BIG FURNITURE WAREHOUSE COLONIAL G-COLTRSWHT User manual

Batch No.16211 (PO# 2349)
Page 1 of 10
W520 X D132 X H258MM
Colour: WHITE
PLEASE READ this sheet prior to assembly to familiarise yourself with the various stages of construction.
Carefully open the pack supplied and check the contents against the parts and fittings check list. Do not
destroy any of the packaging until you are certain that you have all the necessary parts for the assembly.
CAUTION: There are small components used in the construction of this unit. These loose items should be
kept away from young children whilst assembling your unit to avoid the danger of choking hazards.
Tools Required
COLONIAL TOWEL RAIL SHELF
ASSEMBLY INSTRUCTIONS
Thank you for purchasing the COLONIAL TOWEL RAIL SHELF.
Please read the instructions carefully to ensure safe operation of the product.
x 2

Batch No.: WMI 16211 (PO#2349)
Page 2 of 10
IMPORTANT - READ CAREFULLY - RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENC E.
INFORMATION
•Due to the size of this product we recommend that it is assembled in the room intended for use.
•When you are ready to start, make sure that you have the right tools, plenty of space and a clean, dry area
for assembly.
•Unwrap all packaging materials and place the components on top of the carton box or on a clean floor to
prevent it from scratching.
•Check the pack and make sure you have all the parts listed.
•Ensure that this product is fully assembled as illustrated before use.
•Check all screws or bolts are ghtened and inspect regularly
•Tools are not included.
WARNINGS
•Keep small parts out of reach of children.
•use power tools to construct this product.
•over en screws or bolts.
•
DO
DO
DO use this product if parts are missing, damaged or worn.
•DO
NOT
NOT
NOT
NOT sit or stand on the product.
CARE INFORMATION
•Never use scourers, abrasives or chemical cleaners.
•To clean wipe with a sponge and warm soapy water. Do not use solvent based cleaners or detergents as they
can bleach or damage the product.
•We recommend the use of the wall fixings provided for safety reasons.
N.B. If in doubt please consult a qualified tradesperson. Warning: Always ensure the area
to be drilled is free from hidden electrical wires, water and gas pipes.
•Iprovided.
COLONIAL TOWEL RAIL SHELF
ASSEMBLY INSTRUCTIONS

Batch No.: WMI 16211 (PO#2349)
Page 3 of 10
Please check the pack contents before assembling the product. If any components are missing,
please contact your retailer. The fittings pack contains small items that should be kept away from
small children.
COLONIAL TOWEL RAIL SHELF
ASSEMBLY INSTRUCTIONS

Batch No.: WMI 16211 (PO#2349)
Page 4 of 10
Parts and Checklist
Please check the pack contents before assembling this product. If any components are missing, please contact your
retailer.
The fings pack contains small items that should be kept away from small children.
Parts
1 2 3
4
5 6
7
Description: TOP PANEL
Qty: 1PC
Description: LEFT SIDE PANEL
Qty: 1PC
Description:
SHELF PANEL
Qty: 1PC
Description: TOWEL RAIL
Qty: 1PC
Size: 520X130X15MM Size: 245X115X12MM
Size: 460×110×12MM Size: 16×470MM
Description: RIGHT SIDE PANEL
Qty: 1PC
Size:
245X115X12MM
Description: BACK RAIL
Qty: 1PC
Size: 460×50×12MM
Description:
Upper Back Panel
Qty: 1PC
Size: 475×130×3MM
8
Description: Lower Back Panel
Qty: 1PC
Size: 475×120×3MM
COLONIAL TOWEL RAIL SHELF
ASSEMBLY INSTRUCTIONS

Batch No.: WMI 16211 (PO# 2349)
Page 5 of 10
CAUTION: There are many small components used in the construction of this product.
Please keep these components away from young children whilst assembling this product.
If you keep the fittings in a bowl during assembly you will be less likely to lose them!
Fixings (to scale)
Ref Dimensions Qty
A Wood Dowel- M6x30MM 14
B Cam Bolt- M6x25MM 4
C 4Cam-15x10MM
16D
F
(Not to scale)
10 20 30 40 50 60 70
Screw- M3x12MM
Wall Anchor 2
Screw- M4x30MM
E
2
COLONIAL TOWEL RAIL SHELF
ASSEMBLY INSTRUCTIONS

Batch No.: WMI 16211 (PO#2349)
Page 6 of 10
Lay out all part on a soft surface i.e. Rug, Carpet or Packaging
Carton.
Layout Parts on Soft Surface
General Hints and Tips
COLONIAL TOWEL RAIL SHELF
ASSEMBLY INSTRUCTIONS

Batch No.: WMI 16211 (PO#2349)
Page 7 of 10
STEP 1 Parts Required
2. Left Side Panel x 1
3. Right Side Panel x 1
4. Shelf Panel x 1
6. Back Rail x 1
B. Cam Bolt x 2
A. Wood Dowel x 14
COLONIAL TOWEL RAIL SHELF
ASSEMBLY INSTRUCTIONS

Batch No.: WMI 16211 (PO#2349)
Page 8 of 10
STEP 2 Parts Required
2. Left Side Panel x 1
3. Right Side Panel x 1
4. Shelf Panel x 1
6. Back Rail x 1
B. Cam Bolt x 2
C. 10mm Cam x 2
1. Top Panel x 1
5. Towel Rail x 1
COLONIAL TOWEL RAIL SHELF
ASSEMBLY INSTRUCTIONS

Batch No.: WMI 16211 (PO#2349)
Page 9 of 10
STEP 3 Parts Required
8. Lower Back
Panel x 1
D. 12mm Screw x 16
C. 10mm Cam x 2
7. Upper Back
Panel x 1
STEP 4 Parts Required
F. 30mm Screw x 2
E. Wall Anchor x 2
COLONIAL TOWEL RAIL SHELF
ASSEMBLY INSTRUCTIONS

Batch No.: WMI 16211 (PO#2349)
Page 10 of 10
Complete Assembly
Keepinstructions for future reference
Your COLONIAL TOWEL RAIL SHELF is now completely assembled.
Periodically check to ensure that the components are in their proper position, free from damage.
Also, make sure the connectors are tight and secure.
