Big Mikes Performance Parts STO N SHO SNS 28a Reference guide

Installation Procedures 2012-2013 Corvette Grand
Sport/Z06/ZR1
SNS 28a

Warning: Please read directions completely before starting. If you have any
questions please contact BMPP before beginning your installation. Also please
check our website (bigmikesperformanceparts.com) for any updates or changes.
Thank You.
Parts Included: License Plate mounting bracket Assembly. Includes Base Plate and
License Plate Holder.
License Plate mounting Screws: (2) 6mm X 16mm (Phillips head), (2) 6mm
nuts with lock washers (10mm wench size)
Base plate mounting screws: (1) 4.2 X 30mm screw.
Tools Needed: 7mm socket with ratchet Note: 1/4 inch drive referred but 3/8 will work
but extra caution will be needed when tightening bolts.
Phillips screwdriver, 7mm and 10mm wrench
Step 1: Insure all parts listed above are accounted for. Note: If at any time during the
installation process you need assistance please call [phone].
Step 2: Separate the license plate holder from the base by simply pulling the pull pin ring
outward and sliding apart.
Step 3: Remove the left or right spoiler screw as shown in figure 1 or 1a. Position the base
mount with the two holes forward and the single Post centered over the hole behind where the
screw was just removed. Note: The metal “J” clip located in the hole may have to be slightly
moved to allow the nylon peg to enter hole. See figure 1. Note: If mounting on the right side
use the forward left hole and if mounting on the left use the right. See figure 2.
Step 4: : Using the 4.2mm X 30mm screw secure the front of base plate to the vehicle using the
following method. Caution: When tightening the screws extreme care should be taken not to
over tighten screws or the hole may become stripped and lose its ability to secure the base
plate. Note: Z06/ZR1 require the 7mm wrench and the Grand Sport the socket. Be sure to cover
top of spoiler opening while installing bracket. See figure 3.
Step 5: Secure the license plate and frame (optional) to the license plate bracket using the two
screws and nuts provided. NOTE: If mounting bracket on right side of vehicle (as looking at it),
use the upper left hole and lower right hole. Reverse for left side. See figure 4. Requires the
Phillips screwdriver and 10mm wrench (Not included).

Step 6: Slide the license plate rods into the two tubes located on the base plate. Slide the rods
into the tubes until the rods hit the pull pin. Simply pull the ring on the pull pin and advance the
rods. Release ring and continue to advance rods until the pull pin locks into place. See figure 5.
In some occasions the license plate may require a little adjustment to level. Simply pull pin and
slide plate out approximately two inches, grab frame at arrows (See figure 6) and rotate. If plate
is high on left or right side, rotate high side down slightly and release. Verify alignment and
repeat as necessary. Once leveled plate will remain level.
Congratulations! You have just installed the Sto n ShoTM front license plate mounting system.
Thank You for your purchase.
Caution: Bracket lowers ground clearance by approx 1/2 inch.
Remove prior to entering automated car wash
Exercise care when entering or exiting steep driveways or damage will occur
Parking Stops or high curbs, stop well before or damage will occur
Advanced skill level required. If unsure, have bracket installed by your local Dealer or Body
shop.
Limited Lifetime Warranty (Transferable)
Big Mike's Performance Parts (BMPP) warrants to the original purchaser only that this
product will be free of manufacturing defects in material and workmanship for the life of the
product to the limitations and exclusions set forth below:
Return product to any authorized dealer. Contact BMPP for the dealer nearest you. Upon
examination, BMPP or its representative will, at its sole option and expense, repair or replace
any product found to be defective. If product to be replaced via mail, BMPP will return the
repaired or replaced unit to you via its usual shipping method from the factory to your address
in the United States of America or Canada only. Any shipping costs for addresses outside of the
United States or Canada shall be the responsibility of the purchaser.
This warranty is transferable when product is attached to a vehicle
REMEDIES FOR BREACH OF WARRANTY.
This Warranty does not include repair for damage caused by improper use or handling,
including but not limited to damage caused by accident, mishandling, improper installation,
abuse, negligence, or any defect caused by repair to the product by anyone other than BMPP.

This warranty does not cover reimbursement for your costs of removing and transporting the
product for warranty service evaluation, or installation of any replacement product provided
under this warranty.
This Warranty will be void if the product was not purchased from an authorized dealer or
reseller.
THE FOREGOING WARRANTIES ARE EXCLUSIVE AND IN LIEU OF ALL OTHER EXPRESSED AND
IMPLIED WARRANTIES. ALL SUCH OTHER WARRANTIES, INCLUDING BUT NOT LIMITED TO
IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NON-
INFRINGEMENT, WITH RESPECT TO THE PRODUCT. TO THE MAXIMUM EXTENT PERMITTED BY
LAW, BMPP SHALL NOT BE RESPONSIBLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES
EXCEPT TO THE EXTENT PROVIDED (OR PROHIBITED) BY APPLICABLE LAW, EVEN IF BMPP HAS
BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
Notwithstanding the above, if you qualify as a “consumer” under the Magnuson-Moss
Warranty Act, or applicable state laws, then you may be entitled to any implied warranties
allowed by law for the Warranty Period. Further, some states do not allow limitations on how
long an implied warranty lasts or allow the exclusion or limitation of consequential damages, so
such limitations may not apply to you. This warranty gives you specific legal rights, and you may
also have other rights which vary from state to state.

Fig 1 Grand Sport
Fig 1a Z06/ZR1

Fig 2
Fig 3

Fig 4
Fig 5

Fig 6
