Important
Before you begin, read and comply with all safety and operating instructions,
and ensure all parts and correct quantities are included.
Any parts damaged during shipment must be reported within 5 days of receipt. To
report information regarding missing parts or damage, to purchase parts or acces-
sories, or if you have any questions, please contact us.
www.spectrumfurniture.com
800-235-1262, 715-723-6750
Thank you for purchasing Spectrum products!
Rack Cabinet
Figure 1
Cabinet rear
(open-back)
Cabinet front
(instructor-side)
Side hatch
Figure 2
Glide posts
(to dock cabinet
to lectern)
The removable rack cabinet (14RU front, 10RU rear)
simplies installation and provides the ability to integrate
equipment remotely, and dock into the lectern at a later date.
Note: Roller glides under the cabinet provide easy
repositioning for quick and easy access (not intended for
long-range transport).
0119056R1 Page 1 of 4
Assembly Instructions
Rack Cabinet
for Freedom XRS Elite
55297
Figure 5
Figure 4
Figure 3
Detaching Cabinet
Docking Cabinet
Quick-Release Door
0119056R1 Page 2 of 4
Quick-
release
lever
Quick-
release
lever
1. To detach the rack cabinet from the lectern, unlock
the cabinet lock pawl near the oor. Figure 4.
2. Slide the cabinet toward the center of the lectern
to release the cabinet from the keyhole slots.
Rack cabinet
(shown on left-
side of lectern)
1. To secure the rack cabinet to the lectern, position the
cabinet on the left, or right-side of the lectern. Figure 3.
2. Engage the keyhole slots and slide the cabinet toward
the outside leg of the lectern to secure.
3. Lock the cabinet lock pawl near the oor.
Bottom of
Rack cabinet
Lock pawl secures
cabinet to lectern
Keyed lock
(one on each side)
Keyed lock
(one on each side)
The symmetrical door can easily be removed or switched to be hinged from
left or right using the quick-release hinge lever located on the door. Figure 5.
If switching sides, the nylon bushing must be relocated to the lower hinge pin.
Glide posts in
keyhole slots
(to dock cabi-
net to lectern)
Nylon bushing on
lower hinge pin
Section view A-A
14RU available
(rail shown in
outer position)
Clearance for
cord channel and
overbridge-installed
devices
Instructor sideAudience side
Side hatch
Optional inner
mounting positions
(Overall depth)
(Overall
height)
10RU available
(rail shown in
outer position)
Note: Check the dimen-
sions of all equipment
before installation.
Rack Rails
If necessary, the rack rails can be repositioned to
accommodate rack-mount components with protruding
controls/knobs. Figure 6. To relocate, remove the
1/4-20 locknuts and install on the 2nd set of studs.
Figure 6
0119056R1 Page 3 of 4
7/16” or
Adjustable
wrench
Tools
Required
Figure 7
Cords and wires
from Rack Cabinet
Rack Cabinet
Leave enough slack in the cords and wires from the rack cabinet
to pull the rack cabinet out from the lectern. Figure 7.
Wiring
0119056R1 Page 4 of 4
925 FIRST AVENUE, CHIPPEWA FALLS, WI 54729 / 800-235-1262 / 715-723-6750 / WWW.SPECTRUMFURNITURE.COM
