Big Dipper SEVEN STARS M020RG/4 User manual

SEVEN STARS
BIG DIPPER LASER SCIENCE & TECHNOLOGY CO.,LTD
REV:2.00
LASERDISPLAYSYSTEM
USER MANUAL
Please read the manual carefully before operating
®
®

BEAM LASER USER MANUAL
MODEL: M020RG/4
Notices
1. This is 3B laser product .Avoid eyes direct exposure to the laser
light.
2. Operate abide by the user manual .Do not disassemble or
repair the system by yourself . When there is a problem, please
contact technician, or your local dealer.
3. Installation should be done by professional technician.
4. Please set the laser product far away from those things as
strobe light.
5. Do not exposure the system to wet environment.
6. Do not touch the system by wet hand and pull the power cable
forcefully.
7. The work temperature is 10-40℃,so the laser conduct doesn’t
work until it reach the work temperature when taking it in from
cold environment .
8. Do not turn on or off the system frequently, avoid turning on it
for long time.
9. Prevent from strong vibration or G-shock to the system.
10. Prevent other harmful objects from entering the system.
11. Keep at least 1 meter between the system and the objects in
the lighting.
12. Connect the power cable after the system has been installed.
13. Turn on the computer after the laser display system is on,
or you must power on the computer again.
Page 1
ADDRESS: DMX address setup
1. When the 10th code is ON, the function of 1-9 codes is the
following
The 1st code is OFF-----Sound control mode
The 1st code is ON------AUTO play mode
The 3th code is ON------patterns and dots mode
2. When the 10th code is OFF---DMX control
Maintenance
Clean the lens regularly. Do not use a wet cloth or chemicals; use a
damp cloth. The maintenance period depends on the usage
frequency and surrounding conditions of the LASER display system.
It is recommended that the system should be cleaned every 15 days.
Warning
Power off any related system before maintenance.
Declare
The end-user of this product should abide by the above instructions
and warnings. Performing actions which was advised not too do so
as stated by this manual may void the warranty of this laser display
system.
All products made from Big Dipper Laser Company have anti -
fake identification. please verify the anti-counterfeit label at the
bottom of the case to ensure the interests of consumers.
Page 6

DMX channel setting
Channel NO.
DMX512
value
Content
1 Control
mode
0-63 Shut off the LASER diode
64-127
Sound mode
128-191 Auto mode
192-255
Manual mode
2 Pattern 0-39 Static pattern
40-255
Dynamic pattern
3 Strobe 0-30 No strobe
31-255
Strobe ,8 grade speed
4 Display 0-69 Normal display
70-255
Dot and line display
5 Horizontal
move
0-160 Manual move
161-220
Unilateralism move
221-255 Automatic move around
6 Vertical
move
0-160
Manual move
161-220
Unilateralism move
221-255
Automatic fluctuate (from up to
down and down to up)
7 Zoom
0-2 No zoom
3-90 Manual zoom
91-146
Automatic zoom out
147-200 Automatic zoom in
201-255
Automatic zoom
8 Color 0-99 Red and Green
100-199
Red
200-255 Green
9 Reset 0-255
The channel value is 200 or bigger
than 200, then the system reset.
10 Y-axis
rotation 0-150 Manual rotation
151-255 Auto rotation
11
X-axis
rotation
0-150
Manual rotation
151-255 Auto rotation
12
Z-axis
rotation
0-180
Manual rotation
181-255 Auto rotation
Page 5
14.Before powering on the system, be sure the power cable is
connected into the power socket well.
15.Turn off the system for 25 minutes after running constantly for
three hours, ensure that the system is able to cool down in a
suitable environment.
16.When to be transported, use the original package to avoid
damage.
17. This sign indicates separate collection for electronics and
electrical equipment.
Inspection
Check that the following components are present within the package
when receiving system - from the list below:
1 x LASER display system 1 x User manual
1 x Power cable
1 x DMX cable（option）
Installation
1. Be sure that there is no flammable or explosive subjects nearby.
The least clear proximity from the system should be 1.5 meters. At
the same time, keep more than half a meter between the wall and
LASER display system.
2. Be sure the power socket output voltage matches that off the
LASER display system.
Page 2

3. Ensure the fan and the exhaust is not blocked.
4. The LASER display system should be statically fixed.
5. It is essential to be earthed well for the sake of safety.
Back panel
①②③④⑤
Key-press function instruction
① DMX OUT：DMX512 signal output
② DMX IN：DMX512 signal input
③ DMX ADDRESS：Binary address switch
④Fan
⑤ F3AL 250V: Input power with internal fuse (3A)
Page 3
Technical parameters
Model
Parameter M020RG/4
1
LASER diode
Red/Green
2 Power supply 100-240VAC, 50/60HZ
3
LASER power
R:650nm 120-150mW G:532nm 40-50mW
4 Scanner angle ±18°
5
Control mode
Sound/auto-play/single pattern by DMX
6 Peculiarity
Saving static and dynamic patterns. Displaying
two effects (one is fast, another is slow). Can be
changed by DMX,and easy to operate.
7 Effect
Displaying more than 50 light beams and
patterns, displaying laser patterns specified by
international laser display association, such as
diffusing laser network. Slowly rotating color fan,
time and space tunnel and fairy flowers. (Can be
programmed with customers)
8 Dimensions 432.4 × 202.4 × 117mm
9 Net weight/
Gross weight 5.3/6.0KG
Remark: On the DMX 512 mode, the LASER display system will
shut off ，if the DMX 512 signal intermit.
