Sauder Heritage Hill Lateral File 102702 User manual

Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
sauder.com
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
Enlish p 1-22
Français p 23-25
Español p 26-28
Lot # 361775 04/10/14
Purchased: __________________
Be sure to ive us a rin before
makin any returns. 1-800-523-3987
Lateral File
Heritae Hill Collection | 102702
Get all organized
and stu.

Table of Contents Assembly Tools Required
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Hammer
Not actual size
2-3
4-5
6-22
23-25
26-28
29-30
31
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
102702 www.sauder.com/servicesPae 2
Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the ede
to help distinuish similar parts from each other. Use this part identification to help identify similar parts.
A4 RIGHT END (1)
B3 LEFT END (1)
C3 TOP (1)
D LARGE BACK (1)
E2 BOTTOM (1)
F SMALL BACK (1)
G TOP MOLDING (1)
H3 UPPER DRAWER FRONT (1)
I3 LOWER DRAWER FRONT (1)
J BASE (1)
D61 DRAWER BACK (2)
D87 RIGHT DRAWER SIDE (2)
D88 LEFT DRAWER SIDE (2)
D729 DRAWER BOTTOM (2)
Tape Measure

Part Identification
102702www.sauder.com/services Pae 3
A4
D
D61
B3
C3
E2
F
G
H3
I3
J
D61
D87
D87
D88
D88
D729
D729

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
(EXTENSION SET SHOWN SEPARATED)
EXTENSION RAIL - 4
OEXTENSION SLIDE - 4 P
INTERLOCK TRACK - 1
T
FILE ROD - 4
QFILE BAR - 4
R
FILE GLIDE - 4
SANGLE BRACKET - 8
UTOUCH-UP PEN - 1
V
JJ TWIST-LOCK®FASTENER - 12
FILE BRACKET - 2
Y
AA SLIDE CAM - 4 BB DRAWER ACTUATOR - 2
PULL - 4
PP PULL MOUNT - 8 QQ
29G CABINET ACTUATOR - 2
REAR FILE BRACKET - 2
12B
LOCK PACK - 1
Z
102702 www.sauder.com/servicesPae 4

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
BLACK 9/16" LARGE HEAD SCREW - 20
CC
EE SILVER 5/8" MACHINE SCREW - 8
BROWN 7/16" LARGE HEAD SCREW - 8
DD
FF GOLD 5/16" FLAT HEAD SCREW - 16 NAIL - 10 MM
102702www.sauder.com/services Pae 5
30S BLACK 1-9/16" FLAT HEAD SCREW -8

Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratchin your unit or the floor.
å To bein assembly, push a SAUDER TWIST-LOCK®
FASTENER (JJ) into the lare holes in the RIGHT
END (A4) and LEFT END (B3).
å Repeat this step for the LARGE BACK (D) and BOTTOM (E2).
102702 www.sauder.com/servicesPae 6
JJ
A4
B3
(12 used)
Do not tihten the TWIST-LOCK® FASTENERS in this step.

Step
å The next three steps involve an important safety feature
desined to prevent more than one drawer from openin
at the same time.
å Insert two CABINET ACTUATORS (29G) into the holes
shown in the RIGHT END (A4).
Step 2
102702www.sauder.com/services Pae 7
A4
29G
This pin must insert into the location
holes in the RIGHT END (A4).

Step
å Diaram 1. Cut out and use the "spacer" at the top of this pae to measure 2-1/2" from one end of the INTERLOCK
TRACK (T). Position the INTERLOCK TRACK as shown.
å ACTUATOR / TRACK ATTACHMENT:
Diaram 2. Tilt the first ede of the INTERLOCK TRACK (T) into the CABINET ACTUATOR (29G).
å Diaram 3. Rotate the INTERLOCK TRACK and apply force to snap the second ede into the CABINET ACTUATOR.
å Diaram 4. Repeat the ACTUATOR / TRACK ATTACHMENT for the next CABINET ACTUATOR while holdin the previously
completed CABINET ACTUATOR in its location hole. Repeat these steps until all ACTUATORS have been attached.
å Visually check that all INTERLOCK TRACK edes have been snapped into the CABINET ACTUATORS as shown in
diaram 3. Then, remove the INTERLOCK TRACK assembly from the END.
Step 3
102702 www.sauder.com/servicesPae 8
T
29G
Cut out this rectanle to use as a "spacer"
2-1/2"
2-1/2"
29G
T
Do not slide the CABINET ACTUATORS
onto the INTERLOCK TRACK.
1.
2. 3.
4.
A4
The interlock system is a safety feature that prevents more than one drawer
from opening at the same time. Do not use excessive force to open the drawers.

Step
å Separate the EXTENSION SLIDES (P) from the EXTENSION RAILS (O) as shown in the upper diaram below. Be prepared,
the parts are reasy.
å Lay the INTERLOCK TRACK (T) and CABINET ACTUATORS (29G) in the roove of the RIGHT END (A4) as shown.
å Fasten two EXTENSION RAILS (O) to each END (A4 and B3). Use eiht GOLD 5/16" FLAT HEAD SCREWS (FF).
å NOTE: For each EXTENSION RAIL, turn a SCREW into the hole shown in the enlared diaram. Then, slide the inner cartride of the
EXTENSION RAIL out to find the other hole that lines up with the hole in the END. Turn a SCREW into this hole.
å NOTE: The EXTENSION SLIDES will be used later for the DRAWERS.
å Fasten two ANGLE BRACKETS (U) to the ENDS (A4 and B3). Use two BLACK 9/16" LARGE HEAD SCREWS (CC).
å NOTE: Be sure the edes of the ANGLE BRACKETS are even with the edes of the ENDS.
Step 4
102702www.sauder.com/services Pae 9
U
U
O
O
O
O
A4
B3
T29G
Finished ede
Open end
Finished ede
Open end
BLACK 9/16" LARGE HEAD SCREW
(2 used for the ANGLE BRACKETS)
CC
After fastenin the EXTENSION RAILS to the RIGHT END (A4), the
CABINET ACTUATOR should touch the top ede of the RAILS. If the ap is
larer than 1/16", the drawers could lock up and not open. If this happens,
open two drawers at the same time to override the interlock system.
Remove the drawers to re-adjust the INTERLOCK TRACK assembly.
GOLD 5/16" FLAT HEAD SCREW
(8 used for the RAILS)
FF
Surface with
TWIST-LOCK®
FASTENERS
Surface with
TWIST-LOCK®
FASTENERS
29G
O
Push the black lever in and pull the SLIDE from the RAIL.
PO

Step
å Fasten six ANGLE BRACKETS (U) to the TOP (C3) and
BOTTOM (E2). Use six BLACK 9/16" LARGE
HEAD SCREWS (CC).
å NOTE: Be sure the edes of the ANGLE BRACKETS are
even with the edes of the TOP and BOTTOM.
å Fasten the TOP MOLDING (G) to the TOP (C3) and the
BASE (J) to the BOTTOM (E2). Use six BLACK 9/16"
LARGE HEAD SCREWS (CC).
Step 5
102702 www.sauder.com/servicesPae 10
U
C3
E2
G
J
This hole must be here.
(6 used)
These holes must be near the top ede.
BLACK 9/16" LARGE HEAD SCREW
(12 used in this step)
CC

Step
å Fasten the LEFT END (B3) to the TOP (C3). Tihten two
TWIST-LOCK® FASTENERS.
å Fasten the LARGE BACK (D) to the LEFT END (B3).
Tihten two TWIST-LOCK® FASTENERS.
å Fasten the BOTTOM (E2) to the LEFT END (B3). Tihten
two TWIST-LOCK® FASTENERS.
Step 6
102702www.sauder.com/services Pae 11
B3 C3
D
E2
Dowel end
How to use the SAUDER TWIST-LOCK®FASTENER
1. Insert the dowel end of the FASTENER into the hole of the
adjoinin part.
NOTE: The dowel end of the FASTENER must remain fully
inserted in the hole of the adjoinin part while lockin
the FASTENER.
2. Tihten the FASTENER with a Phillips screwdriver as tiht
as possible.
Surface with TWIST-LOCK® FASTENERS
These holes must be here.
1st
2nd
3rd
G
J

Step
å Fasten the RIGHT END (A4) to the TOP (C3),
LARGE BACK (D), and BOTTOM (E2). Tihten six
TWIST-LOCK® FASTENERS.
Step 7
102702 www.sauder.com/servicesPae 12
A4
C3
D
E2

Step
å Carefully turn your unit over onto its front edes. Lay the
SMALL BACK (F) over your unit.
å Make equal marins alon all four edes of the SMALL
BACK (F). Push on opposite corners of your unit if needed
to make it "square".
å Fasten the SMALL BACK (F) to the LARGE BACK (D). Use
four BLACK 9/16" LARGE HEAD SCREWS (CC)
å Fasten the SMALL BACK (F) to your unit usin the NAILS (MM).
å NOTE: Be sure the notched ede of the SMALL BACK is
alon the top ede of your unit.
å Fasten the BASE (J) to the ENDS (A4 and B3). Use two
BLACK 9/16" LARGE HEAD SCREWS (CC) throuh the
ANGLE BRACKETS on the ENDS and into the BASE.
Step 8
102702www.sauder.com/services Pae 13
F
D
J
A4
B3
Do not stand the unit upriht without the
BACK fastened. The unit may collapse.
Caution
NAIL
(10 used in this step)
MM
CC
BLACK 9/16" LARGE HEAD SCREW
(6 used in this step)
CC
Notch

StepStep 9
102702 www.sauder.com/servicesPae 14
VIEW THE T-LOCK BOX VIDEO
å Fasten the DRAWER BACK (D61) to the DRAWER SIDES (D87 and D88). Use four BLACK 1-9/16" FLAT HEAD SCREWS (30S).
å NOTE: Be sure the DRAWER BOTTOM (D729) inserts into the roove of the DRAWER BACK (D61).
å Repeat this step for the remainin drawer usin the LOWER DRAWER FRONT (I3).
12
3
å Insert the DRAWER SIDES (D87 and D88) at
an anle into the slot at each end of the UPPER
DRAWER FRONT (H3).
å Slide the DRAWER BOTTOM (D729) into the rooves
in the DRAWER SIDES (D87 and D88) and UPPER
DRAWER FRONT (H3).
The tabs should insert freely
into the slots. Gently tilt the
DRAWER SIDES side to side
until the tabs slip into the slots.
Groove
Start each screw a few turns before
completely tihtenin any of them.
BLACK 1-9/16" FLAT HEAD SCREW
(8 used in this step)
30S
Be sure the DRAWER
BOTTOM inserts into the
DRAWER FRONT roove.
D88
D87 D729
D61
H3
Unfinished
surface
With the palm of your
hand, tap the DRAWER
BOTTOM down into
the roove.
D88
D87
H3
D88
D87
D729

Step
å Insert a SLIDE CAM (AA) into the LEFT DRAWER SIDE (D88).
å Fasten an EXTENSION SLIDE (P) to a LEFT DRAWER
SIDE (D88). Use two GOLD 5/16" FLAT HEAD
SCREWS (FF) throuh holes #1 and #4.
å NOTE: The screw head in the CAM must be visible
throuh the slotted hole in the SLIDE.
Step 10
102702www.sauder.com/services Pae 15
PAA
4
Screw head - turn CAM to line up holes in
the SLIDES with holes in DRAWER SIDES
1
2
3
Open end
D88
D87
GOLD 5/16" FLAT HEAD SCREW
(4 used in this step)
FF

Step
å Flip the drawer over onto the LEFT DRAWER SIDE (D88).
å Insert a SLIDE CAM (AA) into the RIGHT DRAWER SIDE (D87).
å Diaram 1. Insert the tabs on a DRAWER ACTUATOR (BB) into the slots in a EXTENSION SLIDE (P). You may need to
insert one tab first, then the other.
å Diaram 2. Visually check that the DRAWER ACTUATOR (BB) is seated in the SLIDE (P).
å Diaram 3. If the DRAWER ACTUATOR is not seated, use your hammer to ently tap the SLIDE until the tabs are properly
seated in the slots.
å Now, fasten the EXTENSION SLIDE (P) to the RIGHT DRAWER SIDE (D87). Use two GOLD 5/16" FLAT HEAD SCREWS (FF)
throuh holes #1 and #4.
å Repeat steps 10 and 11 for the remainin drawer.
Step 11
102702 www.sauder.com/servicesPae 16
BB
BB
P
2. 3.
Post
Seated
AA
Screw head - turn CAM to
line up holes in the SLIDES
with holes in DRAWER SIDES
P
4
1
2
3
D88
D87
GOLD 5/16" FLAT HEAD SCREW
(4 used in this step)
FF
1.
BB
P
These tabs must
insert into the slots.
Slot
Open end

Step
å Press one of the FILE GLIDES (S) over the RIGHT
DRAWER SIDE (D87) on one of the drawers. The FILE
GLIDES are necessary to han files.
å Fasten a FILE BRACKET (Y) to the UPPER DRAWER
FRONT (H3) and REAR FILE BRACKET (12B) to the
DRAWER BACK (D61). Use four BROWN 7/16" LARGE
HEAD SCREWS (DD).
å Repeat this step for the other drawer.
Step 12
102702www.sauder.com/services Pae 17
Y
H3
S
D87
12B
BROWN 7/16" LARGE HEAD SCREW
(8 used in this step)
DD
D61

Step
å Slide the FILE RODS (Q) throuh a FILE BAR (R), throuh
the holes in the FILE BRACKETS (Y and 12B), throuh
another FILE BAR (R), and into the FILE GLIDE (S) on the
RIGHT DRAWER SIDE (D87).
å Slide another FILE GLIDE (S) onto the other end of the
FILE RODS (Q), then press this FILE GLIDE over the LEFT
DRAWER SIDE (D88).
å Repeat this step for the other drawer.
Step 13
102702 www.sauder.com/servicesPae 18
Q
Q
R
R
S
S
D87
12B
D88

Step
å Fasten four PULL MOUNTS (QQ) and two PULLS (PP) to
the UPPER DRAWER FRONT (H3). Use four SILVER 5/8"
MACHINE SCREWS (EE).
å Repeat this step for the other drawer.
Step 14
102702www.sauder.com/services Pae 19
SILVER 5/8" MACHINE SCREW
(8 used in this step)
EE
H3
QQ
PP

Step
å An enlared portion of the UPPER DRAWER FRONT (H3)
is shown in this step
å Fasten the LOCK PACK (Z) to the UPPER DRAWER
FRONT (H3) in the exact order shown. It is important to
be sure the CAM points as shown.
å NOTE: If the key will not turn counter-clockwise, turn it
clockwise and fasten the CAM exactly as shown.
å NOTE: When the upper drawer is locked, the CAM should
be positioned behind the TOP MOLDING.
Step 15
102702 www.sauder.com/servicesPae 20
H3
CAM
NUT
WASHER
LOCK
SCREW
Z
This end of the CAM must be closer to the UPPER
DRAWER FRONT than the other end of the CAM.
