AND INSTRUCTIONS
Riva COMBI
WALL HUNG GAS BOILER FOR
CENTRAL HEATING AND DOMESTIC
HOT WATER SUPPLY
Please Read Instructions Carefully
Save for Future Reference
— Do not store or use gasoline or other flammable vapors and liquids
in the vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electric switch; do not use any phone in your
building.
• Immediately call your gas supplier from a neighbor’s phone.
Follow the gas supplier’s instructions.
• If you can not reach your gas supplier call the fire department.
— Installation and service must be performed by a qualified installer,
service agency or the gas supplier.
WARNING: If the information in this manual is not
followed exactly, a fire or explosion may result causing
property damage, personal injury or loss of life.
Manufactured by:
Biasi S.p.A.
Verona, Italy
Distributed By:
Quincy Hydronic Technologies, Inc.
80 Rochester AVE. Suite # 12
Portsmouth, NH 03801
Phone: [phone]
Fax: [phone]
RIVA COMBI USER MANUAL - REV
A

RIVA COMBI USER MANUAL - REV A 2

RIVA COMBI USER MANUAL - REV A 3
Dear Customer:
Thank you for buying a Biasi Riva Combi Boiler System.
The Riva Combi is a high efficiency, non-condensing, wall mounted gas boiler which
provides central heat and domestic hot water.
We realize that it is not possible to answer all questions about the Riva Combi boiler
system in this manual. Reading this installation manual does not make the reader an
expert in all aspects of installation and operation, and does not replace the need for a
qualified, licensed heating contractor. We urge you to contact your installing contractor or
distributor if you are in question about any aspect of your boiler's performance. Our main
concern is that you are satisfied with your boiler and its performance. We require that your
contractor complete efficiency tests using instruments.
The external controls and accessories listed in this manual (excluding those supplied
inside the boiler) are intended to serve as guidelines rather than specific
recommendations. We realize that other makes and models of such devices are available
and can be used as successfully as those we specify. The installing contractor is the best
judge of a system's specific requirements, as well as the local availability of certain makes
and models of controls and accessories. The preceding does not apply, however, to the
equipment that comes with every boiler, such as the overheat control and pressure relief
valves. The installation of the specific devices supplied with every boiler is
absolutely necessary to the safe operation of the boiler and protection of the
heating system.
All BIASI wall hung boilers are built in accordance with the ASME boiler and pressure
vessel code, and bear the "H" stamp. The Entire range of applications for the Riva Combi
has been tested to standard CSA 4.9 and is CSA compliant.
This Riva Combi has a 2 year warranty, a copy of which is provided with the boiler. Please
be sure to return the warranty registration card as the warranty will be void without your
boiler's serial numbers (located on the ratings label affixed to the boiler), date of
installation and the name of your installer being on record in our files.
Thank you for purchasing our Riva Combi boiler. If you have questions or comments,
please don't hesitate to contact us immediately. Our goal is 100% customer satisfaction.
QHT inc.

Table of Contents
Section Title Section Number Page
Warnings - 5-6
Important Information - 7
General Information 1 8
Technical Information 2 8-9
Appliance Description 3 10
Operation Lights 4 11
Instructions for Use 5 12-14
Warnings 5.1 12
Refilling Procedure 5.2 12
Lighting/Operation Instruction 5.3 13
Central Heating Circuit Temp. 5.4 13-14
Domestic Hot Water Temp. 5.5 14
Extinguishing Instructions 5.6 15
Useful Advice 6 16-18
Central Heating 6.1 16
Frost Protection 6.2 16
Periodic Maintenance 6.3 16
External Cleaning 6.4 17
Operational Faults 6.5 17-18
Warranty 19
RIVA COMBI USER MANUAL - REV A 4

Boiler is certified as an indoor appliance. Do not install boiler outdoors or locate where
it will be exposed to freezing temperatures.
W
ARNING
— Do not store or use gasoline or other flammable vapors and liquids
in the vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electric switch; do not use any phone in your
building.
• Immediately call your gas supplier from a neighbor’s phone.
Follow the gas supplier’s instructions.
• If you can not reach your gas supplier call the fire department.
— Installation and service must be performed by a qualified installer,
service agency or the gas supplier.
WARNING: If the information in this manual is not followed
exactly, a fire or explosion may result causing property
damage, personal injury or loss of life.
Caution: Do not use this boiler if any part has been under water. Immediately
call a qualified service technician to inspect the boiler and to replace any part of
the control system and any gas control which has been under water.
Caution: Should overheating occur or the gas supply fail to shut off, do not turn
off or disconnect the electrical supply to the pump. Instead, shut off the gas
supply at a location external to the appliance.
Caution: Do not store or use flammable materials, chemicals or flammable
liquids, especially gasoline, in the vicinity of this heating appliance.
DANGER
RIVA COMBI USER MANUAL - REV A 5

Any appliance that burns natural gas, propane gas, fuel oil, wood or coal is capable of
producing carbon monoxide (CO). Carbon Monoxide (CO) is a gas which is odorless,
colorless and tasteless but is very toxic. CO is lighter than air and thus may travel
throughout the building.
BRIEF EXPOSURE TO HIGH CONCENTRATIONS OF CO, OR
PROLONGED EXPOSURE TO LESSER AMOUNTS OF CO MAY
RESULT IN CARBON MONOXIDE POISONING. EXPOSURE CAN BE
FATAL AND EXPOSURE TO HIGH CONCENTRATIONS MAY RESULT
IN THE SUDDEN ONSET OF SYMPTOMS INCLUDING
UNCONSCIOUSNESS.
Symptoms of CO poisoning include the following:
dizziness vision problems shortness of breath
headache loss of muscle control unclear thinking
nausea weakness unconsciousness
The symptoms of CO poisoning are often confused with those of influenza, and the
highest incidence of poisoning occurs at the onset of cold weather or during flu season.
A victim may not experience any symptoms, only one symptom, or a few symptoms.
Suspect the presence of carbon monoxide if symptoms tend to disappear when
you leave your home.
The following signs may indicate the presence of carbon monoxide:
• Hot gasses from appliance, venting
system pipes or chimney, escaping into
the living space.
• Flames coming out around the appliance.
• Yellow colored flames in the appliance.
If any of the symptoms of CO occur, or if any of the signs of carbon monoxide are
present, VACATE THE PREMISES IMMEDIATELY AND CONTACT A QUALIFIED
HEATING SERVICE COMPANY OR THE GAS COMPANY OR THE FIRE
DEPARTMENT.
ONLY QUALIFIED, LICENSED SERVICE CONTRACTORS SHOULD PERFORM
WORK ON YOUR BIASI RIVA COMBI BOILER.
• Stale or smelly air.
• The presence of soot or carbon in or
around the appliance.
• Very high unexplained humidity inside
the building.
W
ARNING
RIVA COMBI USER MANUAL - REV A 6

IMPORTANT INFORMATION
Please read this page carefully.
• ALL BOILERS MUST BE INSTALLED IN ACCORDANCE WITH NATIONAL,
STATE AND LOCAL PLUMBING, HEATING AND ELECTRICAL CODES AND
ORDINANCES, AS WELL AS THE REGULATIONS OF THE SERVING
ELECTRICAL, WATER AND GAS UTILITIES.
• All systems should be designed by competent contractors, and only persons
knowledgeable in the layout and installation of heating systems should
attempt the installation of any boiler. It is the responsibility of the installing
contractor to see that all controls are correctly installed and operating
properly when the installation is completed.
• This boiler is intended for use, only with propane or natural gas. All
flammable liquids (especially gasoline), chemicals, rags, paper, wood
scraps, debris, etc., should be kept away from the boiler at all times. Keep
the boiler area clean and free of all fire hazards.
• Please read the literature and warranties supplied by the manufacturers of
the various accessory equipment. This equipment is warranted by the
respective manufacturers, not by Quincy Hydronic Technologies, Inc. Each
piece of equipment must be installed and used according to the
recommendations of the manufacturer.
Codes and Regulations:
Installation of the boiler and related equipment must conform to national, state and
local regulating agencies and codes applicable to the installation of the equipment.
In the absence of local requirements, the following codes apply:
RIVA COMBI USER MANUAL - REV A 7
A. ANSI/NFPA - #70 National Electric Code
B. ANSI/NFPA - #211 Chimneys and Vents
C. ANSI/NFPA - #Z223.1 National Fuel Gas Code
C. ANSI/NFPA - Domestic Gas Conversion Burner
D. CAN/CGA - B149 Installation Codes
E. ANSI/ASME - CSD-1
The above codes are available from:
National Fire Protection Association (NFPA)
Battery March Park
Quincy, Massachusetts, 02269
http://www.nfpa.org
CSA International
8501 E. Pleasant Valley Road
Cleveland, OH 44134-5575
http://www.csa-international.org

1. General Information
The Riva Combi is a high efficiency, non-condensing, wall mounted gas boiler which
provides central heat and domestic hot water. The boiler features a gas valve which
modulates the energy input from 44,000 BTU/h to 108,000 BTU/h. The boiler is shipped
fully assembled. All units are pressure and combustion tested at the factory prior to
shipping.
Key Features:
• Wall mountable - saving valuable
floor space.
• Several flue options available.
• Electronic spark ignition.
• Safety flow switch - positioned on the
main circuit, which monitors the flow
and protects the main heat exchanger
from thermal shock should there be a
lack of water in the system.
• Frost protection - contains an integral
frost protection system to prevent
frost damage which can occur in
areas susceptible to very cold
weather conditions.
• Boiler operation recognition
system - should the boiler not be used
for longer than 24 hours, it then
performs a controlled system test to
ensuring the motorized components
within the boiler do not become
inoperable due to lack of use.
• Gas valve modulation - the gas input
modulates based off central heating
and domestic hot water temperature
to within ± 2 ºF.
• Diagnostic information system
equipped with three LED diagnostic
lights for quick error assessment.
2. Technical Information
(
M35.30CB
)
RIVA COMBI USER MANUAL - REV A 8
GENERAL
Height in
35.4
Width in
23.6
Depth in 18.1
Weight lb
172
CENTRAL HEATING
Maximum working temp. °F 185
Temp. Regulation range* °F 100-176
Maximum pressure psi 30.0
Minimum pressure psi 4.35
Max head loss (at 4.4 GPM) ft 10
*At the minimum useful output
DOMESTIC HOT WATER
Maximum temperature °F 140
Minimum temperature °F 100
Maximum pressure psi 116
Useful tank capacity gal 13.2
D.h.w circuit flow rate
∆T = 30 °K gpm 3.99
Continous d.h.w production
∆T = 25 °K gpm 4.54
Continous d.h.w. production
∆T = 40 °K gpm 2.85
Preparation time min 7’57”

2.Technical Information Cont.
RIVA COMBI USER MANUAL – REV A 9
ENERGY CAPACITY
Nominal heat input
(0/2000ft) MBH 122.8
Nominal heat input
(2000/4500ft) MBH 116.7
Minimum heat input MBH 49.5
Maximum useful output
(0/2000ft) MBH 100.7
Maximum useful output
(2000/4500ft) MBH 95.9
Minimum useful output MBH 37.0
GAS SUPPLY PRESSURE
Gas Normal Min Max
Natural inwc 7.0 3.5 10.5
Propane inwc 11.0 8.0 12.0
GAS PRESSURE AT BURNER
Gas Min Max Ignition
Natural inwc 0.8 5.3 2.4
Propane inwc 1.4 9.0 5.2
FLUE DESIGN
Minimum Venturi pressure inwc 0.66
Flue pipe diameter
Coaxial in
2.25/4
3.25/5
Twin split pipes in 3.25/3.25
Nominal heat flow rate
(0/2000ft) MBH 122.8
Nominal heat flow rate
(
2000/4500ft
)
MBH 116.7
Min Exhaust temperature °F 255
Max Exhaust temperature °F 302
INJECTORS No. Size
Natural 14 130
Propane 14 89
GAS FLOW RATE
Gas Min Max
Natural ft³/h 48.7 121.1
Propane lb/h 2.23 5.55
ELECTRICAL
Voltage V 120
Frequency Hz 60
Current A < 1.6
Power consumption W 176

3. Appliance Description
3.1 Overview:
1 Case front panel
2 Control panel
3 Control panel cover
3.2 Control Panel:
4 Central heating circuit temperature
and pressure gauge
5 Lock-out signal lamp
6 Boiler reset button
7 Function switch and Central heating
temperature adjustment knob
8 Domestic hot water temperature
adjustment knob
9 Appliance operation lights
1
2
3
Figure 3.1
9 78 6 5 4
Figure 3.2
3.3 Piping Connections:
10 D.h.w. PRV discharge pipe
11 C.h. PRV discharge pipe
12 Domestic cold water inlet pipe
13 Domestic hot water outlet pipe
14 Central heating flow pipe
15 Central heating return pipe
16 Gas inlet pipe
15 1213 10 11
14
16
Figure 3.3
RIVA COMBI USER MANUAL – REV A 10

4. Operation Lights
Three lights (9 in Fig. 3.2) give detailed indication regarding the operation of the boiler.
The following table gives the relationship between each of the possible light combinations
and their meaning.
A short pulse every 4seconds: stand-by condition Function
selector in position. Anti-freeze system active
1 second pulse every 2 seconds: normally operating boiler.
Function selector in on position
Central heating operation
Domestic hot water operation
Frost protect operation
Domestic hot water operation
Excessive temperature on primary circuit
Faulty central heating temperature probe NTC
Faulty domestic hot water temperature probe NTC
Faulty primary circuit (no water or absence of flow)
Lack of burner ignition (no ignition signal from the full
sequence ignition device
Ignition gas pressure adjustment
Minimum gas pressure adjustment
Lamp OFF Lamp ON Flashing lamp, alone
or simultaneously
with another lamp.
Flashing lamp,
alternate with
another lamp
RIVA COMBI USER MANUAL – REV A 11

5. Instructions For Use
5.1 Warnings:
• In order to guarantee safety and correct operation, it is essential that all the tests are
carried out by a competent and responsible licensed service person before lighting up
the boiler.
• The tests are described in the installation, operation and service instructions manual in
Section 15 Commissioning.
• Ensure that the Central Heating circuit is regularly filled with water (even if the boiler is
only used for d.h.w. supply) checking that the pressure indicated on the temperature
and pressure gauge (4 on figure 3.2) is not lower than 1 bar (14.5 psi) as shown on
figure 5.1.
• If the pressure reading on the pressure gauge is below 1 bar (14.5 psi), then the
system will require filling. An automatic filling valve is normally provided by the installer
for this purpose.
• If you are in any doubt regarding this procedure you are advised to contact your
Installer or an Approved Service Person.
• This appliance is provided with a built in anti-freeze system that operates the boiler
when the temperature is below 41 °F
• Therefore, when the boiler is not lit or used in cold weather, with consequent risk of
freezing do not switch off the boiler at the circuit breaker or close the gas inlet
cock.
• When you expect not to use the boiler for a long period follow the instructions given in
section 5.6 on page 15.
5.2 Refilling procedure:
• Isolate the boiler from the electrical
supply at the circuit breaker.
• The boiler should have been installed
with an automatic fill valve, external to
the unit. Open the cold water supply
to the automatic fill valve.
• The pressure should be 1 – 1,5 bar
(14.5 – 22 psi).
• The automatic fill valve should
maintain this pressure, but not exceed
it.
0 42
31
Figure 5.1
Air introduced into the boiler during this filling process will vent through the automatic air
purger fitted to the boiler. You may also find it necessary to vent air from your heating
circuit using the installed vents, however be aware that excessive venting will cause the
pressure in the system to drop. Always ensure that the pressure gauge is set at the
required pressure.
RIVA COMBI USER MANUAL – REV A 12

5. Instructions For Use Cont.
5.3 Lighting/Operating Instructions:
Warnings: Do not attempt to start the boiler unless all cleanout doors are secured
and sealed. Do not attempt to light the burner by hand.
1 Check that the cocks connected to
the gas inlet pipe and to the domestic
cold water inlet pipe (see 3.3 for
pipes) are open.
2 Turn on the electricity supply to the
boiler, switching on the circuit
breaker. The appliance operation
light 9 (figure 5.2) will flash every 4
seconds (stand-by condition).
9 78 6
5
Figure 5.2
3 If the boiler is to be used for c.h and
d.h.w position the function selector 7
as in figure 5.3. The appliance
operation light 9 will flash every 2
seconds (operating boiler).
9 78 6
5
Figure 5.3
4 If the boiler is to be used for d.h.w.
only position the function selector 7
as in figure 5.4. The appliance
operation light 9 will flash every 2
seconds (operating boiler).
9 78 6
5
Figure 5.4
5 If the appliance will not operate,
follow the extinguishing instructions
on page 15 and call your service
technician or gas supplier.
5.4 Central Heating Circuit Temperature:
1 The output temperature of c.h. water
is adjustable from a minimum of
about 100 °F to a maximum of about
176 °F (Figure 5.5), by turning the
knob 8
2 Adjustment of the boiler temperature
alters the gas flow at the burner
according to the thermal demand in
the system. So it is usual to see the
burner lit at the minimum level for
more or less long periods.
3 Adjustment of central heating. output
on the boiler is automatic. The
greatest output is factory pre-set,
however, it can be reduced
according to actual system
requirements; this does not affect
the maximum output in d.h.w.
operation. These adjustments must
be carried out by a qualified person;
therefore we advise you to contact
your installer or Service Agent.
Figure 5.5
RIVA COMBI USER MANUAL – REV A 13

5. Instructions For Use Cont.
Adjustment:
• In order to achieve optimal settings for
economy and comfort, we recommend
adjusting the operating temperature of
the central heating water according to
the outside temperature, positioning
the knob as in figure 5.6
• Your installer may have installed
aditional energy saving equipment
and will be able to recommend the
most suitable adjustment for your
system.
• The temperature and pressure gauge
(Fig. 5.1 on page 12) will allow you to
check that the set temperature is
obtained.
Lower than
23 °F
From 41 to 59 °F Between 23
and 41 °F
Figura 5.6
5.5 Domestic Hot Water Temperature:
• The temperature of the domestic hot
water (d.h.w.) leaving the boiler can
be varied from 100 °F to a maximum
of about 140 °F (Figure 5.7), by
turning the knob 8.
• The adjustment system integrated
within the boiler automatically controls
the flow of gas to the burner in order
to keep the temperature of d.h.w.
delivered constant, between the limits
of maximum and minimum output.
• Where the demand is at a low level or
with the temperature set to the
minimum, it is normal to see a cycle of
lighting and extinguishing of the
burner when running.
Minimum
Maximum
8
Figure 5.7
Adjustment:
• It is advisable to adjust the d.h.w.
temperature to a level commensurate
with the demand, minimising the need
to mix with cold water. In this way, the
automatic control facilities will be fully
exploited.
• Where the amount of limescale
present in the water may be
particularly great not exceeding the
position in Fig. 5.8 of the d.h.w.
temperature control knob 8, minimises
annoying incidences of scale deposits
and clogging.
• However it is advisable to install a
small water treatment device or
softener. With such a device you
should avoid periodic descaling.
Minimum
8
OK
Figure 5.8
RIVA COMBI USER MANUAL – REV A 14

5. Instructions For Use Cont.
5.6 Extinguishing Instructions:
• To turn the boiler off set the function
selector 7 to the position shown in the
Figure 5.9.
• The appliance operation light 9 will
flash every 4 seconds (stand-by
mode).
• Turn off electric power to the appliance
at the circuit panel of boiler
serviceman’s switch.
9 78 6
5
Figure 5.9
When you expect not to use the boiler for a long period:
• Switch off the electricity supply to the boiler, by means of the circuit breaker;
• Shut off the gas supply cock connected to the gas inlet pipe and the cock connected to
the domestic cold water inlet pipe (see 3.3 for pipes)
• Empty the water circuits, if necessary, as shown in the installation, operation and
service instructions manual in the maintenance section .
RIVA COMBI USER MANUAL – REV A 15

6. Useful Advice
6.1 Central Heating:
• For reasonably economical service
install a room thermostat.
• Never shut off the radiator in the area
where the room thermostat is
installed.
• If a radiator (or a convector) does not
heat up, check that no air is present in
it and that its valve is open.
• If the ambient temperature is too high,
do not alter the radiator valves.
Reduce the central heating
temperature instead by means of the
room thermostat and the knob (7 in
Fig. 6.1).
7
Figure 6.1
6.2 Frost Protection:
• The built in antifreeze system and any additional system protect the boiler from
possible damages due to the icing.
• This system doesn’t guarantee the protection of the whole central heating system.
• In the case that the external temperature may be lower than 32°F it is suggested to
leave the system running setting the room thermostat at a low temperature.
• When the boiler is completely switched off for a long period, it is recommended to
empty completely both central heating and domestic hot water circuits.
6.3 Periodic Maintenance:
• For efficient and continuous operation of the boiler, it is advisable to arrange
maintenance and cleaning by an Authorised Service Person, at least once a year.
• During the service, the most important components of the boiler will be inspected and
cleaned. This service can be part of a maintenance contract.
In particular, you are advised to have the following checks carried out:
• primary heat exchanger;
• magnesium anode;
• burner;
• exhaust fume duct and flue;
• pressurization of the expansion vessels;
• filling up of the central heating circuit;
• bleeding of air from the central heating system;
• general check of the appliance’s operation.
RIVA COMBI USER MANUAL – REV A 16

6. Useful Advice Cont.
6.4 External Cleaning:
• Before performing any cleaning, disconnect the appliance from the electrical mains,
using the dedicated circuit breaker or serviceman’s switch located adjacent to the
appliance.
• To clean the external panels, use a cloth soaked in soapy water. Do not use solvents,
abrasive powders or sponges.
• Do not carry out cleaning of the appliance and/or its parts with readily flammable
substances (for example petrol, alcohols, naphtha, etc.).
6.5 Operational Faults:
If the lock-out signal lamp comes on:
• This indicates that the safety lock-out
5 (Fig. 6.2) has stopped the boiler
• To re-start the boiler, it is necessary to
turn the function selector 7 in the
position and then press the boiler
reset button 6 (Fig. 6.2).
• For the first light up and following
maintenance procedures for the gas
supply, it may be necessary to repeat
the resetting operation several times
so as to remove the air present in the
pipework.
6
5
7
Figure 6.2
If noises due to air bubbles are heard during operation:
• You should check that the pressure on the temperature and pressure gauge(Fig. 5.1 on
page 12) is not below the correct setting.
• If required, fill up the system correctly, as described in the section 5.2 of this manual.
• Bleed any air present in the radiators, if necessary.
If the pressure on the temperature and pressure gauge (Figure 5.1 on page 12) has
gone down:
• It is necessary to fill up the appliance with water again, so as to raise the pressure to an
adequate level as described in the section 5.2 of this manual.
• If filling up with water has to be done very frequent, have the system checked for leaks.
If water comes out of the pressure relief valve 11 in Fig. 6.3:
• Check on the temperature and pressure gauge (page 12) that the pressure in the
central heating circuit is not close to 3 bars (43.5 psi). In this case, temperature rise in
the circuit can cause the pressure relief valve to open.
• So that this does not happen and to decrease the pressure to a normal value, it is
advisable to vent some of the water in the appliance through the bleed valves present
in the heating system.
RIVA COMBI USER MANUAL – REV A 17

6. Useful Advice Cont.
If water comes out of the storage tank pressure relief valve 10 in Fig. 6.3:
• This means that the pressure in the
domestic hot water circuit is more
than 8 bars (115 psi).
• To avoid this situation, it is advisable
to install a pressure reducing device
upstream of the domestic hot water
inlet valve.
• The pressure in the domestic hot
circuit should be lower than 8 bars
(115 psi).
10 11
Figure 6.3
If water should occasionally leak from the boiler:
• Close the cocks connected to the inlet gas pipe and to the domestic cold water inlet
pipe under the boiler and call an Authorised Service Person.
In case of problems other than those mentioned here, switch off the boiler, as
described in Section 5.6 on page 15 and call a competent and responsible service
person.
RIVA COMBI USER MANUAL – REV A 18

Warranty
For RIVA Residential
Wall Hung Gas Boilers
FIRST 2 YEARS-WARRANTY FOR RIVA SERIES
RESIDENTIAL HOT WATER BOILERS: QHT warrants that
itswall hung boiler and casing are free from defects in material
and workmanship for 2 years from the date of installation. If
any part on the boiler is found to be defective within this
period, QHT will replace the part free of charge.
FIRST 5 YEARS-WARRANTY FOR RIVA SERIES
RESIDENTIAL HOT WATER BOILERS: Biasi warrants that
the copper tube heat exchanger of the RIVA boilers are free
from defects in material and workmanship for 5 years from the
date of installation. If the copper tube heat exchanger is found
to be defective within the first 5 years after installation, QHT
and Biasi will replace the copper tube heat exchanger.
These warranties are subject to the condition that a heating
contractor whose principal occupation is the sale and
installation of heating equipment must have installed the
boiler. PARTS, WHICH ARE COVERED, consists of all
materials supplied by Biasi, identified by QHT's part numbers
in its literature. Other parts supplied by the installer carry their
own warranty and each manufacturer has responsibility for its
own products.
NOTE: ANY PART, WHICH IS REPLACED UNDER
WARRANTY, CARRIES ONLY THE UNEXPIRED PORTION
OF THE ORIGINAL WARRANTY.
OWNER RESPONSIBILITIES:
1. Provide for proper installation, which includes pressure
relief and pressure reducing valves and high limit safety
controls on closed systems.
2. Provide qualified periodic service to prolong proper
operation and service.
3. Insure that boiler is installed in accordance with all codes
and ordinances.
4. This warranty does not apply to boilers, which are subject
to misuse, abuse, neglect, alteration, accident, excessive
temperature, excessive pressure, or corrosive water or
atmosphere.
5. Owner will be responsible for return of faulty components to
Portsmouth, NH, freight pre-paid.
QHT and Biasi will not be responsible for:
1. Components that are part of the heating system, but were
not manufactured by Biasi or QHT as part of the boiler.
2. The workmanship of the installers of RIVA boilers.
Furthermore, this warranty does not assume any liability
for unsatisfactory performance caused by improper
installation.
3. Any costs for labor to remove or replace the faulty
component.
4. Improper boiler application or adjustments, control settings,
care or maintenance.
5. Any damage associated with corrosion or leakage due to
the use of "non-barrier", plastic pipe in the heating system.
*IMPLIED WARRANTIES OF FITNESS FOR A PARTICULAR
PURPOSE AND MERCHANTABILITY SHALL BE LIMITED
TO THE DURATION OF THE EXPRESSED WARRANTY.
BIASI AND QHT EXPRESSLY DISCLAIM AND EXCLUDE
ANY LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL
DAMAGES FOR BREACH OF ANY EXPRESSED OR
IMPLIED WARRANTY.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS,
AND YOU MAY HAVE OTHER RIGHTS THAT VARY FROM
STATE TO STATE.
For prompt warranty service, notify the installer, who, in turn,
will notify the distributor from whom the boiler was purchased.
If this does not result in corrective action, contact Biasi
through Quincy Hydronic Technologies (Address Below) with
details in support of the warranty claim. All claims must be
processed through proper trade channels. Contact with Biasi
directly is not recommended for rapid claim settlement.
Quincy Hydronic Technologies,
80 Rochester Ave. Suite #12
Portsmouth, NH, 03801
Tel. [phone]
_
______________________________________________________
_
______________________________________________________________
BIASI BOILER WARRANTY REGISTRATION
IMPORTANT., Registration required. To gain complete warranty
Protection, fill in and mail this card, within 1 year of installation to the address listed below
NAME:____________________________________ ADDRESS:__________________________
CITY:_______________________ STATE:______ ZIP:____________
BOILER SERIAL NO.: ___________________ DATE OF INSTALL:________________________
NAME OF INSTALL CO.:______________________ ADDRESS:__________________________
CITY:_______________________ STATE:______ ZIP:____________
RETURN TO: QHT, INC., 80 ROCHESTER AVE., SUITE 12, PORTSMOUTH, NH 03801

*1796212870*
17962.1287.0 2906 (20A4)USA
